Dishwasher
Installation Manual
DDS25840X
DIS25840
USA
Document Number :
15 0607 0100_AA_USA/ 03-03-16.(8:56)

Advertisement

Table of Contents
loading

Summary of Contents for Beko DIS25840

  • Page 1 Dishwasher Installation Manual DDS25840X DIS25840 Document Number : 15 0607 0100_AA_USA/ 03-03-16.(8:56)
  • Page 2 Dishwasher Installation Manual DDS25840X DIS25840 Document Number : 15 0607 0100_AA_USA/ 03-03-16.(8:56)
  • Page 3: Table Of Contents

    To prevent accidents, which could cause serious injury or death, as well as machine damage read these instructions before installation and / or use. INTRODUCTION 1. IMPORTANT SAFETY INSTRUCTIONS 1.1 INSPECT THE DISHWASHER 2. TOOLS WHICH MAY BE NEEDED 3. MATERIALS WHICH MAY BE NEEDED 4.
  • Page 4: Introduction

    INTRODUCTION NOTICE : Please read this installation manual Read these installation instructions and particularly the safety instructions completely before installing and follow completely and carefully. They will save you them carefully. Save these installation time and effort and help to ensure optimum instructions and pass them on to any dishwasher performance.
  • Page 5: Inspect The Dishwasher

    Only connect the dishwasher to the Old appliances may contain materials • • power supply when all installation and that can be recycled. Please contact plumbing work is complete. your local recycling authority about If the dishwasher is installed in a the possibility of recycling these •...
  • Page 6: Tools Which May Be Needed

    2. TOOLS WHICH MAY BE NEEDED 3. MATERIALS WHICH MAY BE NEEDED (Additional materials may be required to comply with local codes) Hot Water Supply Line - Minimum 3/8” O.D. copper tubing or metal braided dishwasher supply line. UL listed conduit connector or strain relief. Teflon tape or other pipe thread compound to seal plumbing connections.
  • Page 7: Materials Supplied

    4. MATERIALS SUPPLIED 4.1 PARTS SUPPLIED and sized to fit your water supply line (copper tubing/ Parts for your dishwasher will compression fitting, or braided come in several plastic bags. hose) on the other leg. Check your parts bags shown to make sure you have all the 4.4 DISHWASHER parts as listed to the left.
  • Page 8: Dishwasher Specifications

    5. DISHWASHER SPECIFICATIONS 5.1 TECHNICAL FEATURES 8 place settings Load capacity Permissible water 4.35 - 145 psi (0.3 - 10 bars) pressure 120 V (volts), 12 A (amps), Electrical connection 60 Hz (hertz) 1400 W (watts) Total power 1240 W (watts) Heater power NOTICE : Because we continually strive to improve our products, we may change our specifications...
  • Page 9: Enclosure Preparation

    Bend sides of mounting brackets ( ) in order to fix from sides (if necessary). NOTICE : For these model, DIS25840, note that extra bending should be done on the brackets as shown. 6.3 ADJUSTING HEIGHT Measure the height of the enclosure.
  • Page 10 6.3.1 INSTALLING THE FOOT SUPPORTS Supplied ( If the height of the enclosure is 337/16” to 341/4” (850mm - 870mm) use short supports as shown in the figure. If the height of the enclosure is above Supplied ( 341/4” (870mm) use long supports as shown in the figure.
  • Page 11 Adjust the front foot level with the adjusting wrench to balance and raise the dishwasher to the enclosure height. Adjust the rear foot level with a screwdriver to balance and raise the dishwasher to the enclosure height. NOTICE : Make sure the dishwasher is plumb and •...
  • Page 12: Preparing The Water Connection (A)

    6.4 PREPARING THE WATER CONNECTION (A) Install an easily accessible shut-off valve (not supplied) in the water supply line. All solder connections must be made before the water line is connected to the dishwasher’s water inlet valve. Water can also be supplied to the dishwasher by using a flexible braided hose line.
  • Page 13: Drain Preparation

