TABLE OF CONTENTS TABLE OF CONTENTS - Viewing Photos LICENSES - Viewing the Contents List - DivX VOD Guide ® ASSEMBLING AND PREPARING CUSTOMIZING SETTINGS Accessories Accessing Main Menus Parts - PICTURE Settings To Install in a Portrait Layout - TIME Settings STORAGE METHOD FOR PANEL - OPTION Settings PROTECTION...
LICENSES LICENSES Supported licenses may differ by model. For more information of the licenses, visit www.lg.com . The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
Product specifications or contents in this manual may be changed without prior notice due to upgrade of product functions. SuperSign software and manual. - Downloading from the LG Electronics website. - Visit the LG Electronics website ( http://partner.lge.com ) and download the latest software for your model.
ASSEMBLING AND PREPARING To Install in a Portrait Layout When installing in a Portrait Layout, rotate the monitor clockwise 90 degrees (when facing the screen).
ASSEMBLING AND PREPARING STORAGE METHOD FOR PANEL PROTECTION Correct Method Incorrect Method Panel Panel If the product needs to be set upright, hold both sides of the product, and tilt backward carefully for. Do not let the panel not to touch the floor. If the product is tilted onto the bezel, the bottom of the panel may be damaged.
ASSEMBLING AND PREPARING Installing on a Wall CAUTION Disconnect the power cord first, and then move or install the monitor set. Otherwise To install the Monitor on a wall (optional), use the VESA screws provided as accessories to electric shock may occur. fasten it.
Page 9
ASSEMBLING AND PREPARING Securing the product to a wall (optional) WARNING (Depending on model) If a product is not positioned in a sufficiently stable location, it can be potentially hazardous due to falling. Many injuries, particularly to children, can be avoided by taking simple precautions such as: »...
ASSEMBLING AND PREPARING IR RECEIVER CONNECTION IR RECEIVER This allows a remote control sensor to be placed in a custom location. Then that display can control other displays via an RS-232C cable. 47LV35A IR IN 55LV35A IR IN...
ASSEMBLING AND PREPARING Tiling Displays How to Mount the Set Example of 2 x 2 Tiling Using the screws for attaching the VESA wall mount, mount the set to the wall mount plate or the wall. 47LV35A Screws for attaching the VESA wall mount 16-M4 Screw ≤...
Page 12
ASSEMBLING AND PREPARING 55LV35A Screws for attaching the VESA wall mount 16-M4 Screw ≤ 6 mm <Rear view of the set with the wall mount plate>...
ASSEMBLING AND PREPARING How to Join Sets 47LV35A Join other sets using screws for fi xing the VESA wall mount in the same way as above. Set 4 joined to the rest of the sets (2 x 2 tiling) After joining the sets, use the tiling guide to adjust the gap between the sets. Now the 2 x 2 tiling is complete.
Page 14
ASSEMBLING AND PREPARING 55LV35A Join other sets using screws for fi xing the VESA wall mount in the same way as above. Set 4 joined to the rest of the sets (2 x 2 tiling) After joining the sets, use the tiling guide to adjust the gap between the sets. Now the 2 x 2 tiling is complete.
REMOTE CONTROL REMOTE CONTROL The descriptions in this manual are based on the buttons of the remote control. Please read this manual carefully and use the monitor set correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching ends to the label inside the compartment, and close the battery cover.
Page 16
REMOTE CONTROL ⓘ AUTO INFO Automatically adjusts picture Displays information about position and minimizes image the program or screen that is instability.(RGB input only) currently used. SETTINGS W.BAL Accesses the main menus Enters the White Balance or saves your input and exit menu.
REMOTE CONTROL Displaying the Device Name Connected to an Input Port Display which devices are connected to which NOTE external input ports. External inputs supported : HDMI, DVI-D Access the Input list screen and press the red Labels available : PC, DTV (input label) button on the remote control.
