Asus Republic of Gamers GT-AC2900 User Manual

Rapture dual-band gaming router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
E15761

Advertisement

Table of Contents
loading

Related Manuals for Asus Republic of Gamers GT-AC2900

Summary of Contents for Asus Republic of Gamers GT-AC2900

  • Page 1 E15761...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    Table of contents Getting to know your wireless router Welcome! ...................7 Package contents ................7 Assembling your router ...............7 Your wireless router ..............11 Positioning your router ............. 13 Setup Requirements ..............14 Getting started Router Setup ................. 15 Wired connection..............15 Wireless connection ..............16 Quick Internet Setup (QIS) with Auto-detection....
  • Page 4 Using the Network Map ............52 4.1.1 Setting up the wireless security settings ......53 4.1.2 Managing your network clients ..........54 4.1.3 Monitoring your USB device ..........55 4.1.4 ASUS AiMesh ................57 Wireless ................... 63 4.2.1 General ..................63 4.2.2 WPS ....................65 4.2.3 Bridge ...................67 4.2.4 Wireless MAC Filter ..............69...
  • Page 5 Table of contents WAN ....................81 4.5.1 Internet Connection ..............81 4.5.2 Dual WAN ..................84 4.5.3 Port Trigger .................85 4.5.4 Virtual Server/Port Forwarding ...........87 4.5.5 DMZ ....................90 4.5.6 DDNS ....................91 4.5.7 NAT Passthrough ..............92 Using the USB Application ............93 4.6.1 Using AiDisk ................94 4.6.2 Using Servers Center ...............96 4.6.3 3G/4G ..................
  • Page 6 Utilities Device Discovery ...............119 Firmware Restoration ...............120 Setting up your printer server ..........121 5.3.1 ASUS EZ Printer Sharing ............. 121 5.3.2 Using LPR to Share Printer ..........125 Download Master ..............130 5.4.1 Configuring Bit Torrent download settings ....131 5.4.2 NZB settings ................132 Troubleshooting Basic Troubleshooting .............133...

  • Page 7: Getting To Know Your Wireless Router

    HD streaming; SMB server, UPnP AV server, and FTP server for 24/7 file sharing; a capability to handle 300,000 sessions; and the ASUS Green Network Technology, which provides up to 70% power-saving solution. 1.2 Package contents...
  • Page 8 To Stand: Place the dual-purpose stand under the router, align the protrusion to the hollow, and then tighten the screw. To Hang: 1. Place the dual-purpose stand behind the router, and then align the protrusion to the hollow.
  • Page 9 2. Push the stand upwards until hearing a slightly click sound. 3. Tighten the screw.
  • Page 10 4. Hang the router on the wall with hooks and screws. Note: Ensure that each hook can reliably hold at least 2 kg and is secured by screws to prevent the router from dropping down. Hooks are not included in the package.

  • Page 11: Your Wireless Router

    1.4 Your wireless router WAN (Internet) LED Off: No IP or no physical connection. On: Has physical connection to a wide area network (WAN). 2.4GHz / 5GHz Wi-Fi LED Off: No 2.4GHz / 5GHz signal. On: Wireless system is ready. ROG Boost Key Press this button to change the Aura lighting effects or turn on/off Game Boost, DFS channels and GeForce Now QoS.
  • Page 12 Power button Press this button to power on or off the system. Power (DC-IN) port Insert the bundled AC adapter into this port and connect your router to a power source. USB 2.0 port Insert USB 2.0 compatible devices such as USB hard disks or USB flash drives into this port.

  • Page 13: Positioning Your Router

    • Keep the device away from metal obstructions and away from direct sunlight. • Keep the device away from 802.11g or 20MHz only Wi-Fi devices, 2.4GHz computer peripherals, Bluetooth devices, cordless phones, transformers, heavy-duty motors, fluorescent lights, microwave ovens, refrigerators, and other industrial equipment to prevent signal interference or loss. • Always update to the latest firmware. Visit the ASUS website at http://www.asus.com to get the latest firmware updates. • Place the wireless router horizontally. 45° 45°...

  • Page 14: Setup Requirements

    1.6 Setup Requirements To set up your wireless network, you need a computer that meets the following system requirements: • Ethernet RJ-45 (LAN) port (10Base-T/100Base- TX/1000BaseTX) • IEEE 802.11a/b/g/n/ac/ax wireless capability • An installed TCP/IP service • Web browser such as Internet Explorer, Firefox, Safari, or Google Chrome NOTES: • If your computer does not have built-in wireless capabilities, you may install an IEEE 802.11a/b/g/n/ac/ax WLAN adapter to your computer to connect to the network.

  • Page 15: Getting Started

    Getting started 2.1 Router Setup IMPORTANT! • Use a wired connection when setting up your wireless router to avoid possible setup problems. • Before setting up your ASUS wireless router, do the following: • If you are replacing an existing router, disconnect it from your network. • Disconnect the cables/wires from your existing modem setup. If your modem has a backup battery, remove it as well. • Reboot your cable modem and computer (recommended). A. Wired connection NOTE: You can use either a straight-through cable or a crossover cable for wired connection.

  • Page 16: Wireless Connection

    2. The web GUI launches automatically when you open a web browser. If it does not auto-launch, enter http://router.asus.com 3. Set up a password for your router to prevent unauthorized access. Wireless connection To set up your wireless router via wireless connection: 1.
  • Page 17 Default SSID: ASUS_XX ASUS router XX refers to the last two digits of the MAC address. You can find it on the label at the bottom of your ROG router. 3. Once connected, the web GUI launches automatically when you open a web browser. If it does not auto-launch, enter http://router.asus.com.

  • Page 18: Quick Internet Setup (Qis) With Auto-Detection

    Reset button on your wireless router to reset it to its factory default settings. To use QIS with auto-detection: 1. Launch a web browser. You will be redirected to the ASUS Setup Wizard (Quick Internet Setup). If not, key in http://router.asus.com manually.
  • Page 19 NOTES: • The auto-detection of your ISP connection type takes place when you configure the wireless router for the first time or when your wireless router is reset to its default settings. • If QIS failed to detect your Internet connection type, click Skip to manual setting and manually configure your connection settings. 3. Assign the wireless network name (SSID) and security key for your 2.4GHz and 5 GHz wireless connection.
  • Page 20 5. On the Login Information Setup page, change the router’s login password to prevent unauthorized access to your wireless router. NOTE: The wireless router's login username and password is different from the 2.4GHz/5GHz network name (SSID) and security key. The wireless router's login username and password allows you to log into your wireless router's Web GUI to configure your wireless router's settings.

  • Page 21: Connecting To Your Wireless Network

    2.3 Connecting to your wireless network After setting up your wireless router via QIS, you can connect your computer or other smart devices to your wireless network. To connect to your network: 1. On your computer, click the network icon in the notification area to display the available wireless networks.

  • Page 22: Configuring The General Settings Of Rog Gaming Center

    To log into the web GUI: 1. On your web browser, manually key in the wireless router’s default IP address: http://router.asus.com. 2. On the login page, key in the default user name (admin) and the password that you have set in 2.2 Quick Internet Setup (QIS) with Auto-dection.

  • Page 23: Dash Board

    3.2 Dash Board Dash Board allows you to monitor the real-time traffic for your networking environment and analyze the real-time network ping and ping deviation. Network ping refers to online game experiences. Higher ping means higher latency for real-time games. For most online games, network ping that is less than 99 ms is considered good quality.
  • Page 24 • Game Radar: Game Radar from Dashboard could give you a quick look about ping time for specific game server.
  • Page 25 • Aura RGB: Allows users to define or turn on/off the Aura RGB from Dashboard. You can setup any color and choose either of the 11 lighting patterns. • Event Trigger When choosing Event Trigger light mode, the system will detect the following events, and trigger the LED to show different lighting effects as notifications.
  • Page 26 • L og-in Fail When failing to log in ASUSWRT, you will see Comet in Red on the LED bar. • A ttack Block When the system successfully blocks a potential attack, the LED shows Comet in Red. Note: Once selecting Event Trigger mode, the system will show different lighting effects based on the current detected events.

  • Page 27: Aiprotection Pro

    3.3 Aiprotection Pro Aiprotection Pro provides real-time monitoring that detects malware, spyware, and unwanted access. It also filters unwanted websites and apps and allows you to schedule Internet access time for a connected device.

  • Page 28: Configuring Aiprotection Pro

    3.3.1 Configuring Aiprotection Pro Aiprotection Pro prevents network exploits and secures your network from unwanted access. To Configure Aiprotection Pro: 1. From the navigation panel, go to General > Aiprotection Pro. 2. From the Aiprotection Pro main page, click Network Protection. 3. From the Network Protection tab, click Scan. The search results are displayed on the Router Security Assessment page.
  • Page 29 IMPORTANT! Items marked with Yes on the Router Security Assessment page are considered to be safe. 4. (Optional) From the Router Security Assessment page, manually configure the items marked as No, Weak, or Very Weak. To do this: Click an item to go to the item’s setting page. b. F rom the item’s security settings page, configure and make the necessary changes and click Apply when done.

  • Page 30: Blocking Malicious Sites

    3.3.2 Blocking Malicious Sites This feature restricts access to known malicious websites in the cloud database for an always-up-to-date protection. NOTE: This function is automatically enabled if you run the Router Weakness Scan. To enable Malicious Sites Blocking: 1. From the navigation panel, go to General > Aiprotection Pro. 2. From the Aiprotection Pro main page, click Network Protection.

