OWNER'S MANUAL
LG Digital
Signage
(MONITOR SIGNAGE)
Please read this manual carefully before operating your set and retain it
for future reference.
42LS75A
42LS73B
49LS75A
49LS73B
55LS75A
55LS73B
Copyright © 2018 LG Electronics Inc. All Rights Reserved.
www.lg.com

Advertisement

Table of Contents
loading

Related Manuals for LG 49LS75A

Summary of Contents for LG 49LS75A

  • Page 1 OWNER’S MANUAL LG Digital Signage (MONITOR SIGNAGE) Please read this manual carefully before operating your set and retain it for future reference. 42LS75A 42LS73B 49LS75A 49LS73B 55LS75A 55LS73B www.lg.com Copyright © 2018 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    - Quick Settings Connecting IR & Light Sensor - Picture Settings Portrait Layout - Sound Settings Connecting the OPS - Network Settings Attaching and Removing the LG - General Settings Logo Bracket TROUBLESHOOTING Installing on a Wall REMOTE CONTROL PRODUCT SPECIFICATIONS...

  • Page 3: Licenses

    LICENSES LICENSES Supported licenses may differ by model. For more information of the licenses, visit www.lg.com. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

  • Page 4: Assembly And Preparation

    Product specifications or contents in this manual may be changed without prior notice due to upgrade of product functions. SuperSign Software & Manual • - Downloading from the LG Electronics website. - Visit the LG Electronics website (http://partner.lge.com) and download the latest software for your model.

  • Page 5: Optional Accessories

    ASSEMBLY AND PREPARATION Optional Accessories Without prior notice, optional accessories are subject to change to improve the performance of the product, and new accessories may be added. The illustrations in this manual may differ from the actual product and accessories. Screws Stand Diameter 4.0 mm x Pitch 0.7 mm x...
  • Page 6 ASSEMBLY AND PREPARATION KT-OPSA Screws Connecting Cable Power Cord Card (Easy Setup Guide) OPS kit AN-WF500 KT-SP0 Wi-Fi Dongle kit Pixel sensor kit NOTE Optional accessories are available for some models. If necessary, please purchase them separately. • Pixel sensor is sold separately. You can obtain additional accessories from your local retail store. •...

  • Page 7: Parts And Buttons

    ASSEMBLY AND PREPARATION Parts and Buttons Buttons Connection Panel Buttons Description INPUT Changes the input source. MENU Accesses the main menus, or saves your input and exits the menus. Adjust the up and down. Moves left and right. AUTO/SET Displays the current signal and mode. Turns the power on or off.

  • Page 8: Connecting The Stand

    ASSEMBLY AND PREPARATION Connecting the Stand Connecting the Speakers - For certain models only. - For certain models only. - The image may be different according to the - The image may be different according to the model model. Place a soft cloth on the table and place the Connect an input signal cable before product with the screen facing downward.

  • Page 9: Connecting Ir & Light Sensor

    ASSEMBLY AND PREPARATION Portrait Layout NOTE When installing in a portrait layout, rotate the Please turn off the power before removing • monitor counterclockwise 90 degrees (when the cable. Connecting or removing the facing the screen). speaker cable while turned on may result in no sound.

  • Page 10: Connecting The Ops

    ASSEMBLY AND PREPARATION Connecting the OPS - For certain models only. Align the KT-OPSA along the four screw - The image may be different according to the model. holes on the rear of the set and attach it to the rear of the set using the four screws Lay a clean cloth on the floor, put the provided.
  • Page 11 ASSEMBLY AND PREPARATION Close the top cover of the KT-OPSA and tighten it on the left and right with the two screws provided. Insert the OPS Player (sold separately) into the bottom hole of the KT-OPSA and finish the installation by tightening the two screws provided on the bottom.

  • Page 12: Attaching And Removing The Lg Logo Bracket

    - The image may be different according to the model. Removing the LG Logo Attaching the LG Logo on the right side Lay a clean cloth on the floor, and then put Lay a clean cloth on the floor, and then put the monitor on it with the screen face down.

  • Page 13: Installing On A Wall

    For more information, please refer to the • guide provided with the wall mount. the product and cause the monitor to fall. LG Electronics is not liable for any accidents related to the use of non-standard screws. Please use VESA standard as below. 785 mm and above •...
  • Page 14 ASSEMBLY AND PREPARATION Securing the monitor to a wall (optional) WARNING Procedure may differ depending on the model. If the monitor is not positioned in a • sufficiently stable location, there is a danger that it will fall. Many injuries, particularly to children, can be avoided by taking simple precautions such as: Using cabinets or stands...

  • Page 15: Remote Control

    REMOTE CONTROL REMOTE CONTROL The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully to use the monitor correctly. To install batteries, open the battery cover, place batteries (1.5 V AAA) matching terminals to the labels inside the compartment, and close the battery cover.
  • Page 16 REMOTE CONTROL AUTO Automatically adjusts picture position and minimizes image instability (available HOME for RGB input only). Activates the Launcher. (Depending upon the model, this feature may not be supported.) SETTINGS W.BAL Accesses the main menus This model does not support or saves your input and exit this.

  • Page 17: Making Connections

    MAKING CONNECTIONS MAKING CONNECTIONS You can connect various external devices to your monitor. Change the input mode and select the external device you want to connect. For more information about external device connections, see the user manual provided with each device.

