- Page 1 1,MFL69020710,영어 2017. 8. 21. 오후 7:00 페이지 1 OWNER’S MANUAL DEHUMIDIFIER Please read this manual carefully before operating your set and retain it for future reference. RD17GQGD1 www.lg.com/hk P/NO : MFL69020710 Rev01_012017...
- Page 2 1,MFL69020710,영어 2017. 8. 21. 오후 7:00 페이지 2 SAFETY PRECAUTIONS SAFETY PRECAUTIONS The following safety precautions are intended to prevent accidental property damage and per- sonal injury through safe and correct use of the product. WARNING Failure to follow the instructions could result in death or serious injury of the user. CAUTION Failure to follow the instructions could result in personal injury or property damage.
- Page 3 1,MFL69020710,영어 2017. 8. 21. 오후 7:00 페이지 3 SAFETY PRECAUTIONS • Keep the air inlet and outlet free from obstructions. Failure to do this could result in poor performance or malfunction. • Do not cover the power cord with a mat etc. If heavy objects are placed on the mat, the power cord underneath could be damaged, causing fire or electric shock.
- Page 4 1,MFL69020710,영어 2017. 8. 21. 오후 7:00 페이지 4 SAFETY PRECAUTIONS • Turn off the dehumidifier and empty the water tank before moving the dehumidifier. The water could overflow from the tank, wetting household items or causing fire or electric shock. •...
-
Page 5: Table Of Contents
1,MFL69020710,영어 2017. 8. 21. 오후 7:00 페이지 5 TABLE OF CONTENTS TABLE OF CONTENTS SAFETY PRECAUTIONS Smart Fuction Using Smart ThinQ Application QUICK START HOW TO CLEAN NAME OF EACH PART How to clean the exterior and inlet of Front side the dehumidifier Back side How to clean water tank... -
Page 6: Quick Start
1,MFL69020710,영어 2017. 8. 21. 오후 7:00 페이지 6 QUICK START QUICK START Dehumidifier efficiency varies depending on room tempera- ture and relative humidity • A lower temperature and lower relative humidity will reduce the moisture removal rate. • The compressor operates in dehumidification mode only when the set humidity is lower than the room humidity. -
Page 7: Name Of Each Part
1,MFL69020710,영어 2017. 8. 21. 오후 7:00 페이지 7 NAME OF EACH PART NAME OF EACH PART Front side Display Start/stop button Outlet Louver It adjusts the direction of the wind. Water tank lid Water tank It stores dehumidified water. Back side Hose cover Antibiotic ultra-fine filter Inlet... -
Page 8: Display Panel
1,MFL69020710,영어 2017. 8. 21. 오후 7:00 페이지 8 NAME OF EACH PART Display Panel Wind strength lamp Timer indicator lamp Operation mode Wind strength Humidity control Ionizer Start/stop control Light timer Operation mode Humidity &Off timer Wi-Fi Bucker full indicator lamp lamp display indicator lamp... -
Page 9: Checklist Before Usage
1,MFL69020710,영어 2017. 8. 21. 오후 7:00 페이지 9 CHECKLIST BEFORE USAGE CHECKLIST BEFORE USAGE Dehumidification amount changes according to indoor temperature and relative humidity. - If the temperature or relative humidity is low, dehumidification amount is decreased. - Dehumidification is performed with compressor operation only when the desired humidity is lower than the current humidity. -
Page 10: How To Use
1,MFL69020710,영어 2017. 8. 21. 오후 7:00 페이지 10 HOW TO USE HOW TO USE Push start/stop button. - The louver opens and smart dehumidification starts. But, if there is no button operation, it operates continuously for 30 minutes before operating at desired humidity 50%. -
Page 11: Smart Dehumidification
1,MFL69020710,영어 2017. 8. 21. 오후 7:00 페이지 11 HOW TO USE To stop the product, press start/stop button one more time. - Louver closes. - All lamps will be turned off and the product stops. CAUTION • If the product started again right after stopping the operation, dehumidification operation does not start for about 3 minutes to protect the compressor. -
Page 12: Jet Dehumidification
1,MFL69020710,영어 2017. 8. 21. 오후 7:00 페이지 12 HOW TO USE Jet Dehumidification When you want to remove indoor moisture quickly - Press Operation Mode button to select Jet dehumidification mode. - After setting the jet dehumidification, it operates in power wind (Po), and after 60 minutes, the current humidity is displayed on the humidity display, and it operates in high wind mode. -
Page 13: Spot Drying
1,MFL69020710,영어 2017. 8. 21. 오후 7:00 페이지 13 HOW TO USE Spot Drying When you need spot drying of shoes, closet, etc. - Press Operation Mode button to select Spot drying mode. - In Spot drying mode, the louver is closed. - Wind amount is set to high wind, and humidity control &... -