  • Page 31: Two-Way Ips

    3.3.3 Two-Way IPS This feature resolves common exploits within the router configuration. NOTE: This function is automatically enabled if you run the Router Weakness Scan. To enable Two-Way IPS: 1. From the navigation panel, go to General > Aiprotection Pro. 2. From the Aiprotection Pro main page, click Network Protection. 3. From the Two-Way IPS pane, click ON.

  • Page 32: Infected Device Prevention And Blocking

    3.3.4 Infected Device Prevention and Blocking This feature prevents infected devices from communicating personal information or infected status to external parties. NOTE: This function is automatically enabled if you run the Router Weakness Scan. To enable infected device prevention and blocking: 1. From the navigation panel, go to General > Aiprotection Pro. 2. From the Aiprotection Pro main page, click Network Protection.

  • Page 33: Setting Up Parental Control

    3.3.5 Setting up Parental Control Parental Control allows you to control the Internet access time or set the time limit for a client’s network usage. To enable Parental Control: 1. From the navigation panel, go to General > Aiprotection Pro. 2. From the Aiprotection Pro main page, click Parental Controls tab.
  • Page 34 Web & Apps Filters Web & Apps Filters is a feature of Parental Controls that allows you to block access to unwanted web sites or applications. To configure Web & Apps Filters: 1. From the navigation panel, go to General > Aiprotection Pro. 2.
  • Page 35 Time Scheduling Time Scheduling allows you to set the time limit for a client’s network usage. NOTE: Ensure that your system time is synchronized with the NTP server. To configure Time Scheduling: 1. From the navigation panel, go to General >Aiprotection Pro >...

  • Page 36: Game Acceleration

    3.4 Game Acceleration...

  • Page 37: Triple-Level Game Acceleration

    Simply connecting the gaming device to the gaming port (at GT-AC2900:LAN1) to get the first priority of the traffic. ROG First is a ASUS ROG Motherboard utility in Game first V, which can work with ASUS ROG gaming routers. • Game Packet Prioritization This feature allows you to enable Game Boost with one click.

  • Page 38: Qos

    3.4.2 QoS This feature ensures bandwidth for prioritized tasks and apps. To enable the QoS function: 1. From the navigation panel, go to General > Game Acceleration > QoS tab. 2. From the Enable QoS pane, click ON. 3. Fill in the upload and download bandwidth fields. NOTE: Get the bandwidth information from your ISP.
  • Page 39 GeForce NOW QoS GeForce NOW QoS mode is a unique QoS mode for NVIDIA cloud gaming service GeForce NOW enabled devices (e.g. Nvidia shield TV). By enabling GeForce NOW QoS mode, the router will reserve the required bandwidth, wireless mode, and QoS priority for GeForce NOW enabled devices defined by Nvidia.

  • Page 40: Game Private Network

    To update the firmware: 1. Launch the web browser and key in http://router.asus.com, enter the router’s default login name and password (admin/admin) to enter ASUSWRT GUI. 2. Go to Administration > Firmware Upgrade and click Check and follow the onscreen instructions to upgrade the firmware.
  • Page 41 To use wtfast: 1. From the navigation panel, go to General > Game Acceleration > wtfast. 2. Create a free wtfast account via https://www.wtfast.com/. 3. Log into the wtfast account. 4. From the wtfast Rules list, create the profile for the device that you want to use wtfast GPN on.

  • Page 42: Open Nat

    3.5 Open NAT When playing PC or console games, there may be some connection issues due to the ISP or router settings in your environment such as NAT and port blocks. Open NAT helps ensure that ROG Rapture gaming router is not blocking the game connection.
  • Page 43 3. Tick the platform you want to use. 4. Fill in your device IP address in the Internal IP field. 5. Click OK and then click Apply. Notes: • If you want to set up port forwarding rules for FTP server or other services, please go to WAN >...

  • Page 44: Game Radar

    3.6 Game Radar Game Radar is a diagnostic tool that helps you identify the connection quality of servers for specific games. To use Game Radar: 1. From the navigation panel, go to General > Game Radar and select a game from the game list. 2.

  • Page 45: Wifi Radar

    3.7 WiFi Radar Wi-Fi Radar, an advanced analysis tool for your wireless network, delves deep into the channels and packet data for troubleshooting. NOTE: Enabling WiFi Radar may result to a drop wireless performance. Only enable Wi-Fi Radar when needed. To use WiFi Radar: 1.

  • Page 46: Wifi Site Survey

    2. Click Start Data Collection. 3. Click Submit after you set all the parameters. 3.7.1 WiFi Site Survey WiFi Site Survey allows you to search for wireless networks in your environment.

  • Page 47: Wireless Channel Statistics

    3.7.2 Wireless Channel Statistics This feature shows channel usage of all bands and channel distribution statistics in your environment. 3.7.3 Advanced Troubleshooting This feature shows WiFi glitch statistics in your environment.

  • Page 48: Vpn

    3.8 VPN A virtual private network (VPN) provides a secure communication with a remote computer or network over a public network such as the Internet. NOTE: Before setting up a VPN connection, you would need the IP address or domain name of the VPN server. To set up access to a VPN server: 1.

  • Page 49: Vpn Fusion

    3.8.1 VPN Fusion VPN Fusion allows you to connect to multiple VPN servers simultaneously and assign your client devices to connect to different VPN tunnels. Some devices like set-top boxes, smart TVs and Blu-ray players do not support VPN software. This feature provides VPN access to such devices in a home network without having to install VPN software, while your smartphone remains connected to Internet not VPN.

  • Page 51: Traffic Analyzer

    3.9 Traffic Analyzer Traffic Analyzer gives you an at-a-glance view of what’s happening on your network on a daily, weekly, or monthly basis. It lets you to quickly see each user’s bandwidth usage or the device or app used, helping you reduce the bottlenecks in your Internet connection.

  • Page 52: Configuring The Advanced Settings

    Configuring the Advanced Settings 4.1 Using the Network Map Network Map allows you to configure your network’s security settings, manage your network clients, and monitor your USB device.

  • Page 53: Setting Up The Wireless Security Settings

    4.1.1 Setting up the wireless security settings To protect your wireless network from unauthorized access, you need to configure its security settings. To set up the wireless security settings: 1. From the navigation panel, go to Advanced Settings > Network Map. 2. On the Network Map screen and under System status, you can configure the wireless security settings such as SSID, security level, and encryption settings.

  • Page 54: Managing Your Network Clients

    IMPORTANT! The IEEE 802.11n/ac standard prohibits using High Throughput with WEP or WPA-TKIP as the unicast cipher. If you use these encryption methods, your data rate will drop to IEEE 802.11g 54Mbps connection. 5 Click Apply when done. 4.1.2 Managing your network clients To manage your network clients: 1.

  • Page 55: Monitoring Your Usb Device

    USB hard disk or USB flash drive, to the USB 3.0/2.0 ports on the rear panel of your wireless router. Ensure that the USB storage device is formatted and partitioned properly. Refer to the Plug- n-Share Disk Support List at http://event.asus.com/networks/ disksupport • The USB ports support two USB drives or one printer and one USB drive at the same time.
  • Page 56 To monitor your USB device: 1. From the navigation panel, go to Advanced Settings > Network Map. 2. On the Network Map screen, select the USB Disk Status icon to display your USB device’s information. 3. On the AiDisk Wizard field, click GO to set up an FTP server for Internet file sharing. NOTES: • For more details, refer to the section 4.6.2 Using Servers Center in this user manual. • The wireless router works with most USB HDDs/Flash disks (up to 4TB size) and supports read-write access for FAT16, FAT32, NTFS, and HFS+.

  • Page 57: Asus Aimesh

    4.1.4 ASUS AiMesh 4.1.4.1 Before setting Preparing to setup an AiMesh Wi-Fi system 1. Two (2) ASUS routers (models supporting AiMesh: https://www.asus.com/AiMesh/). 2. Assign one as AiMesh router, and another one as AiMesh node. NOTE: If you have multiple AiMesh routers, we recommend using the router with the highest specifications as your AiMesh router and the others as AiMesh nodes.
  • Page 58 AiMesh router 1) Refer to the other router Quick Start Guide to connect your AiMesh router to your PC and modem, and then log in into the web GUI. Modem AiMesh router AiMesh node Logout/Reboot AiMesh Router 2) Go to Network Map page, click AiMesh icon and then Search for your extending AiMesh node.
  • Page 59 3) Click Search, it will automatically search for your AiMesh node. When the AiMesh node shows on this page, click it to add it into the AiMesh system. NOTE: If you cannot find any AiMesh node, please go to TROUBLE SHOOTING. 4) A message is displayed when synchronization is completed.
  • Page 60 Power on your AiMesh node and connect it to your PC via a network cable. iii. Launch a web GUI. You will be redirected to the ASUS Setup Wizard. If not, navigate to http://router.asus.com iv. Go to Administration > Firmware Upgrade. Click on Choose File, and upload the AiMesh-supported firmware.
  • Page 61 Q1: Does the AiMesh router support Access Point mode? A: Yes. You can choose to set the AiMesh router as router mode or access point mode. Please go to web GUI (http://router.asus. com), and go to the page Administration > Operation Mode.
  • Page 62 1) Follow the setup steps to establish a connection between the AiMesh router and node via Wi-Fi first. 2) Place the node in the ideal locations for best coverage. Run an Ethernet cable from the LAN port of the AiMesh router to the WAN port of AiMesh node.