  • Page 18: External Device Connection

    MAKING CONNECTIONS External Device Connection Connect a HD receiver, DVD, or VCR player to the monitor and select an appropriate input mode. The illustrations may differ from the actual accessories. Some of the cables are not provided. For the best picture and sound quality, connecting external devices to your monitor using HDMI cables is recommended.
  • Page 19 MAKING CONNECTIONS NOTE For the best image quality, using the monitor with HDMI connection is recommended. • To comply with the standard specifications of the product, use a shielded interface cable with a ferrite • core, such as a DVI-D cable. If you turn the monitor on when the set is cold, the screen may flicker.

  • Page 20: Daisy Chain Monitors

    MAKING CONNECTIONS Daisy Chain Monitors To use different products connected to each other, connect one end of the signal input cable (DP Cable) to the DP Out connector of Monitor 1 and connect the other end to the DP In connector of the other product.

  • Page 21: Using The Multi Display Mode Function

    MAKING CONNECTIONS Using the Multi Display Mode Function The Multi Display Mode function displays a video signal received from DP In either in single mode (SST: Single Stream Transport) or multi-mode (MST: Multi Stream Transport) through DP Out. This function can be configured in the Installation Menu (For more information, refer to the •...

  • Page 22: Using The Input List

    ENTERTAINMENT ENTERTAINMENT Using the Input List Remote Control (HOME) Using My Media Input Mode Description HDMI1 You can watch content on a PC, HDMI2/OPS Connecting USB Storage DVD player, digital set-top box, DISPLAYPORT and other high definition devices. Devices DVI-D Connect a USB storage device such as a USB flash memory or an external hard drive to the CAUTION...
  • Page 23 ENTERTAINMENT Tips for using USB storage devices Only a USB storage device can be recognized. • A USB device does not work effectively when it is connected via a USB hub. • • A USB storage device using an automatic recognition program may not be recognized. A USB storage device using its own driver may not be recognized.

  • Page 24: Files Supported By My Media

    ENTERTAINMENT Files Supported by My Media Supported External Subtitle Format *.smi, *.srt, *.sub (MicroDVD, SubViewer 1.0/2.0), *.ass, *.ssa, *.txt (TMPlayer), *.psb (PowerDivX), • *.dcs (DLP Cinema) To use Select Play, Remote Control (HOME) Photos/ Videos/ Music Play Selection: plays back selected content. •...
  • Page 25 ENTERTAINMENT Supported Internal Subtitle Format FULL HD Video • 1920 X 1080: XSUB (Supports internal subtitles generated from DivX6) Supported Video Codec Extension Codec .asf Videos VC-1 Advanced Profile (excluding WMVA), VC-1 Simple and Main Profiles .wmv Audio WMA Standard (excluding WMA v1/WMA Speech), WMA 9 Professional .divx Videos DivX3.11, DivX4, DivX5, DivX6, XViD (except 3 warp-point GMC), H.264/AVC,...
  • Page 26 ENTERTAINMENT Supported Audio File File Format Item Information .MP3 Bit rate 32 Kbps - 320 Kbps Sample freq. 16 KHz - 48 KHz Support MPEG1, MPEG2, Layer2, Layer3 .wav Support .ogg Support Vorbis .wma Support Supported Photo File File Format Format Item 2D (jpeg, jpg,...

  • Page 27: Viewing Videos

    ENTERTAINMENT Viewing Videos Play video files on display. All of the saved video files are shown in your display. To play video files on display Remote Control (HOME) Videos Tips for Playing Video Files Some user-created subtitles may not work properly. •...
  • Page 28 ENTERTAINMENT NOTE Option values changed in Videos do not affect the Photos and Music. and in turn are not affected • by option values changed in Photos or Music. Option values changed in Photos and Music do affect each other. •...

  • Page 29: Viewing Photos

    ENTERTAINMENT Viewing Photos The displays on the screen may differ from the model. Viewing image files Remote Control (HOME) Photos Listening to Music Viewing music files Remote Control (HOME) Music NOTE Files with unsupported extensions are not displayed. • If a file is invalid, a broken image and the message "unrecognizable file" are displayed. •...

  • Page 30: Settings

    ENTERTAINMENT Settings You must register your product to play a DRM-protected DivX video. ® In order to register/deregister purchased or rented DivX contents Remote Control (HOME) Settings DivX ® ® In order to play purchased or rented DivX VOD contents, you should register your device with 10 digit DivX registration code from your device at www.divx.com/vod.

  • Page 31: Supersign Contents

    ENTERTAINMENT SuperSign Contents File Manager Plays stored files using the Export option in You can move, copy, or delete files. SuperSign Editor. To move, copy, or delete files To play back the stored files using the Remote Control (HOME) Export option You can move or copy files or folders from •...

  • Page 32: Picture Id Settings

    ENTERTAINMENT PICTURE ID Settings PICTURE ID is used to change the settings of a Assign the Set ID to the selection of your specific set (display) using a single IR receiver choice. for multi-vision. Communication is possible between a monitor with an IR receiver and A set with a different Set ID from the •...

  • Page 33: User Settings

    USER SETTINGS User Settings Main Menu Settings Quick Settings Configures frequently used settings menus. To turn your monitor on or off automatically Remote Control (SETTINGS) Quick On Timer/Off Timer You can set the On/Off Timer for your monitor. If you do not want to set the On/Off Timer, select Off in Repeat.

