- Page 1 Oven CM676GB.1 User manual and installation instructions Register your product on My Siemens and discover exclusive ser- vices and offers. siemens-home.bsh-group.com/welcome The future moving in. Siemens Home Appliances...
-
Page 2: Table Of Contents
en Safety Table of contents ¡ Keep the instruction manual and the product information safe for future refer- ence or for the next owner. ¡ Do not connect the appliance if it has been INFORMATION FOR USE damaged in transit. Safety .............. 2 1.2 Intended use Preventing material damage ....... -
Page 3: Safety
Safety en 1.4 Safe use Hot steam may escape when you open the appliance door. Steam may not be visible, de- Always place accessories in the cooking com- pending on the temperature. partment the right way round. ▶ Open the appliance door carefully. → "Accessories", Page 11 ▶... - Page 4 en Safety An ingress of moisture can cause an electric Food and its packaging and containers may shock. catch fire. ▶ Do not use steam- or high-pressure clean- ▶ Never heat food in heat-retaining pack- ers to clean the appliance. aging. ▶...
- Page 5 Safety en Airtight packaging may burst when food is WARNING ‒ Risk of injury! heated. Unsuitable cookware may crack. Porcelain or ▶ Always follow the instructions on the pack- ceramic cookware can have small perfora- aging. tions in the handles and lid. These perfora- ▶...
-
Page 6: Preventing Material Damage
en Preventing material damage 1.6 Cleaning function WARNING ‒ Risk of harm to health! The cleaning function heats up the cooking WARNING ‒ Risk of fire! compartment to a very high temperature so Loose food remnants, fat and meat juices that food left over from roasting, grilling and may catch fire when the cleaning function is in baking will burn off. -
Page 7: Environmental Protection And Saving En- Ergy
Environmental protection and saving energy en Using oven cleaner in a hot cooking compartment Using accessories directly on top of one another damages the enamel. causes sparks. ▶ ▶ Never use oven cleaner in the cooking compartment Do not combine the wire rack with the universal when it is still warm. -
Page 8: Familiarising Yourself With Your Appliance
en Familiarising yourself with your appliance 4 Familiarising yourself with your appliance 4.1 Control panel Buttons The buttons on the left- and right-hand side of You can use the control panel to configure all functions the control panel have a pressure point. Press of your appliance and to obtain information about the a button to execute its function. -
Page 9: Operating Modes
Operating modes en If you have set a cooking time and the cooking time is You can remove the rails, e.g. for cleaning. deleted, the countdown time takes over from the time → "Rails", Page 25 that has already elapsed from the cooking time. You can therefore always check how long the operation has already been running. - Page 10 en Operating modes 5.1 Types of heating To ensure that you always use the right type of heating When you select a type of heating, the appliance sug- to cook your food, we explain the differences and ap- gests a suitable temperature or setting. You can use plications below.
-
Page 11: Accessories
Accessories en 5.2 Microwave power settings This is where you can find an overview of the different microwave power settings and when to use them. The microwave power settings are levels and do not always correspond to the exact wattage that the appliance uses. Microwave power in Maximum cooking watts... - Page 12 You will find a comprehensive range of products for your appliance in our brochures and online: siemens-home.bsh-group.com Accessories vary from one appliance to another. When purchasing accessories, always quote the exact product number (E no.) of your appliance.
-
Page 13: Basic Operation
Change any further settings depending on the selec- button lights up blue. ‒ tion. a The Siemens logo appears in the display. A type of Press to start. heating and a temperature are then displayed. 8.6 Setting the type of heating and the 8.2 Switching off the appliance... - Page 14 en Time-setting options 9.1 Setting rapid heating a The symbol appears on the left of the display next to the temperature. To ensure an even cooking result, do not place the a The progress line begins to fill up. food in the cooking compartment until rapid heating a When rapid heating has come to an end, a signal has come to an end.
-
Page 15: Microwave
Microwave en Use the rotary selector to reset the cooking time to a Once the cooking time has elapsed, an audible sig- zero. nal sounds. A notification appears in the status bar. To continue without setting a cooking time, press Once the cooking time has elapsed: ‒... - Page 16 en Microwave Cookware and accessories with MicroCombi ¡ To prevent condensation, when the microwave out- By combining the microwave and a type of heating, put is 600 watts (max), the appliance automatically metal cookware and accessories are also possible. switches on a heating element. The cooking com- partment and the accessories become hot.
- Page 17 Dishes en 11.3 Microwave combination Once the cooking time has elapsed: Press to silence the audible signal manu- ‒ To reduce the cooking time, you can use certain types ally. of heating in combination with the microwave. If necessary, set another combination. ‒...
- Page 18 en Dishes In order to obtain an optimal cooking result, you must 12.4 Adjusting the dish also set the weight. Unless otherwise indicated, set the Note: Once it has started, you can no longer change or total weight for your dish. You can set the weight only interrupt the dish or the settings.
-
Page 19: Dishes
Childproof lock en 13 Childproof lock You can secure your appliance to prevent children a A confirmation notification appears on the display. from accidentally switching it on or changing the set- a The appears in the status bar when the appliance tings. -
Page 20: Sabbath Mode
en Cleaning and servicing 15.2 Changing the basic settings Basic setting Selection Night-time dimming Switched off Press . Switched on Press . Brand logo Display a The operating modes menu opens. Do not display Select the "Settings" operating mode. a The first basic setting appears. -
Page 21: Cleaning And Servicing
Cleaning and servicing en Appliance door Area Suitable cleaning agents Information Door panels ¡ Hot soapy water Do not use a glass scraper or a stainless steel wool. Tip: Remove the door panels in order to clean them thoroughly. → "Appliance door", Page 24 Door cover ¡... - Page 22 en Self-cleaning 17 Self-cleaning 17.2 Setting the self-cleaning function With the self-cleaning cleaning function, the cooking compartment is cleaned virtually automatically. Ventilate the kitchen while the cleaning function is run- Use the "Self-cleaning" to clean the cooking compart- ning. ment every two to three months. You can use the "Self- cleaning"...
