Page 2
Warning! Safety Instructions • Ventilation - Install your TV where there is proper ventilation. Do not install in a confined space such as a bookcase. - Do not install the product on a carpet or cushion. - Do not block or cover the product with cloth or other materials while unit is plugged in.
Page 3
Unauthorised modification could void the user’s authority to operate this product. • Use only an authorised attachments / accessories approved by LG Electronics. Otherwise, this may result in fire, electric shock, malfunction, or product damage. • Never disassemble the AC adapter or power cord. This may result in fire or electric shock.
Stand Model • The device must be easily accessed to a location outlet near the AM-ST19CA 43US342H0ZC access. Some devices are not made by turning on / off button, turning off the device and unplugging the power cord. 50US342H0ZC AM-ST19CC •...
Lifting and moving the TV • Avoid touching the screen at all times, as this may result in damage to the screen. • Do not move the TV by holding the cable holders, as the cable holders may break, and injuries and damage to the Please note the following advice to prevent the TV from being scratched TV may occur.
Attaching the TV to a Desk Using the Kensington security system (Depending on model) The TV should be attached to a desk so it cannot be pulled in a forward/ (Depending on model) backward direction, potentially causing injury or damaging the product. The Kensington security system connector is located at the rear of the TV.
LG recommends that wall mounting be performed by a qualified professional installer. We recommend the use of LG’s wall mount bracket. LG’s wall mount bracket is easy to move with cables connected. When you do not use LG’s wall mount bracket, please...
Connections Other connections Connect your TV to external devices. For the best picture and audio quality, connect the external device and the TV with the HDMI cable. Connect various external devices to the TV and switch input modes to Some separate cable is not provided. select an external device.
External Speakers External Devices Available external devices are: Blu-ray player, HD receivers, DVD players, (Depending on model) VCRs, audio systems, USB storage devices, PC, gaming devices, and other external devices. • The external device connection may differ from the model. •...
Network Method of volume control port (Depending on model) (Depending on model) • Cable Spec. Wired network connection This TV can be connected to a Pro:Centric server via the port. After Each up/down pins making the physical connection, the TV needs to be set up for network are connected to CPU communication.
Using Button Adjusting the menu When the TV is turned on, press the button one time. You can adjust the Menu items using the button. You can simply operate the TV functions, using the button. Turns the power off. Changes the input source. Scrolls through the saved programmes.
Using Remote Control * To use the button, press and hold for more than 3 seconds. (POWER) Turns the TV on or off. Adjusts the brightness of the screen to reduce The descriptions in this manual are based on the buttons on the remote energy consumption.
Troubleshooting • Do not mix new batteries with old batteries. This may cause the batteries to overheat and leak. • Failure to match the correct polarities of the battery may cause the battery to burst or leak, resulting in fire, personal The software version can be updated for improvement in performance.
Abnormal display • If the product feels cold to the touch, there may be a small “flicker” when it is turned on. This is normal, there is nothing wrong with product. • This panel is an advanced product that contains millions of pixels. You may see tiny black dots and/or brightly coloured dots (red, blue or green) at a size of 1 ppm on the panel.
Specifications (Depending on country) Broadcasting Specifications Digital TV Analogue TV DVB-S/S2 PAL/SECAM B/G, D/K, I Television system DVB-T/T2 SECAM L DVB-C DVB-S/S2 DVB-C DVB-T/T2 VHF III: 174 ~ 230 MHz Channel coverage UHF IV: 470 ~ 606 MHz 46 ~ 862 MHz (Band) 950~2,150 MHz 46 ~ 890 MHz...
Page 16
HDMI-DTV supported mode HDMI-PC supported Mode • PC audio is not supported. Horizontal Vertical Resolution • Use HDMI IN 1 for PC mode. (Depending on model) Frequency (kHz) Frequency (Hz) 31.46 59.94 Horizontal Vertical 640 x 480p Resolution 31.5 Frequency (kHz) Frequency (Hz) 31.47 59.94...
