- Page 1 OWNER’S MANUAL Wall Mounting Bracket Please read this manual carefully before operating your set and retain it for future reference. LSW220BX P/NO : MFL63640513 (1203-REV00) www.lg.com...
-
Page 2: Important Safety Instructions
Component units units Guide spacer 4 units User manual Wall mount anchor 4 Wall mount screw 10 Guide space screw 4 units Safety clip 2 units Safety clip screw 2 units Set protection cushion (M4X12mm) 4 units IMPORTANT SAFETY INSTRUCTIONS Read these instructions. -
Page 3: Before Installation
Caution Install the product according to the directions in the When installing the product or adjusting the height of user manual. the product after installing, always do so with 2 people. If the product is not installed based on the directions in Working alone can cause the product to fall off and result in the user manual, it can cause a serious injury or damage injury or damage to the product. -
Page 4: Installation Method
Installation method - Tools you will need : Phillips head "+" driver(Manual or motorized) Ø4mm drill bit for wood or steel / Level / Stud finder / Drill. You may also need an 8mm socket wrench or an 8mm drill bit for concrete. - The actual product may differ from the picture. - Page 5 → If the screw cannot be assembled in the designated location inevitably, it can be assembled by rearranging to the closest location. But, do not change 2 or more locations from the designated spot. → Assemble the wall mount screw on 1 left and 1 right location on the top part and 1 left and 1 right location on the bottom part.
-
Page 6: Product Specification
- Attach the set protection cushion to mitigate the impact between the wall and the set when adjusting the angle. Attach the set protection cushion as shown in the picture. Product specification <With the bracket removed.> <With the bracket attached.> Model Name LSW220BX Model Name LSW220BX Width (mm) Width (mm) Height (mm) - Page 7 [ Unit : mm ] 15±2° 13±2° <With the bracket removed.> LSW220A LSW220A LSW220A MAX. MIN. LSW220A LSW220A 97.5 147.5 107.3 118.3 97.5 147.5 107.3 118.3 97.5 97.5 147.5 147.5 107.3 107.3 118.3 118.3 97.5 147.5 107.3 118.3 <With the bracket attached.> 131.5 128.5 MAX.
- Page 8 The model and serial number of the product is located Supported Displays on the back or one side of the product. Record it below (Please contract the retailers or refer to the TV owner’s should you ever need service. manual for applicable models.) MODEL SERIAL...
