DATA PROJECTOR
VPL-FH65
VPL-FH60
VPL-F635H
VPL-F630H
VPL-F535H
VPL-F530H
REMOTE COMMANDER
RM-PJ27
SERVICE MANUAL
1st Edition (Revised 1)

Advertisement

Table of Contents
loading

Related Manuals for Sony VPL-FH65

Summary of Contents for Sony VPL-FH65

  • Page 1 DATA PROJECTOR VPL-FH65 VPL-FH60 VPL-F635H VPL-F630H VPL-F535H VPL-F530H REMOTE COMMANDER RM-PJ27 SERVICE MANUAL 1st Edition (Revised 1)
  • Page 2 WARNUNG For kundene i Norge (VPL-FH65/FH60) Beim Einbau des Geräts ist daher im Festkabel ein leicht zugänglicher Unterbrecher einzufügen, Dette utstyret kan kobles til et IT-strømfordelingssystem.
  • Page 3 FÖRSIKTIGHET! 注意 指定以外の電池に交換すると，破裂する危険があり Fara för explosion vid felaktigt placerat batteri. ます。 Byt endast mot samma eller likvärdig typ av batteri, 必ず指定の電池に交換してください。 enligt tillverkarens rekommendationer. 使用済みの電池は，国または地域の法令に従って När du kasserar batteriet ska du följa rådande lagar 処理してください。 för regionen eller landet. CAUTION PAS PÅ...

  • Page 5: Table Of Contents

    Table of Contents Manual Structure 1-10. Function for Service (Network) ......1-46 (E) 1-10-1. Outline ............1-46 (E) Purpose of this manual ............3 (E) 1-10-2. Connection Procedure ........1-46 (E) 1-10-3. Update Function ..........1-47 (E) Related manuals ..............3 (E) 1-10-4. Setup Function ..........1-51 (E) Trademarks ................
  • Page 6 2-5-6. Writing of Main/Prism/3DGamma (UF Level)/ LookUpTable (CS)/Chiral/GCFB/ VCS Gain Data ..........2-17 (E) 2-5-7. Writing of DDC Data ........2-18 (E) 2-5-8. Writing of NVM Data ........2-19 (E) 2-5-9. Writing of Unit/CSCO Data ......2-20 (E) 2-6. Adjustment Item Initialize Data ......2-21 (E) 2-6-1.

  • Page 7: Manual Structure

    Manual Structure Purpose of this manual This manual is the Service Manual of the Data Projector VPL-FH65/FH60/F630H/ F635H/F530H/F535H. This manual describes the information on the premise of providing the block level service (such as service overview, adjustment, spare parts and block diagrams).

  • Page 9: Service Overview

    Section 1 Service Overview 1-1. Precautions for Service Personnel 1-1-1. Precautions during Service Do not remove the lens when the set is lighting. Otherwise, it may cause damage to eyes or skin. 1-1-2. About the Serial Number of This Unit In some parts of this manual, this unit is classified by the serial number, which is described as “Group A”...

  • Page 10: Appearance Figure

    1-2. Appearance Figure 1-2 (E) VPL-FH60...

  • Page 11: Precaution For Transport

    1-3. Precaution for Transport When transporting this unit, be sure to attach the packing cap. 1. Turn on the power of this unit. 2. Press the [SHIFT] button of this unit or the [LENS|SHIFT] button of the remote control, then press the [RESET] button of the remote control.

  • Page 12: Board Location

    1-4. Board Location C board TL board SB board U board H board NF board Q board TA board V board AR board MX board 1-5. Tightening Torque Tighten the each screw with the torque below. . B2 x 5: 0.20 ?0.02 N.m .

  • Page 13: Disassembly

    1-6. Disassembly Do not remove the lens when the set is lighting. Otherwise, it may cause damage to eyes or skin. 1-6-2. Lens Assembly 1-6-1. Electrostatic Filter Assembly 1-6-3. Rear Cover Assembly and Lens Cover Assembly 1-6-4. Lamp Assembly 1-6-6. C Board 1-6-5.
  • Page 14 1-6-13. Power Unit (Lamp) 1-6-14. Power Unit (G Board) 1-6-10. Q Board and MX Board 1-6-7. DC Fan (For Lamp Exhaust) and TL Board 1-6-12. DC Fan (For Power Supply) and NF Board 1-6-11. Optical Block Assembly 1-6-15. U Board 1-6 (E) VPL-FH60...
  • Page 15 1-6-16. PS Assembly 1-6-17. In-polarizer (R)/(G)/(B) 1-6-18. Shift Unit Assembly, Assemblies Prism Block Assembly, Unit Assembly and 4P Output Glass Assembly 1-7 (E) VPL-FH60...

  • Page 16: Electrostatic Filter Assembly

    1-6-1. Electrostatic Filter Assembly Preparation 1. Place this unit with the bottom side facing upward. 2. Open the terminal cover. 5 Strap Terminal cover 4 Nylon rivet Bottom side 0 Electrostatic filter UNLOCK LOCK 7 Two screws (with drop-safe) 2 Slide to the “UNLOCK”...