  • Page 34: Picture Settings

    USER SETTINGS Picture Settings To Select Picture Mode Remote Control (SETTINGS) Picture Picture Mode Select the picture mode that is best suited to the video type. Vivid: adjusts the video image for a retail environment by enhancing the contrast, brightness, and •...
  • Page 35 USER SETTINGS To fine-tune the picture mode Remote Control (SETTINGS) Picture Picture Adjust Backlight: adjusts the brightness of the screen by controlling the LCD backlight. The closer the value • is to 100, the brighter the screen is. Contrast: adjusts the difference between the light and dark areas of the picture. The closer the value •...
  • Page 36 USER SETTINGS Picture Options: customizes the picture options. • Noise Removes irregularly generated tiny dots for a clear picture. Reduction MPEG Noise Reduces the noise produced while creating digital video signals. Reduction Black Level Adjusts the black level of the picture to correct the brightness and contrast of the picture. Real Cinema Optimizes the video image for a cinematic look.
  • Page 37 USER SETTINGS CAUTION If a fixed image is displayed on the screen for a long period of time, it will be imprinted and become • a permanent disfigurement on the screen. This image burn or burn-in is not covered by the warranty. If the aspect ratio is set to 4:3 for a long period of time, image burn may occur on the letterboxed •...

  • Page 38: Sound Settings

    Speaker: adjusts the sync between video and audio coming from external speakers, such as those • connected to the digital audio output port, LG audio equipment, or headphones. From the default value, the closer the value is to -, the faster the sound output becomes, and the closer the value is to +, the slower the sound output becomes.

  • Page 39: Network Settings

    USER SETTINGS To Run a sound test Remote Control (SETTINGS) Sound Sound Test Run a sound test to check that sound signals are outputted normally, then solve any problems by selecting the relevant option on the screen. If there are no problems with the Sound Test, check connected external devices.
  • Page 40 • service may be limited by the applicable terms of service. For details, contact your ISP. LG is not responsible for any malfunction of the display and/or the Internet connection feature due • to communication errors/malfunctions associated with your Internet connection, or other connected equipment.

  • Page 41: General Settings

    USER SETTINGS Tips for Wireless Network Setting Wireless networks can be subject to interference from other devices operating at a frequency of 2.4 • GHz (wireless phones, Bluetooth devices or microwave ovens). There may also be interference from devices with a frequency of 5 GHz, same as other Wi-Fi devices. The surrounding wireless environment can cause the wireless network service to run slowly.
  • Page 42 USER SETTINGS To apply Daylight Saving Time Remote Control (SETTINGS) General Daylight Saving Time You can set the application period for Daylight Saving Time and enable or disable the function by selecting On/Off. Start Time / End Time: You can set the time by configuring month/nth/day/time settings. •...

  • Page 43: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING No image is displayed Problem Action Is the product power cord Check if the power cord is correctly plugged into the power » connected? outlet Does the Out of range message The signal from the PC (video card) is out of the vertical »...
  • Page 44 TROUBLESHOOTING After-image appears on the product. Problem Action After-image appears when the If you use a fixed image for a long time, the pixels may be » product is turned off. damaged. Use the screen-saver function. When a dark image is displayed on the screen after an image »...
  • Page 45 TROUBLESHOOTING CAUTION Image sticking does not occur when using constantly changing images but may occur when using • a fixed image for an extended period of time. Therefore, it is recommended that you use the instructions below to decrease the likelihood of image sticking occurring when using a fixed image. It is recommended that you change the screen at least once every 12 hours at the very minimum;...

