- Page 1 Operating Instructions Dishwasher To prevent accidents and machine damage, read these instructions be- fore installation or use. en-US HG05 M.-Nr. 10 546 790...
-
Page 2: Table Of Contents
Contents IMPORTANT SAFETY INSTRUCTIONS .............. 4 Guide to the dishwasher.................. 13 Appliance overview ....................13 Control panel ......................14 Caring for the environment ................ 15 Energy-saving dishwashing................... 16 Before using for the first time ................ 17 Opening the door ....................17 Closing the door.................... - Page 3 Contents Unloading the dishwasher..................45 Interrupting a program................... 46 Changing a program....................46 Options ......................... 47 Short ........................ 47 Turning off the refill indicators ................48 Delay Start......................49 AutoOpen ......................51 Optimize Standby....................52 Factory default settings ..................53 Program overview ....................
-
Page 4: Important Safety Instructions
Keep the installation plan and the operating instructions in a safe place and pass them on to any future owner. Miele cannot be held liable for damage caused by non-compliance with this information. - Page 5 IMPORTANT SAFETY INSTRUCTIONS Correct use This dishwasher is intended for use in domestic households and similar residential environments. This dishwasher is not suitable for outdoor use. It must only be used as specified in these operating instructions for cleaning domestic dishes and cutlery.
- Page 6 IMPORTANT SAFETY INSTRUCTIONS Safety with children Children must be kept away from the appliance unless they are constantly supervised. Children should be supervised to ensure that they do not play with the appliance. Keep small children away from the appliance at all times to avoid the risk of injury.
- Page 7 Miele cannot be held liable for the consequences of an inadequate grounding system (e.g. electric shock). ...
- Page 8 IMPORTANT SAFETY INSTRUCTIONS To avoid the risk of damage to the dishwasher, make sure that the connection data on the data plate (fuse rating, voltage, and fre- quency) matches the electrical supply before connecting the dish- washer to the mains. Consult a qualified electrician if in any doubt. ...
- Page 9 If the connection cable is damaged, it must be replaced with a special cable of the same type (available from Miele) by a Miele-au- thorized service technician only. This dishwasher is supplied with a special bulb to cope with par- ticular conditions (e. g.
- Page 10 IMPORTANT SAFETY INSTRUCTIONS Proper installation The dishwasher must be installed and connected in compliance with the installation plan. Be careful when installing the dishwasher. Wear protec- tive gloves to avoid injury on any sharp metal components. The dishwasher must be correctly aligned horizontally to ensure problem-free operation.
- Page 11 IMPORTANT SAFETY INSTRUCTIONS Proper use Do not use solvents in the dishwasher. Danger of explosion! Do not inhale or ingest powder detergent. Dishwasher detergents contain irritant or corrosive ingredients which can cause burning in the nose, mouth, and throat if swallowed, or inhibit breathing. Seek medical attention immediately if detergent has been swallowed or in- haled.
- Page 12 Please observe the information given in "Technical data" regarding the capacity of the dishwasher. Accessories Use only genuine original Miele parts. If spare parts or acces- sories from other manufacturers are used, the warranty may become invalid. Disposal of your old dishwasher ...
-
Page 13: Guide To The Dishwasher
Guide to the dishwasher Appliance overview a Upper spray arm (not visible) g Filter combination b Cutlery tray (depending on model) h Data plate c Upper basket i Rinse aid reservoir d Middle spray arm j Double-chamber detergent dispenser e Heat exchanger return (depending on k Reservoir for reactivation salt model) f Lower spray arm... -
Page 14: Control Panel
Guide to the dishwasher Control panel a Program selection e Short button with indicator light b Time display f Delay Start button with indicator light c Check/Refill indicators g Program selection button d Start button with indicator light h (On/Off) button These operating instructions apply to several different dishwasher models with different heights. -
Page 15: Caring For The Environment
Consult with local authorities, dealers or Miele in order to dispose of and recycle electrical and electronic appliances. Miele assumes no responsibility for deleting any personal data left on the appliance being disposed. -
Page 16: Energy-Saving Dishwashing
Caring for the environment Energy-saving dishwashing This dishwasher is economical in the consumption of water and energy. For best results follow these tips: – For most economical dishwashing, make full use of the baskets without overloading the dishwasher. – Choose a program that best suits the degree of soiling and the type of dishes being washed. -
Page 17: Before Using For The First Time
Before using for the first time Opening the door Closing the door Push the baskets in. At the end of programs with a drying phase (see "Program overview") the Then lift the door upwards and push door will open automatically a little in until it clicks into position. -
Page 18: Water Softener
Before using for the first time Enter the water hardness below: Water softener ____________ gr/gal (°d) In order to achieve good cleaning re- sults, the dishwasher needs to operate The dishwasher is programmed at the with soft water. Hard water results in a factory for a water hardness level of 1 build-up of calcium deposits on dish- gr/gal (1 °d). -
Page 19: Displaying And Setting The Water Hardness Level
Before using for the first time Displaying and setting the water The value which has been set for the hardness level water hardness appears as a figure in the time display (see table) according to Turn the dishwasher off with the . - Page 20 Before using for the first time °d gr/gal °f Time °d gr/gal °f Time display display 37-45 39--47 66-80 46-60 48-63 82-107 61-70 64-73 109-125...