  • Page 17: Lens Assembly

    1-6-2. Lens Assembly For the removal procedure of the lens assembly, refer to Section 1-7. Lens assembly 1-6-3. Rear Cover Assembly and Lens Cover Assembly 4 Strap 3 Nylon rivet 2 Rear cover assembly 1 Three screws (with drop-safe) 4 Strap 6 Lens cover assembly 5 Two screws (with drop-safe) 1-9 (E)

  • Page 18: Lamp Assembly

    1-6-4. Lamp Assembly Front side 3 Lamp assembly Lamp connector assembly 2 Two screws (with drop-safe) When attaching the lamp assembly, insert it into the lamp connector 1 Screw (with drop-safe) assembly securely. 1-10 (E) VPL-FH60...

  • Page 19: Top Cover Assembly And H Board

    1-6-5. Top Cover Assembly and H Board 4 Top cover assembly H board 3 Harness 2 Screw (BVTP3 Slightly lift up the top cover assembly slowly and disconnect the harness from the connector (CN3000) on the H board. 1 Eight screws (BVTP3 Bottom side 1-11 (E)
  • Page 20 Top cover assembly 8 Button (ARROW) 7 H board 6 Holder (H) 5 Nylon rivet 9 Button (H) 1-12 (E) VPL-FH60...

  • Page 21: C Board

    1-6-6. C Board Perform step 1 in Section 2-2-3 before replacing the C board, and perform steps 3 to 5 after replacement. Group A C board (Side A) CN103 (To the power unit) CN107 (To the TL board) CN102 (To the power unit) CN104 CN2503 (To the fuse)
  • Page 22 1 Eight screws (PSW3 2 Bracket (C TOP) CN1500, CN1600, CN1700/C board (Side A) Pull out the two hooks in the direction of the 0 Three radiation sheets 9 Two radiation sheets (large) arrow A, then remove the flexible flat cable in (small) the direction of the arrow B.
  • Page 23 Group B C board (Side A) CN2300 (To the laser source unit) CN103 (To the power unit) CN107 (To the laser source unit) CN102 (To the power unit) CN104 CN2503 (To the fuse) (To the fan 4 and fan 5) CN105 CN110 (To the U board)
  • Page 24 1 Screw (PSW3 3 Seven screws (PSW3 2 Ground wire 4 Bracket (C TOP) CN1500, CN1600, CN1700/C board (Side A) Pull out the two hooks in the direction of the ![ Three radiation sheets != Two radiation sheets (large) arrow A, then remove the flexible flat cable in (small) the direction of the arrow B.

  • Page 25: Dc Fan (For Lamp Exhaust) And Tl Board

    1-6-7. DC Fan (For Lamp Exhaust) and TL Board 1 Relay connector 6 Four screws 3 Remove the harness (BVTP3 from the two hooks. 2 Relay connector 9 Lamp house top 7 Screw (BVTP3 To the C board 4 Remove the harness from the two hooks 5 Harness !\ TL board...

  • Page 26: Dc Fan (For Air Intake) And V Board

    (BVTP3 2 Bracket (C A) 3 Two screws (BVTP3 4 Lamp duct assembly 6 Two screws (BVTP3 To the C board VPL-FH65/ VPL-FH60/F530H/ 5 Relay connector F630H/F635H F535H 8 Four screws 7 Fan 6 (BVTP3 Attach the fan 6 so that...
  • Page 27 Two harnesses To the C board @/ Screw Hooks (BVTP3 != Relay connector Attach the fan 2 and fan 3 by fixing the harnesses with the hooks. !. Harness To the C board @- V board !] Fan 3 !- Relay connector Attach the fan 3 so that the label side faces as shown in the illustration.

  • Page 28: Ta Board

    1-6-9. TA Board 2 Case (FILTER TOP) To the C board 1 Five screws (BVTP3 Harnesses 4 Harness Groove To the C board 6 TA board portion 5 Screw (BVTP3 Assemble the case (FILTER TOP) and case (FILTER BOTTOM) by passing the harnesses through the groove portion.

  • Page 29: Q Board And Mx Board

    1-6-10. Q Board and MX Board . When replacing the Q board, perform the procedure in Section 2-2-6. . When replacing the MX board, perform the procedure in Section 2-2-7. 5 Seven screws (PSW3 6 Two screws (PSW3 !- Three screws (PSW3 1 Three screws (PSW3...

  • Page 30: Optical Block Assembly

    1-6-11. Optical Block Assembly 3 Three screws (PSW3 4 Bracket (C B) 5 Three screws (BVTP3 6 Screw 1 Remove the two clampers. (PSW3 7 Optical block assembly 2 Remove the four harnesses. 1-22 (E) VPL-FH60...

  • Page 31: Dc Fan (For Power Supply) And Nf Board

    1-6-12. DC Fan (For Power Supply) and NF Board 1 Four screws 2 Lens side cover (BVTP3 3 Two screws (BVTP3 To the C board 4 Relay connectors 5 Two screws (PSW3 6 Fan 7 ![ NF board 9 Harness != Holder (LED) !- Nylon rivet Label side...

  • Page 32: Power Unit (Lamp)

    1-6-13. Power Unit (Lamp) VPL-FH65/F630H/F635H 1 Remove the two clampers. !\ Duct (BALLAST TOP) !] Open the slide clamp and remove the harness. !, Blacket (BALLAST) !. Two screws (BVTP3 @= Power unit (lamp) !' Harness To the power unit (G board) 2 Remove the four harnesses.

