Operating Instructions
LED TV
Model No.
TH-40GX700Z
TH-50GX700Z
For more detailed instructions, please refer to [eHELP]
(Built-in Operating Instructions).
●
Thank you for purchasing this Panasonic product.
Please read these instructions carefully before operating this product and
retain them for future reference.
Please carefully read the "Safety Precautions" of this manual before use.
The images shown in this manual are for illustrative purposes only.
M0519-1059
TH_40_50GX700Z.indb 1
TH_40_50GX700Z.indb 1
How to use [eHELP]
(p. 18)
(image: TH-50GX700Z)
English
TQB4GD0265-1
English
13/5/2019 11:11:26 AM
13/5/2019 11:11:26 AM
Advertisement
Table of Contents
Related Manuals for Panasonic TH-40GX700Z
Summary of Contents for Panasonic TH-40GX700Z
- Page 1 ● How to use [eHELP] (p. 18) Thank you for purchasing this Panasonic product. Please read these instructions carefully before operating this product and retain them for future reference. Please carefully read the “Safety Precautions” of this manual before use.
-
Page 2: Table Of Contents
® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is under license. Other trademarks and trade names are those of their respective owners. x.v.Colour™ is a trademark. -
Page 3: Important Notice
Service as well as Additional information may be obtained from MPEG LA, to protect the rights or property of Panasonic. If you wish LLC. to know more about the processing of your information See http://www.mpegla.com. -
Page 4: Safety Precautions
Mains Plug and lead types vary depending on the ● Do not use an unapproved pedestal / mounting model and countries. equipment. Be sure to ask your local Panasonic dealer to perform the setup or installation of approved ● This TV is designed to operate on AC 220-240 V, wall-hanging brackets. - Page 5 Do not use the pedestal if it becomes warped or and the devices that use 2.4 GHz signal. physically damaged. If this occurs, contact your ■ Ventilation nearest Panasonic dealer immediately. ● Caution During setup, make sure that all screws are securely tightened.
-
Page 6: Accessories
● Whether you are using a pedestal or not, always Accessories ensure the vents at the bottom of the TV are not blocked and there is sufficient space to enable adequate ventilation. Remote Control ■ Moving the TV ● N2QAYB001189 Caution (p. -
Page 7: Installing The Tv
Installing the TV Cushioning material 40-inch model Assembling / Removing the pedestal Assembly screw (4) M5 × 12 50-inch model Assembly screw (4) M4 × 12 Bracket Preparations ● Make sure to assemble the pedestal before taking out the TV from the carton. ●... - Page 8 Assembling the pedestal ● Do not assemble the pedestal by any method other than those specified below. ● Cable arrangement (p. 14) 50-inch model 40-inch model English TH_40_50GX700Z.indb 8 TH_40_50GX700Z.indb 8 13/5/2019 11:11:28 AM 13/5/2019 11:11:28 AM...
- Page 9 Note When lifting the TV, support the TV as shown. ● Do not hold the screen part strongly as shown. ● Lift the TV with the protective sheet attached. Note ● Do not place the TV temporarily on the floor or desk ●...
-
Page 10: Installing The Wall-Hanging Bracket
Installing the wall- Preventing the TV from falling over It is recommended to secure the pedestal to a furniture hanging bracket as shown to prevent the TV from falling over. ● This information is designed to reduce the risk of injuries caused by the TV falling over. -
Page 11: Connections
Connections Basic connections ■ Mains lead ● External equipment and cables shown are not supplied with this TV. ● Please ensure that the unit is disconnected from the mains socket before attaching or disconnecting any AC 220-240 V, cables. 50 / 60 Hz ●... - Page 12 ■ Set top box HDMI cable Set top box Satellite dish Network ■ A broadband network environment is required to be able Satellite dish to use internet services. ● If you do not have any broadband network services, please consult your retailer for assistance. ●...
- Page 13 Other connections Connections for 4K / HDR compatible equipment ■ DVD Player (COMPONENT equipment) HDMI cable 4K / HDR compatible equipment ● To watch high-definition 4K more accurately or HDR content, connect the 4K / HDR compatible equipment to HDMI1 or 2 terminal. ●...
- Page 14 ■ Amplifier (listening with external speakers) Cable arrangement ● To enjoy multi-channel sound from external Fix the cables using the pedestal cover. equipment (e.g. Dolby Digital 5.1ch), connect the equipment to the amplifier. For information about the Fixing the cables connections, read the manuals of the equipment and amplifier.
-
Page 15: Identifying Controls
Identifying Controls 8 [Option Menu] ● Easy optional setting for viewing, sound, etc. 9 Coloured buttons Remote Control (red-green-yellow-blue) ● Used for the selection, navigation and operation of various functions. 10 Volume Up / Down 11 Numeric buttons ● Changes channel and teletext pages. ●... - Page 16 ■ Installing / Removing batteries 5 Volume Up / Down ● Cursor Left / Right (when in the menu system) 6 Mains power On / Off switch Pull open ● Use to switch the mains power. Hook ● To turn Off the apparatus completely, you must pull the mains plug out of the mains socket.
-
Page 17: First Time Auto Tuning
First time Auto Tick the TV signal mode to tune, and then select [Start Auto Tuning] Tuning : Satellite TV : Digital TV : Digital TV (DVB-T2) : Analogue TV When the TV is turned on for the first time, it will automatically search for available TV channels and give If satellite TV is selected, select your preferred options to set up the TV. -
Page 18: Watching
Watching TV How to Use eHELP [eHELP] is the detailed operating instructions built into Turn power on the TV, and gives a more detailed explanation for a better understanding of the operation of each feature. (TV) Display [eHELP] (Remote Control) ●... - Page 19 ● To scroll the description (if more than 1 page) While the description is highlighted ● To open the reference screen ( ● To display the menu related to the description (only for some descriptions) (red) ● To check the features of this TV Search by Purpose >...
-
Page 20: Faqs
● Check the mains lead is plugged into the TV and the mains socket. About the inquiry ● Please contact your local Panasonic dealer for The TV goes into Standby mode assistance. ● Auto power standby function is activated. If you make an inquiry from a place where this TV... -
Page 21: Maintenance
First, remove the mains plug from the ■ mains socket. Model No. Display panel, Cabinet, Pedestal 40-inch model TH-40GX700Z Regular care: 50-inch model Gently wipe the surface of the display panel, cabinet, TH-50GX700Z or pedestal by using a soft cloth to remove dirt or fingerprints. - Page 22 Sound PAL 60 Hz Playback of NTSC tape from some PAL Video Speaker output recorders (VCR) 20 W (10 W + 10 W) AUDIO OUT M.NTSC 3.5 mm stereo mini jack × 1 Playback from M.NTSC Video recorders (VCR) Connection terminals NTSC AV IN (COMPONENT / VIDEO) Playback from NTSC Video recorders (VCR)
- Page 23 TH_40_50GX700Z.indb 26 TH_40_50GX700Z.indb 26 13/5/2019 11:11:32 AM 13/5/2019 11:11:32 AM...
- Page 24 WARRANTY - New Zealand only NEW ZEALAND Distributed in New Zealand by Panasonic New Zealand Limited 18 Sir Woolf Fisher Drive, Highbrook, East Tamaki, Private Bag 14911, Panmure, Auckland Tel. 09 272 0100 Customer Care Center Email: Customerservice@nz.panasonic.com www.panasonic.co.nz Warranty Customer’s Record...