-
Page 21: Before Using The Appliance For The First Time, You Require
Before using for the first time Before using the appliance for If the water in your area is very soft the first time, you require: and consistently lower than 5 gr/gal (5 °d - German scale) you do not – Approx. 2 qt (2 l) of water have to add dishwasher salt. -
Page 22: Filling The Salt Reservoir
Before using for the first time Filling the salt reservoir Important! Before filling the salt reservoir with dishwasher salt for the first time, you must fill it with approx. 2 qt (2 l) of water to enable the salt to dissolve. Once the dishwasher has been used for the first time, there is always suf- ficient water in the reservoir. -
Page 23: Salt Refill Indicator
Before using for the first time Salt refill indicator If you only ever use combination prod- ucts in your dishwasher, you can Fill the salt reservoir with dishwasher switch both refill indicators for salt and salt when the Salt indicator light rinse aid off if you wish (see "Options, comes on. -
Page 24: Rinse Aid
Before using for the first time Rinse aid Rinse aid is needed to prevent spotting on dishes and glassware. The rinse aid is filled in the reservoir and the set amount will be automatically dosed. Filling the rinse aid reservoir with detergent will damage the reservoir. -
Page 25: Rinse Aid Indicator
Before using for the first time Turn the dishwasher off with the Rinse aid indicator button, if it is turned on. When the Rinse Aid indicator lights up, the rinse aid reservoir contains suffi- Press the Start button and, simulta- cient rinse aid for 2 - 3 programs only. -
Page 26: Loading The Dishwasher
Loading the dishwasher – Make sure that small items cannot Tips fall through the holders in the bas- Remove coarse food residues from the kets. dishes. Small items, e.g., lids, should there- fore be placed in the cutlery tray or There is no need to rinse items under cutlery basket (depending on model). - Page 27 Loading the dishwasher Items not recommended for dish- Glass care washing – Clouding may occur on glasses after – Wooden cutlery, cutting boards and frequent washing. If delicate glass- dishes or items with wooden parts ware is washed in the dishwasher, ensure that only very low tempera- –...
-
Page 28: Loading Examples
Loading the dishwasher Loading examples Loading for 10 standard place settings with cutlery tray Lower basket Upper basket Cutlery tray (depending on model) - Page 29 Loading the dishwasher Loading for 16 standard place settings with cutlery tray Upper basket Lower basket Cutlery tray (depending on model)
- Page 30 Loading the dishwasher Loading for 10 standard place settings with cutlery basket Lower basket Upper basket Cutlery basket...
- Page 31 Loading the dishwasher Loading for 13 standard place settings with cutlery basket Lower basket Upper basket Cutlery basket...