  • Page 46: Product Specifications

    PRODUCT SPECIFICATIONS PRODUCT SPECIFICATIONS 42LS75A 42LS73B LCD screen Screen type 106.4 cm Wide Thin Film Transistor (TFT) Liquid Crystal Display (LCD) Screen Diagonal length of the screen: 106.4 cm 42” class (41.9” / 106.4 cm diagonal) Pixel pitch 0.4833 mm (H) x 0.4833 mm (V) Video signal Maximum resolution 1920 x 1080 @ 60 Hz...
  • Page 47 PRODUCT SPECIFICATIONS Dimensions (Width x Height x Depth) / Weight 948.7 mm x 555.3 mm x 31.7 mm / 12.5 kg (37.3 inches x 21.8 inches x 1.2 inches / 27.5 lbs) 948.7 mm x 617.7 mm x 298.3 mm / 13.9 kg (37.3 inches x 24.3 inches x 11.7 inches / 30.6 lbs) 948.7 mm x 555.3 mm x 81.3 mm / 13.3 kg (37.3 inches x 21.8 inches x 3.2 inches / 29.3 lbs)
  • Page 48 PRODUCT SPECIFICATIONS 49LS73B 49LS75A LCD screen Screen type 123.2 cm Wide Thin Film Transistor (TFT) Liquid Crystal Display (LCD) Screen Diagonal length of the screen: 123.2 cm 49” class (48.5” / 123.2 cm diagonal) Pixel pitch 0.55926 mm (H) x 0.55926 mm (V)
  • Page 49 PRODUCT SPECIFICATIONS Dimensions (Width x Height x Depth) / Weight 1094.6 mm x 637.4 mm x 31.7 mm / 15.6 kg (43.0 inches x 25.0 inches x 1.2 inches / 34.3 lbs) 1094.6 mm x 699.7 mm x 298.3 mm / 17.0 kg (43.0 inches x 27.5 inches x 11.7 inches / 37.4 lbs) 1094.6 mm x 637.4 mm x 81.3 mm / 16.4 kg (43.0 inches x 25.0 inches x 3.2 inches / 36.1 lbs)
  • Page 50 PRODUCT SPECIFICATIONS 55LS75A 55LS73B LCD screen Screen type 138.7 cm Wide Thin Film Transistor (TFT) Liquid Crystal Display (LCD) Screen Diagonal length of the screen: 138.7 cm 55” class (54.6” / 138.7 cm diagonal) Pixel pitch 0.630 mm (H) x 0.630 mm (V) Video signal Maximum resolution 1920 x 1080 @ 60 Hz...
  • Page 51 PRODUCT SPECIFICATIONS Dimensions (Width x Height x Depth) / Weight 1230.4 mm x 713.7 mm x 31.7 mm / 20.7 kg (48.4 inches x 28.0 inches x 1.2 inches / 45.6 lbs) 1230.4 mm x 776.1 mm x 298.3 mm / 22.1 kg (48.4 inches x 30.5 inches x 11.7 inches / 48.7 lbs) 1230.4 mm x 713.7 mm x 81.3 mm / 21.5 kg (48.4 inches x 28.0 inches x 3.2 inches / 47.3 lbs)
  • Page 52 PRODUCT SPECIFICATIONS Product Dimensions The illustrations in this manual may differ from the actual product and accessories. Please see “Mounting on a wall” section for screw sizes. The product specifications below may be changed without prior notice due to upgrade of product functions.
  • Page 53 PRODUCT SPECIFICATIONS 49LS73B 49LS75A (Unit: mm (inches)) 1094.6 (43.0) 28.8 (1.1) 7.4 (0.2) 31.7 (1.2) 135.1 (5.3) 817.6 (32.1) 347.3 (13.6) 347.3 (13.6) 400 (15.7)
  • Page 54 PRODUCT SPECIFICATIONS 55LS73B 55LS75A (Unit: mm (inches)) 28.8 (1.1) 1230.4 (48.4) 7.4 (0.2) 31.7 (1.2) 135.1 (5.3) 727.4 (28.6) 400 (15.7) 415.2 (16.3) 415.2 (16.3)
  • Page 55 PRODUCT SPECIFICATIONS HDMI(OPS) / DVI-D / DISPLAYPORT (PC) Support Mode NOTE Horizontal Vertical Resolution frequency PC resolutions available for the Input • frequency (Hz) (kHz) Label option in HDMI(OPS) / DVI-D / 640 x 480 31.469 59.94 DISPLAYPORT input modes: 640 x 480/60 Hz, 1280 x 720/60 Hz, 1920 x 1080/60 Hz;...

  • Page 56: Ir Codes

    IR CODES IR CODES All models do not support the HDMI/USB function. Some key codes may not be supported depending on the model. Code (Hex) Function Remarks Remote control button Remote control button Remote control button Energy Saving Remote control button INPUT Remote control button Remote control button...
  • Page 57 IR CODES Code (Hex) Function Remarks TILE Remote control button EXIT Remote control button ID ON (RED) Remote control button ID OFF (GREEN) Remote control button YELLOW Remote control Button BLUE Remote control button Remote control button Remote control button Remote control button Remote control button Remote control button...

  • Page 58: To Control Multiple Products

    TO CONTROL MULTIPLE PRODUCTS TO CONTROL MULTIPLE PRODUCTS Use this method to connect several products to a single PC. You can control several products at a time by connecting them to a single PC. In the Option menu, the Set ID must be between 1 and 1000 without being duplicated. Connecting the Cable Connect the RS-232C cable as shown in the picture.

  • Page 59: Command Reference List

    TO CONTROL MULTIPLE PRODUCTS Command Reference List COMMAND DATA (Hexadecimal) Power 00 to 01 Select input See Select Input Aspect Ratio See Aspect Ratio Energy Saving See Energy Saving Picture Mode See Picture Mode Contrast 00 to 64 Brightness 00 to 64 Sharpness 00 to 32 Color...
  • Page 60 TO CONTROL MULTIPLE PRODUCTS COMMAND DATA (Hexadecimal) White Balance Blue Gain 00 to FE White Balance Red Offset 00 to 7F White Balance Green Offset 00 to 7F White Balance Blue Offset 00 to 7F Backlight 00 to 64 Screen off 00 to 01 Tile Mode 00 to FF...