  • Page 63: Wireless

    4.2 Wireless 4.2.1 General The General tab allows you to configure the basic wireless settings. To configure the basic wireless settings: 1. From the navigation panel, go to Advanced Settings > Wireless > General tab. 2. Select 2.4GHz or 5GHz as the frequency band for your wireless network.
  • Page 64 4. Assign a unique name containing up to 32 characters for your SSID (Service Set Identifier) or network name to identify your wireless network. Wi-Fi devices can identify and connect to the wireless network via your assigned SSID. The SSIDs on the information banner are updated once new SSIDs are saved to the settings.

  • Page 65: Wps

    4.2.2 WPS WPS (Wi-Fi Protected Setup) is a wireless security standard that allows you to easily connect devices to a wireless network. You can configure the WPS function via the PIN code or WPS button. NOTE: Ensure that the devices support WPS. To enable WPS on your wireless network: 1.
  • Page 66 4. In the WPS Method field, select Push Button or Client PIN code. If you select Push Button, go to step 5. If you select Client PIN code, go to step 6. 5. To set up WPS using the router’s WPS button, follow these steps: a.

  • Page 67: Bridge

    ASUS wireless router. It can also be considered as a wireless repeater where your ASUS wireless router communicates with another access point and other wireless devices.
  • Page 68 • HYBRID: Enables the Wireless Bridge feature and allows other wireless devices/stations to connect to the router. NOTE: In Hybrid mode, wireless devices connected to the ASUS wireless router will only receive half the connection speed of the Access Point.

  • Page 69: Wireless Mac Filter

    4.2.4 Wireless MAC Filter Wireless MAC filter provides control over packets transmitted to a specified MAC (Media Access Control) address on your wireless network. To set up the Wireless MAC filter: 1. From the navigation panel, go to Advanced Settings > Wireless >...

  • Page 70: Radius Setting

    4.2.5 RADIUS Setting RADIUS (Remote Authentication Dial In User Service) Setting provides an extra layer of security when you choose WPA- Enterprise, WPA2-Enterprise, or Radius with 802.1x as your Authentication Mode. To set up wireless RADIUS settings: 1. Ensure that the wireless router’s authentication mode is set to WPA-Enterprise or WPA2-Enterprise.

  • Page 71: Professional

    4.2.6 Professional The Professional screen provides advanced configuration options. NOTE: We recommend that you use the default values on this page. In the Professional Settings screen, you can configure the following: • Frequency: Select the frequency band that the professional settings will be applied to.
  • Page 72 • Time of Day to Enable Radio: You can specify a time range when wireless networking is enabled during the weekend. • Set AP isolated: The Set AP isolated item prevents wireless devices on your network from communicating with each other.
  • Page 73 three milliseconds. • Beacon Interval: Beacon Interval is the time between one DTIM and the next. The default value is 100 milliseconds. Lower the Beacon Interval value for an unstable wireless connection or for roaming devices. • Enable TX Bursting: Enable TX Bursting improves transmission speed between the wireless router and 802.11g devices.

  • Page 74: Creating A Guest Network

    4.3 Creating a Guest Network The Guest Network provides temporary visitors with Internet connectivity via access to separate SSIDs or networks without providing access to your private network. NOTE: GT-AC2900 supports up to six SSIDs (three 2.4GHz, and three 5GHz). To create a guest network: 1.
  • Page 75 6. Select an Authentication Method. 7. If you select a WPA authentication method, select a WPA Encryption. 8. Specify the Access time or choose Limitless. 9. Select Disable or Enable on the Access Intranet item. 10. When done, click Apply.

  • Page 76: Lan

    4.4 LAN 4.4.1 LAN IP The LAN IP screen allows you to modify the LAN IP settings of your wireless router. NOTE: Any changes to the LAN IP address will be reflected on your DHCP settings. To modify the LAN IP settings: 1.

  • Page 77: Dhcp Server

    4.4.2 DHCP Server Your wireless router uses DHCP to assign IP addresses automatically on your network. You can specify the IP address range and lease time for the clients on your network. To configure the DHCP server: 1. From the navigation panel, go to Advanced Settings > LAN > DHCP Server tab.
  • Page 78 6. In the Lease Time field, specify in seconds when an assigned IP address will expire. Once it reaches this time limit, the DHCP server will then assign a new IP address. NOTES: • We recommend that you use an IP address format of 192.168.1.xxx (where xxx can be any number between 2 and 254) when specifying an IP address range.

  • Page 79: Route

    4.4.3 Route If your network makes use of more than one wireless router, you can configure a routing table to share the same Internet service. NOTE: We recommend that you do not change the default route settings unless you have advanced knowledge of routing tables. To configure the LAN Routing table: 1.

  • Page 80: Iptv

    4.4.4 IPTV The wireless router supports connection to IPTV services through an ISP or a LAN. The IPTV tab provides the configuration settings needed to set up IPTV, VoIP, multicasting, and UDP for your service. Contact your ISP for specific information regarding your service.

  • Page 81: Wan

    4.5 WAN 4.5.1 Internet Connection The Internet Connection screen allows you to configure the settings of various WAN connection types. To configure the WAN connection settings: 1. From the navigation panel, go to Advanced Settings > WAN > Internet Connection tab. 2.
  • Page 82 • Enable WAN: Select Yes to allow the router Internet access. Select No to disable Internet access. • Enable NAT: NAT (Network Address Translation) is a system where one public IP (WAN IP) is used to provide Internet access to network clients with a private IP address in a LAN. The private IP address of each network client is saved in a NAT table and is used to route incoming data packets.
  • Page 83 To avoid connection issues due to an unregistered MAC address, you can: • Contact your ISP and update the MAC address associated with your ISP service. • Clone or change the MAC address of the ASUS wireless router to match the MAC address of the previous networking device recognized by the ISP. • DHCP query frequency: Changes the DHCP Discovery...

  • Page 84: Dual Wan

    4.5.2 Dual WAN Your ASUS wireless router provides dual WAN support. You can set the dual WAN feature to any of these two modes: • Failover Mode: Select this mode to use the secondary WAN as the backup network access.

  • Page 85: Port Trigger

    4.5.3 Port Trigger Port range triggering opens a predetermined incoming port for a limited period of time whenever a client on the local area network makes an outgoing connection to a specified port. Port triggering is used in the following scenarios: • More than one local client needs port forwarding for the same application at a different time.
  • Page 86 4. On the Trigger Port List table, key in the following information: • Description: Enter a short name or description for the service. • Trigger Port: Specify a trigger port to open the incoming port. • Protocol: Select the protocol, TCP, or UDP. •...

  • Page 87: Virtual Server/Port Forwarding

    4.5.4 Virtual Server/Port Forwarding Port forwarding is a method to direct network traffic from the Internet to a specific port or a specific range of ports to a device or number of devices on your local network. Setting up Port Forwarding on your router allows PCs outside the network to access specific services provided by a PC in your network.
  • Page 88 5. On the Port Forwarding List table, key in the following information: • Service Name: Enter a service name. • Port Range: If you want to specify a Port Range for clients on the same network, enter the Service Name, the Port Range (e.g.
  • Page 89 • You will need a client outside your LAN but has Internet access (referred to as “Internet client”). This client should not be connected to the ASUS router. • On the Internet client, use the router’s WAN IP to access the server.

  • Page 90: Dmz

    4.5.5 DMZ Virtual DMZ exposes one client to the Internet, allowing this client to receive all inbound packets directed to your Local Area Network. Inbound traffic from the Internet is usually discarded and routed to a specific client only if port forwarding or a port trigger has been configured on the network.

  • Page 91: Ddns

    DNS name rather than WAN IP address. • Server and Host Name: Choose ASUS DDNS or other DDNS. If you want to use ASUS DDNS, fill in the Host Name in the format of xxx.asuscomm.com (xxx is your host name).

  • Page 92: Nat Passthrough

    4.5.7 NAT Passthrough NAT Passthrough allows a Virtual Private Network (VPN) connection to pass through the router to the network clients. PPTP Passthrough, L2TP Passthrough, IPsec Passthrough and RTSP Passthrough are enabled by default. To enable / disable the NAT Passthrough settings, go to the Advanced Settings >...

  • Page 93: Using The Usb Application

    USB hard disk or USB flash drive, in the USB 2.0 port on the rear panel of your wireless router. Ensure that the USB storage device is formatted and partitioned properly. Refer to the ASUS website at http://event.asus.com/2009/networks/disksupport/ for the file system support table.

  • Page 94: Using Aidisk

    4.6.1 Using AiDisk AiDisk allows you to share files stored on a connected USB device through the Internet. AiDisk also assists you with setting up ASUS DDNS and an FTP server. To use AiDisk: 1. From the navigation panel, go to Advanced Settings > USB application, then click the AiDisk icon.
  • Page 95 4. Create your domain name via the ASUS DDNS services, read the Terms of Service and then select I will use the service and accept the Terms of service and key in your domain name. When done, click Next. You can also select Skip ASUS DDNS settings and then click Next to skip the DDNS setting.