MAKING CONNECTIONS MAKING CONNECTIONS You can connect various external devices to your monitor. Change the input mode and select the external device you want to connect. For more information about external device connections, see the user manual provided with each device. Connecting to a PC The illustrations may differ from the actual accessories.
Page 19
MAKING CONNECTIONS NOTE The monitor set with the HDMI connection for the best image quality. To comply with the specifications of the product, use a shielded interface cable with ferrite core, such as a D-sub 15-pin cable and DVI/HDMI cable. If you turn the monitor set on when the set becomes cold, the screen may flicker.
MAKING CONNECTIONS External Device Connection Connect a HD receiver, DVD, or VCR player to the monitor and select an appropriate input mode. The illustrations may differ from the actual accessories. Some of the cables are not provided. For the best picture quality, connecting external devices to your monitor using HDMI cables is recommended.
MAKING CONNECTIONS Using the Input List Adjusting Aspect Ratio Resize the image to view the image at its optimal Press to access the input source list. INPUT size by pressing while you are watching Press the navigation buttons to scroll to one of Monitor set.
Page 22
MAKING CONNECTIONS : This selection will allow you to adjust the : This selection will allow you to view a 16:9 picture horizontally, in linear proportion, to fill the picture with an original 4:3 aspect ratio, black entire screen(useful for viewing 4:3 formatted bars will appear on both the left and right of the DVDs).
ENTERTAINMENT ENTERTAINMENT To set up the network settings: (Even if your dis- Connecting to a Wired Network play has already connected automatically, running setup again will not harm anything), Connect the display to a local area network (LAN) via the LAN port as shown on the following illustra- Press SETTINGS to access the main menus.
Press the navigation buttons to scroll to ble terms of service. For details, contact your and press OK. NETWORK ISP. LG is not responsible for any malfunction of the Press the navigation buttons to select display and/or the Internet connection feature Network Status.
ENTERTAINMENT Using the My Media Tips for Using USB Storage Devices Only a USB storage device is recognizable. Connecting USB Storage Devices If the USB storage device is connected through a USB hub, the device is not recog- Connect USB storage devices such as a USB nizable.
Page 26
ENTERTAINMENT Be sure to back up important files since data stored in a USB memory device may be damaged. We will not be responsible for any data loss. If the USB HDD does not have an external power source, the USB device may not be detected.
ENTERTAINMENT Browsing Files Browse files saved in a USB storage device. Press SETTINGS to access the main menu. Press the search button to scroll to MY MEDIA and press OK. Press the Search button to go to the Movie List, Photo List or Content List that you want, and press Page 1/1 PAGE Page Change...
Page 28
ENTERTAINMENT Supported file format Type Supported file format Movie Codec Media Container Profile Video MPEG1 / MPEG2 DAT, MPG, MPEG, 1080p @ 30 fps DVD, TS, TP MPEG4 AVI, DIVX, MP4, MKV, 1080p @ 30 fps (DivX 3.11, DivX 4, TS, TRP DivX 5, DivX 6, Xvid 1.01, Xvid 1.02,...
ENTERTAINMENT Viewing Movies Plays movie files saved in the USB storage device. Press SETTINGS to access the main menu. Press the navigation button to scroll to MY MEDIA and press OK. Press the navigation button to scroll to Movie List and press OK. Press the navigation buttons to scroll to a folder you want and press OK.
Page 30
ENTERTAINMENT During movie playback, press OK to access the following settings. Selects the desired point and plays. 00:42:03 /01:03:00 Option Hide Exit Remote Description button Stops the playback. Plays a video. Pauses or resumes the playback. Scans backward in a file. Scans forward in a file.
Page 31
ENTERTAINMENT Select Set Video Play. to access the following Video options menus: Press SETTINGS to access the Pop-Up menus. Menu Description Press the navigation buttons to scroll to Set Selects your desired picture Picture Size Video Play or Set Video. and press OK. format during movie play.
ENTERTAINMENT Viewing Photos View image files saved in the USB storage device. Press SETTINGS to access the main menu. Press the navigation button to scroll to MY MEDIA and press OK. Press the navigation button to scroll to Photo List and press OK. Press the navigation buttons to scroll to a folder you want and press OK.
