HP Compaq dx6120 MT Supplementary Manual

HP Compaq dx6120
Business PC Series - EMEA only
Illustrated Parts Map
Microtower
System Unit
1 Access panel
2 Chassis
3 Front bezel with 5.25" ODD bezel blank and lower
3.5" bezel blank, painted
4 Power supply, PFC, 300W, ATX
5 3.5" bezel blank, top bay, painted
6 5.25" bezel blank, carbonite
Mass Storage Devices (not illustrated)
40 GB\7200 RPM SATA hard drive
80 GB\7200 RPM SATA hard drive
160 GB\7200 RPM SATA hard drive
250GB\7200 RPM SATA hard drive
48X CD-ROM drive with mounting screws
48X/32X/48X +16X DVD/CD-RW drive
16X DVD+R/RW drive
16/48X DVD ROM drive
© 2006 Hewlett-Packard Development Company, L.P.
HP and the HP logo are trademarks of Hewlett-Packard
All other product names mentioned herein may be trademarks of
HP shall not be liable for technical or editorial errors or
omissions contained herein. The information in this document is
provided "as is" without warranty of any kind and is subject to
change without notice. The warranties for HP products are set
forth in the express limited warranty statements accompanying
such products. Nothing herein should be construed as
constituting an additional warranty.

Cables

395969-001 1 SATA hard drive cable, 13-inch
not spared 2 IDE UATA dual device, Optical Disk Drive data
cable, 14-inch
368085-001
3 RJ-11 telephone cable
405872-001 4 Power/LED cable with switch and switch holder
335938-005 * USB+audio front I/O panel cable
335937-005
*Not shown
Keyboard (not illustrated)
365555-001
PS/2, Basic
345713-005
USB, Basic
PS/2, Basic[1]
345712-005
USB, Basic[1]
393303-001
Belgian
397130-001
BHCSY
405425-001
Czech
405760-001
Danish
405761-001
Finnish
French
French Arabic
German
Greek[1]
Hebrew
Hungarian
[1] 396215, 396217 - Greek (-151) only
Development Company, L.P.
their respective companies.
3rd Edition, June 2006
1st Edition, January 2005
Document Number
376217-003
391738-001
395964-001
198220-005
395965-001
395966-001
382925-xxx
382926-xxx
396215-xxx
396217-xxx
-181 International -B31
-B41 Italian -061
-221 Norwegian -091
-081 Portuguese -131
-351 Romanian -271
-051 Slovakian -231
-DE1 Spanish -071
-041 Swedish -101
-151 Swiss -111
-BB1 Turkish -141
-211 U.K. -031

Standard and Optional Boards

1 System board with alcohol pad and thermal grease
Memory Modules
* 256 MB/533 MHz FSB, DDR2, PC2-4200
* 512 MB/533 MHz FSB, DDR2, PC2-4200
Intel Celeron D Processors with thermal grease and alcohol pad
* 2.8 GHz/533 MHz FSB, 256 KB cache
* 3.06 GHz/533 MHz FSB, 256 KB cache
* 3.2 GHz/533 MHz FSB, 256 KB cache
Intel Pentium 4 Processors with thermal grease and alcohol pad
* 2.8 GHz/800 MHz FSB, 1 MB cache
* 3.0 GHz/800 MHz FSB, 2 MB cache
* 3.06 GHz/533 MHz FSB, 1 MB cache
* 3.2 GHz/800 MHz FSB, 2 MB cache
* 3.4 GHz/800 MHz FSB, 2 MB cache
Other Cards
* PCI Modem, ATX
* Intel Gigabit NIC
Graphics Solution
* ATI RV515 VGA graphics, 256M, ATX bracket
FH = Full Height mounting bracket
* Not shown
Miscellaneous Parts
1 Speaker
2 Chassis fan
3 Heatsink with fan, alcohol pad, and thermal grease
* Real-time clock battery
* Rubber foot (4 ea)
* Media card reader, 3.5-inch
Mouse
* 2-Button, PS/2, with scroll wheel
* 2-Button, USB, optical with scroll wheel
* 2-Button, PS/2, optical with scroll wheel
Miscellaneous screw kit, includes:
* M3 x 5mm hi top, taptite, (4 ea) (247348-001)
* #6-32 x 1/4 Hi top, taptite, T15 (4 ea) (192308-001)
* #6-32 x 5/16 Hi top, taptite, T15 (2 ea) (192308-002)
* #6-32 x 3/16 Hi top, taptite, T15 (4 ea) (192308-003)
* Countersunk, flat head plastite (4 ea) (247481-001)
* Thumbscrew (1 ea) (368224-002)
Modem Cable Adapters (not illustrated) (use with 198220-005)
Belgium 316904-181 Italy
Cameroon 316904-AR1 Macedonia
Czech 234963-225 Netherlands
Germany 316904-045 Poland/Russia
Greece 316904-151 Scandinavia
France 316904-051 Switzerland
Hungary 234963-215 Turkey
Israel 316904-BB1 U.K.
*Not shown
419303-001
393392-001
393393-001
391941-001
405693-001
382503-001
394643-001
419651-001
412985-001
384786-005
384787-005
398661-001
398332-001
413023-001
399871-001
392412-001
418841-001
153099-001
370708-001
407187-001
390937-001
390938-001
417966-001
414180-001
316904-065
419652-001
316920-335
316904-241
382848-DH1
304398-115
316904-141
158593-035