  • Page 96: Using Servers Center

    4.6.2 Using Servers Center Servers Center allows you to share the media files from the USB disk via a Media Server directory, Samba share service, or FTP share service. You can also configure other settings for the USB disk in the Servers Center. Using Media Server Your wireless router allows DLNA-supported devices to access multimedia files from the USB disk connected to your wireless...
  • Page 97 • Media Server Status: Displays the status of the media server. • Media Server Path Setting: Select All Disks Shared or Manual Media Server Path. Using Network Place (Samba) Share service Network Place (Samba) Share allows you to set up the accounts and permissions for the Samba service.
  • Page 98 2. Follow the steps below to add, delete, or modify an account. To create a new account: a) Click to add new account. b) In the Account and Password fields, key in the name and password of your network client. Retype the password to confirm.
  • Page 99 3. From the list of folders, select the type of access permission that you want to assign for specific folders: • R/W: Select this option to assign read/write access. • R: Select this option to assign read-only access. • No: Select this option if you do not want to share a specific file folder.
  • Page 100 To use FTP Share service: Ensure that you have set up your FTP server through NOTE: AiDisk. For more details, refer to the section 4.6.1 Using AiDisk. 1. From the navigation panel, click Advanced Settings > USB application > Media Services and Servers > FTP Share tab. 2.
  • Page 101 3G/4G USB modems can be connected to the router to allow Internet access. NOTE: For a list of verified USB modems, please visit: http://event.asus.com/2009/networks/3gsupport/ To set up 3G/4G internet access: 1. From the navigation panel, click Advanced Settings > USB application >...

  • Page 102: Using Aicloud 2.0

    To use AiCloud 2.0: 1. From Google Play Store or Apple Store, download and install the ASUS AiCloud app to your smart device. 2. Connect your smart device to your network. Follow the instructions to complete the AiCloud setup process.

  • Page 103: Cloud Disk

    1. Insert a USB storage device into the wireless router. 2. Turn on Cloud Disk. 3. Go to https://router.asus.com and enter the router login account and password. For better user experience, we recommend that you use Google Chrome or Firefox.
  • Page 104 4. You can now start accessing Cloud Disk files on devices connected to the network. NOTE: When accessing the devices that are connected to the network, you need to enter the device’s user name and password manually, which will not be saved by AiCloud for security reason.

  • Page 105: Smart Access

    4.7.2 Smart Access The Smart Access function allows you to easily access your home network via your router’s domain name. NOTES: • You can create a domain name for your router with ASUS DDNS. For more details, refer to section 4.5.6 DDNS. • By default, AiCloud provides a secure HTTPS connection. Key in https://[yourASUSDDNSname].asuscomm.com for a very secure Cloud Disk and Smart Access usage.

  • Page 106: Aicloud Sync

    1. Launch AiCloud, click AiCloud Sync > Go. 2. Select ON to enable AiCloud Sync. 3. Click Add new account. 4. Enter your ASUS WebStorage account password and select the directory that you want to sync with WebStorage. 5. Click Apply.

  • Page 107: Ipv6

    4.8 IPv6 This wireless router supports IPv6 addressing, a system that supports more IP addresses. This standard is not yet widely available. Contact your ISP if your Internet service supports IPv6. To set up IPv6: 1. From the navigation panel, go to Advanced Settings > IPv6. 2.

  • Page 108: Firewall

    4.9 Firewall The wireless router can serve as a hardware firewall for your network. NOTE: The Firewall feature is enabled by default. 4.9.1 General To set up basic Firewall settings: 1. From the navigation panel, go to Advanced Settings > Firewall >...

  • Page 109: Keyword Filter

    4.9.3 Keyword filter Keyword filter blocks access to webpages containing specified keywords. To set up a keyword filter: 1. From the navigation panel, go to Advanced Settings > Firewall > Keyword Filter tab. 2. On the Enable Keyword Filter field, select Enabled. 3.

  • Page 110: Network Services Filter

    4.9.4 Network Services Filter The Network Services Filter blocks LAN to WAN packet exchanges and restricts network clients from accessing specific web services such as Telnet or FTP. To set up a Network Service filter: 1. From the navigation panel, go to Advanced Settings > Firewall >...

  • Page 111: Administration

    In this mode, the firewall, IP sharing, and NAT functions are disabled. • AiMesh mode: This setup requires at least two ASUS routers which support AiMesh. Enable AiMesh node, and log in...

  • Page 112: System

    AiMesh router web UI to search for available AiMesh nodes nearby to join your AiMesh system. AiMesh system provides whole-home coverage and centralized management. 3. Click Apply. NOTE: The router will reboot when you change the modes. 4.10.2 System The System page allows you to configure your wireless router settings.

  • Page 113: Firmware Upgrade

    4.10.3 Firmware Upgrade NOTE: Download the latest firmware from the ASUS website at http://www.asus.com To upgrade the firmware: 1. From the navigation panel, go to Advanced Settings > Administration > Firmware Upgrade tab. 2. In the New Firmware File field, click Browse to locate the downloaded file.

  • Page 114: System Log

    4.11 System Log System Log contains your recorded network activities. NOTE: System log resets when the router is rebooted or powered off. To view your system log: 1. From the navigation panel, go to Advanced Settings > System Log. 2. You can view your network activities in any of these tabs: • General Log • DHCP Leases • Wireless Log...

  • Page 115: Smart Connect

    • Via the Wireless screen 1. On your web browser, manually key in the wireless router’s default IP address: http://router.asus.com. 2. On the login page, key in the default user name (admin) and password (admin) and click OK. The QIS page launches automatically.

  • Page 116: Smart Connect Rule

    4.12.2 Smart Connect Rule ASUSWRT provides default condition settings to trigger switching mechanism. You can also change the trigger conditions according to your networking surroundings. To change the settings, go to the Smart Connect Rule tab on the Network Tools screen. Smart Connect Rule controls are divided into four sections: • Steering Trigger Condition • STA Selection Policy...
  • Page 117 Steering Trigger Condition This set of controls sets the criteria to initiate band steering. • Bandwidth Utilization When bandwidth use exceeds this percentage, steering will be initiated. • Enable Load Balance This controls load balancing. • RSSI If the received signal level of any associated client meets this criteria, steering will be triggered.
  • Page 118 STA Selection Policy Once steering has been triggered, ASUSWRT will follow the STA Selection Policy to select a client(STA) that is going to be steered to the most appropriate band. Interface Select and Qualify Procedures These controls determine where the steered client will end up. The Target Band controls specify first and second choice of steering targets.

  • Page 119: Utilities

    ASUS/LiveUpdate/Release/Wireless/Rescue.zip • Windows Printer Utility v1.0.5.5 at http://dlcdnet.asus.com/pub/ ASUS/LiveUpdate/Release/Wireless/Printer.zip • The utilities are not supported on MAC OS. 5.1 Device Discovery Device Discovery is an ASUS WLAN utility that detects an ASUS wireless router device, and allows you to configure the wireless networking settings. To launch the Device Discovery utility: • From your computer’s desktop, click Start >...

  • Page 120: Firmware Restoration

    5.2 Firmware Restoration Firmware Restoration is used on an ASUS Wireless Router that failed during its firmware upgrading process. It uploads the firmware that you specify. The process takes about three to four minutes. IMPORTANT: Launch the rescue mode on the router before using the Firmware Restoration utility.

  • Page 121: Setting Up Your Printer Server

    5.3 Setting up your printer server 5.3.1 ASUS EZ Printer Sharing ASUS EZ Printing Sharing utility allows you to connect a USB printer to your wireless router’s USB port and set up the print server. This allows your network clients to print and scan files...
  • Page 122 NOTE: The print server function is supported on Windows® 7/8/8.1/10. To set up the EZ Printer sharing mode: 1. From the navigation panel, go to Advanced Settings > USB Application > Network Printer Server. 2. Click Download Now! to download the network printer utility. NOTE: Network printer utility is supported on Windows®...
  • Page 123 4. Follow the onscreen instructions to set up your hardware, then click Next. 5. Wait a few minutes for the initial setup to finish. Click Next. 6. Click Finish to complete the installation. 7. Follow the Windows OS instructions to install the printer ®...
  • Page 124 8. After the printer’s driver installation is complete, network clients can now use the printer.

  • Page 125: Using Lpr To Share Printer

    5.3.2 Using LPR to Share Printer You can share your printer with computers running on Windows® and MAC operating system using LPR/LPD (Line Printer Remote/ Line Printer Daemon). Sharing your LPR printer To share your LPR printer: 1. From the Windows® desktop, click Start > Devices and Printers >...
  • Page 126 3. Select Create a new port then set Type of Port to Standard TCP/IP Port. Click New Port. 4. In the Hostname or IP address field, key in the IP address of the wireless router then click Next.
  • Page 127 5. Select Custom then click Settings. 6. Set Protocol to LPR. In the Queue Name field, key in LPRServer then click OK to continue.
  • Page 128 7. Click Next to finish setting up the standard TCP/IP port. 8. Install the printer driver from the vendor-model list. If your printer is not in the list, click Have Disk to manually install the printer drivers from a CD-ROM or file.
  • Page 129 9. Click Next to accept the default name for the printer. 10. Click Finish to complete the installation.

  • Page 130: Download Master

    5.4 Download Master Download Master is a utility that helps you download files even while your laptops or other devices are switched off. NOTE: You need a USB device connected to the wireless router to use Download Master. To use Download Master: 1.

  • Page 131: Configuring Bit Torrent Download Settings

    5. Use the navigation panel to configure the advanced settings. 5.4.1 Configuring Bit Torrent download settings To configure BitTorrent download settings: 1. From Download Master’s navigation panel, click Bit Torrent to launch the Bit Torrent Setting page. 2. Select a specific port for your download task. 3.