-
Page 32: Flexassist
Loading the dishwasher Cup rack FlexAssist Using the yellow lever , lift the cup The yellow FlexAssist components indi- rack upwards to make room for tall cate which elements of the baskets for items. dishes and cutlery tray are moveable. They also act as grips and have sym- Glasses can be arranged along the po- bols embossed on them to show what... -
Page 33: Adjusting The Upper Basket
Loading the dishwasher Adjusting the upper basket Dishwashers with cutlery basket (see data plate for model number) In order to gain more space for taller items the upper basket can be adjusted Plate in inches (cm) Upper on three levels with 3/4" (2 cm) between basket Upper basket Lower... -
Page 34: Lower Basket
Loading the dishwasher Removable MultiComfort insert Lower basket The rear section of the lower basket is used for washing cups, glasses, plates, pots and pans. You can remove the MultiComfort insert to make more room for larger items such as casserole dishes. Removing the insert ... - Page 35 Loading the dishwasher FlexCare glass holder Hinged spikes (depending on model) Silicone padding in the FlexCare glass The spikes at the front are used for holder provides a stable and secure washing plates, soup bowls, platters, hold for delicate stemware. dessert bowls, and saucers.
-
Page 36: Cutlery
Loading the dishwasher Cutlery The upper spray arm must not be blocked by items which are too big. 3D cutlery tray+ (depending on model) The side sections of the tray can be Arrange the cutlery in the tray as moved into the middle using the yellow shown. - Page 37 Loading the dishwasher Both rows of spikes in the middle sec- tion of the cutlery tray can be flipped over to make room for larger pieces of cutlery. You can use the yellow slide to adjust the height of the middle section of the cutlery tray to make more room for large items of cutlery, such as serving spoons and ladles.
-
Page 38: Cutlery Basket (Depending On Model)
Loading the dishwasher Cutlery basket (depending on model) Fit it onto the cutlery basket if re- quired. The cutlery basket can be placed any- where on the front rows of spikes in the lower basket. To avoid the risk of injury, knives and forks should be placed with the han- dles upwards in the basket. -
Page 39: Operation
(e.g., tea, cof- For optimum cleaning and drying re- fee, tomato sauce). sults, use Miele dishwasher detergent and add Miele salt and Miele rinse aid Most dishwasher detergents are mildly separately. alkaline and contain enzymes and oxy- gen-based bleaching agents. - Page 40 Operation Detergent dosage Dishwasher detergents can Follow the dosage recommended by cause burning in the nose, mouth, the manufacturer on the packaging. and throat if swallowed, or inhibit breathing. Unless directed otherwise, use one Avoid inhaling or swallowing dish- detergent tab or add 1 1/4 - 2 table- washer detergent.
- Page 41 Operation Adding detergent Add the required amount of detergent and close the flap. Press the opening catch on the deter- gent dispenser. The flap will spring Make sure that the detergent packag- open. ing is properly closed after use to avoid it getting damp and becoming The flap is always open at the end of a lumpy.
-
Page 42: Turning On
Operation Turning on Selecting a program Make sure the spray arms are not ob- Choose your program according to the structed. type of load and the degree of soiling. Close the door. The different programs and their uses are described in the Program Over- ... -
Page 43: Starting A Program
Operation Starting a program Time display The duration of the program selected The dishwasher can be started only if appears in hours and minutes in the the door is closed. display before the program begins. Dur- Press the Start button. ing the program, the time left until the end of the program is displayed. -
Page 44: Energy Management
Operation Energy management At the end of the program The program has finished when . To save energy, the dishwasher will switch off automatically 10 minutes af- appears in the time display and the ter the last time a button has been door has opened slightly. -
Page 45: Turning Off The Dishwasher
Operation Turning off the dishwasher Unloading the dishwasher At the end of a program: Dishes tend to break and chip more easily when they are hot. Allow the The dishwasher can be switched off dishes to cool until they are comfortable at any time using the ... -
Page 46: Interrupting A Program
Operation Interrupting a program Changing a program A program will be interrupted as soon If the detergent dispenser flap has al- as the door is opened. ready opened, do not change the program. Close the door and press the Start button. -
Page 47: Options
Options Turn the dishwasher on with the Short button. The "Short" option reduces the du- The Start indicator light flashes. ration of programs in which this option is available (see "Program overview"). Select a program. In order to achieve optimum cleaning ... -
Page 48: Turning Off The Refill Indicators
Options Press the button 9 times. Turning off the refill indicators The indicator light will flash 9 times If you consistently use a Tab detergent, at short intervals. you can deactivate the refill indicators if you wish. The flashing sequence in the time dis- ... -
Page 49: Delay Start
Options Turn the dishwasher on with the Delay Start button. You can set the start time for a pro- The Start indicator light flashes. gram. The start time can be delayed be- tween 30 minutes and 24 hours. Select the desired program. The delay period is shown in 30 min- ... - Page 50 Options If Optimize Standby is switched on If you open the door during the delay (see "Programming options, Optimize start time, you must then press the Standby"), the time display will go out Start button to continue the delay start after a few minutes following activa- time.