  • Page 33: Power Unit (G Board)

    1-6-14. Power Unit (G Board) 1 Open the wire saddle and remove the two harnesses. 2 Two screws To the C board (PSW3 5 Two harnesses CN401 CN301 7 Power unit (G board) 3 Holder (G) 4 Bracket (G TOP) 6 Two screws (PSW3 8 Bracket (G BOTTOM)

  • Page 34: U Board

    1-6-15. U Board Hook VPL-FH60/F530H/F535H Route the harness of the U board as shown in the illustration. VPL-FH65/F630H/F635H Hook 1 Harness 1 Harness Rear side Rear side 2 Screw (BVTP3 3 Holder (U) PND 4 U board 1 Harness 1-26 (E)

  • Page 35: Ps Assembly

    1-6-16. PS Assembly VPL-FH65/F630H/F635H 1 PSC spring cover Marking 2 PS assembly Inorganic phase Attach the PS assembly so that the difference plate assembly marking is placed in the direction as shown in the illustration. VPL-FH60/F530H/F535H Unit assembly PS assembly...

  • Page 36: In-Polarizer (R)/(G)/(B) Assemblies

    1-6-17. In-polarizer (R)/(G)/(B) Assemblies 1 Screw 3 Screw 4 In-polarizer (G) assembly 5 Screw 2 In-polarizer (B) assembly 6 In-polarizer (R) assembly If the screw is tightened strongly from the beginning, the in-polarizer is moved and the misalignment of angle occurs. When tightening the screw, hold the adjustment knob firmly and lightly tighten the screw at first.
  • Page 37 1-6-18. Shift Unit Assembly/Prism Block Assembly/Unit Assembly/4P Output Glass Assembly . When replacing the unit assembly, perform the procedure in Section 2-2-1. . When replacing the prism block assembly, perform the procedure in Section 2-2-2. Group A 2 Two screws (PSW3 To the C board 1 Harness...
  • Page 38 Group B 2 Two screws (PSW3 To the C board 1 Harness To the C board 3 Two screws (PSW3 6 Prism block assembly To the C board 8 Harness 5 Three screws 4 Unit assembly (PSW3 7 4P output glass assembly 9 Shift unit assembly To the C board To the C board...

  • Page 39: Installation/Removal Of Lens Assembly

    1-7. Installation/Removal of Lens Assembly . Be careful not to drop the lens assembly. . Do not touch the lens assembly portion. . Do not work with this unit suspended from the ceiling. Removal The lens assembly cannot be removed unless it is returned to the center position. [LENS|RELEASE] button Lens assembly 1.
  • Page 40 Installation 1. Attach the lens assembly with its marking line facing upper side of this unit, then insert it all the way Upper side of this unit Marking line Lens assembly 2. Rotate the lens assembly in the clockwise direction (2) until it clicks. When attaching the lens assembly, do not press the [LENS|RELEASE] button.

  • Page 41: Auto Filter Cleaning Function

    1-8. Auto Filter Cleaning Function This unit is equipped with the plunger solenoid by which cleaning of the electrostatic filter is performed automatically when the power of this unit is turned off. This function is operated only when the power of this unit is turned off.
  • Page 42 Replacement of plunger solenoid 1. Remove the side cover. (Refer to steps 1 to 3 in Section 1-6-1.) 2. Remove the lens assembly. (Refer to Section 1-6-2.) 3. Remove the rear cover assembly and lens cover assembly. (Refer to Section 1-6-3.) 4.
  • Page 43 9. Remove the five screws, then remove the case (FILTER TOP). Case (FILTER TOP) BVTP 1-35 (E) VPL-FH60...
  • Page 44 10. Remove the four screws, then remove the solenoid block. BVTP Solenoid block Case (FILTER TOP) 11. Remove the four screws, then remove the plate solenoid. Plate (solenoid) Plunger solenoid 1-36 (E) VPL-FH60...
  • Page 45 12. Attach the cushion (solenoid) to the new plunger solenoid. The following part cannot be reused. When replacing the plunger solenoid, prepare the new part. . Cushion (solenoid): Part number 4-574-597-01 Plunger solenoid Cushion (solenoid) 13. Perform steps 1 to 11 in the reverse order to attach the plunger solenoid. 1-37 (E) VPL-FH60...

  • Page 46: Cleaning

    1-9. Cleaning The dust and dirt entered inside of this unit and adhered to the surface of the optical parts may cause the degradation of luminance, screen discoloration, etc. In such a case, perform the cleaning as required. 1-9-1. Optical Block Assembly Require items Air blower, brush Preparation...
  • Page 47 Procedure 1. Blow off the dust and dirt adhered to the surface of the in-polarizer (G) assembly and in-polarizer (B) assembly using the air dust spray. 2. Perform the cleaning of the in-polarizer (R) assembly. The in-polarizer (R) assembly uses the organic polarizing film. Therefore, you can wipe off the dust and dirt on it.