  • Page 132: Nzb Settings

    5.4.2 NZB settings You can set up a USENET server to download NZB files. After entering USENET settings, Apply.

  • Page 133: Troubleshooting

    1. Launch the Web GUI. Go to Advanced Settings > Administration > Firmware Upgrade tab. Click Check to verify if the latest firmware is available. 2. If the latest firmware is available, visit the ASUS global website at https://www.asus.com/Networking/ROG-Rapture-GT- AC2900/HelpDesk_BIOS/ to download the latest firmware.
  • Page 134 Check if your network settings are correct. • Each client on the network should have a valid IP address. ASUS recommends that you use the wireless router’s DHCP server to assign IP addresses to computers on your network. • Some cable modem service providers require you to use the MAC address of the computer initially registered on the account.

  • Page 135: Frequently Asked Questions (Faqs)

    6.2 Frequently Asked Questions (FAQs) I cannot access the router GUI using a web browser • If your computer is wired, check the Ethernet cable connection and LED status as described in the previous section. • Ensure that you are using the correct login information. The default factory login name and password is “admin/admin”. Ensure that the Caps Lock key is disabled when you enter the login information.
  • Page 136 The client cannot establish a wireless connection with the router. NOTE: If you are having issues connecting to 5GHz network, make sure that your wireless device supports 5GHz or features dual band capabilities. • Out of Range: • Move the router closer to the wireless client. • T ry to adjust antennas of the router to the best direction as described in section 1.5 Positioning your router.
  • Page 137 • SSID has been hidden. If your device can find SSIDs from other routers but cannot find your router’s SSID, go to Advanced Settings > Wireless > General, select No on Hide SSID, and select Auto on Control Channel. • If you are using a wireless LAN adapter, check if the wireless channel in use conforms to the channels available in your country/area.
  • Page 138 Internet is not accessible. • Check if your router can connect to your ISP’s WAN IP address. To do this, launch the web GUI and go to Advanced Settings> Network Map, and check the Internet Status. • If your router cannot connect to your ISP’s WAN IP address, try restarting your network as described in the section Restart your network in following sequence under Basic Troubleshooting.
  • Page 139 The following are the factory default settings: User Name: admin Password: admin Enable DHCP: Yes (if WAN cable is plugged in) IP address: http://router.asus.com (or 192.168.1.1) Domain Name: (Blank) Subnet Mask: 255.255.255.0 DNS Server 1: 192.168.1.1 DNS Server 2: (Blank) SSID (2.4GHz):...
  • Page 140 Cannot access Web GUI Before configuring your wireless router, do the steps described in this section for your host computer and network clients. Disable the proxy server, if enabled. Windows ® 1. Click Start > Internet Explorer to launch the browser. 2.
  • Page 141 MAC OS 1. From your Safari browser, click Safari > Preferences > Advanced > Change Settings... 2. From the Network screen, deselect FTP Proxy and Web Proxy (HTTP). 3. Cllick Apply Now when done. NOTE: Refer to your browser's help feature for details on disabling the proxy server.
  • Page 142 3. To obtain the IPv4 IP settings automatically, tick Obtain an IP address automatically. To obtain the IPv6 IP settings automatically, tick Obtain an IPv6 address automatically. 4. Click OK when done. MAC OS 1. Click the Apple icon located on the top left of your screen.
  • Page 143 Disable the dial-up connection, if enabled. Windows ® 1. Click Start > Internet Explorer to launch the browser. 2. Click Tools > Internet options > Connections tab. 3. Tick Never dial a connection. 4. Click OK when done. NOTE: Refer to your browser's help feature for details on disabling the dial-up connection.

  • Page 144: Appendices

    Notices ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components, as well as the packaging materials.
  • Page 145 IMPORTANT NOTE: Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. To maintain compliance with FCC exposure compliance requirement, please follow operation instruction as documented in this manual.
  • Page 146 • N E PAS utiliser de cordons d'alimentation, d'accessoires ou autres périphériques endommagés. • S i l'adaptateur est endommagé, n'essayez pas de le réparer vous-même. Contactez un technicien électrique qualifié ou votre revendeur. • P our éviter tout risque de choc électrique, débranchez le câble d'alimentation de la prise électrique avant de toucher au système. Radiation Exposure Statement Déclaration d'exposition aux radiations This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 31cm between the radiator &...
  • Page 147 Port Gain (dBi) 5GHz 5GHz 5GHz 5GHz 5GHz 5GHz Set Ant. Brand Type Connector B1/B2 B1/B2 WHA YU C660-510413-A Dipole Reverse SMA Plug 1.9 - WHA YU C660-510413-A Dipole Reverse SMA Plug 1.9 - WHA YU C660-510413-A Dipole Reverse SMA Plug 1.9 - WHA YU C660-510413-A Dipole Reverse SMA Plug 1.9 - WHA YU C660-510413-A Dipole Reverse SMA Plug - WHA YU C660-510413-A Dipole Reverse SMA Plug -...
  • Page 148 IMPORTANT NOTE: IC Radiation Exposure Statement: This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 31cm between the radiator & your body. Cet équipement est conforme aux limites d’exposition aux rayonnements IC établies pour un environnement non contrôlé.
  • Page 149 NCC 警語 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變 更頻率、加大功率或變更原設計之特性及功能。 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時， 應立即停用，並改善至無干擾時方得繼續使用。 前項合法通信，指依電信法規定作業之無線電通信。 低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干 擾。 產品之限用物質含有情況」之相關資訊，請參考下表： 「 限用物質及其化學符號 單元 鉛 汞 鎘 六價鉻 多溴聯苯 多溴二苯醚 (Pb) (Hg) (Cd) （PBB) （PBDE) ○ ○ ○ ○ ○ 印刷電路板及電子組件 結構組件（金屬 / 塑膠） ○ ○ ○ ○ ○ ○ ○ ○...
  • Page 150 電子電氣產品有害物質限制使用標識要求：圖中之數字為產品之環保使 用期限。僅指電子電氣產品中含有的有害物質不致發生外洩或突變從而 對環境造成污染或對人身、財產造成嚴重損害的期限。 产品中有害物质的名称及含量 有害物質 部件名稱 鉛 六價鉻 多溴聯苯 多溴二苯醚 汞(Hg) 鎘(Cd) (Pb) (Cr(VI)) (PBB) (PBDE) 印刷電路板及其電子組件 × ○ ○ ○ ○ ○ 外殼 ○ ○ ○ ○ ○ ○ 電源適配器 × ○ ○ ○ ○ ○ 外部信號連接頭及線材 × ○ ○...
  • Page 151 ASUS products in order to reduce the risk of interference. c. Kindly use ASUS products in good reception conditions in order to minimize the radiation’s level. d. Keep the device away from pregnant women and the lower abdomen of the teenager.
  • Page 152 India RoHS This product complies with the "India E-Waste (Management) Rules, 2016" and prohibits use of lead, mercury, hexavalent chromium, polybrominated biphenyls(PBBs) and polybrominated diphenyl ethers (PBDEs) in concentrations exceeding 0.1 % by weight in homogenous materials and 0.01 % by weight in homogenous materials for cadmium, except for the exemptions listed in Schedule II of the Rule.
  • Page 153 Ülkeler simgeler halinde kutu üzerinde belirtilmiştir. Manufacturer ASUSTeK Computer Inc. Tel: +886-2-2894-3447 Address: 4F, No. 150, LI-TE RD., PEITOU, TAIPEI 112, TAIWAN Authorised ASUS Computer GmbH representative in Address: HARKORT STR. 21-23, 40880 RATINGEN, Europe GERMANY Authorised BOGAZICI BILGISAYAR TICARET VE SANAYI A.S.