-
Page 51: Autoopen
Options Press the button seven times. AutoOpen The indicator light will flash briefly At the end of programs with a drying seven times at short intervals. phase (see "Program overview"), the door will open automatically a little in The flash pattern in the time display in- order to help the drying process. -
Page 52: Optimize Standby
Options Press the button 8 times. Optimize Standby The indicator light will flash 8 times "Optimize Standby" is activated by de- at short intervals. fault. The flashing sequence in the display To save energy, the dishwasher will shows whether or not Optimize Standby switch off automatically a few minutes is activated. -
Page 53: Factory Default Settings
Options Press the button 19 times. Factory default settings The indicator light will flash once at a If you have altered any settings from the long interval and then 9 times at short factory default, you can reset them intervals. -
Page 54: Program Overview
Program overview Program When to use Program sequence Pre- Main Interim Final Drying wash wash rinse rinse °F/°C °F/°C Program for regular use to completely 117- 140/ Normal wash a full load of normally soiled needed 140/ dishes with the ability to adjust en- ergy and water consumption based on the soil load of the dishes. - Page 55 Program overview Consumption Duration Energy Water Cold water Hot water Gallons/Liters Cold water Hot water 50°F/10°C 120°F/49°C 50°F/10°C 120°F/49°C h:min h:min 1.02 1.11 3.2/12.1 2:19 2:00 1.30 1.55 3.8/14.5 3:24 3:07 0.85 1.05 3.4/13.0 2:23 2:03 1.15 1.25 3.0/11.5 1:15 0:58 1.45 1.65...
-
Page 56: Cleaning And Care
If, however, there are limescale or grease deposits in the wash cabinet, these can be removed with a special cleaning agent (available from Miele). Follow the instructions on the packag- ing. If you mainly use low temperature pro- grams (<... -
Page 57: Cleaning The Door Front
Cleaning and care To better maintain your appliance Cleaning the door front avoid the following: If soiling remains longer, it may – Cleaning products containing soda, happen that the surfaces can be- ammonia, acid, or chloride come discolored or changed. –... -
Page 58: Filter System
Cleaning and care Filter system Filter system Turn the dishwasher off. The filter system in the base of the wash cabinet prevents food from being redeposited on dishes. It also protects the circulation pump from damage caused by foreign objects. ... - Page 59 Cleaning and care Replace the filter system so that it lies To clean the inside of the filter, the flap flat in the base of the wash cabinet. must be opened: Press catches together in the di- ...
-
Page 60: Cleaning The Spray Arms
Cleaning and care Cleaning the spray arms Particles of food can get stuck in the spray arm jets and bearings. The spray arms should therefore be inspected and cleaned regularly (approx. every 4 - 6 months). Turn the dishwasher off. Remove the spray arms as follows: ... -
Page 61: Frequently Asked Questions
Reset the fuse (see data plate for the correct fuse rating). If the circuit breaker trips again, contact Miele Ser- vice. The time display is The door has not closed properly, because it had not... - Page 62 Press the Start button. pears in the display. If the indicator lights flash again, there is a technical fault. Contact Miele Service. Fault : The WaterProof System has reacted. The drain pump is still Turn off the water supply.
-
Page 63: Water Intake Fault
Frequently Asked Questions Water intake fault Problem Possible cause and solution The Intake/Drain indica- The water supply is turned off. tor flashes on and off. Turn on the water supply fully. The dishwasher stops Before fixing the fault: during a program. ... -
Page 64: General Problems
Frequently Asked Questions General problems Problem Possible cause and solution The indicator lights and The dishwasher has switched off automatically to time display are dark. save energy. Turn the dishwasher on again with the button. Detergent residue is left The dispenser was still damp when detergent was in the dispenser at the added. -
Page 65: Noises
Frequently Asked Questions Noises Problem Possible cause and solution There is a knocking A spray arm is hitting the dishes. noise in the wash cabi- Interrupt the program, and rearrange the items net. which are obstructing the spray arm. There is a rattling noise Dishes is moving around in the wash cabinet. -
Page 66: Poor Cleaning Results
Frequently Asked Questions Poor cleaning results Problem Possible cause and solution The dishes are not The dishes were not loaded correctly. clean. See notes in "Loading the dishwasher". The program was not powerful enough. Select a more intensive program (see "Program overview"). - Page 67 Frequently Asked Questions Problem Possible cause and solution Dishes is not dry or cut- The rinse aid dosage is set too low or the rinse aid lery and glasses are reservoir is empty. spotty. Replenish the reservoir, increase the dosage, or change the brand of rinse aid (see "Before using for the first time - Rinse aid").
