Related Manuals for Haier HDW6WH
Summary of Contents for Haier HDW6WH
-
Page 1: Installation Instructions
Installation instructions Technical Characteristics Width Depth Height Capacity Mains water pressure Power voltage Total absorber power 45 cm 50 cm 80 cm 6 standard place settings 0.03-0.6 MPa 220-240V~ 50Hz 1650W... -
Page 2: Installation
Installation In order to function correctly the dishwasher must be properly installed. Specifications for the water intake and waste-water drainage, as well as electrical connections, must fulfil the cri- teria that are set out in the following paragraphs and the in- stallation instructions. -
Page 3: Troubleshooting
Dishes, cutlery, etc. have not been dried - Selected programme did not include drying function. - Amount of rinse-aid was set too low. - Items were removed from dishwasher too soon. Glasses have a dull appearance - Amount of rinse-aid was set too low. - Page 4 - Crockey has not been stacked properly inside the appliance. Knocking sound coming from inlet valves. - This is caused by the water pipes in the house and is not a fault with the dishwasher..With the dishes, cultery, etc. Remnants of food are stuck to the dishes, cutlery, etc.
-
Page 5: Maintenance
- Check that no grease or scale has accumulated on the in- side of the dishwasher. If you discover any deposits: - Clean the interior of the dishwasher thoroughly with a deter- gent solution. Filters The filters 11 prevent larger remnants of food or other ob- jects from getting inside the pump. -
Page 6: Washing Dishes
Washing dishes Cycle Selection Cycle Information Very dirty dishes, pots I n t e n s i v e and pans (not to be used Wash with delicate items). Normally dirty dishes, Normal Wash pots and pans. Standard daily cycle. For dishes that need to Rinse be rinsed and dried only. -
Page 7: Turning On The Appliance
They will also dry better. Energy Saving Tips -It is important to try and run the dishwasher when it is fully loaded in order to save on energy. In order to prevent odors from forming and food from caking onto the dishes, you can run the pre-rinse cycle. -
Page 8: Arranging Crockery, Glasses, Etc. In The Dishwasher
You can use any liquid or powder detergent, that has been specially designed for use in domestic dishwashers. (Do not use normal washing-up liquid!) Nowadays there are three types of dishwasher detergent available: 1.those containing phosphates and chlorine, 2.those containing phosphates but no chlorine, 3.those containing neither phosphates nor chlorine. -
Page 9: Filling The Rinse-Aid Container
- Select a programme with as low a temperature and as short a duration as possible. - Connect the dishwasher to a hot water supply, this will give shorter wash cycles. - To prevent damage, take glass and cutlery out of the dish- washer as soon as possible after the programme has ended. -
Page 10: Getting To Know Your Dishwasher
˜‡ · ¨ ˇ´ 4."WQP6-3¡– ‚ 5mm 19.5 106.5 Appliance interior 7 Lower rack 8 Upper rack 9 Middle sprayer Arm 10 Lower sprayer Arm 11 Washing Filter 12 Detergent and Rinse-aid Dispenser Heating indicator light HDW6WH 1¡¢Intensive 2¡¢Normal 3¡¢Rinse 4¡¢Glass 5¡¢Pre-rinse... -
Page 11: Safety Precautions
- Ensure that the domestic wiring is properly earthed. - The mains power supply must conform to the details shown on the dishwasher rating plate. - Do not connect the dishwasher to the power supply via an extension cable. - IMPORTANT: The top panel can be removed to build the appliance in un- der a bench . -
Page 12: Domestic Dishwasher
Domestic Dishwasher HDW6WH For domestic use only Code: 0120502698...