  • Page 48: Illumination System Optical Parts

    3. Attach the in-polarizer (R)/(G)/(B) assemblies. The in-polarizer (R)/(G)/(B) assemblies do not require adjustment. Attach the in-polarizer (R)/(G)/(B) assemblies so that each screw is located in the center of the elon- gate hole. In-polarizer (G) assembly The screw is located in the center of the elongate hole.
  • Page 49 Procedure 1. Remove the two hooks, then remove the dust cover (MIRROR). 2. Remove the five screws, then remove the unit cover. 3. Remove the B transmission dichroic mirror, G reflection dichroic mirror and R channel mirror. 4. Wipe off the dust and dirt adhered to the removed optical parts on both sides with the tissue paper dampened with drinking water.

  • Page 50: Ps Converter, First Fly-Eye Lens And Second Fly-Eye Lens

    5. Blow off the dust and dirt adhered to the optical parts that are not removed from the unit using the air dust spray. 6. Sweep out the dust and dirt adhered to the parts using the brush being careful not to touch the B channel mirror.
  • Page 51 Procedure 1. Remove the hook, then remove the PS spring cover. 2. Remove the PS converter. VPL-FH65/F630H/F635H PS spring cover Marking PS converter VPL-FH60/F530H/F535H Hook First fly-eye lens Second fly-eye lens PS converter 1 Wipe one side. 2 Wipe the other side.

  • Page 52: Prism Assembly

    3. Wipe off the dust and dirt adhered to the PS converter on both sides with the tissue paper dampened with drinking water or with the cotton swab. 4. Blow off the dust and dirt adhered to the first fly-eye lens and the second fly-eye lens. 5.
  • Page 53 Group B Do not remove the SC assembly. 1. Blow off the dust and dirt adhered to the portions A (liquid crystal plate and out-polarizer) using the air dust spray or blower. Portions A Prism assembly (top view) SC assembly 1-45 (E) VPL-FH60...

  • Page 54: Function For Service (Network)

    1-10. Function for Service (Network) 1-10-1. Outline This unit is provided with a network terminal. Using a Web browser, it can check the state of a projector and control and set the network blocks. Additionally, this unit has Update function through a network as a service-dedicated function. .

  • Page 55: Update Function

    . User name: service . Password: (model name in half-width lowercase characters) Example) vpl-fh65, vpl-f635h, etc. When moving from the service mode to other page and entering the service mode again, close the Web browser once, and then start the browser again.
  • Page 56 2. Procedure (1) Check the network setting of this unit. (Refer to “2. Connection of this unit and PC” and “3. Check of IP address” in Section 1-10-2.) (2) Type the following in the address bar of the Web browser. IPv4: http:// (IP address of this unit)/ update/ IPv6: http:// [xxxx:xxxx:~xxxx]/ update/ (3) Type the user name and password.
  • Page 57 Example of Web page during upload Completion of upload → Example of Web page during update After waiting for a while, the Web page is updated and the completion message is displayed. It takes about 1 hour to complete all updates. 1-49 (E) VPL-FH60...
  • Page 58 Example of web page for completion of upload Update Status When the update is properly executed, the following is displayed in Update Status. status update_status complete message success progress 100% updating Only when the C board of the repair part number: Suffix -B (board part number: Suffix -21) is not installed in the unit in group A (7) Disconnect the power cord from this unit.

  • Page 59: Setup Function

    1-10-4. Setup Function 1. Outline This unit is provided with the setup page to perform the various settings of the network block via the Web browser. The user can set the access authority to the setup page. If the user has forgotten the password of the access author- ity, change the password in the following procedure and notify the user that the password has been changed.
  • Page 60 (6) Change the password of Administrator. 1-52 (E) VPL-FH60...

  • Page 61: Indicator Display

    1-11. Indicator Display In this unit, the error state is indicated by the blinking of indicators. The ON/STANDBY indicator and WARNING indicator are installed in the top cover assembly. The content of error varies depending on the blinking state of indicators. For details, refer to the following. ON/STANDBY WARNING indicator...
  • Page 62 The ON/STANDBY indicator stays lit in red. The WARNING indicator blinks in red. (Stays lit in red.) (Blinks in red.) Error Number of blinking Details of the error content Cover error The filter has come off. The top cover has come off. Light source error The light source does not light up normally.

  • Page 63: Circuit Description

    1-12. Circuit Description 1-12-1. Video/Audio Signal Processing Board Q board The Q board mounts all external input/output connectors. The mounted connectors are as follows: . RS-232C input . VGA (D-sub 15-pin) input . VGA (D-sub 15-pin) output . DVI input .

  • Page 64: Sensor Boards

    1-12-3. Sensor Boards NF board The NF board mounts the photo-sensing block of a Front SIRCS signal and an LED indicator. U board The U board mounts the photo-sensing block of a Rear SIRCS signal, a top cover detection block and installation angle sensor.

  • Page 65: Power Supply Board

    It drives the lamp by a voltage of 380 V supplied from the G board. 1-13. Power Cord To get a power cord, please contact your local Sony Sales Office/Service Center. Use the approved Power Cord (3-core mains lead)/Appliance Connector/Plug with earthing-contacts that conforms to the safety regulations of each country if applicable.

  • Page 67: Adjustments

    Otherwise, it may cause damage to eyes or skin. 2-2. Procedure When Replacing the Parts For obtaining the data released for service, contact your local Sony Sales Office/Service Center. 2-2-1. Unit Assembly When replacing the unit assembly, perform the following procedure.