  • Page 61: Transmission/Reception Protocol

    TO CONTROL MULTIPLE PRODUCTS Transmission/Reception Protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] * [Command1]: identifies between the factory setting and the user setting modes. * [Command2]: controls monitor sets. * [Set ID]: Used for selecting a set you want to control. A unique Set ID can be assigned to each set ranging from 1 to 1000(01H~3E8H) under Settings in the OSD menu.
  • Page 62 TO CONTROL MULTIPLE PRODUCTS 01. Power (Command: k a) 04. Energy Saving (Command: j q) Controls the power on/off of the set. Sets the Energy Saving. Transmission Transmission [k][a][ ][Set ID][ ][Data][Cr] [j][q][ ][Set ID][ ][Data][Cr] Data 00: Off Data 00: Off 01: On 01: Minimum...
  • Page 63 TO CONTROL MULTIPLE PRODUCTS 07. Brightness (Command: k h) Adjusts the screen brightness. 10. Tint (Command: k j) Transmission Adjusts the screen tint. Transmission [k][h][ ][Set ID][ ][Data][Cr] [k][j][ ][Set ID][ ][Data][Cr] Data 00 to 64: Brightness 0 to 100 Acknowledgement Data 00 to 64: Tint red 50 to green 50...
  • Page 64 TO CONTROL MULTIPLE PRODUCTS 13. Sound mode (Command: d y) 17. Time 2 (hour/minute/second) (Command: f x) Selects a sound mode. Adjusts the Time 2 (hour/minute/second) value. Transmission Transmission [d][y][ ][Set ID][ ][Data][Cr] [f][x][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr] Data 01: Standard Data1 00 to 17: 00 to 23 hours...
  • Page 65 TO CONTROL MULTIPLE PRODUCTS 20. Off Timer (Repeat/Time) (Command: f e) 21. On timer (Repeat/Time) (Command: f d) Configures Off Timer (Repeat/Time) settings. Configures On Timer (Repeat/Time) settings. Transmission Transmission [f][e][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr] [f][d][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr] Data1 Data1 1.
  • Page 66 TO CONTROL MULTIPLE PRODUCTS 22. On Timer Input (Command: f u) 23. No Signal Power Off (15Min) (Command: f g) Select an external input for the current On Time setting and Configures the automatic standby settings. add a new schedule. Transmission Transmission [f][g][ ][Set ID][ ][Data][Cr]...
  • Page 67 TO CONTROL MULTIPLE PRODUCTS 26. Reset (Command: f k) Performs the Picture and Factory Reset functions. 29. Time Elapsed (Command: d l) Checks the elapsed time. Transmission Transmission [f][k][ ][Set ID][ ][Data][Cr] [d][l][ ][Set ID][ ][Data][Cr] Data 00: Picture Reset Data FF: Read status 02: Initial Settings (factory reset)
  • Page 68 TO CONTROL MULTIPLE PRODUCTS 32. White balance red gain (Command: j m) 35. White Balance Red Offset (Command: s x) Adjusts the white balance red gain value. Adjusts the white balance red offset value. Transmission Transmission [j][m][ ][Set ID][ ][Data][Cr] [s][x][ ][Set ID][ ][Data][Cr] Data 00 to 7F: Red Offset 0 to 127...
  • Page 69 TO CONTROL MULTIPLE PRODUCTS 38. Backlight (Command: m g) 41. Check Tile Mode (Command: d z) Adjusts the backlight brightness. Checks the tile mode. Transmission Transmission [d][z][ ][Set ID][ ][Data][Cr] [m][g][ ][Set ID][ ][Data][Cr] Data FF: checks the tile mode Data 00 to 64: Backlight 0 to 100 Acknowledgement...
  • Page 70 TO CONTROL MULTIPLE PRODUCTS 44. DPM Select (Command: f j) 47. Fail Over Select (Command: m i) To set the DPM (Display Power Management) function. Selects an input mode for auto switch. Transmission Transmission [m][i][ ][Set ID][ ][Data][Cr] [f][j][ ][Set ID][ ][Data][Cr] Data 00: Off Data...
  • Page 71 TO CONTROL MULTIPLE PRODUCTS 50. Local Key Operation (Command: t o) 53. Speaker (Command: d v) Configures the local key operation settings of the product. Sets the speaker function. Transmission Transmission [t][o][ ][Set ID][ ][Data][Cr] [d][v][ ][Set ID][ ][Data][Cr] Data 00: locks off all of the keys Data 00: Off...
  • Page 72 In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com.
  • Page 73 USER GUIDE LG Digital Signage (MONITOR SIGNAGE) Please read this manual carefully before operating your set and retain it for future reference. webOS 1.0 www.lg.com...
  • Page 74 In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com .

  • Page 75: User Settings

    NOTE • The software-related contents may be changed without prior notice due to upgrade of the product functions. • Some features described in the User Guide may not be supported in certain models. USER SETTINGS Main Menu Settings Quick Settings Configures frequently used settings menus.

  • Page 76: Picture Settings

    Picture Settings To Select Picture Mode Picture Picture Mode Select the picture mode that is best suited to the video type. Vivid: adjusts the video image for a retail environment by enhancing the contrast, brightness, and • sharpness. • Standard: adjusts the video image for a normal environment. APS: APS (Auto power saving ) mode reduces power consumption by dimming control.
  • Page 77 To fine-tune the picture mode Picture Picture Adjust • Backlight: adjusts the brightness of the screen by controlling the LCD backlight. The closer the value is to 100, the brighter the screen is. • Contrast: adjusts the difference between the light and dark areas of the picture. The closer the value is to 100, the greater the difference is.
  • Page 78 • Picture Options: customizes the picture options. Noise Reduction: Removes irregularly generated tiny dots for a clear picture. – – MPEG Noise Reduction: Reduces the noise produced while creating digital video signals. Black Level: Adjusts the black level of the picture to correct the brightness and contrast of the picture. –...
  • Page 79 To use the Energy Saving function Picture Energy Saving Reduces power consumption by adjusting peak screen brightness. Auto: adjusts the brightness of the monitor according to ambient light. (This feature is available only with • certain models.) Off: disables the Energy Saving mode. •...