  • Page 154: Asus Contact Information

    Online support https://www.asus.com/support ASUS COMPUTER INTERNATIONAL (America) Address 4 8720 Kato Rd., Fremont, CA 94538, Telephone +15107393777 Fax +15106084555 Website usa.asus.com Online support https://www.asus.com/support ASUS COMPUTER GmbH (Germany and Austria) Address H arkort Str. 21-23, D-40880 Ratingen, Germany Support Fax +49-2102-959931 Website asus.com/de Online contact eu-rma.asus.com/sales Technical Support Telephone (Component) +49-2102-5789555 Telephone Germany...
  • Page 155 ASUSTek Computer Inc. hereby declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. Full text of EU declaration of conformity is available at https://www.asus.com/Networking/ROG-Rapture-GT-AC2900/HelpDesk_Declaration/. Declaration of Conformity for Ecodesign directive 2009/125/EC Testing for eco-design requirements according to (EC) No 1275/2008 and (EU) No 801/2013 has been conducted.
  • Page 156 Bulgarian CE statement Опростена декларация за съответствие на ЕС С настоящото ASUSTeK Computer Inc. декларира, че това устройство е в съответствие със съществените изисквания и другите приложими постановления на Директива 2014/53/EC. Пълният текст на декларацията за съответствие на ЕС е достъпен на адрес https://www.asus.com/Networking/ ROG-Rapture-GT-AC2900/HelpDesk_Declaration/. Декларация за съответствие за Директива за екодизайна 2009/125/ЕО Проведени са тестове за съвместимост с изискванията за екодизайн съгласно (ЕО) No. 1275/2008 и (ЕС) No. 801/2013. Когато устройството е в Networked Standby Mode (Режим на готовност на мрежа), I/O и мрежовият интерфейс са в спящ режим и може да не работят както трябва. За да събудите устройството, натиснете Wi-Fi on/off (Wi-Fi вкл./изкл.), LED on/off (LED вкл./изкл.), reset (нулиране) или бутона WPS. Това устройство е в съответствие с границите за радиочестотно облъчване, установени от ЕС за...
  • Page 157 CE statement Pojednostavljena EU Izjava o sukladnosti ASUSTek Computer Inc. ovime izjavljuje da je uređaj sukladan s osnovnim zahtjevima i ostalim važnim odredbama direktive 2014/53/EU. Cijeli tekst EU izjave o sukladnosti dostupan je na https://www.asus. com/Networking/ROG-Rapture-GT-AC2900/HelpDesk_Declaration/. Izjava o sukladnosti za direktivu o ekodizajnu 2009/125/EZ Provedeno je testiranje zahtjeva na ekodizajn u skladu s (EC) No 1275/2008 i (EU) No 801/2013. Kada je uređaj u umreženom načinu mirovanja, njegovi ulazi/izlazi i mrežno sučelje su također u načinu mirovanja...
  • Page 158 Czech CE statement Zjednodušené prohlášení o shodě s EU Společnost ASUSTek Computer Inc. tímto prohlašuje, že toto zařízení splňuje základní požadavky a další příslušná ustanovení směrnice 2014/53/EU. Plné znění prohlášení o shodě EU je k dispozici na adrese https://www.asus.com/Networking/ROG-Rapture-GT-AC2900/HelpDesk_Declaration/. Prohlášení o shodě se směrnicí o ekodesignu 2009/125/ES Bylo provedeno testování požadavků na ekodesign podle směrnic (ES) č. 1275/2008 a (EU) č. 801/2013. Když se toto zařízení nachází v pohotovostním síťovém režimu, jeho vstupy/výstupy a síťové rozhraní jsou v režimu spánku a nemusí fungovat správně. Zařízení lze probudit vypínačem Wi-Fi, vypínačem LED, resetovacím tlačítkem nebo tlačítkem WPS. Toto zařízení vyhovuje limitům EU pro vystavení vyzařování stanoveným pro neřízené prostředí. Toto zařízení musí být nainstalováno a provozováno v minimální vzdálenosti 20 cm mezi zářičem a vaším tělem. Všechny provozní režimy: 2.4GHz: 802.11b, 802.11g, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40) 5GHz: 802.11a, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40), 802.11ac (VHT80) Níže je uvedena frekvence, režim a maximální vysílaný výkon v EU:...
  • Page 159 Estonian CE statement Lihtsustatud ELi vastavusdeklaratsioon Käesolevaga kinnitab ASUSTek Computer Inc., et see seade on vastavuses direktiivi 2014/53/EL oluliste nõuete ja teiste asjakohaste sätetega. ELi vastavusdeklaratsiooni täielik tekst on saadaval aadressil https:// www.asus.com/Networking/ROG-Rapture-GT-AC2900/HelpDesk_Declaration/. Vastavuse kinnitus ökodisaini direktiivile 2009/125/EÜ Ökodisaini erinõuetele vastavust testiti kooskõlas määruste (EÜ) nr 1275/2008 ja (EÜ) nr 801/2013 nõuetega. Kui seade on võrku ühendatud ooterežiimis, on selle I/O ja võrguliides unerežiimis ning seetõttu on võimalik, et seade ei toimi nõuetekohaselt. Seadme äratamiseks vajutage Wi-Fi on/off-nuppu, LED on/ off-nuppu, lähtestusnuppu või WPS nuppu. Käesolev seade vastab kontrollimata keskkonnale sätestatud ELi kiirgusnormidele. Antud seadme paigaldamisel ja kasutamisel tuleb arvestada, et see peab jääma radiaatorist ja teie kehast vähemalt 20 cm kaugusele. Kõik töörežiimid: 2.4GHz: 802.11b, 802.11g, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40) 5GHz: 802.11a, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40), 802.11ac (VHT80) Teave sageduse, režiimi ja maksimaalse edastatava võimsuse kohta ELis on esitatud allpool:...
  • Page 160 Hungarian CE statement Egyszerűsített EU-megfelelőségi nyilatkozat Az ASUSTek Computer Inc. ezennel kijelenti, hogy ez a készülék megfelel a 2014/53/EU irányelv alapvető követelményeinek és egyéb vonatkozó rendelkezéseinek. Az EU-megfelelőségi nyilatkozat teljes szövegét a következő weboldalon tekintheti meg: https://www.asus.com/Networking/ROG-Rapture-GT-AC2900/ HelpDesk_Declaration/. Megfelelőségi nyilatkozat a környezettudatos tervezésről szóló 2009/125/EK irányelvhez A környezettudatos tervezés követelményeit illetően tesztelést végeztünk az (EK) 1275/2008 és (EU) 801/2013 előírásai szerint. Ha a készülék hálózati készenléti üzemmódra van állítva, akkor az I/O és a hálózati csatoló alvó üzemmódba kerül, és elképzelhető, hogy nem működik megfelelően. A készülék felébresztéséhez nyomja meg a Wi-Fi vagy a LED főkapcsolóját, a reset gombot vagy a WPS gombot. Ez a berendezés megfelel az Európai Unió rádiófrekvenciás sugárzásra vonatkozó, ellenőrizetlen környezethez megállapított határértékeinek. A készülék telepítésekor és használata során legalább 20 cm távolságot kell hagyni a fűtőtest és a teste között. Minden működési üzemmód: 2.4GHz: 802.11b, 802.11g, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40) 5GHz: 802.11a, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40), 802.11ac (VHT80) Az alábbiakban megtekintheti az Európai Unióban érvényes frekvenciát, üzemmódot és maximális átviteli...
  • Page 161 Latvian CE statement Vienkāršots ES paziņojums par atbilstību Ar šo ASUSTek Computer Inc. paziņo, ka šī ierīce atbilst Direktīvas Nr. 2014/53/ES būtiskām prasībām un citiem attiecīgiem noteikumiem. Pilns ES atbilstības paziņojuma teksts ir pieejams šeit: https://www.asus. com/Networking/ROG-Rapture-GT-AC2900/HelpDesk_Declaration/. Atbilstības paziņojums ekodizaina Direktīvai Nr. 2009/125/EK Veikta ekodizaina prasību pārbaude saskaņā ar Komisijas Regulu (EK) Nr. 1275/2008 un Komisijas Regulu (ES) Nr. 801/2013. Ja ierīce ir tīkla gaidstāves režīmā, tās I/O (ievade/izvade) un tīkla interfeiss ir miega režīmā un var nedarboties pareizi. Lai aktivizētu ierīci, nospiediet pogu Wi-Fi on/off (Wi-Fi ieslēgts/izslēgts), LED on/off (LED ieslēgts/izslēgts), reset (atiestatīt) vai WPS. Šī ierīce atbilst ES radiācijas iedarbības ierobežojumiem, kas noteikti videi, kur šī iedarbība netiek kontrolēta. Šī ierīce ir jāuzstāda un jādarbina, ievērojot minimālo attālumu 20 cm starp radiatoru un ķermeni. Visi darbības režīmi: 2.4GHz: 802.11b, 802.11g, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40) 5GHz: 802.11a, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40), 802.11ac (VHT80) Frekvence, režīms un maksimālā pārraidītā jauda ES ir norādīta tālāk.
  • Page 162 Lituanian CE statement Supaprastinta ES atitikties deklaracija Šiame dokumente bendrovė „ ASUSTek Computer Inc. “ pareiškia, kad šis prietaisas atitinka pagrindinius reikalavimus ir kitas susijusias Direktyvos 2014/53/EB nuostatas. Visą ES atitikties deklaracijos tekstą rasite https://www.asus.com/Networking/ROG-Rapture-GT-AC2900/HelpDesk_Declaration/. Ekologinio projektavimo direktyvos 2009/125/EB atitikties deklaracija Atliktas ekologinio projektavimo reikalavimų pagal (EB) Nr. 1275/2008 ir (ES) Nr. 801/2013 atitikimo patikrinimas. Kai prietaisas yra prijungtas prie tinklo ir veikia budėjimo režimu, jo įjungimo / išjungimo ir tinklo sąsaja veikia miego režimu ir negali tinkamai veikti. Norėdami pažadinti prietaisą, paspauskite „ Wi- Fi“ įjungimo / išjungimo, šviesos diodo įjungimo / išjungimo, nustatymo iš naujo arba WPS mygtuką. Ši įranga atitinka ES radiacijos poveikio ribas, nustatytas nekontroliuojamai aplinkai. Šį prietaisą reikia statyti ir naudoti ten, kur jis būtų bent 20 cm atstumu nuo jūsų kūno. Visi operaciniai režimai: 2.4GHz: 802.11b, 802.11g, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40) 5GHz: 802.11a, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40), 802.11ac (VHT80)