  • Page 68: C Board

    2-2-3. C Board When replacing the C board, perform the following procedure. 1. Save the Main data and NVM (All) data before replacement of the C board using Quick Access3. (Refer to Sections 2-5-2 and 2-5-4.) 2. Replace the C board. (Refer to Section 1-6-6.) 3.

  • Page 69: Electrical Adjustment

    The message “Do you want to enter the Service Mode? [Yes] [No]” appears. Select [Yes] and press the [ENTER] button. In the case that the main version is v1.40.0 or later For details on how to enter the service mode, contact your local Sony Sales Office/Service Center. 2-3 (E) VPL-FH60...
  • Page 70 How to enter the advanced user mode The Main version can be checked in the same procedure as described in the “How to enter the service mode”. 1. Press the [MENU] button. The menu appears. 2. Set the Status to “On” in the Operation menu. 3.

  • Page 71: Com Adjustment

    2-3-2. V COM Adjustment 1. Enter the service mode. (Refer to Section 2-3-1.) 2. Select the menus in the following order: Device → Other → 07 Other/Pattern Enb. Then, set the value to “1”. 3. Select the menus in the following order: Device → Panel Driver → 04 P.Drv/V Common R, and adjust using [&] and [*] the value so that the flicker is minimum.
  • Page 72 2. INPUT A Color Temperature: 7500K (1) Select the menus in service mode: Device → W/B → Middle. (2) Input the 80% flat field computer signal to the INPUT A. (3) Adjust the GAIN R, GAIN B, and GAIN G until the target chromaticity. Target chromaticity (x, y): 0.297, 0.306 (4) Change the input signal to the 30% flat field computer signal.
  • Page 73 5. VIDEO IN Color Temperature: 7500K (1) Select the menus in service mode: Device → W/B → Middle. (2) Copy the adjusted values of GAIN R/B/G and BIAS R/B/G in “2. INPUT A Color Temperature: Middle” to each item. (3) Input the 10 step video signal to the VIDEO IN, then perform the virtual check the chromaticity of each step.

  • Page 74: Software Update

    . ProjectorUpdateTool_V1.00.zip - ProjectorUpdateTool_OperationManual(J).doc - ProjectorUpdateTool_OperationManual(E).doc For obtaining the each version upgrade file, contact your local Sony Sales Office/Service Center. . USB memory: Compatible with USB 2.0 (Free space of 64 MB or more, FAT format (except for exFAT)) Connection .
  • Page 75 RS-232C connection Terminal cover Bottom side RS-232C RS-232C cross cable USB-RS-232C dual connection Terminal cover Bottom side USB-B USB sheet RS-232C RS-232C cross cable USB cable 2-9 (E) VPL-FH60...

  • Page 76: Procedure For Updating All Cpus Collectively

    6. Connect this unit with PC by RS-232C or USB-RS-232C dual, referring to the “Connection” in this section. 2-4-2. Procedure for Updating All CPUs Collectively When updating all CPUs collectively, contact your local Sony Sales Office/Service Center. 2-10 (E) VPL-FH60...

  • Page 77: Main (Scan Converter)

    Update using the USB memory 1. Copy the file to be written in the root folder of the USB memory. For the software to be written, contact your local Sony Sales Office/Service Center. 2. Connect the USB memory to this unit.

  • Page 78: Sub

    Perform the procedure with the USB memory connection. 1. Copy the file to be written in the root folder of the USB memory. For the software to be written, contact your local Sony Sales Office/Service Center. 2. Connect the USB memory to this unit.

  • Page 79: Quick Access3

    2-5. Quick Access3 2-5-1. Preparation Required equipment/Tools . Personal computer (PC): RS-232C interface equipped . RS-232C cross cable . QuickAccess3: Executable: QuickAccess3.exe Preparation 1. Install the QuickAccess3 in PC. 2. Connect this unit with PC. (Refer to RS-232C connection in Section 2-4-1.) 2-5-2.

  • Page 80: Saving Of Ddc Data

    2-5-3. Saving of DDC Data 1. Connect the power cord and set this unit to standby state. 2. Press the [I/O] button on this unit. The lamp lights and the image is displayed. 3. Double-click QuickAccess3.exe to start the application. 4.

  • Page 81: Saving Of Nvm Data

    2-5-4. Saving of NVM Data 1. Connect the power cord and set this unit to standby state. 2. Double-click QuickAccess3.exe to start the application. 3. Select a target model on the Model pull-down menu. 4. Select Read from Projector on the Read/Write pull-down menu. 5.

  • Page 82: Saving Of Unit/Csco Data

    2-5-5. Saving of Unit/CSCO Data 1. Connect the power cord and set this unit to standby state. 2. Double-click QuickAccess3.exe to start the application. 3. Select a target model on the Model pull-down menu. 4. Select Read from Projector on the Read/Write pull-down menu. 5.

  • Page 83: Writing Of Main/Prism/3Dgamma (Uf Level)

    2-5-6. Writing of Main/Prism/3DGamma (UF Level)/LookUpTable (CS)/Chiral/GCFB/ VCS Gain Data 1. Connect the power cord and set this unit to standby state. 2. Press the [I/O] button on this unit. The lamp lights and the image is displayed. 3. Double-click QuickAccess3.exe to start the application. 4.

