Electrolux E900 User Maintenance Manual

3
2
1
5
4
1
Satin-finish Steel Surfaces (including the Lid)
Remove grime, fat and other cooking residuals from steel surfaces
when cool using soapy water, with or without detergent, and a
cloth or a sponge. Dry the surfaces thoroughly after cleaning.
2
Other surfaces (Knob)
Clean plastic parts only with nonaggressive detergents.
Stop immediately using those products if detecting any visual
or tactile characteristic change on surfaces and thoroughly
rinse with water (examples: plastic discoloring/melting/other).
Carefully dry after rinsing.
3
Vessel
Remove any cooking residuals and starch from tank and baskets
using boiled water and a degreasing cleaning agent if necessary.
Rinse thoroughly with fresh water to completely eliminate chemical
residues and dry carefully for preventing any liquid stagnation.
Vessel descaling (wear personal protections!)
Descale the appliance with a solution of 10% vinegar, 10%
phosphoric acid (or a suitable descaling solution available for
purchase).
Cleaning external surfaces
Wash the external surfaces with warm, soapy water. Avoid using detergents containing abrasive substances, steel wool, brushes or steel scrapers. Rinse with a
damp cloth and dry carefully. Avoid using chlorine or ammonia-based products. Clean the control panel with a soft cloth dampened with water and, if necessary
with neutral detergent. Do not wash the equipment with direct or high pressure jets of water. With the aim of reducing the emission of polluting substances into
the atmosphere, it is advisable to clean the equipment (externally and, when necessary, internally) with products that have a biodegradability exceeding 90%.
Electrolux Professional strongly recommends to use Electrolux Professional approved cleaning agents, rinse and descaling agents to obtain better results and
maintain product efficiency over time. Damages caused by cleaning, as a consequence of use of not approved cleaning agents, rinse and descaling, will be
excluded by the warranty.
The operations described must be performed wearing the needed Personal Protection Equipment. Refer to the User Manual.
05UMA19F_O__ENG0
Boiling Pan
E900
User maintenance guide
3
2
1
2
5
4
Never use steel-wool or other abrasive materials which can
scratch the surface of the stainless steel.
daily
4
Drain Tap with metal seal
Dismantle the drain tap:
0. Using the Allen key supplied, loosen the threaded grain
of the lower ring nut.
daily
1. Unscrew the lower ring nut of the tap.
2. Turn the tap clockwise until it reaches the unlock position.
3. Lift the inner assembly (conical part) with the handle.
Clean the tap with a mild cleaning agent, then rinse
with fresh water and dry it. Grease the tap with 0G5344
(lubricant for taps with metal seal). Reassemble the
tap by carrying out operations 0, 1, 2 and 3 in reverse
daily order.
Jacket water level check (manual indirectly
5
heated model)
First open the upper tap then the lower one. Check that
a uniform flow of water comes out of the lower tap for a
1 few seconds. If the water flow is not uniform, top up the
per
level following the instructions in the user manual: use only
month
demineralized water.
Essentia
3
1
5
4
daily
1
per
week
2021-06-28
Performance maintenance programmes
In order to ensure the safety and performance of your equipment,
it is recommended that service is undertaken by Electrolux
Professional authorised engineers every 12 months, in
accordance with the manufacturer indications.
Please contact your local Electrolux Professional Service
Centre for details on the maintenance agreement.
Suggested for you
For more Accessories & Consumables
please look at our Catalogues or contact
our Electrolux Professional Service Partner.
0S2227
Drain Tap
006101
Water additive
against corrosion
5 pcs
0CC039
150 LT
100 LT 60 LT 150LT 100LT 60LT
150 LT 100 LT
60 LT
Measuring rod
60LT
0CC040
Measuring rod
100LT
0CC041
Measuring rod
150LT
150 LT
100 LT 60 LT
150 LT
100 LT
60 LT
0G5344
Grease
20GR
for drain tap
metal seal
0CC045
Trolley with
lifting &
removable
tank
0CC043
2Section
universal
basket
for 150LT pans
0CC044
2Section
universal
basket
for 100LT pans