- Page 68 Frequently Asked Questions Problem Possible cause and solution White residue is visible The rinse aid dosage is too low. on dishes and cutlery, Increase the dosage (see "Before using for the first clouding occurs on time, Rinse aid"). glassware; this film can The salt reservoir is empty.
-
Page 69: Cleaning The Drain Pump And Non-Return Valve
Frequently asked questions Cleaning the drain pump and non-return valve If the water has not been pumped away at the end of a program, the drain pump or the non-return valve might be blocked. They are, however, easy to clean. ... -
Page 70: Customer Service
Miele appliance. Please note that unless expressly ap- proved in writing by Miele’s Service de- partment, Extended Service Contracts offered by other providers for Miele products will not be recognized by Miele. -
Page 71: Optional Accessories
These and many other useful products glass protection additives can be ordered from a Miele dealer or – Phosphate-free - kind to the environ- via the Miele Webshop (see end of this ment booklet for contact details). - Page 72 Optional accessories Dishwasher care products Miele cleaning and care products pro- vide optimum care for your dishwasher. Dishwasher cleaner – Cleans the dishwasher effectively and thoroughly – Removes grease, bacteria, and un- pleasant odors – Ensures excellent dishwashing re- sults Dishwasher descaler –...
-
Page 73: Installation Instructions
Installation Instructions Please refer to the Installation Diagram supplied with these instructions. To comply with IEC sound testing protocols, please contact Miele for additional instructions. Information is subject to change. Please refer to our website to obtain the most current product specification, technical & warranty information. -
Page 74: Electrical Connection
Technical Service Department: USA: 1-800-999-1360 A damaged power cord must only be CDN: 1-800-565-6435 replaced with a genuine Miele cord by a Miele service technician. Specifications The dishwasher comes equipped with a Grounding instructions 4 ft (1.2 m) powercord (measured from... - Page 75 Electrical connection Hardwired electrical connection Prior to making a hardwire connec- It is possible to hardwire this appliance tion to the terminal, remove the pow- to an existing power cable. ercord. Otherwise there will be a risk of electric shock from the attached CAUTION: Before servicing, discon- plug.
-
Page 76: Water Connection
Water connection Water intake To avoid any damage to the ap- pliance, the dishwasher must only be Water in the dishwasher must operated when it is connected to a not be used as drinking water. fully vented plumbing system. –... -
Page 77: Drainage
Water connection Drainage Make sure that there are no kinks in the hose, and that it is not – The machine comes equipped with a squashed or stretched. built-in non-return valve on the dis- charge side to prevent waste water from flowing back into the dish- After servicing the appliance, ensure washer. -
Page 78: Sound Emission Testing
Sound emission testing Prerequisites for sound emission tests Load the dishwasher with 16 standard place settings and use the Normal pro- gram. Setup for sound emission tests The dishwasher must be set up according to the following specifications. Install the dishwasher into an analyzing unit. ... - Page 79 Sound emission testing Push the provided fleece strips (depending on model) under the toe-kick until it is flush with the appliance feet . Push the toe-kick into place in such a way that it is flush with the door front .
- Page 80 Sound emission testing Remove the protective film from the provided insulating strip (depending on model) . Push the insulating strip into the front top edge of the toe-kick .
- Page 83 Technical Service. U.S.A. Canada Miele, Inc. Importer Miele Limited National Headquarters 9 Independence Way Headquarters and Miele Centre Princeton, NJ 08540 161 Four Valley Drive Phone: 800-843-7231 Vaughan, ON L4K 4V8 609-419-4298 Fax: www.miele.ca www.mieleusa.com...
- Page 84 G 6620 / G 6625 en-US M.-Nr. 10 546 790 / 01...