  • Page 80: Sound Settings

    Speaker: adjusts the sync between video and audio coming from external speakers, such as those connected to the digital audio output port, LG audio equipment, or headphones. From the default value, the closer the value is to -, the faster the sound output becomes, and the closer the value is to +, the slower the sound output becomes.

  • Page 81: Network Settings

    Network Settings To Set a Signage Monitor Name Network Signage Name You can set a name for Signage Monitor that will be used on the network by using the on-screen keyboard. To Set Your Network Network Wired Connection (Ethernet) • Connecting to a wired network: Connect your monitor to a local area network (LAN) via the LAN port, and configure the network settings.
  • Page 82 For details, contact your ISP. • LG is not responsible for any malfunction of the display and/or the Internet connection feature due to communication errors/malfunctions associated with your Internet connection, or other connected equipment.
  • Page 83 Tips for Wireless Network Setting (It may not be supported depending on the model.) • Wireless networks can be subject to interference from other devices operating at a frequency of 2.4 GHz (wireless phones, Bluetooth devices or microwave ovens). There may also be interference from devices with a frequency of 5 GHz, same as other Wi-Fi devices.

  • Page 84: General Settings

    General Settings To configure the language General Menu Language Select one of the languages on the menu displayed on the screen. • Menu Language: sets a language for Signage. To set the time/date General Time & Date You can check or change the time. •...
  • Page 85 NOTE • On Time/Off Time can be saved for up to seven schedules; the monitor is turned on or off at the preset time in the schedule list. If multiple preset times are stored in the schedule list, this function works at the nearest time from the current time.

  • Page 86: Entertainment

    ENTERTAINMENT Using My Media Connecting USB Storage Devices Connect a USB storage device such as a USB flash memory or an external hard drive to the display and use multimedia features. CAUTION • Do not turn off the monitor or remove a USB storage device when the My Media screen is activated. This could result in loss of files or damage to the USB storage device.
  • Page 87 • If the USB HDD does not have an external power source, the USB device may not be detected. To ensure the device is detected, connect the external power source. - Use a power adapter for an external power source. We do not provide a USB cable for an external power source.

  • Page 88: Files Supported By My Media

    Files Supported by My Media Supported External Subtitle Format • *.smi, *.srt, *.sub (MicroDVD, SubViewer 1.0/2.0), *.ass, *.ssa, *.txt (TMPlayer), *.psb (PowerDivX), *.dcs (DLP Cinema To use Select Play, Photos/ Videos/ Music • Play Selection: plays back selected content. To set Device Selection, Photos/ Videos/ Music •...
  • Page 89 Supported Video Codec Extension Codec .asf Videos VC-1 Advanced Profile (excluding WMVA), VC-1 Simple and Main Profiles .wmv Audio WMA Standard (excluding WMA v1/WMA Speech), WMA 9 Professional .divx Videos DivX3.11, DivX4, DivX5, DivX6, XViD (except 3 warp-point GMC), H.264/AVC, Motion .avi Jpeg, MPEG-4 Audio...

  • Page 90: Viewing Videos

    Supported Photo File File Format Format Item 2D (jpeg, jpg, JPEG Minimum : 64 x 64 jpe) Maximum: Normal Type: 15360 (W) x 8640 (H) / Progressive Type: 1920 (W) x 1440 2D (png) Minimum : 64 x 64 Maximum: 1920 (W) x 1080 (H) 2D (bmp) Minimum : 64 x 64 Maximum: 1920 (W) x 1080 (H)
  • Page 91 NOTE • Option values changed in Videos do not affect the Photos and Music and in turn are not affected by option values changed in Photos or Music. Option values changed in Photos and Music do affect each other. • •...

  • Page 92: Viewing Photos

    Viewing Photos Settings The displays on the screen may differ from the You must register your product to play a DRM- protected DivX video. model. Viewing image files In order to register/deregister purchased or rented DivX contents Photos Settings DivX VOD Listening to Music In order to play purchased or rented DivX VOD contents, you should register your device with 10...

  • Page 93: Supersign Contents

    SuperSign Contents File Manager Plays stored files using the Export option in You can move, copy, or delete files. SuperSign Editor. To move, copy, or delete files To play back the stored files using the Export option • You can move or copy files or folders from internal to external memory.

  • Page 94: Picture Id Settings

    PICTURE ID Settings NOTE • If PICTURE ID is set to 2, only the upper PICTURE ID is used to change the settings of a right monitor, which has a Set ID of 2, can be specific set (display) using a single IR receiver for controlled by IR signals.

  • Page 95: Ir Codes

    IR CODES All models do not support the HDMI/USB function. Some key codes may not be supported depending on the model. Code (Hex) Function Remarks Remote control button Remote control button Remote control button Energy Saving Remote control button INPUT Remote control button Remote control button Number Key 0...
  • Page 96 Code (Hex) Function Remarks TILE Remote control button EXIT Remote control button ID ON (RED) Remote control button ID OFF (GREEN) Remote control button YELLOW Remote control Button BLUE Remote control button Remote control button Remote control button Remote control button Remote control button Remote control button W.BAL...

