- Page 1 KMK525800M Microwave combi-oven User Manual Get the most out of your appliance For quick access to manuals, how-to guides, support and more through our photo registration visit electrolux.com/register...
- Page 2 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.
-
Page 3: Table Of Contents
CONTENTS 1. SAFETY INFORMATION................5 1.1 Children and vulnerable people safety............. 5 1.2 General Safety....................5 2. SAFETY INSTRUCTIONS................8 2.1 Installation......................8 2.2 Electrical connection..................9 2.3 Use........................9 2.4 Care and cleaning...................10 2.5 Internal lighting....................10 2.6 Service......................11 2.7 Disposal......................11 3. PRODUCT DESCRIPTION................12 3.1 General overview....................12 3.2 Accessories.................... - Page 4 CONTENTS 10.7 Information for test institutes.................31 11. CARE AND CLEANING................33 11.1 Notes on cleaning..................33 12. TROUBLESHOOTING................34 12.1 What to do if....................34 12.2 Service data....................34 13. ENERGY EFFICIENCY................36 13.1 Energy saving....................36 14. IT'S EASY!....................37 4/44...
-
Page 5: Safety Information
SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. - Page 6 SAFETY INFORMATION Always use oven gloves to remove or put in accessories or • ovenware. Before carrying out any maintenance, disconnect the • appliance from the power supply. WARNING: Ensure that the appliance is switched off before • replacing the lamp to avoid the possibility of electric shock. Do not use the appliance before installing it in the built-in •...
- Page 7 SAFETY INFORMATION When heating food in plastic or paper containers, observe • the appliance due to the possibility of ignition. The appliance is intended for heating food and beverages. • Drying of food or clothing and heating of warming pads, slippers, sponges, damp cloth and similar may lead to risk of injury, ignition or fire.
-
Page 8: Safety Instructions
2. SAFETY INSTRUCTIONS 2.1 Installation WARNING! Only a qualified person must install this appliance. • Remove all the packaging. • Do not install or use a damaged appliance. • Follow the installation instructions supplied with the appliance. • Always take care when moving the appliance as it is heavy. Always use safety gloves and enclosed footwear. -
Page 9: Electrical Connection
SAFETY INSTRUCTIONS 2.2 Electrical connection WARNING! Risk of fire and electric shock. • All electrical connections should be made by a qualified electrician. • The appliance must be earthed. • Make sure that the parameters on the rating plate are compatible with the electrical ratings of the mains power supply. -
Page 10: Care And Cleaning
SAFETY INSTRUCTIONS • Do not use microwave function to preheat the oven. WARNING! Risk of damage to the appliance. • To prevent damage or discoloration to the enamel: – do not put aluminium foil directly on the bottom of cavity of the appliance. –... -
Page 11: Service
SAFETY INSTRUCTIONS 2.6 Service • To repair the appliance contact the Authorised Service Centre. • Use original spare parts only. 2.7 Disposal WARNING! Risk of injury or suffocation. • Disconnect the appliance from the mains supply. • Cut off the mains electrical cable close to the appliance and dispose of it. •... -
Page 12: Product Description
3. PRODUCT DESCRIPTION 3.1 General overview Control panel Knob for the heating functions Display Control knob Heating element Microwave generator Lamp Turntable shaft 3.2 Accessories Turntable set To prepare food. ≤ 4 kg Grill rack set To grill. 12/44... -
Page 13: Control Panel
4. CONTROL PANEL 4.1 Buttons Sensor field / Button Description To set the clock functions and microwave power. Use only while a heating function works. To start a heating function. Press to extend a microwave func‐ tion duration for 30 sec. To confirm. -
Page 14: Before First Use
5. BEFORE FIRST USE WARNING! Refer to Safety chapters. To set the Time of day refer to "Clock functions" chapter. 5.1 Initial Cleaning Step 1 Step 2 Step 3 Clean the oven and the ac‐ Remove all accessories from cessories with a soft cloth, Place the accessories in the the oven. -
