主な仕様
ト ラ ッ ク 方 式
: ステレオ
録 音 方 式
: AC バイアス
消 去 方 式
: マグネット消去
モ ニ タ ー 方 式
: バリアブル
周 波 数 範 囲
(ノーマルポジション)
再
生
: 40-16000Hz(EIAJ)
録 音 / 再 生
: 70-8000Hz(EIAJ)
入 力 端 子
マ
イ
ク
: 0.6mV(200-600 Ω)
(ステレオ M3 ジャック、 プラグインパワータイプ)
出 力 端 子
ヘ ッ ド ホ ン
: 50 Ω(ステレオ M3 ジャック)
ス ピ ー カ ー
: 3.6cm 丸型 6 Ω
実 用 最 大 出 力
(乾電池使用時)
ヘ ッ ド ホ ン
: 3 mW i 3 mW(EIAJ)
ス ピ ー カ ー
: 420 mW i 420 mW(EIAJ)
電
源
乾
電
池
: DC 3V(単 3 形乾電池× 2 個)
外 部 電 源
: DC 3V(別売り AC アダプター RP-AC31B 使用)
寸
法
最大外形寸法
: 115.7 (W)× 90.7 (H)× 38.2 (D) ㎜(EIAJ)
本 体 寸 法
: 113.0 (W)× 86.6 (H)× 38.0 (D) ㎜
質
量
:約 219 g (乾電池含む)
約 182 g (乾電池含まず)
電池持続時間(EIAJ)
使用乾電池
使用条件
録 音
インサイドホン
(ヘッドホン)使用
再生
スピーカー使用
電池持続時間は、使用条件によって短くなる場合があります。
●
この仕様は、性能向上のため変更することがあります。
●
停止時の消費電力:約 1.3W(AC のとき)
Operating Instructions
The numbers - B- refer to the illustration on page 2.
Power Sources
Dry cell batteries
Use the two R6/LR6 (UM-3) batteries.
When the batteries are weak, the B [電池
残量] lamps will turn off one by one.
AC adaptor
Connect the Panasonic AC adaptor (RP-
AC31B, not included) to @ [外部電源 DC
IN 3V K].
Tape Playback
1. Insert the tape.(You can use normal
position type tapes only.)
2. Slide up > [一時停止] to release
pause.
3. Set < [2 倍録音] to [標準] or [2 倍].
Use the same setting you used when
the recording was made.
4. Press 9 [ 1 再生] to start playback.
5. Adjust the volume with 5 [音量].
Recording
1. Insert the tape.(You can use normal
position type tapes only.)
2. Slide up > [一時停止] to release
pause.
3. Set < [2 倍録音] to [標準] or [2 倍].
標準:To record sound at a normal
speed
2 倍:To record about twice the length
of the tape for long meetings, etc.
4. Press 7 [¥ 録音] to start recording.
9 [ 1 再生] is also pressed with 7 [¥
録音].
Auto stop
During playback or recording, when the
tape reaches its end, the automatic stop
system will release 9 [ 1 再生] or 7 [¥ 録
音] and automatically turn off the unit.
■ To stop playback/recording
Press 8 [∫ 停止].
■To stop playback/recording
temporarily
Slide down > [一時停止].
To resume, slide up > [一時停止] again.
ナショナルネオ
パナソニック
《黒》乾電池
アルカリ乾電池
(R6PU)
(LR6)
約 6 時間 30 分
約 20 時間
約 7 時間 30 分
約 24 時間
約 3 時間
約 14 時間
■ To listen with an earphone
Connect the stereo earphones (included)
to 6 [Ë].
When playing the sound through the
earphones, volume can be adjusted with
5 [音量].
■How to use the tape counter ( 2 ) and
the reset button ( 1 )
The digits advance with the tape to
provide a reference to quickly find a
desired portion of tape.
The digits return to " 0 0 0 " when the reset
button is pressed.
■ To fast forward or rewind
Press : [ 6 巻戻し/レビュー] (rewind) or
; [ 5 早送り/キュー] (fast forward) in
the stop mode.
■ To cue and review
Sound can be monitored at a high speed
as long as : [ 6 巻戻し/レビュー]
(review) or ; [ 5 早送り/キュー] (cue) is
held down during playback.
When the button is released, normal
playback will start.
■ To change the playback speed
Adjust the speed with A [再生スピード].
■ Follow up recording
Recording can be started during playback
by simply pressing 7 [¥ 録音].
■ Quick review
The review operation is possible during
recording by pressing : [ 6 巻戻し/レ
ビュー], only the 7 [¥ 録音] will be
released, and playback begin.
■To record through an external
microphone
Plug the external microphone (included)
into 4 [ステレオマイク(プラグインパワ
ー)].
≥You can use a condenser microphone
with or without built-in power supply.
12
このたびは、ステレオカセットレ
コーダーをお買い上げいただき、
まことにありがとうございました。
■この取扱説明書と保証書をよく
お 読 み の う え 、 正 し く お 使 い
く だ さ い 。 そ の あ と 保 存 し 、
必要なときにお読みください。
■保証書は、 「お買い上げ日・販売
店名」などの記入を必ず確かめ、
販売店からお受け取りください。
保証書付き
上手に使って上手に節電
便利メモ(おぼえのため、記入されると便利です。 )
お買い上げ日
年 月 日 品 番
販 売 店 名
松下電器産業株式会社 オーディオ事業部
〒 571-8505 大阪府門真市松生町 1 番 4 号
Matsushita Electric Industrial Co., Ltd. Audio Division
1-4 Matsuo-cho, Kadoma City, Osaka, Japan 571-8505
C Matsushita Electric Industrial Co., Ltd. (松下電器産業株式会社) 1999
パナソニック音響製品保証書
本書はお買い上げの日から下記期間中故障が発生した
場合には本書裏面記載内容で無料修理を行なうことを
お約束するものです。詳細は裏面をご参照ください。
品 番
お買い上げ日から
保証期間
※
お買い上げ日
※
ご住所
お
客
お名前
様
電 話(
※
住所・氏名
販
売
店
電話(
松下電器産業株式会社 オーディオ事業部
〒 571-8505 大阪府門真市松生町 1 番 4 号 TEL (06) 6909-1021
ご販売店さまへ ※印欄は必ず記入してお渡しください。
ステレオカセットレコーダー
Stereo Cassette Recorder
取扱説明書
Operating Instructions
品番 RQ-L70
付属品
単 3 形乾電池 2 本
●
ハンドストラップ
●
(RKHT0001-K)
ステレオマイク
●
(RFEM302P)
ステレオインサイドホン
●
(RFEV324P-KS)
付 属 品 の 買 い 替 え は 、
お買い上げの販売店へご
相談ください。
かっこ内は、買い替え時の
品番を表します。
RQ-L70
i(
)
−
RQTT0377-S F1199KY0(D)
持込修理
RQ-L70
本体 1 年間
年 月 日
