Initial Startup

You will need the following:
1. Attach the power supply output to the IPC's DC power plug
2. Insert the plug into the IPC's Input Power connector and securely tighten the attaching
3. Connect a VGA-compatible video monitor and tighten down its attaching screws. Also attach
4. Power up the unit and check whether any concealed damage has been caused by incorrect
Models that include the Windows 7 operating system (ICRXIBN7xxxxx):
5. The Windows 7 operating system starts in accordance with the BIOS settings. During power
6. ICRXIBN7x001x models contain Windows Embedded Standard 7and do not require license
7. For ICRXIBN7x000x, activate the Windows 7 Professional operating system license during
8

24VDC, 18–32V range, 48W power supply, Class 2 or LPS
The product is supplied with a Phoenix Contact part number 1827716 or 1851245 (spring
loaded/quick release) power terminal block for use with a power supply. The power
supply used must be a UL Listed (or equivalent) Limited Power Source (LPS) or Class 2
power source.

Power cord
with 28 AWG –16 AWG wires

VGA-compatible video monitor

USB-compatible keyboard

USB-compatible mouse (optional)
using 16 to 28 AWG (1.31 to 0.08mm
shortest length 16 AWG (1.31mm
Recommended wire stripping length is 7mm (0.28 in.).
Tighten the screws that hold the wires to a torque of
4 in-lb (0.452 Nm).
screws.
The torque range for the attaching screws is 1.95–2.21 in-lb (0.22–0.25 Nm).
a USB-compatible keyboard, and if desired, a USB-compatible mouse.
transportation, operating/storage conditions or handling.
For ICRXIBN7x000A-CA or earlier units only: to power up the unit, press the Power On/Off
switch for at least ½ second. ICRXIBN7x001A will start up once power is applied, without the
need to depress the On/Off switch.
If you notice any damage, remove power from the unit immediately and secure it against
unintentional use.
During normal power up and operation, the Power On/Off status indicator display is:

Blinking blue while the IPC is starting up

Solid green when the IPC has completed startup and is running

Solid green when the IPC is restarted without a loss of power
up, you should see the normal operating system starting displays on the monitor.
activation.
initial power-up by following the on-screen prompts. The Windows 7 product key is printed
on the Microsoft Certificate of Authenticity label, located on the right side of the IPC.
Unpacking and Initial Startup
2
). For frame ground, use
2
) wire to ground.
PACSystems* RXi Box IPC
FGND 0V +24V