Page 33
ENTERTAINMENT While viewing photos, you can access the following settings. Slideshow Option Hide Exit Menu Description Starts or stops a slideshow with selected photos. If there are no selected photos, all photos saved in Slideshow the current folder display during a slideshow. To set a slideshow speed, select Option. Rotates photos clockwise (90 °, 180 °, 270 °, 360 °).
ENTERTAINMENT Viewing the Contents List Plays back the stored files using the Export option in SuperSign Manager. Press SETTINGS to access the main menu. Press the navigation button to scroll to MY MEDIA and press OK. Press the navigation button to scroll to Contents List and press OK. Press the navigation buttons to scroll to a folder you want and press OK.
ENTERTAINMENT ® ® DivX VOD Guide DivX VOD Deregistration You should deregister your device with 8 digit DivX deregistration code from your device at www.divx. com/vod. ® DivX VOD Registration In order to play purchased or rented DivX ® contents, you should register your device with 10 Press SETTINGS to access the main menus.
CUSTOMIZING SETTINGS CUSTOMIZING SETTINGS Accessing Main Menus Press to access the main menus. SETTINGS Press the navigation buttons to scroll to one of the following menus and press OK. Press the navigation buttons to scroll to the setting or option you want and press OK.
CUSTOMIZING SETTINGS PICTURE Settings PICTURE Move Energy Saving : Off (User) Press to access the main menus. SETTINGS Smart Energy Saving : Off Press the navigation buttons to scroll to PICTURE Picture Mode : Standard press OK. Backlight Contrast Press the navigation buttons to scroll to the setting or Brightness option you want and press OK.
Page 38
CUSTOMIZING SETTINGS Setting Description Customizes the PC display options in RGB mode. Screen (In RGB Option Mode Only) Selects a proper resolution. Resolution Sets to adjust the screen position, clock, and phase automatically. Auto Configure The displayed image may be unstable for a few seconds while the configuration is in progress.
Page 39
CUSTOMIZING SETTINGS Advanced Control - Picture Mode (Standard/ APS/ Sport/ Game) Setting Description Adjusts the contrast to the optimal level according to the brightness of the image. Dynamic Contrast Adjusts color for more natural-looking colors. Dynamic Color Selects the range of colours that can be expressed. Color Gamut Skin Color spectrum can be separately set to implement the skin color as defined by the user.
CUSTOMIZING SETTINGS TIME Settings TIME Move • Clock Press to access the main menus. SETTINGS • Off Time : Off Press the navigation buttons to scroll to and press OK. • On Time : Off TIME • Auto Off(15Min.) : Off Press the navigation buttons to scroll to the setting or option •...
CUSTOMIZING SETTINGS OPTION Settings OPTION Move • Language Press to access the main menus. SETTINGS • ISM Method : Normal Press the navigation buttons to scroll to and press • DivX(R) VOD OPTION • Initial Setting • Set ID Press the navigation buttons to scroll to the setting or option •...
CUSTOMIZING SETTINGS NETWORK Settings NETWORK Move • Network Setting Press to access the main menus. SETTINGS • Network Status Press the navigation buttons to scroll to NETWORK press OK. Press the navigation buttons to scroll to the setting or option you want and press OK.
Page 43
CUSTOMIZING SETTINGS Tile Mode This monitor can be tiled with additional monitors to create a large tiled display. When using 9 monitors When using 2 monitors When using 4 monitors When the Tile Mode option is disabled ID 3 ID 3 ID 2 ID 2 ID 2...
CUSTOMIZING SETTINGS Picture ID Picture ID is used to change the settings of a To change the Picture ID, press the ON button, specific display using a single IR receiver for or the left and right arrow buttons continuously. multi-vision. The set receiving the IR signal Assign the ID you want.
