Contents 1 Important Safety Notice 2 Your Micro Hi-Fi System Introduction What’s in the box Overview of the main unit Overview of the remote control 3 Connect Connect speakers Connect power 4 Get started Prepare the remote control Auto install radio stations Set clock Turn on 5 Play...
1 Important Safety a Read these instructions. b Keep these instructions. c Heed all warnings. d Follow all instructions. e Do not use this apparatus near water. f Clean only with dry cloth. g Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
Notice Any changes or modifications made to this device that are not expressly approved by Philips Consumer Lifestyle may void the user’s authority to operate the equipment. Your product is designed and manufactured with high quality materials and components, which can be recycled and reused.
This apparatus includes this label: 2 Your Micro Hi-Fi System Congratulations on your purchase, and welcome to philips! To fully benefit from the support that philips offers, register your product at www.philips.com/welcome. Introduction With this unit, you can: • enjoy music from audio discs, USB devices and other external devices directly •...
Overview of the main unit a Disc compartment b IR • Remote control sensor. c Display panel • Show current status. d MP3 LINK • Jack for an external audio device. • Headphone jack. • USB socket. g SOURCE • Select a source: Disc, USB, FM tuner, or MP3 link.
p FM antenna • Improve FM reception. q AC MAINS~ • Power cord socket. Overview of the remote control USB MP3 LINK REP ALL SHUF a POWER • Turn on the unit, or switch to standby mode. b Source selection keys (DISC, TUN, USB,MP3 LINK) •...
e TIMER • Set the alarm timer. • Search within a track/ disc/USB. • Tune to a radio station. • Adjust time. • Skip to the previous/next track. h DBB • Turns on or off dynamic bass enhancement. • Stop play or erase a program. j VOL +/- •...
Always follow the instructions in this chapter in sequence. If you contact Philips, you will be asked for the model and serial number of this apparatus. The model number and serial number are on the rear of the apparatus. Write the numbers here: Model No.
Note • If you are not going to use the remote control for a long time, remove the batteries. • Do not use old and new or different types of batteries in combination. • Batteries contain chemical substances, so they should be disposed of properly.
5 Play Play discs Press DISC to select the disc source. Press to open the disc compartment. Insert a disc with the printed side facing up, then close the disc door. Play starts automatically. » Play from USB Note • Ensure that the USB device contains playable audio contents for supported formats (see ‘USB playability information’...
Repeat play Play a track repeatedly During play, press REP. » [REP] (repeat) is displayed: the current track is played repeatedly. To return to normal play, press REP again. Play all tracks or an album repeatedly During play, press REP ALL repeatedly to select: »...
Program radio stations manually Note • You can program a maximum of 20 preset radio stations. Tune to a radio station. Press PROG to activate program mode. » [PROG] (program) blinks on the display. Press ALB/PRESET+/- to allocate a number (1 to 20) to this radio station, then press PROG to confirm.
Set the sleep timer This unit can switch to standby automatically after a set period of time. When the unit is turned on, press SLEEP repeatedly to select a set period of time (in minutes). When sleep timer is activated, the »...
Total Harmonic Distortion < 3% Signal to Noise Ratio > 45 dBu Speakers Speaker Impedance 4ohm Speaker Driver 3.5” Sensitivity >82dB/m/W General information AC power 110 - 127/220-240 V, 50/60 Hz Operation Power Consumption 20 W Standby Power Consumption < 4 W USB Direct Version 2.0/1.1 Dimensions...
If you encounter problems when using this apparatus, check the following points before requesting service. If the problem remains unsolved, go to the Philips web site (www. philips.com/welcome). When you contact Philips, ensure that the apparatus is nearby and the model number and serial number are available.
