TITLE PAGE
Service
Manual
AV RECEIVER
SC-LX901(B)
SC-LX901(B),(S)
SC-LX901(B)
/MDC
/MGP
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S)
AND TYPE(S).
/MHB
SC-LX901(B)
SC-LX901(B)
SC-LX901(B)
SC-LX901(S)
This service manual is intended for qualified service technicians; it is not meant
for the casual do-it-yourselfer. Qualified technicians have the necessary test
equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the
product and may void the warranty. If you are not qualified to perform the repair
of this product properly and safely, you should not risk trying to do so and refer
the repair to a qualified service technician.
SC-LX901
Model
Type
Power Requirement
MDC
AC 120 V
MGP
AC 220 V to 230 V
MHB
AC 220 V to 230 V / 240 V
MGP
AC 220 V to 230 V
ⓒ Onkyo & Pioneer Corporation 2016
ORDER NO.
ARP4012
Remarks
-----
-----
-----
-----
O-4584