CUSTOMIZING SETTINGS Daisy Chain Monitors Use this function to share the DVI video signal with other monitors without having to use a separate signal splitter box. • To use different products connected to each other Connect one end of the signal input cable (DVI Cable) to the DVI OUT connector of product 1 and connect the other end to the DVI IN connector of other products.
TROUBLESHOOTING TROUBLESHOOTING No image is displayed Problem Resolution Is the product power cord See if the power cord is properly connected to the outlet. connected? Power is on, but the screen Adjust brightness and contrast again. appears extremely dark. Backlight may need repair. Does the Invalid Format The signal from the PC (video card) is out of the vertical or horizontal message appear?
Page 47
TROUBLESHOOTING After-image appears on the product. Problem Resolution After-image appears when the If you use a fixed image for a long time, the pixels may be damaged product is turned off. quickly. Use the screen-saver function. Screen color is abnormal. Problem Resolution Screen has poor color resolution...
Page 48
TROUBLESHOOTING CAUTION Image sticking does not occur when using constantly changing images but may occur when using a fixed image for an extended period of time. Therefore, it is recommended that you use the instruc- tions below to decrease the likelihood of image sticking occurring when using a fixed image. It is recommended that you change the screen at least once every 12 hours at the very minimum;...
SPECIFICATIONS SPECIFICATIONS 47LV35A LCD Panel Screen Type 119 cm Wide TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel. Visible diagonal size 119 cm Pixel Pitch 0.5415 mm (H) X 0.5415 mm (V) Video Signal Max. Resolution 1920 x 1080 @ 60 Hz HDMI/DVI 1920 x 1080 @ 60 Hz - It may not be supported depending on the OS or video card type.
Page 50
SPECIFICATIONS 55LV35A LCD Panel Screen Type 139 cm Wide TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel. Visible diagonal size 139 cm Pixel Pitch 0.630 mm (H) x 0.630 mm (V) Video Signal Max. Resolution 1920 x 1080 @ 60 Hz HDMI/DVI 1920 x 1080 @ 60 Hz - It may not be supported depending on the OS or video card type.
IR CODES IR CODES All models do not support the HDMI/USB function. Some key codes are not supported depending on the model. Code (Hexa) Function Note R/C BUTTON (Power) INPUT R/C BUTTON MONITOR ON R/C BUTTON MONITOR OFF R/C BUTTON ENERGY SAVING ( R/C BUTTON R/C BUTTON...
CONTROLLING THE MULTIPLE PRODUCT CONTROLLING THE MULTIPLE PRODUCT Use this method to connect several products to a single PC. You can control several products at one time by connecting them to a single PC. In the Option menu, Set ID must be between 1 and 255 (or from 1 to 1,000) without being duplicated. Connecting the cable Connect the RS-232C cable as shown in the picture.
CONTROLLING THE MULTIPLE PRODUCT Command Reference List COMMAND DATA (Hexadecimal) Power 00 to 01 Select input See [Select input] Aspect ratio See [Aspect ratio] Energy saving See [Energy saving] Picture mode See [Picture mode] Contrast 00 to 64 Brightness 00 to 64 Sharpness 00 to 32 Color...
Page 55
CONTROLLING THE MULTIPLE PRODUCT COMMAND DATA (Hexadecimal) Power On Delay 00 to 64 Tile Mode 00 to 01 Tile Mode Check Tile ID Refer to ‘Tile ID'. Tile H Position 00 to 32 Tile V Position 00 to 32 Tile H Size 00 to 32 Tile V Size 00 to 32...
CONTROLLING THE MULTIPLE PRODUCT Transmission / Receiving Protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] * [Command1]: First command to control the set. * [Command2]: Second command to control the set. * [Set ID]: Used for selecting a set you want to control. A Set ID can be assigned to each set from 1 to 255 (from 01H to FFH), or from 1 to 1,000 (from 001H to 3e8H) in certain models, under OPTION in the OSD menu.