  • Page 84: Writing Of Ddc Data

    2-5-7. Writing of DDC Data 1. Connect the power cord and set this unit to standby state. 2. Press the [I/O] button on this unit. The lamp lights and the image is displayed. 3. Double-click QuickAccess3.exe to start the application. 4.

  • Page 85: Writing Of Nvm Data

    2-5-8. Writing of NVM Data 1. Connect the power cord and set this unit to standby state. 2. Double-click QuickAccess3.exe to start the application. 3. Select a target model on the Model pull-down menu. 4. Select Write on the Read/Write pull-down menu. 5.

  • Page 86: Writing Of Unit/Csco Data

    2-5-9. Writing of Unit/CSCO Data 1. Connect the power cord and set this unit to standby state. 2. Double-click QuickAccess3.exe to start the application. 3. Select a target model on the Model pull-down menu. 4. Select Write to Projector on the Read/Write pull-down menu. 5.

  • Page 87: Adjustment Item Initialize Data

    2-6. Adjustment Item Initialize Data 2-6-1. Group A Initialize data Menu Item Memory Name Title Name Status network CSCo2 Memory Picture Memory Memory Micro Memory Memory Memory Memory Memory Custom Custom Custom All Channels Dynamic Standard Brightness Multi Priority Screen Picture Picture Mode Dynamic...
  • Page 88 Menu Item Memory Name Title Name Status network CSCo2 Memory Picture Memory Memory Micro Memory Memory Memory Memory Memory Custom Custom Custom All Channels Dynamic Standard Brightness Multi Priority Screen Picture Hue(Blue) Saturation(Blue) Value(Blue) Hue(Magenta) Saturation(Magenta) Value(Magenta) Film Mode Auto Auto Auto Auto...
  • Page 89 Menu Item Memory Name Title Name Status network CSCo2 Memory Picture Memory Memory Micro Memory Memory Memory Memory Memory Custom Custom Custom All Channels Dynamic Standard Brightness Multi Priority Screen Installation Multi Screen Color Space Custom1 Custom3 Custom1 Custom3 Cyan-Red(x) Magenta-Green(y) Color Matching 0 *All Level...
  • Page 90 Menu Item Memory Name Title Name Status network CSCo2 Memory Picture Memory Memory Micro Memory Memory Memory Memory Memory Custom Custom Custom All Channels Dynamic Standard Brightness Multi Priority Screen Installation Adjust Item SHIFT Adjust Color Pattern Color Adjust (Shift) (H,V) = (0,0) Adjust (ZONE) (H,V) = (0,0)
  • Page 91 Initialize data Device Name Item Name Memory Name Status Channel Memory Video Chroma Memory(Video) No Memory Memory Micro Memory Video S Video Input-A NoInput NTSC3.58 TSC4.43 PAL PALM PALN A/D Converter ADC/ R Gain (Other) R Gain (Video GBR) R Gain (Component 15k) R Gain (Component 30k) R Gain (Component HD) G Gain (Other)
  • Page 92 226(*1) Fan 7 Target RPM Fan 8 Target RPM Read Data Read Data Read Data Read Data RS 232C Parity RS 232C StopBits Disable Filter Cleanup Digital1 EQ Gain Digital2 EQ Gain *1: VPL-FH65: 226 VPL-FH60: 208 2-26 (E) VPL-FH60...

  • Page 93: Group B

    2-6-2. Group B Initialize data Menu Title Item Name Memory Name Sub Micro No Status network CSCo2 Memory Picture Memory Memory Memory Memory Memory Memory Memory Custom Custom Custom All Channels Dynamic Standard Brightness Multi Priority Screen *1 *3 Picture Picture Mode Dynamic Reset...
  • Page 94 Menu Title Item Name Memory Name Sub Micro No Status network CSCo2 Memory Picture Memory Memory Memory Memory Memory Memory Memory Custom Custom Custom All Channels Dynamic Standard Brightness Multi Priority Screen Picture Hue(Magenta) Saturation(Magenta) Zone4 R Zone5 R Zone6 R Zone7 R Zone8 R Zone9 R...
  • Page 95 Initialize data Device Name Item Name Advanced Memory Name User Status Channel Memory Video Chroma Memory(Video) No Memory Memory Micro Memory Video S Video Input-A NoInput NTSC3.58 NTSC4.43 PAL PALM PALN A/D Converter ADC/ R Gain (Other) R Gain (Video GBR) R Gain (Compornent 15k) R Gain (Compornent 30k) R Gain (Compornent HD)
  • Page 96 Device Name Item Name Advanced Memory Name User Status Channel Memory Video Chroma Memory(Video) No Memory Memory Micro Memory Video S Video Input-A NoInput NTSC3.58 NTSC4.43 PAL PALM PALN Display B REG V Engine G Panel LR DFT AUT HPC R RGT0 Read Data HPC G RGT0 Read Data...

  • Page 97: Spare Parts

    Therefore, specified parts should be used in the case of な部品です。したがって，交換する時は必ず指定 replacement. の部品を使ってください。 2. Standardization of Parts 2.  部品の共通化 Some repair parts supplied by Sony differ from those   ソニーから供給する補修用部品は，セットに使われて used for the unit. These are because of parts common- いるものと異なることがあります。 ality and improvement.

