Unique Features
USB Direct Recording
Record music from CD to
your USB device.
Go to page 20
9:28 AM
Page 1
Model: HW554PH (HW554PH-D0, SH54PH-F/S/C/W, W93-T/R)
HW554TH (HW554TH-D0, SH54TH-F/S/C/W, W93-T/R)
HW554TM (HW554TM-D0, SH54TM-S/C/W, W93-T/R)
®
Partner,
Full HD up-scaling
(1080p)
View Full HD picture quality
with simple setup.
Go to page 13
Portable In
Listen to music from your
portable device (MP3,
Notebook, etc).
Go to page 20
5.1ch ez Set-up
Listen sound from TV, DVD
and Digital Device with vivid
5.1ch mode.
Go to page 18
P/NO : MFL60020722
Advertisement
Table of Contents
Related Manuals for LG HW554PH
Summary of Contents for LG HW554PH
- Page 1 HW554PH-D0_BDEULL_ENG_0722 1/8/09 9:28 AM Page 1 Model: HW554PH (HW554PH-D0, SH54PH-F/S/C/W, W93-T/R) HW554TH (HW554TH-D0, SH54TH-F/S/C/W, W93-T/R) HW554TM (HW554TM-D0, SH54TM-S/C/W, W93-T/R) As an E ® Partner, NERGY LG has determined that this product or product models meet the E ® guidelines for NERGY energy efficiency.
- Page 2 European representative : CAUTION concerning the Power Cord LG Electronics Service Europe B.V. Most appliances recommend they be placed upon a dedicated circuit; Veluwezoom 15, 1327 AE Almere, The Netherlands...
-
Page 3: Table Of Contents
LG TV with SIMPLINK are connected through HDMI connection. • Controllable functions by LG TV’s remote control; Play, Pause, Scan, Skip, Stop, Hooking up the unit ......8-9 Power Off, etc. -
Page 4: Setting Up
(plus). Connect the wires to the speakers. Connect the other end of each wire to the correct speaker according to the colour coding Assembling the Speakers (HW554TH, HW554PH) COLOUR SPEAKER POSITION 1 Attach the speakers to the speaker stands by rotating the screw. - Page 5 HW554PH-D0_BDEULL_ENG_0722 1/8/09 9:28 AM Page 5 Setting up Attaching the speakers to the Wireless Receiver Connect the power cord of the Wireless Receiver to the outlet. Connect the wires to the Wireless Receiver. Connect the Wireless Receiver and the rear speaker (right, left) with the speaker cable.
- Page 6 HW554PH-D0_BDEULL_ENG_0722 1/8/09 9:28 AM Page 6 Setting up Be careful of the following About Ferrite Core (For EMI only) - Optional • Set the distance between this unit and Wireless Receiver within 10m. Be sure to attach the ferrite core to the speaker cables (for connecting to •...
-
Page 7: Led Indicator Of Wireless Transmitter
HW554PH-D0_BDEULL_ENG_0722 1/8/09 9:28 AM Page 7 LED indicator of Wireless Setting an ID of Wireless Transmitter Transmitter Operation When the unit is manufactured, the ID is already set. If an interference LED color occurs or you use a new Wireless Receiver, an ID is set again. -
Page 8: Hooking Up The Unit
HW554PH-D0_BDEULL_ENG_0722 1/8/09 9:28 AM Page 8 Hooking up the unit a Connect jacks on the unit and your TV (DVD player or Digital Device etc.) using the cables. Audio In connection Video Out connection The unit’s Audio jacks are colour coded (red for right... - Page 9 HW554PH-D0_BDEULL_ENG_0722 1/8/09 9:28 AM Page 9 Hooking up the unit Hooking up the unit - more you HDMI Out connection can do Connect the HDMI OUTPUT jack on the unit to the HDMI input jack Resolution Setting on a HDMI compatible TV using a You can change the resolution for component video HDMI cable.