Page 57
CONTROLLING THE MULTIPLE PRODUCT 01. Power (Command: k a) 04. Energy saving (Command: j q) Controls the power on/off of the set. Sets the energy saving function. Transmission Transmission [k][a][ ][Set ID][ ][Data][Cr] [j][q][ ][Set ID][ ][Data][Cr] Data 00: Off Data 00: Off 01: On 01: Minimum...
Page 58
CONTROLLING THE MULTIPLE PRODUCT 07. Brightness (Command: k h) 10. Tint (Command: k j) Adjusts the screen brightness. Adjusts the screen tint. Transmission Transmission [k][h][ ][Set ID][ ][Data][Cr] [k][j][ ][Set ID][ ][Data][Cr] Data 00 to 64: Brightness 0 to 100 Data 00 to 64: Tint red 50 to green 50 Acknowledgement Acknowledgement...
Page 59
CONTROLLING THE MULTIPLE PRODUCT 13. V position (Command: f r) 16. Balance (Command: k t) Adjusts the vertical position of the screen. Adjusts the sound balance. This function is only available when the Tile Mode is Transmission set to Off. [k][t][ ][Set ID][ ][Data][Cr] * The operational range varies depending on the Data 00 to 64: Left 50 to right 50...
Page 60
CONTROLLING THE MULTIPLE PRODUCT 19. Volume (Command: k f) 22. Off time schedule (Command: f c) Adjusts the playback volume. Enables/disables the on time schedule. Transmission Transmission [k][f][ ][Set ID][ ][Data][Cr] [f][c][ ][Set ID][ ][Data][Cr] Data 00 to 64: Volume 0 to 100 Data 00: Off 01: On Acknowledgement...
Page 61
CONTROLLING THE MULTIPLE PRODUCT 24. Off timer (repeat mode/time) (Command: f e) 25. On timer (repeat mode/time) (Command: f d) Configures the off time (repeat mode/time) settings. Configures the on time (repeat mode/time) settings. Transmission Transmission [f][e][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr] [f][d][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr] Data1 Data1...
Page 62
CONTROLLING THE MULTIPLE PRODUCT 26. On timer input (Command: f u) 28. Auto off (Command: f g) Adds a new schedule entry by selecting input for the Configures the automatic off settings. current on timer setting. Transmission Transmission [f][g][ ][Set ID][ ][Data][Cr] [f][u][ ][Set ID][ ][Data1][Cr] Data 00: Off (Will not turn off after 15 minutes) [f][u][ ][Set ID][ ][Data1][Data2][Cr]...
Page 63
CONTROLLING THE MULTIPLE PRODUCT 31. Reset (Command: f k) 34. Time elapsed (Command: d l) Resets settings for Picture, Screen and Audio or Checks the elapsed time. restores factory settings. Transmission (Screen reset can only be performed in RGB input [d][l][ ][Set ID][ ][Data][Cr] mode.) Data FF: Read status...
Page 64
CONTROLLING THE MULTIPLE PRODUCT 37. White balance red gain (Command: j m) 40. Backlight (Command: m g) Adjusts the white balance red gain value. Adjusts the back light brightness. Transmission Transmission [j][m][ ][Set ID][ ][Data][Cr] [m][g][ ][Set ID][ ][Data][Cr] Data 00 to FE: Red gain 0 to 254 Data 00 to 64: Back light brightness 0 to 100 Acknowledgement Acknowledgement...
Page 65
CONTROLLING THE MULTIPLE PRODUCT 43. Tile Mode (Command: d d) 46. Tile H Position (Command: d e) To set a Tile Mode and Tile Column/ To adjust the Tile Horizontal position. Row values. * This function is available only when the Natural option of the Tile Mode is set to Off while the Tile Transmission Mode set to On.
Page 66
CONTROLLING THE MULTIPLE PRODUCT 49. Tile V Size (Command: d h) To adjust the Tile Vertical size. *Set Tile V Position to 0x00 before setting Tile V Size. * This function is available only when the Natural option of the Tile Mode is set to Off while the Tile Mode set to On.
Page 68
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of...