  • Page 97: To Control Multiple Products

    TO CONTROL MULTIPLE PRODUCTS Use this method to connect several products to a single PC. You can control several products at a time by connecting them to a single PC. In the Option menu, the Set ID must be between 1 and 1000 without being duplicated. Connecting the Cable Connect the RS-232C cable as shown in the picture.

  • Page 98: Command Reference List

    Command Reference List COMMAND DATA (Hexadecimal) Power 00 to 01 Select input See Select Input Aspect Ratio See Aspect Ratio Energy Saving See Energy Saving Picture Mode See Picture Mode Contrast 00 to 64 Brightness 00 to 64 Sharpness 00 to 32 Color 00 to 64 Tint...
  • Page 99 COMMAND DATA (Hexadecimal) White Balance Red Offset 00 to 7F White Balance Green Offset 00 to 7F White Balance Blue Offset 00 to 7F Backlight 00 to 64 Screen off 00 to 01 Tile Mode 00 to FF Check Tile Mode Tile ID See Tile ID Natural Mode...

  • Page 100: Transmission/Reception Protocol

    Transmission/Reception Protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] * [Command1]: identifies between the factory setting and the user setting modes. * [Command2]: controls monitor sets. * [Set ID]: Used for selecting a set you want to control. A unique Set ID can be assigned to each set ranging from 1 to 1000(01H~3E8H) under Settings in the OSD menu.
  • Page 101 01. Power (Command: k a) 04. Energy Saving (Command: j q) Controls the power on/off of the set. Sets the Energy Saving. Transmission Transmission [k][a][ ][Set ID][ ][Data][Cr] [j][q][ ][Set ID][ ][Data][Cr] Data 00: Off Data 00: Off 01: On 01: Minimum Acknowledgement 02: Medium...
  • Page 102 07. Brightness (Command: k h) 10. Tint (Command: k j) Adjusts the screen brightness. Adjusts the screen tint. Transmission Transmission [k][h][ ][Set ID][ ][Data][Cr] [k][j][ ][Set ID][ ][Data][Cr] Data 00 to 64: Brightness 0 to 100 Data 00 to 64: Tint red 50 to green 50 Acknowledgement Acknowledgement [h][ ][Set ID][ ][OK/NG][Data][x]...
  • Page 103 13. Sound mode (Command: d y) 17. Time 2 (hour/minute/second) (Command: f x) Selects a sound mode. Adjusts the Time 2 (hour/minute/second) value. Transmission Transmission [d][y][ ][Set ID][ ][Data][Cr] [f ][x][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr] Data 01: Standard Data1 00 to 17: 00 to 23 hours 02: Music Data2...
  • Page 104 20. Off Timer (Repeat/Time) (Command: f e) 21. On timer (Repeat/Time) (Command: f d) Configures Off Timer (Repeat/Time) settings. Configures On Timer (Repeat/Time) settings. Transmission Transmission [f ][e][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr] [f ][d][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr] Data1 Data1 1.
  • Page 105 22. On Timer Input (Command: f u) 24. Auto Power Off (4 Hours) (Command: m n) Select an external input for the current On Time setting and add Configures the automatic off settings. Transmission a new schedule. Transmission [m][n][ ][Set ID][ ][Data][Cr] [f ][u][ ][Set ID][ ][Data1][Cr] Data 00: Off...
  • Page 106 27. Current temperature (Command: d n) 30. Product serial number (Command: f y) Checks the inside temperature. Checks the serial number of the product. Transmission Transmission [d][n][ ][Set ID][ ][Data][Cr] [f ][y][ ][Set ID][ ][Data][Cr] Data FF: Check product serial number Data FF: Check the status Acknowledgement...
  • Page 107 33. White Balance Green Gain (Command: j n) Adjusts the white balance green gain value. 36. White Balance Green Offset (Command: s y) Transmission Adjusts the white balance green offset value [j][n][ ][Set ID][ ][Data][Cr] Transmission [s][y][ ][Set ID][ ][Data][Cr] Data 00 to FE: Green Gain 0 to 254 Data...
  • Page 108 39. Screen Off (Command: k d) 42. Tile ID (Command: d i) Turns the screen on or off. Sets the tile ID value of the product. Transmission Transmission [d][i][ ][Set ID][ ][Data][Cr] [k][d][ ][Set ID][ ][Data][Cr] Data 01 to E1: Tile ID 1 to 225** Data 00: turns the screen on FF: checks the tile ID...
  • Page 109 45. Power On Delay (Command: f h) 48. IR Operation (Command: t p) Sets the schedule delay when the power turns on. (unit: Configures the IR operation settings of the product. Transmission seconds). Transmission [t][p][ ][Set ID][ ][Data][Cr] [f ][h][ ][Set ID][ ][Data][Cr] Data 00: locks off all of the keys 01: locks on all of the keys except the Power key...
  • Page 110 49. Status check (Command: s v) 50. Speakers (Command: d v) Check the current signal of the product. Sets the speakers feature. Transmission Transmission [s][v][ ][Set ID][ ][Data][ ][FF][Cr] [d][v][ ][Set ID][ ][Data][Cr] Data 02: Checks whether there is a signal Data 00: Off 05: Checks whether luminance sensors 1 and 2 work properly.
  • Page 111 53. Power Indicator (Command: f o) 56. Luminance Value Read (Command: m u) Sets the Power Indicator Settings. Reads luminance values. Transmission Transmission [f ][o][ ][Set ID][ ][Data][Cr] [m][u][ ][Set ID][ ][FF][Cr] Data 00: Off Acknowledgement 01: On [u][][SetID][][OK/NG][Data1][Data2][Data3][Data4] Acknowledgement [Data5][Data6][Data7][x] [o][ ][Set ID][ ][OK/NG][Data][x] Data1...
  • Page 112 59. Easy Brightness Control Schedule (Command: s s) Sets an Easy Brightness Control schedule. Transmission [s][s][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr] Data1 1. f1 to f6 (data reading) F1: Reads the 1st data from the Easy Brightness Control F2: Reads the 2nd data from the Easy Brightness Control F3: Reads the 3nd data from the Easy Brightness Control F4: Reads the 4th data from the Easy Brightness Control F5: Reads the 5th data from the Easy Brightness Control...
  • Page 114 INSTALLATION MANUAL LG Digital Signage (MONITOR SIGNAGE) Please read this manual carefully before operating your set and retain it for future reference. webOS 1.0 www.lg.com...
  • Page 115 CONTENTS ACCESSING INSTALLATION MENU ..3 INSTALLATION MENU ......4 - Signage Setup ..............4 - USB Cloning ..............8 - Password Change ............8 - Tile Mode ................. 9 - Fail Over ................11 - ISM Method ..............12 - Server ................14 - Lock Mode ..............14...

