- Page 1 EHI3251BE,EHI635BE, EHI977BE Induction hob Installation & User manual...
- Page 2 Customer Care Center...
- Page 4 PRODUCT DESCRIPTION EHI3251BE Induction cooking zone Induction cooking zone Control panel...
- Page 5 PRODUCT DESCRIPTION EHI635BE Induction cooking zone Induction cooking zone Induction cooking zone Control panel Induction cooking zone EHI977BE Induction cooking zone Induction cooking zone Induction cooking zone Induction cooking zone Control panel Induction cooking zone...
- Page 6 Control panel layouts EHI3251BE Sensor field Function To activate and deactivate the appliance To lock / unlock the control panel Sets all operating zones to a keep warm setting To activate the Bridge function To activate and deactivate the Child lock...
- Page 7 Control panel layouts EHI635BE Sensor field Function To activate and deactivate the appliance To lock / unlock the control panel Sets all operating zones to a keep warm setting To activate the Bridge function To activate and deactivate the manual mode of the Hob2Hood function.
- Page 8 PRODUCT DESCRIPTION (CONTINUED) Control panel layouts EHI977BE Sensor field Function To activate and deactivate the appliance To activate the chef function To activate the Sensefry function To increase or decrease the time To set the timer function To activate and deactivate the manual mode of the Hood function.
- Page 9 Heat setting displays Display Description The cooking zone is deactivated The cooking zone operates Sets all operating zones to a keep warm setting The automatic heat up function operates Power function operates There is a malfunction + digit OptiHeat Control (3 step Residual heat indicator) : continue cook / stay warm / residual heat Lock / The child safety function operates Not correct cookware or too small or no cookware on the cooking zone The automatic switch off function operates...
- Page 10 OPERATING INSTRUCTIONS On and off Bridge function Touch for 1 second to activate or deactivate the IMPORTANT! appliance. Use the Bridge Function with the Infinite Plancha accessory Automatic switch off The Bridge Function connects the two left side cooking The function deactivates the appliance automatically if: zones under the accessory and they operate as one.
- Page 11 Automatic heat up Count down timer Use the Count Down Timer to set how long the cooking zone operates for one cooking session. Set the Count Down Timer after the selection of the cooking zone. You can set the heat setting before or after you set the timer.
- Page 12 . The heat setting and volume of what you are cooking. that you set before comes on. Automatic modes Lock Only for applies to EHI3251BE & EHI977BE When the cooking zones operate, you can lock the control Automatic Boiling Frying panel, but not .
- Page 13 only applies to EHI977BE Flexible Induction Cooking Area WARNING! Refer to Safety chapters. FlexiBridge function The flexible induction cooking area consists of four sections. The sections can be combined into two cooking zones with different size, or into one large cooking area. You choose the combination of the sections by choosing the mode applicable to the size of the cookware you want to use.
- Page 14 The power in the first cooking zone automatically decreases. The heat setting display for the reduced zone changes between two levels. Only for EHI3251BE The power management divides the power in all cooking zones (see the illustration). The power function increases the power to the maximum level for one cooking zone.
- Page 15 OPERATING INSTRUCTIONS (CONTINUED) Correct cookware position: Correct cookware position: To use this mode you have to place the cookware on the three connected sections. If you use cookware smaller than two sections the display shows and after 2 minutes the zone switches off. Incorrect cookware position: Incorrect cookware position: FlexiBridge big bridge mode...
- Page 16 Powerslide Function Correct cookware position: To use this mode you have to place the cookware on the This function allows you to adjust the temperature by four connected sections. If you use cookware smaller than moving the cookware to a different position on the three sections the display shows and after 2 minutes induction cooking area.
- Page 17 OPERATING INSTRUCTIONS (CONTINUED) Only for applies to EHI3251BE & EHI977BE • When you activate the function for the first time you SenseFry function will get heat setting for the front position, This function lets you set a heat setting level to fry the middle position and for the rear position.
- Page 18 HELPFUL HINTS AND TIPS Operating the fan speed manually Cookware is correct for an induction hob if: You can also operate the function manually. To do Find the right cookware that touch when the hob is active. This deactivates Only magnetic pots and pans work with induction. automatic operation of the function and allows you Check to see if your cookware is compatible: to change the fan speed manually.
- Page 19 To find the full range of rangehoods which work with this the cookware. The cookware with a smaller diameter than function refer to our consumer website. The Electrolux the minimum receives only a part of the power generated rangehoods that work with this function must have the by the cooking zone.
- Page 20 Examples of cooking applications The relation between the heat setting and the cooking zone consumption of power is not linear. When you increase the heat setting it is not proportional to the increase of the cooking zone consumption of power. It means that the cooking zone with the medium heat setting uses less than a half of its power.
- Page 21 HELPFUL HINTS AND TIPS (CONTINUED) Hints and Tips for Sensefry function Examples of cooking applications for the function The data in the tables shows examples of food for To achieve the best results with the function: each heat setting level. The amount, thickness, quality •...
- Page 22 IMPORTANT! Different sizes of pans can cause different heat up times. Heavy pans store more heat than the light pans but take more time to heat up. Correct pans for Fry Assist function Use only pans with flat bottom. To check if the pan is correct: Put your pan upside down.
- Page 23 CARE AND CLEANING Clean the appliance after each use. 2. R emove after the appliance is sufficiently cool: Always use cookware with clean bottom. limescale rings, water rings, fat, stains, shiny metallic discolourations. Use a special cleaning agent for glass ceramic or stainless steel.
- Page 24 TROUBLESHOOTING TROUBLESHOOTING Problem Possible cause Remedy Red rings, limescale or water Cooktop surface has not been cleaned Use a ceramic glass cleaner such rings, shiny metallic or other correctly. Cleaning/ maintenance of the as Cerapol. discolouration, scratches/ cooktop surface is not covered under shadows, bubbles or other warranty.
- Page 25 TROUBLESHOOTING The sensor fields The cookware is too large or you put it Put large cookware on the rear cooking zones if become hot. too near to the controls. necessary. There is no signal The signals are deactivated. Activate the signals when you touch the (refer to “OffSound control”).
- Page 26 16A 90°C (or higher) 3 x 1.5mm information below from the rating plate. The rating plate is breaker for EHI3251BE, 3 x 4mm2 with an all- on the bottom of the appliance casing. pole 32A breaker for EHI635BE,EHI977BE Model •...
- Page 27 125-145 Right rear 1800 W 2800 W 145-180 Flexible induction 2300 W 3400 W Minimum 100 cooking area EHI3251BE Induction 3.7kW Cooking Nominal Power Power Function Power function maximum Minimum zone (Max heat setting) (W) activated (W) duration (min) cookware...
- Page 28 NOTES...
- Page 29 NOTES...
- Page 30 NOTES...
- Page 31 Warranty...
- Page 32 Office Fax : (+65) 6727 3611 Email:customercare@electrolux.co.id SMS: 0812.8088.8863 Email : customer-care.sin@electrolux.com WA : 0811.8339.777 Consumer Care Tel : (+66 2) 725 9000 Electrolux Thailand Co., Ltd. Consumer Care Center Tel: 1300-88-11-22 Electrolux Electrolux Building 14th Floor Home Appliances Sdn. Bhd. Corporate Office Address: Unit...
