Summary of Contents for DIGITNOW! U600
- Page 1 User Manual Version:1.0 USB3.0 CAPTURE HDMI 4K Please read and retain these instructions for future reference U600...
- Page 2 Thanks for purchasing USB3.0 HDMI Video capture. The following guides you how to set up. Hope this device will bring you nice digital experience. With USB3.0 HDMI Video capture , just plug to your PC(Windows,Mac,Linux) , no need install driver,you can use any 3rd party software to capture or stream your HD game,or other HD video source.
-
Page 3: Ports And Buttons
Ports and buttons: DC 5V USB3.0 HDMI OUT HDMI IN 1. Rainbow lights. After power is on, the rainbow light will be always on if there is no signal input. After power is on, the rainbow light will flash if there is signal input. The rainbow lights will cycle when the computer capture videos. -
Page 4: Connection And Operation
Connection and Operation 1. Connect the HDMI signal source to the HDMI input of the video capture with one HDMI cable. 2. Connect microphone with the 'mic'port of the video capture. 3. Connect the display device to the HDMI output of the video capture with one HDMI cable. - Page 5 6. At Set Audio Output Mode to “Output desktop audio (Wave Out) ”, Audio Device to “USB3.0 4K30 Audio ” 7. Set the video latency for make the audio and video synchronized: Right click “Video Capture Device” then click “Filters”,Click to add “Video Delay (Async)”,Set it to 470ms (You can adjust it smaller or bigger uttil you found the audio and video synchronized).
- Page 6 Work on MAC: Work with OBS Studio: Download and install OBS studio, then do the same as above on MAC. Work with Quick Time Player: 1. Run Quick Time player, select “New Movie Recording”: 2. Choose “USB3.0 4K30 Video” & “ USB3.0 4K30 Audio ” under Camera and Microphone Option: - EN...
- Page 7 Specifications:parameters: Interface USB3.0 System Windows 7,8,10, Mac OS 10.12 or later, Linux,Android 9 or later Requirement Others USB 3.0 cable,HDMI cable, manual The computer hardware requirements are as follows： CPU:Intel Core i5-6XXX or above. NVIDIA GeForce GTX 1060 or above. Desktop RAM:8G(Dual channels) CPU:Intel Core i7-7700HQ or above.