- Page 23 Cleaning assistance en 17.3 Preparing the appliance for use Note: White residues on the enamel surfaces may be caused by heavy soiling. These food residues following the cleaning function are harmless. The deposits do not compromise the Allow the appliance to cool down. functionality of the appliance.
- Page 24 en Appliance door The duration is set to 10:00 min. and cannot be Once the duration has elapsed: changed. A message appears in the display. ‒ Press to start the drying function. Press to silence the audible signal before ‒...
- Page 25 Rails en 20.3 Fitting the door panes Attach the front pane downwards into the left- and right-hand retainers . Push the front pane to the appliance until the left- WARNING ‒ Risk of injury! and right-hand hook is opposite the support ...
-
Page 26: Troubleshooting
en Troubleshooting 21.2 Fitting the retainers Hook the rear retainers with the hook into the top hole and push them into the bottom hole . The retainers may fall out when you detach the rails. Note: The retainers at the front differ from those at the rear. 21.3 Attaching the rails Notes ¡... -
Page 27: Customer Service
Troubleshooting en Fault Cause and troubleshooting The appliance is not Electronics fault working. Briefly disconnect the appliance from the power supply by switching off the fuse. Reset the basic settings to the factory settings. → "Basic settings", Page 19 "Sprache Deutsch" There has been a power cut. appears in the dis- ▶... - Page 28 ▶ Next time, set lower or higher values. Tip: A lot of information about the food preparation and corresponding setting values can be found on our website siemens-home.bsh-group.com . 23 Disposal 23.1 Disposing of old appliance This appliance is labelled in accord- ance with European Directive Valuable raw materials can be reused by recycling.
-
Page 29: How It Works
How it works en ¡ If you are cooking bakes directly in the universal General information about roasting in cookware pan, place the universal pan into the cooking com- ¡ Use heat-resistant, ovenproof cookware. partment at level 1. ¡ Place the cookware on the wire rack. ¡... - Page 30 en How it works ¡ In the main part of the instruction manual, you will ¡ Use salt and seasoning sparingly. When cooking find information on how to configure the microwave food using the microwave mode, most of the food's and microwave combination oven settings. natural flavour will be retained.
- Page 31 How it works en Food Accessory/cook- Shelf pos- Heating Temperature in Microwave Cooking ware ition function °C power setting time in → Page 9 in W mins Bread, without a tin, Universal pan 1. 210–220 1. 10–15 2. 180–190 2. 40–50 1500 g Loaf tin Bread, without a tin,...
- Page 32 en How it works Food Accessory/cook- Shelf pos- Heating Temperature in Microwave Cooking ware ition function °C power setting time in → Page 9 in W mins Leg of lamb, boned, me- Uncovered cook- 170 - 190 50 - 70 dium, 1.5 kg ware Leg of lamb, boned, me- Covered cookware...
- Page 33 How it works en Food Accessory/cook- Shelf pos- Heating Temperature in Microwave Cooking ware ition function °C power setting time in → Page 9 in W mins Yoghurt Individual moulds Cooking 40 - 45 8 - 9 hrs compart- ment floor 1.
- Page 34 en How it works Recommended settings for defrosting Food Accessory/cook- Shelf pos- Heating Temperature in Microwave Cooking ware ition function °C power setting time in → Page 9 in W mins Bread, 500 g Uncovered cook- 1. 180 1. 3 ware 2. 90 2.
- Page 35 How it works en Recommended settings for warming up food using the microwave mode Food Accessory/cook- Shelf pos- Heating Temperature in Microwave Cooking ware ition function °C power setting time in → Page 9 in W mins Drinks, warming up, Uncovered cook- 1000 1 - 3 200 ml...
- Page 36 en How it works Recommended settings for baking Food Accessory/cookware Shelf posi- Heating Temperature in °C Cooking time tion function in mins → Page 9 Viennese whirls Baking tray 150–160 20–30 Viennese whirls Baking tray 140–150 25–35 Small cakes Baking tray ...
-
Page 37: Installation Instructions
Installation instructions en Food Accessory/cook- Shelf pos- Heating Temperature in Microwave Cooking ware ition function °C power setting time in → Page 9 in W mins Cakes Uncovered cook- 190 - 210 12 - 18 ware Chicken Uncovered cook- 180 - 200 25 - 35 ware... - Page 38 en Installation instructions 26.3 Installation below a worktop ATTENTION! Carrying the appliance by the door handle Observe the installation dimensions and the installation could break it. The door handle cannot sup- instructions when installing below a worktop. port the weight of the appliance. ▶...
- Page 39 Installation instructions en 26.5 Installation in a tall unit ¡ To ensure that the appliance door can be opened, you must take the minimum dimensions into consid- Observe the installation dimensions and the installation eration when installing in a corner. The dimension ...
- Page 40 en Installation instructions 26.8 Installing the appliance Slide the appliance in fully and centre it. Screw the appliance into place. For handleless kitchens with vertical bar handle strips: Attach a suitable filling piece in order to cover ‒ any sharp edges and to guarantee a safe install- ation.
- Page 44 Valid within Great Britain: Imported to Great Britain by BSH Home Appliances Ltd. Grand Union House Old Wolverton Road Wolverton, Milton Keynes MK12 5PT United Kingdom Manufactured by BSH Hausgeräte GmbH under the trademark licence of Siemens AG *9001680363* 9001680363 (020504)
