- Page 1 EN FRONT LOAD DRYER INSTALLATION INSTRUCTIONS FR SÉCHEUSE Á CHARGEMENT FRONTAL INSTRUCTIONS D’INSTALLATION ES SECADORA DE CARGA FRONTAL INSTRUCCIONES DE INSTALACIÓN A07020301B January 2017...
-
Page 2: Table Of Contents
MUST be applied when installing, operating and maintaining any appliance. Save these instructions for future reference. Table of contents Important Safety Instructions ........2 Reversing Door ............18-19 Installation Requirements ........3-9 Options ................20 Installation Instructions ..........10-17 ©2016 Electrolux Major Appliances All rights reserved. - Page 3 Please read and save this Questions? guide For toll-free telephone support in the U.S.: Thank you for choosing Electrolux, the premium 1-877-4ELECTROLUX (1-877-435-3287) and in Canada: 1-800-265-8352. brand in home appliances. These Installation Instructions are part of our commitment to...
- Page 4 Installation Requirements Electrical system requirements 4-WIRE POWER SUPPLY CORD (not supplied) NOTE 4-wire receptacle Because of potentially inconsistent voltage capabilities, the use of this dryer with power (NEMA type 14-30R) created by gas powered generators, solar powered generators, wind powered generators The dryer MUST employ a 4-conductor or any other generator other than the local utility power supply cord NEMA 14-30 type SRDT...
-
Page 5: Installation Requirements
Installation Requirements Gas supply requirements 5. A 1/8 inch (0.32 cm) N.P.T. plugged tapping, WARNING accessible for test gauge connection, MUST EXPLOSION HAZARD be installed immediately upstream of the gas Uncoated copper tubing will corrode when supply connection to the dryer. subjected to natural gas, causing gas leaks. - Page 6 Installation Requirements Exhaust system requirements, continued WARNING MAXIMUM LENGTH of 4” (102 mm) Rigid Metal Duct FIRE HAZARD VENT HOOD TYPE A clothes dryer must be exhausted outdoors. (Preferred) Do not exhaust dryer into a chimney, a wall, a ceiling, an attic, a crawl space or any concealed space of a building.
- Page 7 Installation Requirements Exhaust system requirements, continued Install male fi ttings in correct direction: WARNING FIRE HAZARD Do not install the dryer where gasoline or other fl ammables are kept or stored. If the dryer is installed in a garage, it must be a minimum of 18 inches (45.7 cm) above the fl...
- Page 8 Installation Requirements Clearance requirements IMPORTANT MIN INSTALLATION CLEARANCES - Inches (cm) SIDES REAR FRONT DO NOT INSTALL YOUR DRYER: 1. In an area exposed to dripping water or Alcove 0” (0 cm) 0” (0 cm)* 0” (0 cm) outside weather conditions. Under- 0”...
- Page 9 Installation Requirements Dryer dimensions 53.2” (135 cm)* to clear open door 31.6” (80 cm)* 27.0” to front of closed door (68.5 cm) electrical 38.0” supply on (96.5 cm) rear of unit 1.5” 3.7” (4 cm) (9.5 cm) 53.25” (135.5 cm) centerline gas supply height of...
- Page 10 Installation Instructions Electrical installation The following are specifi c requirements for WARNING proper and safe electrical installation of your ELECTRICAL SHOCK HAZARD dryer. Failure to follow these instructions can ● A U.L.-approved strain relief must be create electrical shock and/or a fi re hazard. installed onto power cord.
- Page 11 Installation Instructions Grounding requirements - Electric dryer (Canada) For a grounded, cord-connected dryer: WARNING 1. The dryer MUST be grounded. In the event Improper grounding of the dryer may cause of a malfunction or breakdown, grounding serious injury or death. Check with a licensed will reduce the risk of electrical shock by electrician if you are in doubt as to whether providing a path of least resistance for...
- Page 12 Installation Instructions Electrical connection (non-Canada) - 3 wire cord 3-wire receptacle (NEMA type 10-30R) WARNING 30 AMP 30 AMP NEMA 10-30 NEMA 10-30 Neutral Neutral ELECTRICAL SHOCK HAZARD (center wire) (center wire) Failure to disconnect power source before servicing could result in personal injury or even death.
-
Page 13: Installation Instructions
Installation Instructions Electrical connection (non-Canada) - 4 wire cord 4-wire receptacle (NEMA type 14-30R) Neutral Neutral (WHITE wire) (WHITE wire) WARNING Ground Ground 30 AMP 30 AMP (GREEN wire) (GREEN wire) NEMA 14-30 NEMA 14-30 ELECTRICAL SHOCK HAZARD Failure to disconnect power source before servicing could result in personal injury or even death. - Page 14 Installation Instructions Gas connection Remove the shipping cap from gas pipe at 3. Open the shutoff valve in the gas supply line the rear of the dryer. to allow gas to fl ow through the pipe. Wait a few minutes for gas to move through the IMPORTANT gas line.
- Page 15 Installation Instructions Water connection (Steam Model only) WATER SUPPLY REQUIREMENTS Cold water faucet MUST be installed within 42 inches (107 cm) of your dryer’s water inlet. The faucet MUST be 3/4 inch (1.9 cm) with thread- ing for laundry hose connection. Water pressure MUST be between 20 and 120 psi.
- Page 16 Installation Instructions Water connection, continued (Steam Model only) 5. If your installation has room for the COLD DIRECT CONNECTION water supply to accept the “Y” connector OR WITH EXTENSION* directly, thread the “Y” connector to the COLD water supply and snug it by hand; then tighten it another 2/3 turn with pliers.
- Page 17 Installation Instructions General installation Connect the exhaust duct to the outside exhaust system. Use of a 4” (102 mm) clamp (item A) is recommended to connect the dryer to the exhaust vent system. Use metal foil tape to seal all other joints. 2.
- Page 18 Reversing Door NOTE Door reversibility is available on the following dryer models: 300, 400, 500, or 600 series. IMPORTANT Tools needed for reversal: BEFORE YOU REVERSE YOUR DRYER DOOR: 1. Be sure you have adequate swing area Screwdriver before reversing door. with #2 2.
-
Page 19: Reversing Door
Reversing Door C) Reinstalling Door Assembly D) Reinstalling Latch Cover and Hole Plugs 1. Rotate the door and hang the upper hook 1. Install door latch cover with screws on the back of the hinge in the upper hole removed earlier. of the front panel. -
Page 20: Options
Label all wires prior to disconnection when (1-877-435-3287) in the U.S. or 1-800- servicing controls. Wiring errors can cause 265-8352 in Canada, or visit our website, improper and dangerous operation. Verify www.electroluxappliances.com, for the proper operation after servicing. Electrolux Authorized Parts Distributor nearest you. - Page 22 electrolux.com/shop...