  • Page 98: Exploded Views

    Cover 3-2. Exploded Views BVTP To C board BVTP VPL-FH60...
  • Page 99 Cover Part No. SP Description A-2080-312-B s MOUNTED CIRCUIT BOARD, H (SUFFIX -12) A-2080-312-C s MOUNTED CIRCUIT BOARD, H (SUFFIX -21) A-2080-361-A s LENS ASSY, S A-2083-330-A s ELECTROSTATIC FILTER ASSY,S X-2591-783-2 s COVER ASSY, TOP (For White model) X-2591-784-2 s COVER ASSY (B), TOP (For Black model) X-2591-788-2 s COVER ASSY, LENS (For White model)

  • Page 100: C Board (Suffix: -11)

    C Board (Suffix: -11) C Board (A side) CN103 (To the power unit) CN107 (To the TL board) CN102 (To the power unit) CN104 CN2503 (To the fuse) (To the fan 4 and fan 5) CN105 (To the U board) CN110 CN2601 (To the unit assembly)
  • Page 101 C Board (Suffix: -11) Part No. SP Description A-2081-894-B s MOUNTED CIRCUIT BOARD, C (For VPL-FH65) A-2081-895-B s MOUNTED CIRCUIT BOARD, C (For VPL-FH60) A-2082-350-B s MOUNTED CIRCUIT BOARD, C (For VPL-F630H) A-2082-351-B s MOUNTED CIRCUIT BOARD, C (For VPL-F635H)

  • Page 102: C Board (Suffix: -21)

    C Board (Suffix: -21) C Board (A side) CN103 (To the power unit) CN107 (To the TL board) CN102 (To the power unit) CN104 CN2503 (To the fuse) (To the fan 4 and fan 5) CN105 (To the U board) CN110 CN2601 (To the unit assembly)
  • Page 103 C Board (Suffix: -21) Part No. SP Description A-2081-894-C s MOUNTED CIRCUIT BOARD, C (For VPL-FH65) A-2081-895-C s MOUNTED CIRCUIT BOARD, C (For VPL-FH60) A-2082-350-C s MOUNTED CIRCUIT BOARD, C (For VPL-F630H) A-2082-351-C s MOUNTED CIRCUIT BOARD, C (For VPL-F635H)

  • Page 104: Fan Block

    Fan Block BVTP BVTP C board BVTP BVTP VPL-FH65/ VPL-FH60/F530H/ F630H/F635H F535H To C board BVTP BVTP BVTP To C board BVTP BVTP To C board VPL-FH60...
  • Page 105 Fan Block Part No. SP Description A-2080-309-A s MOUNTED CIRCUIT BOARD, TA (SUFFIX -11) A-2080-309-B s MOUNTED CIRCUIT BOARD, TA (SUFFIX -21) A-2080-310-A s MOUNTED CIRCUIT BOARD, V (SUFFIX -11) A-2080-310-B s MOUNTED CIRCUIT BOARD, V (SUFFIX -21) X-2591-789-1 s CASE ASSY (FILTER BTM) (PND) 1-455-131-11 s PLUNGER SOLENOID 1-855-394-11 s DC FAN (80 SQUARE, SIROCCO) 1-855-396-11 s DC FAN (100 SQUARE, SIROCCO)

  • Page 106: Lamp Unit And Q Board

    Lamp Unit and Q Board BVTP BVTP To C board To C board BVTP To C board To C board To C board BVTP BVTP BVTP BVTP BVTP To C BVTP board BVTP To C board BVTP 3-10 VPL-FH60...
  • Page 107 Lamp Unit and Q Board Part No. SP Description A-2079-578-B s MOUNTED CIRCUIT BOARD, Q (SUFFIX -12) A-2079-578-C s MOUNTED CIRCUIT BOARD, Q (SUFFIX -21) A-2079-579-B s MOUNTED CIRCUIT BOARD, MX (SUFFIX -11) A-2079-579-C s MOUNTED CIRCUIT BOARD, MX (SUFFIX -21) A-2080-311-A s MOUNTED CIRCUIT BOARD, NF (SUFFIX -11) A-2080-311-B s MOUNTED CIRCUIT BOARD, NF (SUFFIX -21) A-2082-346-A s MOUNTED CIRCUIT BOARD, TL (SUFFIX -12)

  • Page 108: Power Unit

    Power Unit VPL-FH60/ F530H/F535H BVTP BVTP 16 PSW BVTP BVTP To C board VPL-FH65/ F630H/F635H BVTP BVTP BVTP To C board BVTP BVTP BVTP BVTP BVTP BVTP To C board 3-12 VPL-FH60...
  • Page 109 X-2591-781-2 s COVER ASSY (B), BOTTOM (For Black model) 1-474-592-21 s POWER UNIT (FOR LAMP) (For VPL-FH60/F530H/F535H) 1-474-622-11 s POWER UNIT (FOR LAMP) (For VPL-FH65/F630H/F635H) 1-474-623-12 s POWER UNIT (FOR SET) 1-843-685-11 s AC INLET (WITH NOISE FILTER) 1-849-140-11 s LAMP CONNECTOR ASSY(BALLAST6K) (For VPL-FH65/F630H/F635H)