    6.5 DRAIN PREPARATION The dishwasher drain hose may be connected to the drain plumbing in one of three ways (Figure NOTICE : Either one of the above methods must be used or the dishwasher will not operate • properly. A hose that attaches to a sink spray can burst if it is installed on the same water •...
  • Page 14: Steam Protection Foil

    6.7 STEAM PROTECTION FOIL Steam will form inside the dishwasher during operation. At the end of the cycle, when the dishwasher door is opened, it is required to use a steam protection foil to prevent any steam from collecting on the underside of the counter top. 6.6.2 FITTING THE PROTECTION FOIL Before applying the steam protection foil to the underside of the countertop, clean the area with...
  • Page 15: Placement Of Dishwasher Into The Opening

    7. PLACEMENT OF DISHWASHER INTO THE OPENING Now place the dishwasher into the opening and get ready to connect all hoses and electrical connections. CAUTION Make sure all hoses are pulled through the side opening of the cabinet, no hoses are kinked and all slack is taken out as shown in the above...
  • Page 16 7.1.2 WATER SUPPLY CONNECTION Water supply may be connected to the dishwasher in one of two ways: • With metal braided hose. • With copper tubing. 7.1.3 BRAIDED HOSE/COPPER TUBING After connections are made turn on the water supply to check for leaks. CAUTION Hot water supply line: Use minimum 3/8”...
  • Page 17: Electrical Connection

    7.2 ELECTRICAL CONNECTION WARNING Make sure the voltage and frequency listed on the data plate correspond • with the household electrical supply. This data must correspond to prevent injury and machine damage. Consult a qualified electrician if in doubt. Only connect the dishwasher to the mains when all installation and •...
  • Page 18: Readjusting Foot Levels

    (3,5mm) Ø " Ø " NOTICE : For model, DIS25840, you should keep the total note that height of the dishwasher at 321/4” (819mm) max. 7.4 ADJUSTING THE MOVABLE TOE KICK Now that you have successfully installed the dishwasher, you need to attach the toe kick to the dishwasher.
  • Page 19 NOTICE : Be sure to notice there is a left and a right bracket. Adjust the toe kick brackets forward or backwards so that they will align with the kitchen toe kick ( Lock the toe kick brackets as shown with the plastic tab in the figure C by pushing the plastic tab on the dishwasher into the teeth of the bracket ( 3.
  • Page 20: Installing The Outer Door

    7.5 INSTALLING THE OUTER DOOR (DIS25840) Measure the height and width of the enclosure (Figure ) and the toe kick. Determine how big the wooden door can be. For example if the height is 337/8” (860mm) and if the toe kick is 315/16”...
  • Page 21 4. Place the plastic mounting brackets over the marked holes and the side tabs must be flush with the edge of the wooden door (Figure 5. Attach the two mounting brackets to the (3,5mm) Ø " wooden door with 4 screws (Ø 1/8” x 5/8” (Ø 3.5mm x 14mm) (Figure 6.
  • Page 22 7. Open the door and remove the two caps and two screws inside the door at position 1 and 3 (Figure 8. Using the four screws Ø 3/16” x 111/16” (Ø 4mm x 43mm) provided, attach the wooden door to the dishwasher at position 1 and 3 (Figure Ø...
  • Page 23 ADJUSTING DOOR TENSION WITH CUSTOM WOODEN DOOR (DIS25840) Check the door tension of the dishwasher: If the door closes too quickly or if the door falls open, the spring tension needs to be adjusted.
  • Page 24 NOTICE : If you have a European kitchen or want to install a wooden toe kick to match your kitchen, please refer to one of the two drawings given below. Follow the same instructions on the brackets as for the removable toe kick. Installation should be done following the steps illustrated in the figures respectively.
  • Page 25: Installer Checklist

    8. INSTALLER CHECKLIST 10. SELF HELP HINTS: Your installer must have completed and The screen does not come on: checked the following: Check to make sure the breaker to the • The dishwasher is square and level. dishwasher is in the on position. •...