-
Page 10: Remote Control
You can control the sound level, input source, and SETUP : Accesses or removes setup menu power switch of LG TVs as well. Hold POWER (TV) and MENU : Accesses the menu on a DVD disc. press PROGRAM (v/V) button repeatedly until the TV DISPLAY: Accesses On-Screen Display. -
Page 11: Main Unit
HW554PH-D0_BDEULL_ENG_0722 1/8/09 9:28 AM Page 11 Main Unit Open/Close Play/Pause, Function DVD/CD Disc Drawer Press and hold down this button for about 3 seconds then press PORT. IN port repeatedly to select other function. The PORT. In port means you can connect an audio device to play trough the surround sound speakers. -
Page 12: Osd Initial Language Settings - Optional
HW554PH-D0_BDEULL_ENG_0722 1/8/09 9:28 AM Page 12 OSD Initial language settings - Optional Adjust the settings During the first use of this unit, the initial language setup menu ON REMOTE appears on your TV screen. You must complete initial language selection before using the unit. English will be selected as the initial... - Page 13 HW554PH-D0_BDEULL_ENG_0722 1/8/09 9:28 AM Page 13 Adjust the display settings • If you turn off the TV or disconnect the HDMI cable during playback of the device, playback will pause. You have to click on the play button to play back TV Aspect –...
-
Page 14: Setting The Sound Mode
HW554PH-D0_BDEULL_ENG_0722 1/8/09 9:28 AM Page 14 Adjust the lock settings Setting the sound mode To access the lock options, you must enter the 4-digit password. If you have not VSM (VIRTUAL SOUND MATRIX) and Dolby Pro Logic II yet entered a password you are prompted to do so. Enter a 4-digit password. -
Page 15: Displaying Disc Information
HW554PH-D0_BDEULL_ENG_0722 1/8/09 9:28 AM Page 15 Displaying Disc Information Playing a Disc or file ON REMOTE ON REMOTE 1 Open the disc tray: (On unit: Z Z ) 1 Press DISPLAY: DISPLAY 2 Insert a Disc: (On unit) U U u u... - Page 16 HW554PH-D0_BDEULL_ENG_0722 1/8/09 9:28 AM Page 16 Fast forward or fast reverse Mixed disc or USB Flash Drive – DivX, MP3/WMA and JPEG When playing a disc or USB Flash Drive containing with DivX, MP3/WMA and Press SCAN (m or M) to play fast forward or fast reverse during playback.
-
Page 17: Viewing Photo Files
HW554PH-D0_BDEULL_ENG_0722 1/8/09 9:28 AM Page 17 Creating your own program Viewing photo files You can play the contents of a disc in the order you want by arranging the order of the music files on the disc. The program is cleared when the disc is removed. -
Page 18: Listening To The Radio
HW554PH-D0_BDEULL_ENG_0722 1/8/09 9:28 AM Page 18 See information about a radio station Listening to the radio The FM tuner is supplied with the RDS (Radio Data System) facility. This shows Be sure that FM aerial is connected. information about the radio station being listened to. Press RDS repeatedly to cycle... -
Page 19: Listening To Music From Your Usb Device
HW554PH-D0_BDEULL_ENG_0722 1/8/09 9:28 AM Page 19 Listening to music from your USB device - Listening to music from your more you can do USB device Compatible USB Devices The advantage of connecting your portable USB player through the system’s USB port is that the USB device can be controlled from the •... -
Page 20: Recording Music From Cd To Your Usb Device
HW554PH-D0_BDEULL_ENG_0722 1/8/09 9:28 AM Page 20 Recording music from CD to • If the USB can not record appears “NO USB”.“ERROR”,“USB FULL”, “NO REC” on the display window. your USB device • File will be stored to CD_REC folder in a format “TRK-001.mp3”. -
Page 21: Language Codes
HW554PH-D0_BDEULL_ENG_0722 1/8/09 9:28 AM Page 21 Language Codes Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu. Language Code Language Code Language Code Language Code Language Code Language Code Afar... -
Page 22: Troubleshooting
HW554PH-D0_BDEULL_ENG_0722 1/8/09 9:28 AM Page 22 Troubleshooting CAUSE CORRECTION PROBLEM No power Plug the power cord into the wall outlet securely. The power cord is disconnected. No picture Select the appropriate video input mode on the TV so the The TV is not set to receive the DVD signal. -
Page 23: Types Of Playable Discs
HDMI licensing LLC. compatible with the LG players when formatting rewritable discs. When setting the option to Live File System, you cannot use it on LG players. (Mastered/Live File System : Disc format system for Windows Vista) -
Page 24: Specifications
HW554PH-D0_BDEULL_ENG_0722 1/8/09 9:28 AM Page 24 Specifications Specifications General Speakers (HW554PH) Power supply 200 - 240V, 50/ 60 Hz Front Rear Power consumption Speaker speaker Net Weight 3.7 kg External dimensions (W x H x D) 430 x 73 x 305 mm... - Page 25 HW554PH-D0_BDEULL_ENG_0722 1/8/09 9:28 AM Page 25...