  • Page 110: Optics Block

    Optics Block To C board Group B To C board To C board Group A To C board To C board 3-14 VPL-FH60...
  • Page 111 A-2080-365-A s IN-POLARIZER ASSY (G), S A-2080-366-A s 4P OUT GLASS ASSY, S A-2081-482-A s COAT WAVE (PND) ASSY, S (For VPL-FH65/F630H/F635H) A-2082-751-A s PRISM BLOCK (PND-6WU) ASSY, S (GROUP A) (For VPL-FH65/F630H/F635H) A-2082-751-C s PRISM BLOCK (PND-6WU) ASSY, S (GROUP B)

  • Page 112: Optional Lens

    Optional Lens VPLL-Z2009 VPLL-2007 VPLL-Z3009 VPLL-3007 VPLL-Z1024 VPLL-Z1032 VPLL-Z3024 VPLL-Z3032 VPLL-3003 VPLL-Z3010 *Correspondence table between option lens and option lens adapter Option lens Option lens adapter VPLL-Z1032 PK-F60LA1 VPLL-Z1024 PK-F60LA2 VPLL-Z2009 PK-F60LA3 VPLL-2007 PK-F60LA4 3-16 VPL-FH60...

  • Page 113: Packing Materials & Supplied Accessories

    3-3. Packing Materials & Supplied Accessories ---------------------------------------- PACKING MATERIALS & SUPPLIED ACCESSORIES ---------------------------------------- *1:[For SY] *2:[For CN] Ref. No. or Q’ty Part No. SP Description 1-492-891-12 s REMOTE COMMANDER (RM-PJ27) 1pc *1 1-839-054-12 s POWER-SUPPLY CORD SET (For J) 1pc *2 1-839-058-12 s AC POWER-SUPPLY CORD 1pc *1 1-848-212-12 s AC POWER SUPPLY CORD SET (For INDIA)

  • Page 115: Block Diagrams

    Overall Overall Section 4 Block Diagrams Group A IC504 IC401, IC402 Pararell DDR2 Flash IC701 IC200 J100 CVBS CVBS CVBS CVBS IC103 VIDEO LVDS VGA_IN_R VGA_R VGA_R VGA_IN_G VGA_G VGA_G VGA_IN_H IC101, IC102 VGA_IN_B VGA_B VGA_B CN100 VGA_IN_V LVDS SYNC INPUT A IPC-PRO SLICER...

  • Page 116: Overall

    Overall Overall PRISM BLOCK ASSEMBLY IC1500 IC1101, IC1102 FAN1 DDR2 (R Panel) PANEL IC800 IC900 IC1200 DRIVER PANEL UNIF_R, UNIF_G, UNIF_B FAN2 (G Panel) LVDS LVDS TG_R, TG_G, TG_B FAN3 EDGE BLENDING IC1204 (B Panel) & X1201 IC1600 GERONIMO WRAPPING 25MHz SELECT FAN4...
  • Page 117 Overall Overall Group B IC504 IC401, IC402 Pararell DDR2 Flash IC701 IC200 J100 CVBS CVBS CVBS CVBS IC103 VIDEO LVDS VGA_IN_R VGA_R VGA_R VGA_IN_G VGA_G VGA_G VGA_IN_H IC101, IC102 VGA_IN_B VGA_B VGA_B CN100 LVDS VGA_IN_V SYNC INPUT A IPC-PRO SLICER RGB/YP VGA_H VGA_DDC_SCL...
  • Page 118 Overall Overall PRISM BLOCK ASSEMBLY IC1500 IC1101, IC1102 FAN1 DDR2 (R Panel) IC800 IC900 IC1200 PANEL DRIVER PANEL UNIF_R, UNIF_G, UNIF_B FAN2 (G Panel) COLOR LVDS LVDS SENSOR TG_R, TG_G, TG_B FAN3 EDGE BLENDING IC1204 (B Panel) X1201 & IC1600 GERONIMO 25MHz WRAPPING...

  • Page 119: Frame Wiring

    (B Panel) FAN4 CN2601 CN2503 (PWR Exhaust) FAN6 (LAMP Intake) FAN5 (LS Exhaust) CN105 CN104 CN107 CN103 CN102 POWER UNIT (FOR LAMP) CN501 CN4000 CN401 CN301 LAMP CN3201 CN101 (POWER UNIT) TEMP FUSE CHASSIS VPL-FH65/F630H/F635H AC INLET Frame Wiring VPL-FH60...
  • Page 120 FAN4 CN2503 (B Panel) (PWR Exhaust) CN2601 FAN5 FAN6 (LS Exhaust) (LAMP Intake) POWER UNIT (FOR LAMP) CN105 CN104 CN107 CN103 CN102 LAMP CN501 CN4000 CN401 CN301 CN3201 CN101 (POWER UNIT) TEMP FUSE CHASSIS VPL-FH65/F630H/F635H AC INLET Frame Wiring VPL-FH60...
  • Page 122 VPL-FH65 (SY) VPL-FH60 (SY) VPL-F635H (CN) VPL-F630H (CN) VPL-F535H (CN) Printed in Japan Sony Corporation VPL-F530H (CN) J, E 2017. 7 32 9-878-668-02 ©2015...