  • Page 163 Polish CE statement Uproszczona deklaracja zgodności UE Firma ASUSTek Computer Inc. niniejszym oświadcza, że urządzenie to jest zgodne z zasadniczymi wymogami i innymi właściwymi postanowieniami dyrektywy 2014/53/UE. Pełny tekst deklaracji zgodności UE jest dostępny pod adresem https://www.asus.com/Networking/ROG-Rapture-GT-AC2900/HelpDesk_ Declaration/. Deklaracja zgodności dotycząca dyrektywy w sprawie ekoprojektu 2009/125/WE Przeprowadzono testy pod kątem wymogów dotyczących ekoprojektu zgodnie z rozporządzeniem (WE) Nr 1275/2008 i (UE) Nr 801/2013. Gdy urządzenie jest w sieciowym trybie czuwania, jego porty We/Wy oraz interfejs sieciowy również znajdują się w trybie uśpienia i mogą nie działać prawidłowo. W celu wznowienia pracy urządzenia należy nacisnąć przycisk włączania/wyłączania sieci Wi-Fi, przycisk włączania/wyłączania wskaźnika LED, przycisk resetowania lub WPS. To urządzenie jest zgodne z limitami UE dotyczącymi ekspozycji na promieniowanie ustanowionymi dla niekontrolowanego środowiska. Urządzenie to powinno być zainstalowane i używane przy zachowaniu minimalnej odległości 20 cm między radiatorem, a ciałem. Wszystkie tryby działania: 2.4GHz: 802.11b, 802.11g, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40) 5GHz: 802.11a, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40), 802.11ac (VHT80) Poniżej wskazano częstotliwość, tryb i maksymalną moc nadawania w UE:...
  • Page 164 Romanian CE statement Declarație de conformitate UE simplificată ASUSTek Computer Inc. declară că acest dispozitiv este în conformitate cu cerinţele esenţiale și cu alte prevederi relevante ale Directivei 2014/53/UE. Declaraţia de conformitate UE completă este disponibilă la adresa: https://www.asus.com/Networking/ROG-Rapture-GT-AC2900/HelpDesk_Declaration/. Declarația de conformitate pentru Directiva privind proiectarea ecologică 2009/125/CE Testarea pentru cerinţele de proiectare ecologică în conformitate cu (CE) nr. 1275/2008 și (UE) nr. 801/2013 a fost efectuată. Când dispozitivul se află în modul de standby în reţea, I/E și interfaţa de reţea se află în modul de repaus și pot să nu funcţioneze corect. Pentru a reactiva dispozitivul, apăsaţi butonul de pornire/oprire Wi-Fi, pornire/oprire LED, resetare sau butonul WPS. Acest dispozitiv se încadrează în limitele de expunere la radiaţii UE stabilite pentru un mediu necontrolat. Acest echipament trebuie instalat și operat cu distanţa minimă de 20 cm între radiator și corpul dvs. Toate modurile de funcţionare: 2.4GHz: 802.11b, 802.11g, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40) 5GHz: 802.11a, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40), 802.11ac...
  • Page 165 ASUSTek Computer Inc. ovim potvrđuje da je ovaj uređaj u saglasnosti sa ključnim zahtevima i drugim relevantnim odredbama Direktive 2014/53/EU. Pun tekst EU deklaracije o saglasnosti je dostupan na adresi https://www.asus.com/Networking/ROG-Rapture-GT-AC2900/HelpDesk_Declaration/. Deklaracija o saglasnosti za Ekodizajn direktivu 2009/125/EC Testiranje za eko-dizajn zahteve u skladu sa (EC) Br 1275/2008 i (EU) Br 801/2013 je obavljeno. Kada je ovaj uređaj u režimu za stanje pripravnosti mreže, njegov I/O i mrežni interfejs su u režimu za spavanje i možda...
  • Page 166 Slovanian CE statement Poenostavljena izjava o skladnosti EU ASUSTek Computer Inc. izjavlja, da je ta naprava skladna s temeljnimi zahtevami in drugimi relevantnimi določili Direktive 2014/53/EU. Celotno besedilo izjave EU o skladnosti je na voljo na spletnem mestu https://www.asus.com/Networking/ROG-Rapture-GT-AC2900/HelpDesk_Declaration/. Izjava o skladnosti za Direktivo o okoljsko primerni zasnovi 2009/125/ES Testiranje glede zahtev za okoljsko primerno zasnovo v skladu z (ES) št. 1275/2008 in (EU) št. 801/2013 je bilo izvedeno. Če je naprava v omrežnem načinu pripravljenosti, sta vhodno-izhodni in omrežni vmesnik v načinu spanja in morda ne bosta delovala pravilno. Če želite napravo prebuditi, pritisnite gumb za vklop/ izklop Wi-Fi, vklop/izklop LED, ponastavitev ali WPS.
  • Page 167 Slovakian CE statement Zjednodušené vyhlásenie o zhode ES Spoločnosť ASUSTek Computer Inc. týmto vyhlasuje, že toto zariadenie je v zhode s hlavnými požiadavkami a ostatnými príslušnými ustanoveniami smernice 2014/53/EÚ. Celý text vyhlásenia o zhode ES nájdete na adrese https://www.asus.com/Networking/ROG-Rapture-GT-AC2900/HelpDesk_ Declaration/. Vyhlásenie o zhode podľa smernice o ekodizajne č. 2009/125/ES Bolo vykonané testovanie na splnenie požiadaviek na ekodizajn podľa smernice (ES) č. 1275/2008 a (EÚ) č. 801/2013. Ak je zariadenie v pohotovostnom režime v rámci siete, jeho vstupné/výstupné a sieťové rozhranie sú v režime spánku a nemusia správne fungovať. Ak chcete zariadenie zobudiť, stlačte tlačidlo Zapnúť/Vypnúť Wi-Fi / Zapnúť/Vypnúť LED / Resetovanie alebo WPS. Toto zariadenie vyhovuje európskym (EÚ) limitným hodnotám pre vystavenie žiareniu stanoveným pre nekontrolované prostredie. Toto zariadenie sa má inštalovať a prevádzkovať minimálne v 20 cm vzdialenosti medzi žiaričom a telom. Všetky prevádzkové režimy: 2.4GHz: 802.11b, 802.11g, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40) 5GHz: 802.11a, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40), 802.11ac...
  • Page 168 CE statement Basitleştirilmiş AB Uygunluk Bildirimi ASUSTek Computer Inc., bu aygıtın temel gereksinimlerle ve 2014/53/EU Yönergesinin diğer ilgili koşullarıyla uyumlu olduğunu bildirir. AB uygunluk bildiriminin tam metni https://www.asus.com/ Networking/ROG-Rapture-GT-AC2900/HelpDesk_Declaration/ adresinde bulunabilir. 2009/125/EC Çevreye Duyarlı Tasarım yönergesi için Uygunluk Bildirimi (EC) No 1275/2008 ve (EU) No 801/2013 uyarınca çevreye duyarlı tasarım gereksinimlerine yönelik test işlemi gerçekleştirilmiştir.
  • Page 169 Danish CE statement Forenklet EU-overensstemmelseserklæringen ASUSTek Computer Inc. erklærer herved, at denne enhed er i overensstemmelse med hovedkravene og øvrige relevante bestemmelser i direktiv 2014/53/EU. Hele EU-overensstemmelseserklæringen kan findes på https://www.asus.com/Networking/ROG-Rapture-GT-AC2900/HelpDesk_Declaration/. Overensstemmelseserklæring for miljøvenligt design i direktiv 2009/125/EC Vedrørende testkrav af øko-design i henhold til (EC) nr. 1275/2008 og (EU) nr. 801/2013 er blevet gennemført. Når enheden er på netværk-standby, er dens I/O og netværksgrænseflade i dvale, og vil muligvis ikke virke ordentligt. For at aktivere enheden, skal du trykke på trådløs til/fra, LED til/fra, nulstil eller WPS-knappen. Dette udstyr er i overensstemmelse med EU's grænser, der er gældende i et ukontrolleret miljø. Dette udstyr skal installeres og bruges mindst 20 cm mellem radiatoren og din krop. Alle driftsfunktioner: 2.4GHz: 802.11b, 802.11g, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40) 5GHz: 802.11a, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40), 802.11ac (VHT80)
  • Page 170 ASUSTek Computer Inc. verklaart dat dit apparaat in overeenstemming is met de essentiële vereisten en andere relevante bepalingen van Richtlijn 2014/53/EU. Volledige tekst EU-conformiteitsverklaring is beschikbaar op https://www.asus.com/Networking/ROG-Rapture-GT-AC2900/HelpDesk_Declaration/. Conformiteitsverklaring voor Ecodesign Richtlijn 2009/125/EG Testen van vereisten van ecodesign overeenkomstig (EG) nr. 1275/2008 en (EU) nr. 801/2013 zijn uitgevoerd.
