Door/window contact II
quick instructions
Product description
The door/window contact II detects open doors
and windows for improved security and energy
efficiency.
Description of the symbols
Safety instructions
▶ Do not charge used batteries, and do not
attempt to reactivate them using heat or
other means. Do not short-circuit batteries.
Do not expose batteries to strong sunlight. Do
not throw batteries into fire!
There is a risk of explosion!
There is a risk of explosion!
Warning!
Note about hazards
Note:
Additional
important information
Note about the installation video
8-750-002-164
Advertisement
Table of Contents
Related Manuals for Bosch Door/window contact II
Summary of Contents for Bosch Door/window contact II
- Page 1 Door/window contact II 8-750-002-164 quick instructions Product description The door/window contact II detects open doors and windows for improved security and energy efficiency. Description of the symbols Warning! Note about hazards Note: Additional important information Note about the installation video Safety instructions ▶...
- Page 2 ▶ Make sure the polarity is correct when inserting the batteries! Only use batteries of the same type. Drained batteries must be removed from the device immediately. Remove batteries from the device if it is not in use for a long period of time. Increased risk of leakage! Increased risk of leakage! ▶...
- Page 3 ▶ Do not open up the device. It does not contain any parts to be maintained by the user. If a fault occurs, have the device checked by a specialist. ▶ We accept no liability for material damage or personal injury which is caused by improper use or failure to observe the safety instructions.
- Page 4 ▶ Only use the device together with original components and recommended products from Bosch partners. ▶ With regard to the magnet supplied, maintain a minimum distance of 10 cm to 15 cm from a pacemaker. The magnets generate a field which can interfere with the functioning of pacemakers.
- Page 5 Notes ▶ The range within buildings can differ significantly from the range in open spaces. In addition to the transmitting power and the receiving properties of the receiver, environmental factors such as humidity, as well as the local structural situation, play an important role.
- Page 6 You can also use the explanatory videos and additional information on our website as an additional aid for mounting, especially the magnet mounting options, installing, starting up or restoring the factory settings on your Bosch Smart Home door/window contact: www.bosch-smarthome.com/rom/ door-window-contact-2 Item Description...
- Page 7 Ensure that you have a Bosch Smart Home controller and the Bosch Smart Home app and have successfully configured both. Now start the Bosch Smart Home app and select “Add new device”. Follow the instructions in the app. Manually triggering individual...
- Page 8 The status LED (2) shows the status of the door/ window contact using flashing codes. Status LED Device status Recommended action Flashes orange Tuning mode Please wait (is active) or device is communicating with the controller Flashes green Tuning mode (successful) or transfer successful / process confirmed...
-
Page 9: Resetting To Factory Settings
When resetting to factory settings, the settings and information are only lost from the device and not from the Bosch Smart Home controller. To re-configure the device, first delete it in the device management section of the Bosch Smart Home app and then add it again in the usual configuring process. -
Page 10: Environmental Protection And Disposal
Dispose of them at your local battery collection point! Simplified declaration of conformity Robert Bosch Smart Home GmbH hereby declare that the radio equipment type Bosch Smart Home BSEN-C2 corresponds with the directive 2014/53/EU. The complete text of... -
Page 11: Technical Data
Technical data BSEN-C2 Device type designation Protection class IP45 Ambient temperature – 20°C … + 60°C Max. humidity 85 % (non-condensing) Dimensions (W × H × D) Sensor unit 22 × 75 × 23 mm Magnet 10 × 20 × 3 mm Weight Sensor unit 22 g (without battery) Magnet... - Page 12 Magnet unit + 2 × spacer, white 8-750-002-150 Magnet unit + 2 × spacer, anthracite Open source software This Bosch Smart Home product uses open- source software. License information for the components used can be found on the cover sheet for the attached documents.
