Contents Getting Started Buttons and screen control Pairing and connecting to wearable devices Measure the wrist circumference and select a strap and airbag Wearing the watch Setting the time and language on the watch/band Setting the AOD watch face Configuring Gallery watch faces Locking or unlocking Customising the function of the Down button Charging...
Getting Started Buttons and screen control The watch is equipped with a colour touchscreen that is highly responsive to your touches and can be swiped in different directions. Up button Operation Function Remarks Press once Wake watch screen when • the screen is off.
Getting Started Wake the screen Press the Up button. • Raise or rotate your wrist inwards. • Swipe down on the home screen to open the shortcut menu. Enable Show Time for the • screen to stay on for five minutes. HarmonyOS/Android users can enable or disable Show Time on the Device settings •...
Page 5
Getting Started If you are using a non-Huawei Android phone, you can download and install the Huawei Health app through either of the following ways: Visit https://appgallery.cloud.huawei.com/appdl/C10414141, or scan the following QR • code to download and install the Huawei Health app. Search for the Huawei Health app in the app store on your phone, and follow the •...
Getting Started Follow the onscreen instructions to go to Settings > Bluetooth and select your device for pairing. Once a pairing request is displayed on the device screen, touch √. When a pop-up requests a Bluetooth pairing via the Huawei Health app, touch Pairing. A pop-up will display, asking you whether to allow the device to display notifications.
Getting Started Align the end of the strap with the buckle and insert the strap into the buckle. After adjusting the tightness, fasten the airbag buckle. Adjust the strap based on your wrist's circumference. Open the watch buckle and airbag buckle. Select the size of the strap based on the measurement, and then fasten the nail buckle.
Getting Started The centre of the watch's face should be on your wrist about two fingers width away from the palm. Do not attach a protector to the back of your watch. Your watch's bottom cover contains a sensor that can identify your body. If the sensor is blocked, the identification may fail or be inaccurate, affecting heart rate, ECG, blood oxygen, and sleep data measurements.
Getting Started 3. Touch √ in the upper right corner, and then touch Save. Your watch will then display the selected image as the watch face. Other settings On the Gallery settings screen: Touch Style, Position, and Function to set the style, location of the date and time and •...
Getting Started Select an app and customise the function of the Down button. After you have finished customising the function, return to the home screen and press the Down button to open the current app. Charging Charging Connect the charging cradle to a power adapter and then connect the power adapter to a power supply.
Getting Started Powering on, powering off, and restarting the watch Powering on Press and hold the Up button. • Charge the device. • Powering off Press and hold the Up button, and then touch Power off. • Press the Up button and go to Settings > System > Power off or Settings > System & •...
Blood pressure management Blood pressure measurement results are different each time Blood pressure varies depending on the time period of the measurement. • Blood pressure fluctuates throughout the day. To correctly manage blood pressure, it is recommended that you measure your blood pressure at the same time every day.
Blood pressure management If you are taking antihypertensive drugs, your blood pressure will rise after the • drug effects wear off. The effects of the antihypertensive drugs will wear off after you take the drugs for a few hours. Then, your blood pressure will rise. Consult a doctor for details. The measured values may also be higher when the watch isn't worn tight.
Page 14
Blood pressure management Do not measure when you are standing or lying down. • Do not measure when your body is under pressure. • Do not measure in a moving vehicle. • Do not stretch or bend the strap and airbag with force. •...
Page 15
Blood pressure management Incorrect postures when measuring blood pressure Tap Measure on the measurement screen to start a measurement. After the measurement is complete, the measurement result will be displayed. You can also press the Down button twice to start a measurement. An error occurred while measuring.
Page 16
Blood pressure management Error Scenarios Icon Possible Causes Solution Post-exercise You performed moderate-to- Rest for at least half measurement high intensity exercise before an hour after the measurement. exercise, then measure your blood pressure. Table2-2 Error notifications during a measurement Error Scenarios Possible Causes Solution...
Page 17
Blood pressure management Error Scenarios Possible Causes Solution Unsuitable The airbag that is installed Measure your wrist circumference as airbag does not match the set wrist instructed in the Quick Start Guide, circumference: The airbag is install a suitable strap and airbag incorrectly installed or the accordingly, and go to Blood pressure wrist circumference is...
Page 18
Blood pressure management You can touch Measurement records to view historical measurement records. • Touch Settings to set your wrist circumstance, unit, and other information. • Touch Guest measurement to enter the guest measurement mode. •...
Care for health Measuring SpO2 To ensure the accuracy of the SpO2 measurement, wear the watch properly and ensure • the strap is fastened. Ensure that the monitoring module is in direct contact with your skin without any obstructions. Single SpO2 measurement Wear your watch correctly and keep your arm still.
Care for health Open the Huawei Health app, touch Devices, then your device name, go to Health • monitoring > HUAWEI TruSleep™, and enable HUAWEI TruSleep™. When enabled, the device can accurately recognise when you fall asleep, when you wake up, and whether you are in a deep sleep, a light sleep, or REM sleep.
Care for health The product is not a medical device. Temperature measurements are mainly used to • monitor the changes in the wrist skin temperature of healthy people over the age of 18 during and after exercise. Results are for reference only and should not be used as a basis for medical diagnosis or treatment.
Care for health tasks include Activity, Sleep, Daily mindfulness, Daily smile, Drink water, Medication reminders, Blood pressure measurement, and Weight measurement. You can touch Goal settings on the task card to set your daily goals. Viewing the task completion status Press the Up button on your watch to enter the app list, and select Healthy Living to view •...
Care for health For devices that support voice broadcasts, press the Up button to pause the workout • and then adjust the volume during a workout. Swipe left or right on the screen to switch between the music, sunrise/sunset, and •...
Care for health Recording daily activities Wear your watch correctly for it to automatically record data relating to calories, distance, climbing stairs, steps, duration of moderate to high intensity activities, and other activities. Press the Up button to access the app list, swipe until you find Activity records, touch it, and then swipe up or down to view data relating to calories, distance, climbing stairs, steps, duration of moderate to high intensity activities, and other activities.
Assistant HUAWEI Assistant·TODAY The HUAWEI Assistant·TODAY screen makes it easy to view weather forecast, wake up the voice assistant, access apps that have been opened, and view push messages from the calendar and AI Tips. Entering/Exiting HUAWEI Assistant·TODAY Swipe right on the watch home screen to enter HUAWEI Assistant·TODAY. Swipe left on the screen to exit HUAWEI Assistant·TODAY.
Assistant Rejecting incoming calls on your watch When there is an incoming call, your watch will inform you and display the caller's number or name. You can reject the call. Press the Up button to stop the watch from vibrating during an incoming call. •...
Assistant Voice assistant The wearable device allows you to use the voice assistant to check for information, and control smart home devices once it is connected to the Huawei Health app on your phone. To ensure that the voice assistant will work, update your watch to the latest version. Only compatible Huawei phones currently support this feature.
