SSM-D1000 Manual
ITEM
MODEL NAME
DESCRIPTION
SOLUTION
SAMSUNG P/N
GoerTek P/N
Green Procurement
Vendor Code
Registration Date
DRAWING
A TERM OF VALIDITY
Indemnification
Goertek will indemnify, hold harmless, and at Samsung's request, defend Samsung and Samsung's
directors, officers, employees, agents and independent contractors from and against any loss, cost,
liability or expense ( including court costs and reasonable fees of attorneys and other
professionals) arising out of or resulting from any third party claim that any Products and/or
Components provided by Goertek infringes patent, copyright, trade secret right or other
intellectual property right. If Goertek receives notice of an alleged patent, copyright, trade secret
or other intellectual property right infringement or if Samsung's use of the Products and/or the
Components provided by Goertek shall be prevented by permanent injunction for reasons of
patent, copyright or trade secret infringement, Goertek may, at its sole option and expense,
procure for Samsung the right to continued use of the Products and/or the Components as provided
hereunder, or modify the allegedly infringing item such that it is no longer infringing, or replace
the allegedly infringing item.
MAKER
ADDRESS
CSR: BC57E687C-GITB-E4
CHECK
OVER AT LEAST 15-YEARS FROM ISSUED DATE
Goertek
Dongfang North Road, New&High-tech Industrial
development Zone, Weifang, Shandong, China
Bluetooth Module
SSM-D1000
Bluetooth V3.0
4709-002101
AGREEMENT
TEL
APPROVAL
Advertisement
Related Manuals for Samsung SSM-D1000
Summary of Contents for Samsung SSM-D1000
- Page 1 Goertek may, at its sole option and expense, procure for Samsung the right to continued use of the Products and/or the Components as provided hereunder, or modify the allegedly infringing item such that it is no longer infringing, or replace the allegedly infringing item.
-
Page 2: Part _ Specification
Part _ Specification 1. Introduction SSM-D1000 is a BT module compliant with Bluetooth 3.0 standard. The core chipset is from CSR, part number is BC57E687C-GITB-E4. 2. Features Chipset: CSR BC05; Interface: 8Pin connect with Audio Dock main board ... -
Page 3: Hardware Architecture
3.1 Main Chipset Information Item Vender Part number Bluetooth Transceiver/PA BC57E687C-GITB-E4 BC57E687C-GITB-E4 Figure 1-1 Chip Block Diagram 3.2 Circuit Block Diagram The major internal components and external interfaces of SSM-D1000 are illustrated in Figure 1-2. Figure 1-2 SSM-A1000 Major Component and System Interface... -
Page 4: Interface Definition
4. Interface definition 5. Specifications 5.1 Supply Voltage: 3.3V±5% DC 5.2 Current Consumttion Status Current consumption Power on with no pair 4.1 mA When pairing 20 mA When playing music 23.4 mA Current Consumption of DUT... -
Page 5: Environmental Spec
6. Environmental Spec. Operating Temperature Range: -10degree C~ 60degree C Storage Temperature Range: Temperature: -20～80℃ Humidity: 95％(MAX) Operating Humidity Range: 10%～90％ (No dew condensation) 7. Notice FCC : This device complies with Part 15 of FCC Rules. Operation is Subject to following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received including interference that cause undesired operation. - Page 6 IMPORTANT NOTE: This module is intended for OEM integrator. The OEM integrator is still responsible for the FCC compliance requirement of the end product, which integrates this module. Any changes or modifications not expressly approved by the manufacturer could void the user's authority to operate this equipment.