Page 14: Laundry Drying
1,MFL69020710,영어 2017. 8. 21. 오후 7:00 페이지 14 HOW TO USE CAUTION • Do not move the dehumidifier by holding the extension hose. Dehumidifier may fall down and cause injury. • If spot drying operation is used for long period of time, the operation may stop to protect the product. -
Page 15: Ionizer
1,MFL69020710,영어 2017. 8. 21. 오후 7:00 페이지 15 HOW TO USE Ionizer When you want to remove harmful bacteria in the air - Select it by pressing Ionizer button. - It removes harmful material in the air such as bacteria, virus, etc. using ionized air. - You can use Ionizer function and dehumidification function at the same time. -
Page 16: Bucket Full
1,MFL69020710,영어 2017. 8. 21. 오후 7:00 페이지 16 HOW TO USE Bucket full When the water tank is full, operation automatically stops, bucket full lamp is lighted, and warning buzzer sounds. (Warning buzzer will sound one more time after 1 minute.) - When the full water is detected, the dehumidification function immediately stops, and fan oper- ates for 3 minutes to remove the remaining condensed water. -
Page 17: Off Timer
1,MFL69020710,영어 2017. 8. 21. 오후 7:00 페이지 17 HOW TO USE OFF Timer Check if it is under operation and press OFF timer button. - OFF timer switches in the following order, so select the setting time. (1 hour gap) → 1 → 2 → … → 8 → No display - The remaining time is displayed as time goes. -
Page 18: Lock Function
1,MFL69020710,영어 2017. 8. 21. 오후 7:00 페이지 18 HOW TO USE Lock Function Press the Ionizer button for 3 seconds. - If you take off your hand when the buzzer sounds 1 time after 3 seconds, it enters Lock function. - “CL”... -
Page 19: How To Empty Water Tank
1,MFL69020710,영어 2017. 8. 21. 오후 7:00 페이지 19 HOW TO USE How to empty water tank Hold the top handle of the water tank and Open the drain lid of the water tank. softly take it out. Drain lid Water tank handle First insert the bottom part of the water tank Pour out the water inside the water tank. -
Page 20: Product Registration Through Wi-Fi Function
1,MFL69020710,영어 2017. 8. 21. 오후 7:00 페이지 20 HOW TO USE Product registration through Wi-Fi function 1. Press button to start dehumidifier operation. 2. Check the information (Wi-Fi network name, password) of AP at the place where the de- humidifier is installed. 3. -
Page 21: Smart Fuction
• To verify the Wi-Fi connection, check that Wi-Fi icon on the control panel is lit. Create an account and sign in. • LG Smart ThinQ is not responsible for any Select Register. network connection problems or any faults, malfunctions, or errors caused by network Select Dehumidifier. - Page 22 Frequency Range 2412 to 2472 MHz Use this function if you need an accurate diag- IEEE 802.11b:18.37 dBm nosis by an LG Electronics customer informa- Output Power(Max) IEEE 802.11g:17.67 dBm tion centre when the appliance malfunctions or IEEE 802.11n:17.67 dBm fails.
-
Page 23: How To Clean
1,MFL69020710,영어 2017. 8. 21. 오후 7:00 페이지 23 HOW TO CLEAN HOW TO CLEAN How to clean water tank Press the fixing part on both sides of the water How to clean the exterior tank to take out the lid. and inlet of the dehumidifier Soak soft cloth in water, squeeze out water, and wipe the dehumidifier. -
Page 24: How To Clean Antibiotic Ultra-Fine Filter
1,MFL69020710,영어 2017. 8. 25. 오전 10:26 페이지 24 HOW TO CLEAN How to clean Antibiotic ultra-fine filter Push antibiotic ultra-fine filter to the right to Clean the antibiotic ultra-fine filter with vac- take it out. uum cleaner or soft brush. - If the contamination is severe, wash with water using neutral detergent. -
Page 25: How To Store
1,MFL69020710,영어 2017. 8. 21. 오후 7:00 페이지 25 HOW TO STORE HOW TO STORE Pull out the power plug from the socket. Completely drain the water remaining inside the water tank. - Separate the water tank lid and wipe the water inside the water tank. Clean the filter. -
Page 26: Troubleshooting Tips
1,MFL69020710,영어 2017. 8. 21. 오후 7:00 페이지 26 TROUBLESHOOTING TIPS TROUBLESHOOTING TIPS Is there something wrong with the product? Please check the following before contacting the service center. Problem Check What To Do The product is not - Is the power plug correctly inserted into - Insert the power plug.
