Bosch TDA7650GB Operating Instructions

Solving Minor Problems Yourself
Problem Possible Causes
Temperature control (I) set to Turn the temperature control to
minimum the desired position
Iron does not
Connection problems Check that the plug is inserted
work or is not
into the mains socket correctly
heating up
The "SensorSecure" system has Grip the handle of the iron to
been activated. re-start it
There is no water in the tank (E). Fill the water tank
Iron is not
The steam regulator (C) is in the Set the steam regulator to the
steaming
position relevant position
Temperature control (I) setting Set the temperature control
is too low. within the steam area (between
the "••" and "max") or turn the
steam regulator (C) to
Steam regulator (C) is set too Turn the steam regulator to a
high in conjunction with a low lower setting.
temperature.
You have pressed the shot of Wait 5 seconds between each
Water is steam button (A) repeatedly press of the jet of steam button
dripping from without waiting for 5 seconds
the holes in the between each press
soleplate
Water has been left in the tank Always empty the tank after
when the sole plate was cold, ironing and set the steam
with the steam regulator (C) set regulator to
at or and when filling the tank
Distilled water has not been Mix distilled water with tap
used (see "Filling the water water as directed in the "Filling
tank" section) or other products the water tank" section and
such as fragrant water have never add any other products to
been added to the tank the water tank
No water in the tank. Add water to the water tank.
Spray does
Obstructed mechanism. Contact an Authorised
not work.
Technical Service Centre.
During first use: Certain This is completely normal and
The iron
components on the appliance will stop after a short while.
begins to
have been lightly greased at the
smoke when
factory and may produce a little
switched on.
smoke when initially heated.
Deposits come Traces of lime scale are coming Carry out a cleaning cycle (see
out through out of the steam chamber Self Cleaning section)
the holes in the
soleplate
"SensorSecure" system has Grip the handle of the iron to
Flashing lamp been activated. re-start it.
on top of The pilot light (N) at the front of
handle the handle will stop flashing and
will show a continuous light.
You can download this manual from the local homepages of Bosch
Thank you for buying the TDA76 SensorSecure steam iron from Bosch.
These instructions contain valuable information about the unique
features of this iron and some hints to make ironing easier for you.
Please visit www.bosch-home.co.uk for more product
information or to register your product, just follow the link to
the Online guarantee registration.
Before using the iron for the first time
Please carry out the following steps:
1. Remove the protective cover from the soleplate before using the
iron.
2. While the iron is unplugged, fill the water tank (E) with tap water
3. Plug the appliance into the mains and set the temperature control
(I) to the "max" position by lining it up with the pointer (H) on the
iron.
4. When the iron has reached the correct temperature, the pilot
light (K) goes out. Set the steam regulator (C) to the maximum
position.
5. Hold the iron horizontally and repeatedly press the shot of steam
button (A). Any residue should come out of the soleplate (F). It may
smoke and smell – this is normal and will cease after a short while.
6. If necessary, carefully clean the soleplate down with a dry, folded
cloth
Cleaning and Maintenance
Attention ! Risk of burns !
For general cleaning, follow the information below:
Problem Solution
Dirty/lightly marked Clean the body of iron or soleplate with a
iron body or soleplate damp cloth then dry it.
Mark develops on Set the iron to its maximum temperature
soleplate during use setting. Rub the iron a few times over with
a dry cotton cloth folded several times.
Heavily stained While the iron is cold, iron a linen cloth
soleplate soaked in white vinegar. Then dampen a
cloth with water and wipe the soleplate
clean and dry thoroughly.
DO NOT de-scale or clean the water tank with cleaning products
or solvents, as these could cause the iron to drip when using the
steam function.
DO NOT use a "professional steam cleaner" for cleaning the
appliance.
DO NOT use sharp objects or abrasive products to clean the soleplate or
any other part of the appliance. To keep the soleplate in good condition,
do not allow it to come into contact with metal objects.
GUARANTEE TERMS
The terms of the guarantee for this appliance are in accordance with
that stated by our representative for the country in which it is sold.
Details of those conditions can be obtained from the retailer from
whom the appliance was purchased. The SALES RECEIPT must
be presented when making any claims against the terms of this
guarantee. We reserve the right to make technical modifications.
Solution
after ironing
Environmental Care
This iron has been designed according to ecological criteria,
related to the sustainable development, analyzing its whole
lifecycle - from material selection to its later reusing or recycling
- evaluating the improvement possibilities, from a technical,
economical and environmental point of view.
Before throwing a used appliance away, you should make it
noticeably inoperable e.g. cut off the mains lead and be certain to
dispose of it in accordance with current laws and regulations.
Your retailer, town council or local council can give you detailed
information about these.
This appliance is labelled in accordance with
European Directive 2002/96/EG concerning
used electrical and electronic appliances (waste
electrical and electronic equipment - WEEE).
The guideline determines the framework for the return
and recycling of used appliances as applicable throughout
the EU.
Tips to help you save energy
Steam production consumes the most energy. To help
minimise the energy used, follow the advice below:
• Start by ironing the fabrics that require the lowest ironing
temperature.
• Regulate the steam according to the selected ironing
temperature.
• Only use steam if necessary. If possible, use the spray
function instead.
• Try to Iron the fabrics while they are still damp and reduce
the steam setting. Steam will be generated from the
fabrics rather than the iron. If you tumble dry your fabrics
before ironing them, set the tumble drier to the 'iron dry'
programme.
• If the fabrics are damp enough, turn off the steam regulator
completely.
• Stand the iron upright during pauses. Resting it horizontally
with the steam regulator on generates wasted steam.
Important
This appliance has been designed exclusively for domestic use
and must not be used for industrial purposes.
Carefully read through the operating instructions for the appliance
and safeguard them for future reference.
Customer Service
Great Britain
Bosch Customer Service
Grand Union House
Old Wolverton Road
Milton Keynes
MK12 5PT
UK +44 (0)844 892 8923
IRL +353 (0)1450 2655
www.bosch-home.co.uk
001 TDA76..GB SensorSecure/01/11
TDA 76..
SensorSecure

