Summary of Contents for Samsung SVD-4600 SVD-4600
- Page 1 High Resolution Vandal-proof Dome Camera SVD-4600 User Guide Before installing and operating this product, please read this manual thoroughly. ENGLISH...
- Page 2 Before operating the camera, confirm the camera model and proper input power voltage. In order to that you can understand this manual thoroughly, we'll introduce our model description. n SVD-4600 SERIES • NTSC MODEL • PAL MODEL SVD-4600(W)N SVD-4600(W)P n MODEL DESCRIPTION • SVD-4600(W)X SIGNAL SYSTEM CAMERA COLOR • SIGNAL SYSTEM N → NTSC MODEL P → PAL MODEL • CAMERA COLOR...
-
Page 3: Table Of Contents
- 0.00004 Lux SSNR (Samsung Super Noise Reduction) Function The high performance SV-IV DSP chip dramatically reduces the gain noise in digital image processing, producing clear, sharp images in low lighting environments. -
Page 4: Precautions
Samsung Techwin cares for the environment at all product manufacturing stages to preserve the environment, and is taking a number of steps to provide customers with more environment-friendly products.The Eco mark represents Samsung Techwin’s will to create environment-friendly products, and indicates that the product satisfies the EU RoHS Directive. Warnings & Cautions This information is provided to ensure your safety and to prevent any losses, financial or otherwise. Please read it carefully and use the product accordingly. * F or product inquiries, please contact the retail shop where you bought the camera. The use of equipment such as an aerial ladder while providing after-sales service shall be at your expense. -
Page 5: Components And Accessories
Precautions Do not drop the camera or subject Never keep the camera face to them to physical shocks. strong light directly. It can cause malfunctions to occur. It can damage the CCD. Do not expose the camera to radioactivity. If it is exposed to radioactivity, For heated CCD, it will be out of order. -
Page 6: Connection
Overview Pan Base : control panning angle of camera ❶ Rotate Base : control rotating angle of camera X3.6 Vari-focal Lens Module Rotate Base Holding Screw : fix rotated position Pan Base Holding Screws (Color : Silver) : fix panned position RS-485 Control Cable : The detailed description refers to p12 Power Input Jack…... -
Page 7: Rs-485 Communication Control
WHITE(TRX-) Using a RS-485 communication, it will be able to control the OSD menu at the SAMSUNG TECHWIN System Controller or DVR. (1) The case which it controls from the PC Using a RS-485 converter, It connects to RS-485 control cable outside camera and serial cable EX) SERIAL PORT OF THE PC(COM1) →... -
Page 8: Special
Operating Your Camera 1. Press the Function Setup switch. • Main setup menu is displayed on the monitor screen. MAIN SETUP Select the function by moving 1.LENS up or down direction of 2.EXPOSURE function setup switch. 3.WHITE BAL 4.BACKLIGHT 5.SSNR 6.DAY/NIGHT AUTO 7.IMAGE ADJ 8.SPECIAL 9.EXIT 2. - Page 9 Operating Your Camera AGC (AUTO GAIN CONTROL) : The higher the gain level, the brighter the screen - but the higher the noise. - OFF : Deactivates the AGC function. - LOW : Allows automatic gain control from 5.3dB to 30dB. - HIGH : Allows automatic gain control from 5.3dB to 42dB.
- Page 10 Operating Your Camera BACKLIGHT This camera is designed so that it delivers a distinctive subject and background at the same time, even when the subject is in backlight, unlike conventional cameras, by adopting a proprietary SV-IV DSP chip. 1. When the SETUP menu screen is displayed, select ‘BACKLIGHT’...
- Page 11 Operating Your Camera SSNR This function reduces the background noise in a low luminance environment. 1. When the SETUP menu screen is displayed, select ‘SSNR’ by using the Function Setup switch so that the arrow indicates ‘SSNR’ . MAIN SETUP 1.LENS 2.EXPOSURE 3.WHITE BAL...
- Page 12 Operating Your Camera Color →… →… Color Fast 2.5 lux 4 lux * The brightness of illumination is changeable Slow 0.8 lux 6 lux by installed environment. EXTERN : This mode allows you to apply a desired filter to external signals. Notes • Y ou cannot control the DAY/NIGHT menu when AGC in the EXPOSURE menu is ‘OFF’.
- Page 13 Operating Your Camera SPECIAL 1. When the SETUP menu screen is displayed, select ‘SPECIAL’ by using the Function Setup switch so that the arrow indicates ‘SPECIAL’. MAIN SETUP 1.LENS 2.EXPOSURE 3.WHITE BAL 4.BACKLIGHT 5.SSNR 6.DAY/NIGHT AUTO 7.IMAGE ADJ 8.SPECIAL 9.EXIT 2.
- Page 14 Operating Your Camera SYNC : In areas where the supply is at 60Hz, you can synchronize the output phase of multiple cameras using the power synchronization function (Line- Lock) without using a synchronization signal generator. - INT : Internal Synchronization Type - L/L : Power Synchronization Type, Line-lock •...
-
Page 15: Troubleshooting
Operating Your Camera COMM ADJ (Communication Adjustment) : This function sets up the camera communication status when controlling the camera through an external control device. …… W hen the SPECIAL menu screen is displayed, press the Function Setup ❶ switch so that the arrow indicates ‘COMM ADJ’. …Set up the mode using the Function Setup switch. -
Page 16: Specification
H : 15.625KHz / V : 50.00Hz English, French, Germany, Spanish, European Representative Name Italy, Chinese, Portuguese European Representative Address Equipment Type/Environment Fixed (1/50 or Flickerless Mode) Model Name Beginning Serial NO. Year of Manufacture Conformance to We, the undersigned, hereby declare that the equipment specified above conforms to the above Directive(s). Manufacturer SAMSUNG TECHWIN CO., LTD Signature 85mm Full Name Position 83.5mm Place Date 85mm DECLARATION OF CONFORMITY 89 / 336 / EEC SAMSUNG TECHWIN CO., LTD SAMSUNG TECHWIN CO., LTD... - Page 17 Tol Free : +1-877-213-1222 FAX : +1-310-632-2195 www.samsungcctvusa.com www.samsungtechwin.com www.samsungcctv.com SAMSUNG TECHWIN EUROPE CO., LTD. • Samsung House, 1000 Hillswood Drive, Hillswood Business Park Chertsey, Surrey, UNITED KINGDOM KT16 OPS TEL : +44-1932-45-5300 FAX : +44-1932-45-5325 P/No. : Z6806-0869-01C VAN 09. 10...