  • Page 171 French CE statement Déclaration simplifiée de conformité de l’UE ASUSTek Computer Inc. déclare par la présente que cet appareil est conforme aux critères essentiels et autres clauses pertinentes de la directive 2014/53/UE. La déclaration de conformité de l'UE peut être téléchargée à partir du site internet suivant: https://www.asus. com/Networking/ROG-Rapture-GT-AC2900/HelpDesk_Declaration/. Déclaration de conformité (Directive sur l'écoconception 2009/125/CE) Test de la conformité aux exigences d'écoconception selon [CE 1275/2008] et [UE 801/2013]. Lorsque l'appareil est en mode Networked Standby, son panneau d'E/S et son interface réseau sont en mode veille et peuvent ne pas fonctionner correctement. Pour sortir l'appareil du mode veille, appuyez sur le bouton Wi-Fi, LED, de réinitialisation ou WPS. Cet appareil a été testé et s'est avéré conforme aux limites établies par l'UE en terme d'exposition aux radiations dans un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de distance entre la source de rayonnement et votre corps.
  • Page 172 Finnish CE statement Yksinkertaistettu EU-vaatimustenmukaisuusvakuutus ASUSTek Computer Inc. vakuuttaa täten, että tämä laite on 2014/53/EU-direktiivin olennaisten vaatimusten ja muiden asiaan kuuluvien lisäysten mukainen. Koko EU-vaatimustenmukaisuusvakuutuksen teksti on nähtävissä osoitteessa https://www.asus.com/Networking/ROG-Rapture-GT-AC2900/HelpDesk_ Declaration/. Ekologisen suunnittelun direktiivin 2009/125/EY-vaatimustenmukaisuusvakuutus Testaus (EY) N:o 1275/2008:n ja (EU) N:o 801/2013:n mukaisista ekologisista suunnitteluvaatimuksista on suoritettu. Kun laite on verkossa valmiustilassa, sen I/O- ja verkkoliittymä ovat lepotilassa eivätkä ne ehkä toimi oikein. Herättääksesi laitteen, paina Wi-Fi päälle/pois -, LED päälle/pois -, nollaa- tai WPS-painiketta. Tämä laite täyttää EU-säteilyrajoitukset, jotka on asetettu hallitsemattomaan ympäristöön. Tämä laitteisto tulee asentaa ja sitä tulee käyttää siten, että säteilijän ja kehosi välinen etäisyys on vähintään 20 cm. Kaikki käyttötilat: 2.4GHz: 802.11b, 802.11g, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40) 5GHz: 802.11a, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40), 802.11ac (VHT80)
  • Page 173 German CE statement Vereinfachte EU-Konformitätserklärung ASUSTeK Computer Inc. erklärt hiermit, dass dieses Gerät mit den grundlegenden Anforderungen und anderen relevanten Bestimmungen der Richtlinie 2014/53/EU übereinstimmt. Der gesamte Text der EU-Konformitätserklärung ist verfügbar unter: https://www.asus.com/Networking/ROG- Rapture-GT-AC2900/HelpDesk_Declaration/. Konformitätserklärung für Ökodesign-Richtlinie 2009/125/EC Die Überprüfung der Ökodesign-Anforderungen nach (EC) Nr. 1275/2008 und (EU) Nr. 801/2013 wurde durchgeführt. Wenn sich das Gerät im Netzwerkbereitschaftsmodus befindet, werden die E/A- und Netzwerkschnittstellen in den Ruhezustand versetzt und arbeiten nicht wie gewöhnlich. Um das Gerät aufzuwecken, drücken Sie die WLAN Ein/Aus-, LED Ein/Aus-, Reset- oder WPS-Taste.
  • Page 174 Greek CE statement Απλουστευμένη δήλωση συμμόρφωσης της ΕΕ Με το παρόν, η ASUSTek Computer Inc. δηλώνει πως αυτή η συσκευή συμμορφώνεται με τις θεμελιώδεις απαιτήσεις και άλλες σχετικές διατάξεις της Οδηγίας 2014/53/ΕΕ. Το πλήρες κείμενο της δήλωσης συμμόρφωσης της ΕΕ είναι διαθέσιμο στη διεύθυνση https://www.asus.com/Networking/ROG-Rapture- GT-AC2900/HelpDesk_Declaration/. Δήλωση συμμόρφωσης για την οδηγία Ecodesign (Οικολογικός σχεδιασμός) 2009/125/ΕΚ Έχει διενεργηθεί δοκιμή για τις απαιτήσεις οικολογικού σχεδιασμού σύμφωνα με τους κανονισμούς (ΕΚ) αριθ. 1275/2008 και (ΕΕ) αριθ. 801/2013. Όταν η συσκευή βρίσκεται σε λειτουργία Αναμονή δικτύου, η διασύνδεση I/O και δικτύου βρίσκονται σε κατάσταση αναμονής και ενδέχεται να μην λειτουργούν σωστά. Για να ενεργοποιήσετε τη συσκευή, πατήστε το πλήκτρο ενεργοποίησης/απενεργοποίησης Wi-Fi, ενεργοποίησης/απενεργοποίησης λυχνίας LED, επαναφοράς ή το πλήκτρο WPS. Ο παρόν εξοπλισμός συμμορφώνεται με τα όρια έκθεσης σε ακτινοβολία της ΕΕ που έχουν διατυπωθεί για μη ελεγχόμενο περιβάλλον. Ο συγκεκριμένος εξοπλισμός πρέπει να εγκατασταθεί και να λειτουργεί με ελάχιστη απόσταση 20 εκ μεταξύ της συσκευής ακτινοβολίας και του σώματός σας. Όλοι οι τρόποι λειτουργίας: 2.4GHz: 802.11b, 802.11g, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40) 5GHz: 802.11a, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40), 802.11ac...
  • Page 175 Dichiarazione di conformità UE semplificata ASUSTek Computer Inc. con la presente dichiara che questo dispositivo è conforme ai requisiti essenziali e alle altre disposizioni pertinenti con la direttiva 2014/53/EU. Il testo completo della dichiarazione di conformità UE è disponibile all'indirizzo https://www.asus.com/Networking/ROG-Rapture-GT-AC2900/ HelpDesk_Declaration/. Dichiarazione di conformità con la direttiva Ecodesign 2009/125/EC I test per i requisiti eco-design (EC) N. 1275/2008 e (EU) N. 801/2013 sono stati eseguiti. Quando il dispositivo si trova nella modalità Standby di rete le sue interfacce di rete e I/O sono in sospensione e...
  • Page 176 Norwegian CE statement Forenklet EU-samsvarserklæring ASUSTek Computer Inc. erklærer herved at denne enheten er i samsvar med hovedsaklige krav og andre relevante forskrifter i direktivet 2014/53/EU. Fullstendig tekst for EU-samsvarserklæringen finnes på https://www.asus.com/Networking/ROG-Rapture-GT-AC2900/HelpDesk_Declaration/. Samsvarserklæring for direktiv om miljøvennlig design 2009/125/EF Testing for miljøutformingskrav i henhold til (EF) nr. 1275/2008 og (EU) nr. 801/2013 er utført. Når enheten er i nettverksventemodus, er I/O- og nettverksgrensesnittet i hvilemodus og fungerer kanskje ikke som det skal. Trykk Wi-Fi på/av-, LED på/av-, tilbakestill- eller WPS-knappen for å vekke enheten. Dette utstyret samsvarer med FCC-grensene for strålingseksponering for et ukontrollert miljø. Dette utstyret bør installeres og brukes med en minimumsavstand på 20 cm mellom radiatoren og kroppen din. Alle operasjonsmoduser: 2.4GHz: 802.11b, 802.11g, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40) 5GHz: 802.11a, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40), 802.11ac (VHT80)
  • Page 177 CE statement Declaração de conformidade simplificada da UE A ASUSTek Computer Inc. declara que este dispositivo está em conformidade com os requisitos essenciais e outras disposições relevantes da Diretiva 2014/53/CE. O texto integral da declaração de conformidade da UE está disponível em https://www.asus.com/Networking/ROG-Rapture-GT-AC2900/HelpDesk_ Declaration/. Declaração de conformidade para a Diretiva Conceção Ecológica 2009/125/CE Foram realizados testes de requisitos de conceção ecológica de acordo com o Nº 1275/2008 (CE) e Nº 801/2013 (UE). Quando o dispositivo se encontra no modo de espera em rede, a interface de E/S e de rede encontram-se no modo de suspensão e poderão não funcionar corretamente. Para ativar o dispositivo,...
  • Page 178 CE statement Declaración de conformidad simplificada para la UE Por el presente documento, ASUSTek Computer Inc. declara que este dispositivo cumple con los requisitos esenciales y otras disposiciones pertinentes de la Directiva 2014/53/UE. En https://www.asus.com/ Networking/ROG-Rapture-GT-AC2900/HelpDesk_Declaration/ está disponible el texto completo de la declaración de conformidad para la UE. Declaración de conformidad para la directiva de ecodiseño 2009/125/CE Se han realizado pruebas para cumplir los requisitos de ecodiseño conforme a las directivas (CE)
  • Page 179 Swedish CE statement Förenklad EU-försäkran om överensstämmelse ASUSTek Computer Inc. deklarerar härmed att denna enhet uppfyller väsentliga krav och andra relevanta bestämmelser i direktiv 2014/53/EU. Hela texten i EU-försäkran om överensstämmelse finns på https:// www.asus.com/Networking/ROG-Rapture-GT-AC2900/HelpDesk_Declaration/. Försäkran om överensstämmelse för Ecodesign-direktivet 2009/125/EC Test för ekodesingkrav i enlighet med (EC) nr 1275/2008 och (EU) nr 801/2013 har utförts. När enheten är i standby-läge för nätverk, är gränssnitten för I/O och nätverk försatta i viloläge och fungerar kanske inte ordentligt. För att väcka enheten, tryck på knappen för att slå på/stänga av Wi-Fi , slå på/stänga av LED, återställa eller WPS-knappen. Denna utrustning uppfyller EU:s strålningexponeringsgräns för en okontrollerad miljö. Denna utrustning skall installeras och hanteras på minst 20 cm avstånd mellan strålkällan och din kropp. Alla funktionslägen: 2.4GHz: 802.11b, 802.11g, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40) 5GHz: 802.11a, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40), 802.11ac (VHT80) Frekvens, läge och maximalt överförd ström i EU anges nedan:...

Table of Contents