Page 15: Daily Use
6. DAILY USE WARNING! Refer to Safety chapters. 6.1 Retractable knobs To use the appliance press the knob. The knob comes out. 6.2 Heating functions Heating function Application The oven is off. Off position To turn on the lamp. Light To heat and cook food. -
Page 16: Setting Function: Microwave
DAILY USE Heating function Application To melt chocolate and butter. Power range is 100 - 400 W. Melting To prepare popcorn. Power range is 700 - 1000 W. Popcorn 6.3 Setting function: Microwave How to start cooking with the default settings: Step 1 Turn the knob for the heating functions. -
Page 17: Setting Function: Microwave Combi
DAILY USE The maximum time of microwave functions depends on microwave power you set: MICROWAVE POWER MAXIMUM TIME 100 - 600 W 90 minutes More than 600 W 7 minutes 6.4 Setting function: Microwave Combi Step 1 Insert the low grill rack. Step 2 Turn the knob for the heating functions to select the function: The display shows the default microwave power. -
Page 18: Clock Functions
7. CLOCK FUNCTIONS 7.1 Clock functions table Clock function Application To show or change the time of day. You can change the time of day only when the oven is off. Time of Day To set the length of cooking. Use only when a heating func‐ tion is set. -
Page 19: How To Set Function: End Time
CLOCK FUNCTIONS Step 3 Turn the control knob to set the minutes. - press to confirm. Step 4 Turn the control knob to set the hours. Press: When the set time ends the signal sounds for 2 min. Time setting flash in the display. The oven turns off automatically. -
Page 20: How To Set Function: Minute Minder
CLOCK FUNCTIONS Step 5 Turn the control knob to set the hour for the function: End Time. Press: Step 6 Turn the control knob to set the minutes for the function: End Time. Press: The display shows: the set temperature, Oven turns on automatically later on, works for the set Duration time and stops at the set End Time. -
Page 21: Using The Accessories
8. USING THE ACCESSORIES WARNING! Refer to Safety chapters. 8.1 Inserting accessories Use only suitable cookware and material. Refer to "Hints and tips" chapter, Microwave suitable cookware and materials. Turntable set: Always cook food on the turntable set. Use only the turntable set supplied with the oven. -
Page 22: Additional Functions
9. ADDITIONAL FUNCTIONS 9.1 Using Child lock When the Child lock is on the oven cannot be turned on accidentally. Step 1 Ensure the knob for the heating functions is in the off position. Step 2 - press and hold at the same time for 2 sec. The signal sounds. -
Page 23: Hints And Tips
10. HINTS AND TIPS WARNING! Refer to Safety chapters. The temperature and cooking times in the tables are guidelines only. They depend on the recipes and the quality and quantity of the ingredients used. 10.1 Cooking recommendations The temperature and cooking times in the tables are guidelines only. They depend on the recipes and the quality and quantity of the ingredients used. -
Page 24: Microwave Suitable Cookware And Materials
HINTS AND TIPS Microwave cooking Microwave defrosting Cook food covered. If you want to keep a crust Put the frozen, unwrapped food on a small up‐ cook food without a cover. turned plate with a container below it, or on a Do not overcook the dishes by setting the pow‐... -
Page 25: Grill
HINTS AND TIPS Cookware / Material Ceramic, porcelain and earth‐ enware with unglazed bottom or with small holes, e.g. on handles Heat-resistant plastic up to 200 °C Cardboard, paper Clingfilm Roasting film with microwave safe closure Roasting dishes made of metal, e.g. -
Page 26: Microwave Cooking
HINTS AND TIPS Preheat the empty oven before cooking. Use the function: Grill. Place the food on the high grill rack. (min) (min) 1st side 2nd side Whole fish, 0.4 - 0.45 kg 10 - 20 10 - 20 Fish cutlet 10 - 20 5 - 10 Toast with topping, 4 pieces... - Page 27 HINTS AND TIPS DEFROSTING MEAT / FISH Set power for 100 W unless specified (kg) (min) Standing otherwise. time (min) Steak 6 - 8 5 - 10 Minced meat, set 200 W 5 - 8 5 - 10 Chicken 20 - 25 20 - 30 Chicken breast 0.15...