Operating instructions

General safety warnings
• Danger of electric shocks or fire!
• This appliance is to be connected and used in accordance with
the information stated on its characteristics plate.
• This appliance must be connected to an earthed socket. If
it is absolutely necessary to use an extension cable, make
sure that it is suitable for 16A and has a socket with an earth
connection.
• The iron should not be used if it has been dropped, if there
are visible signs of damage or if it is leaking water. It must be
checked by an authorized Technical Service Centre before it
can be used again.
• Do not allow the power cable to come into contact with the
soleplate when it is hot.
• In order to avoid that, under unfavourable mains conditions,
phenomena like transient voltage drops or lighting fluctuations
can happen, it is recommended that the iron is connected to a
power supply system with a maximum impedance of 0.27Ω . If
necessary, the user can ask the public power supply company
for the system impedance at the interface point.
• This appliance is not intended to be used by persons (including
children) with reduced physical, sensory or mental capacities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning the use of the appliance
by a person responsible for their safety.
• Keep the appliance out of children's reach.
• Children should be supervised to ensure that they do not play
with the appliance.
• Remove the plug from the socket before filling the appliance with
water or before pouring out the remaining water after use.
• The appliance must be used and placed on a stable surface.
• When placed on its stand, make sure that the surface on which
the stand is placed is stable.
• The iron must not be left unattended while it is connected to
the supply mains.
• Unplug the appliance from the mains supply after each use, or
if a fault is suspected.
• The electrical plug must not be removed from the socket by
pulling the cable.
• Never immerse the iron in water or any other fluid.
• Do not leave the appliance exposed to weather conditions (rain,
sun, frost, etc.)
• With the aim of avoiding dangerous situations, any work or
repair that the appliance may need, e.g. replacing a faulty mains
cable, must only be carried out by qualified personnel from an
Authorised Technical Service Centre.
