COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
Page 3
CDX-L495EE UNLEADED SOLDER Boards requiring use of unleaded solder are printed with the lead free mark (LF) indicating the solder contains no lead. (Caution: Some printed circuit boards may not come printed with the lead free mark due to their particular size.) : LEAD FREE MARK Unleaded solder has the following characteristics.
CDX-L495EE SECTION 2 DISASSEMBLY Note : This set can be disassemble according to the following sequence. 2-5. CHASSIS (T.U) ASSY 2-1. SUB PANEL ASSY (Page 9) (Page 7) 2-6. DISC IN BOARD 2-7. SERVO BOARD 2-2. CD MECHANISM BLOCK (Page 10)
CDX-L495EE SECTION 3 DIAGRAMS 3-1. IC PIN DESCRIPTION • IC501 MN101C49KSN (SYSTEM CONTROL) Pin No. Pin Name Pin Description VREF– — A/D converter power supply (–) pin S-meter voltage detection input Not used. (Fixed at L in this set) 4, 5...
Page 14
CDX-L495EE Pin No. Pin Name Pin Description X_EN Not used. (Open) LIMIT CD mechanism deck Limit switch detection input Not used. (Open) D_SW CD mechanism deck Down switch detection input INSW CD mechanism deck Disc in switch detection input Not used. (Open)
CDX-L495EE 3-6. PRINTED WIRING BOARDS — CD MECHANISM SECTION — • Refer to page 17 for Circuit Boards Location. : Uses unleaded solder. THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS. (In addition to this, the necessary note is printed in each block.)
CDX-L495EE 3-7. SCHEMATIC DIAGRAM — CD MECHANISM SECTION — • Refer to page 17 for Waveforms and page 18 for Common Note on Schematic Diagram. • Refer to page 26 for IC Block Diagrams. TP77 TP78 TP89 TP79 TP80 TP81...
CDX-L495EE 3-9. SCHEMATIC DIAGRAM — MAIN SECTION (1/2) — • Refer to page 17 for Waveforms and page 18 for Common Note on Schematic Diagram. • Refer to page 26 for IC Block Diagrams. J330 C332 C333 C765 C764 D751...
CDX-L495EE SECTION 4 EXPLODED VIEWS NOTE: • The mechanical parts with no reference • Color Indication of Appearance Parts The components identified by mark 0 or dotted line with mark number in the exploded views are not supplied. Example : 0 are critical for safety.
CDX-L495EE 4-3. CD MECHANISM SECTION (1) (MG-393XC-121//Q) not supplied (DISC IN board) not supplied (LOAD board) not supplied supplied not supplied not supplied not supplied M903 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark A-3315-247-D CHASSIS (T.U) ASSY...
CDX-L495EE 4-5. CD MECHANISM SECTION (3) (MG-393XC-121//Q) M901 not supplied (LIMIT board) M902 not supplied (SUB (CD) board) The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified.
CDX-L495EE SECTION 5 ELECTRICAL PARTS LIST NOTE: • Due to standardization, replacements in • Items marked “*” are not stocked since The components identified by mark 0 or dotted line with mark the parts list may be different from the they are seldom required for routine service.
Page 40
CDX-L495EE REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper on the revised page allows you to jump to the next revised page. Ver. Date Description of Revision 2003. 10...
