OptiX RTN 600 ODU
Hardware Description
Performance

Table 3-5 Performance of a waveguide-to-coaxial converter

Item
Attenuation (dB)
Flatness (dB)
Standing wave ratio
Interface

3.2.2 RF Cable

An RF cable is an FSJ1-50A coaxial cable. It is used to connect a waveguide-to-coaxial converter
to an ODU or to connect a hybrid coupler to an ODU.
Appearance

Figure 3-6 Appearance of an RF cable

Performance

Table 3-6 Performance of an RF cable

Item
Attenuation (dB)
Standing wave ratio (dB)
Issue 06 (2010-05-30)
At the side of the
antenna
At the side of the RF
cable
Performance
≤ 0.6
≤ 1.2
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Performance
≤ 0.2
≤ 0.2
≤ 1.15
UDR70
Type N, female
3 Separate Mount Parts
3-9
