SAFETY PRECAUTION Please read the “Safety Precaution” carefully before operating the unit to ensure correct usage of the unit. ● Pay special attention to signs of “ Warning” and “ Caution”. The “Warning” section contains matters which, if not ● observed strictly, may cause death or serious injury.
Page 3
PRECAUTIONS DURING OPERATION The product shall be operated under the manufacturer specifi cation and ● not for any other intended use. Do not attempt to operate the unit with wet hands, this could cause fatal ● accident. During thunder storm, disconnect and turn off the circuit breaker. ●...
Page 4
NAMES AND FUNCTIONS OF EACH PART INDOOR UNIT Pre-fi lter To prevent dust from coming into the indoor unit. (Refer page 20) Front panel Indoor unit indicators Light indicator showing the operating condition. (Refer page 5) Horizontal defl ector Vertical defl ector ●...
INDOOR UNIT INDICATORS OPERATION LAMP This lamp lights during operation. The OPERATION LAMP fl ashes/dimming in the following cases during heating. (1) During preheating For about 2–3 minutes after starting up. (2) During defrosting Defrosting will be performed about once every one hour when frost forms on the heat exchanger of the outdoor unit, for 5–10 minutes each time.
NAMES AND FUNCTIONS OF EACH PART REMOTE CONTROLLER This controls the operation of the indoor unit. The signal range of control is about 7 meters. If inverter ● lamp is used, the range of control may be shorter, in some cases, the control signal may not be received. This unit can be fi...
VARIOUS FUNCTIONS ■ Auto Restart Control If there is a power failure, operation will be automatically restarted when the power is resumed with previous operation ● mode and airfl ow direction. (As the operation is not stopped by remote controller.) If you intend not to continue the operation when the power is resumed, switch off the power supply.
HEATING OPERATION Use the device for heating when the outdoor temperature is under 27°C. ● When it is too warm (over 27°C), the heating function may not work in order to protect the device. In order to keep reliability of the device, please use this device above –15°C of the outdoor temperature. ●...
DEHUMIDIFYING OPERATION Use the device for dehumidifying when the room temperature is over 16°C. When it is under 15°C, the dehumidifying function will not work. Press the FUNCTION selector so that the display indicates (DEHUMIDIFY). Press the (FAN SPEED) button to select LOW and SILENT. START Press the (START/STOP) button.
COOLING OPERATION Use the device for cooling when the outdoor temperature is -10 to 46°C. If humidity is very high (over 80%) indoors, some dew may form on the air outlet grille of the indoor unit. Press the FUNCTION selector so that the display indicates (COOL).
FAN OPERATION You can use the device simply as an air circulator. Use this function to dry the interior of the indoor unit at the end of summer. Press the FUNCTION selector so that the display indicates (FAN). Press the (FAN SPEED) button.
TIMER RESERVATION ■ ON Timer and OFF Timer are available. ■ Operation stop at setting time Timer Reservation OFF TIMER setting ● Select the OFF TIMER by pressing the (OFF) Button. ● Setting time will change according to the below sequence when you press the button.
ECO OPERATION ■ Energy saving operation by changing set temperature and by limiting the maximum power consumption value. By pressing the (ECO) button during Heating, Automatic Dehumidifying or Cooling operation, the air conditioner performs the “ECO” operation. Press (ECO) button during operation. “...
Page 14
HOW TO SET THE SLEEP TIMER By pressing (SLEEP) button during AUTO, HEATING, DEHUMIDIFYING, COOLING or FAN operation, the unit shifts the room temperature and reduces the fan speed. Mode Indication 3 hours ... 1 hour 2 hours 7 hours Sleep Timer Sleep timer off Sleep Timer: The device will continue working for the desired number...
Page 15
ADJUSTING THE AIR DEFLECTORS Adjustment of the conditioned air in the upward and downward directions. The horizontal air defl ector is automatically set to the proper angle suitable for each operation. The defl ector can be swung up and down continuously and also set to the desired angle using the “...
Page 16
HOW TO EXCHANGE THE BATTERIES IN THE REMOTE CONTROLLER – 16 – RAS/RAC-PH30HLT (1-16).indd 16 RAS/RAC-PH30HLT (1-16).indd 16...
Page 17
THE IDEAL WAYS OF OPERATION Suitable Room Temperature Install curtain or blinds Warning It is possible to reduce heat Freezing temperature entering the is bad for health and a room through waste of electric power. windows. Ventilation Effective Usage Of Timer At night, please use the “OFF or ON timer Caution operation mode”, together with your wake up...
Page 18
FOR USER’S INFORMATION The Air Conditioner And The Heat Source In The Room Caution If the amount of heat in the room is above the cooling capability of the air conditioner (for example: more people entering the room, using heating equipments and etc.), the preset room temperature cannot be achieved.
Page 19
ATTACHING THE AIR PURIFYING FILTERS Open the front panel Pull up the front panel by holding it at both sides ● with both hands. Remove the Pre-fi lter Push upward to release the claws and pull out the ● Pre-fi lter. Attaching the air purifying fi...
MAINTENANCE CAUTION Cleaning and maintenance must be carried out only by qualifi ed service personnel. Before cleaning, stop operation and switch off the power supply. PRE-FILTER Please clean the Pre-fi lter once about every two weeks. By doing so, the power rates are saved. In case the air fi...
Page 21
CLEANING OF FRONT PANEL Remove the front panel and wash with clean ● water. Wash it with a soft sponge. After using neutral detergent, wash thoroughly with clean water. When front panel is not removed, wipe it with ● a soft dry cloth. Wipe the remote controller thoroughly with a soft dry cloth.
CAUTION Please use earth line. ● Do not place the earth line near water or gas pipes, lightning-conductor, or the earth line of telephone. Improper installation of earth line may cause electric shock. A circuit breaker should be installed depending on the mounting site of the unit. Without a circuit ●...
Page 23
AFTER SALE SERVICE AND WARRANTY WHEN ASKING FOR SERVICE, CHECK THE FOLLOWING POINTS CONDITION CHECK THE FOLLOWING POINTS If the remote controller is Do the batteries need replacement? ● not transmitting a signal. Is the polarity of the inserted batteries correct? ●...
Page 24
Please note: On switching on the equipment, particularly when the room light is dimmed, a slight brightness fl uctuation may occur. This is of no consequence. The conditions of the local Power Supply Companies are to be observed. Note Avoid to use the room air conditioner for cooling operation when the outside temperature is below ●...