  • Page 116: Accessing Installation Menu

    ACCESSING INSTALLATION MENU Press and hold the SETTINGS button for 5 seconds. MUTE MENU AUTO S.MENU When Toast (The top right corner ) is displayed, enter your password. (The default value is 0, 0, 0, 0 When the Installation Menu is displayed, select the desired option. - Signage Setup - USB Cloning - Password Change...

  • Page 117: Installation Menu

    INSTALLATION MENU NOTE Some features described in the Installation manual may not be supported in certain models. Signage Setup Use this menu to configure the digital signage after installation. Power On Status You can select the operating status of the monitor when the main power is switched on. You can select from among PWR, STD, and LST.
  • Page 118 Auto Power Off You can choose whether to use the 4 Hours Off feature. You can set this option to 4 Hours or Off. If you set this option to 4 Hours, the product turns off when you have not pressed any buttons on the remote control for 4 hours.
  • Page 119 Power On Delay (0 ~ 250) This feature delays power on in order to prevent overload when multiple monitor sets are turned on simultane- ously. You can set the delay interval in the range of 0 to 250 seconds. Digital Audio Input HDMI/DISPLAYPORT: you can hear the sounds of digital signals carried by HDMI, or DISPLAYPORT through the monitor speakers.
  • Page 120 BLU Maintenance Mode Enables or disables the luminance maintenance function. If turned On, the luminance maintenance function is enabled. (XF2B, XF3C: Luminance 2500 nit) If turned Off, the luminance maintenance function is disabled. (XF2B: Luminance 2500 nit, XF3C: Luminance 3000 nit) Power Indicator This feature allows you to configure the power indicator settings.

  • Page 121: Usb Cloning

    USB Cloning You can copy the product settings to other sets. Send to USB You can save the current settings in file format to a USB device. Select the file name and press the OK button to complete You cannot save the following items: Advanced Control under PICTURE, Clock, Sleep Time, Power on Delay, Set ID, Tile ID, and items under NETWORK.

  • Page 122: Tile Mode

    Tile Mode You can configure the integrated screen in the same way as each screen is configured. To use this function - Must be used with multiple monitors. - Must be operated after connecting the monitors using DP Cable and distributor. - Tile mode: row x column (r = 1 to 15, c = 1 to 15) - 15 x 15 available Row (1-15)
  • Page 123 Tile Mode Tile Mode - Natural mode This monitor can be tiled with additional monitors to When active, the part of the image that would create a large tiled display. normally be displayed in the gap between the monitors is omitted. When using 2 monitors Before When the Tile Mode...

  • Page 124: Fail Over

    Fail Over The input source with the highest priority will be selected. The Auto-Fail Over feature is disabled. Auto The input source changes according to the specified order. When several input sources are found, the input source with the highest priority will be selected. Priority: 1.HDMI1, 2.HDMI2, 3.DISPLAYPORT, 4.

  • Page 125: Ism Method

    ISM Method If a still image is displayed on the screen for an extended period of time, image sticking can occur. The ISM method is a feature that prevents image sticking. Mode Selects the desired ISM Method mode. Normal : Disables the ISM method. Inversion: Inverts screen colors to remove image sticking.
  • Page 126 Bar Color You can choose from six colors: red, green, blue, white, black, and gray. This feature is only applicable when Bar Image is set to Off. This option is available only when you have selected Washing Bar. Transparency Off: Displays the bar opaquely. On: Displays the bar translucently.

  • Page 127: Server

    Server Set Automatically The monitor set will be set automatically so that the SuperSign server can search it. Server IP This is a menu where you can set an IP address for the SuperSign server. Server Status Server Status displays the status of the connection between your monitor and the SuperSign server. Not connected: indicates that your monitor is not connected to the SuperSign server.

This manual is also suitable for:
