Panasonic SA-AK750PL Service Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. Stereo System
  5. SA-AK750PL
  6. Service manual

Panasonic SA-AK750PL Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Notes: This model's CD mechanism changer unit is CRS1. Please refer to the original Service Manual
(Order No. MD0509368C0) for this mechanism.
Specifications
n AMPLIFIER SECTION
FTC output power
THD 10%, both channels driven
100 Hz to 3 kHz
(Low channel)
3 kHz to 12 kHz
(High channel)
40 Hz to 100 Hz
(Subwoofer channel)
Total FTC power
RMS output Bi-amp power
THD 10%, both channels driven
1 kHz
(Low channel)
10 kHz
(High channel)
60 Hz
(Subwoofer channel)
Total output power
PMPO
n FM/AM TUNER, TERMINALS SECTION
Preset station
Frequency Modulation (FM)
80 W per channel (3 Ω)
80 W per channel (3 Ω)
160 W per channel (6 Ω)
480 W
110 W per channel (3 Ω)
110 W per channel (3 Ω)
220 W per channel (6 Ω)
660 W
7200 W
FM 20 stations
AM 15 stations
SA-AK750PL
Colour
(K)... Black Type
Frequency range
Sensitivity
S/N 26 dB
Antenna terminal(s)
Amplitude Modulation (AM)
Frequency range
Sensitivity
S/N 20 dB (at 1000 kHz)
Music Port input jack
Terminal
Sensitivity
Phone jack
Terminal
MIC jack
Terminal
Sensitivity
n CASSETTE DECK SECTION
Track system
Heads
Record/playback
Erasure
© 2007 Matsushita Electric Industrial Co. Ltd.. All
rights
reserved.
distribution is a violation of law.
ORDER NO. MD0703022CE
CD Stereo System
87.9 to 107.9 MHz (200 kHz
87.5 to 108.0 MHz (100 kHz
4.0 µV (IHF)
75 Ω (unbalanced)
520 to 1710 kHz (10 kHz step)
Stereo, 3.5 mm jack
100 mV, 4.7 kΩ
Stereo, 3.5 mm jack
Mono, 3.5 mm jack
0.7 mV, 680 Ω
4 track, 2 channel
Solid permalloy head
Double gap ferrite head
Unauthorized
copying
steps)
steps)
2.2 µV
560 µV/m
and