- Page 28 HINTS AND TIPS CAKES AND BREAD Set power for 200 W unless specified (min) Standing otherwise. time (min) Sliced bread 0.2 kg 1 - 2 5 - 10 Bread rolls 4 pieces 1 - 2 5 - 10 FRUIT (kg) (min) Standing time (min)
- Page 29 HINTS AND TIPS LIQUIDS (ml) (min) Milk 1000 1 - 1:30 Water 1000 1:30 - 2 Put the bag with popcorn on the turntable. Prepare one bag at the time. When popping slows down (1 - 2 sec between pops), stop the oven manually. POPCORN (kg) (min)
-
Page 30: Recommended Power Settings For Different Kinds Of Food
HINTS AND TIPS MICROWAVE (min) Standing time (min) Baby milk, put a spoon into the 180 ml 0:20 - 0:40 bottle Microwave Combi function Set the function: Grill + MW. Place the food on the low grill rack. Turn the food halfway through the cooking time. The standing time is 2 - 5 min. -
Page 31: Information For Test Institutes
HINTS AND TIPS 500 - 700 W Defrosting Cooking veg‐ Cooking egg Simmering Simmering Heating one- and heating etables dishes stews rice plate meals frozen meals 300 - 400 W Melting cheese, chocolate, but‐ Cooking / Heating delicate food Continuing cooking 100 - 200 W Defrosting Heating baby... - Page 32 HINTS AND TIPS Use the function: Grill + MW Use the low grill rack. MICROWAVE COMBI FUNCTION Grill intensity (min) level Potato gratin, 1.1 kg 30 - 35 Chicken, 1.1 kg high 30 - 35 Put the meat in round glass con‐ tainer.
-
Page 33: Care And Cleaning
11. CARE AND CLEANING WARNING! Refer to Safety chapters. 11.1 Notes on cleaning Clean the front of the oven with a soft cloth with warm water and a mild deter‐ gent. Use a cleaning solution to clean metal surfaces. Cleaning Clean stains with a mild detergent. -
Page 34: Troubleshooting
12. TROUBLESHOOTING WARNING! Refer to Safety chapters. 12.1 What to do if... Problem Possible cause Remedy You cannot activate or oper‐ The oven is not connected to Check if the oven is correctly ate the oven. an electrical supply or it is connected to the electrical connected incorrectly. - Page 35 TROUBLESHOOTING The necessary data for the service centre is on the rating plate. The rating plate is on the front frame of the oven cavity. Do not remove the rating plate from the oven cavity. We recommend that you write the data here: Model (MOD.) .........
-
Page 36: Energy Efficiency
13. ENERGY EFFICIENCY 13.1 Energy saving The oven contains features which help you save energy during everyday cooking. Make sure that the oven door is closed properly when the oven operates. Do not open the door too often during cooking. Keep the door gasket clean and make sure it is well fixed in its position. -
Page 37: S Easy
14. IT'S EASY! Familiarize yourself with the icons on the Familiarize yourself with the symbols from control panel the Quick Guide To set the clock functions, micro‐ wave power. To start a heating function, extend microwave function duration for 30 Knob for the heating Control knob seconds. - Page 38 IT'S EASY! Setting function: Microwave Setting function: Microwave Combi Setting and changing the time Setting the duration Press repeatedly: - starts to flash on the display. Setting the Minute Minder: Press repeatedly: - starts to flash on the display. 38/44...
- Page 39 IT'S EASY! Setting the Minute Minder: 39/44...
- Page 40 15. ENVIRONMENTAL CONCERNS Recycle materials with the symbol . Put the packaging in relevant containers to recycle it. Help protect the environment and human health by recycling waste of electrical and electronic appliances. Do not dispose of appliances marked with the symbol with the household waste.
- Page 41 41/44...
- Page 42 42/44...
- Page 43 43/44...
- Page 44 www.electrolux.com/shop...