Component port connecting Supported Audio Formats information File Item Info Format Component ports on the TV Bit rate 32 Kbps - 320 Kbps Sample freq. 16 kHz - 48 kHz .mp3 Support MPEG1, MPEG2 Video output ports on DVD player Channels mono, stereo Bit rate Sample freq.
Extension Codec • Some HEVC encoded ULTRA HD videos other than the content VC-1 Advanced Profile (except for officially provided by LG Electronics may not be played. Video .asf WMVA), VC-1 Simple and Main Profiles • Some codecs can be supported after a software upgrade.
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such...
Page 20
IR CODES • This feature is not available for all models. Code (Hexa) Function Note Remote control Button (POWER) (Power On/Off) Remote control Button Remote control Button Remote control Button Remote control Button Number Key 0-9 10-19 Alphabet buttons Remote control Button (SPACE) Remote control Button Remote control Button...
Page 21
Code (Hexa) Function Note Remote control Button Remote control Button (BACK) Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button Remote control Button...
EXTERNAL CONTROL Phone jack Type DEVICE SETUP (Depending on model) • You need to purchase the phone-jack to RS-232C cable required for the connection between the PC and the TV, which is specified in the manual. RS-232C Setup * For other models, connect to the USB port. •...
RS-232C Configurations Communication Parameters • Baud rate: 9,600 bps (UART) 7-Wire Configurations • Data length: 8 bits (Standard RS-232C cable) • Parity: None • Stop bit: 1 bit • Communication code: ASCII code • Use a crossed (reverse) cable. Set ID For [Set ID] number, see "Real data mapping".
Command Reference List Transmission / Receiving Protocol (Depending on model) (Depending on Model) Data Transmission Command1 Command2 (Hexadecimal) (Command1)(Command2)( )([Set ID])( )([Data])(Cr) 1 Power 00 to 01 (Command1) : First command to control the TV. (j, k, m or x) 2 [Aspect Ratio] (See p.
Page 25
1 Power (Command: k a) 3 Screen Mute (Command: k d) ►To control Power On/Off of the set. ►To select screen mute on/off. Transmission Transmission (k)(a)( )([Set ID])( )([Data])(Cr) (k)(d)( )([Set ID])( )([Data])(Cr) [Data] 00 : [Off] [Data] 00 : Screen mute off (Picture on) / Video mute off [Data] 01 : [On] [Data] 01 : Screen mute on (Picture off) [Data] 10 : Video mute on...
Page 26
6 [Contrast] (Command: k g) 9 [Tint] (Command: k j) ►To adjust screen contrast. ►To adjust the screen tint. You can also adjust contrast in the picture settings. You can also adjust tint in the picture settings. Transmission Transmission (k)(g)( )([Set ID])( )([Data])(Cr) (k)(j)( )([Set ID])( )([Data])(Cr) [Data] Min : 00 to Max : 64 [Data] Red : 00 to Green : 64...
Page 27
12 Remote Control Lock Mode (Command: k m) 15 [Energy Saving] (Command: j q) ►To lock the front panel controls on the monitor and remote control. ►To reduce the power consumption of the TV. You can also adjust Energy Saving in picture settings. Transmission Transmission (k)(m)( )([Set ID])( )([Data])(Cr)
Page 28
17 [Equalizer] (Command : j v) 18 Tune Command (Command: m a) ►To adjust equalizer. ►Select channel to following physical number. Transmission Transmission (j)(v)( )([Set ID])( )([Data])(Cr) (m)(a)( )([Set ID])( )([Data] 00)( )([Data] 01)( )([Data] 02)(Cr) [Data] 00 : High channel data [Data] 01 : Low channel data ex.
19 Programme [Skip] / [Add] (Command: m b) 22 Input select (Command: x b) (Main Picture Input) ►To set skip status for the current Programme. ►To select input source for main picture. Transmission Transmission (m)(b)( )([Set ID])( )([Data])(Cr) (x)(b)( )([Set ID])( )([Data])(Cr) [Data] 00 : [Skip] [Data] Structure...
Page 31
The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. Model Serial no.
