Page 1: Table Of Contents
Care And Cleaning........15 Important Safety Instructions....3 Energy Saving Ideas........15 Normal Sounds..........7 Before You Call..........16 Air Conditioner Features......8 Major Appliance Limited Warranty..18 Operating Instructions........ 9 (DY)16120300A20672 (July 2019) Frigidaire.com USA 1-800-944-9044 Frigidaire.ca Canada 1-800-265-8352... -
Page 2: Introduction
INTRODUCTION family Welcome to our Thank you for bringing Frigidaire into your home! We see your purchase as the beginning of a long relationship together. This manual is your resource for the use and care of your product. Please read it before using your appliance. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS The power cord is equipped with a WARNING three-prong grounding plug for protection against shock hazards. For Your Safety • Your air conditioner must be used in a Do not store or use gasoline or other properly grounded wall receptacle. If the flammable vapors and liquids in the vicinity wall receptacle you intend to use is not of this or any other appliance. - Page 4 IMPORTANT SAFETY INSTRUCTIONS • Do not direct airflow at fireplaces or other NOTE heat related sources as this could cause flare ups or make units run excessively. The power supply cord with this air • Do not climb on or place objects on conditioner contains a current detection outdoor part of the unit.
- Page 5 IMPORTANT SAFETY INSTRUCTIONS • The appliance shall be stored in a room • No any open fire or device like switch without continuously operating ignition which may generate spark/arcing shall be sources (for example: open flames, an around air conditioner to avoid causing operating gas appliance) and ignition ignition of the flammable refrigerant used.
- Page 6 IMPORTANT SAFETY INSTRUCTIONS 1. Plug in the Air Conditioner. the LFL of the refrigerant and shall be 2. The power supply cord will have TWO calibrated to the refrigerant employed, buttons on the plug head. Press the TEST and the appropriate percentage of gas (25 button.
-
Page 7: Normal Sounds
NORMAL SOUNDS Explanation of symbols displayed on the unit This symbol shows that this appliance used a flammable refrigerant. If the refrigerant is leaked and exposed to an WARNING external ignition source, there is a risk of fire. This symbol shows that the operation manual should be read CAUTION carefully. -
Page 8: Air Conditioner Features
AIR CONDITIONER FEATURES Air Conditioner Features ELECTRONIC CONTROL Before you begin, thoroughly familiarize yourself with the control panel and remote control and all its functions (as shown below). The unit can be controlled by the touch pad alone, with the remote control. Turns Unit On Or O Sets Fan Speed Ionizer Feature... -
Page 9: Operating Instructions
OPERATING INSTRUCTIONS YOU WILL SEE: NOTE The following instructions represent the touch pad. The same instructions can be used for the remote control. TO TURN UNIT ON: Note: This mode is a fixed combination of Cool mode and Auto fan speed setting. In this mode, the fan speed can not be selected manually. - Page 10 OPERATING INSTRUCTIONS YOU WILL SEE: TO USE AUTO FAN FEATURE: Note: Tap or hold either up ( ) or down ( ) button until the desired temperature is seen DO THIS: on the display. This temperature will be PRESS FAN BUTTON, automatically maintained anywhere between CHOOSE AUTO 62 °F (17 °C) and 86 °F (30 °C).
- Page 11 OPERATING INSTRUCTIONS YOU WILL SEE: SLEEP FEATURE: Note: Use this function only when cooling is DO THIS: not desired, such as for room air circulation or to exhaust stale air on some models. PRESS SLEEP (Remember to open the vent during this BUTTON function, but keep it closed during cooling for maximum cooling e ciency.) You can...
- Page 12 OPERATING INSTRUCTIONS Setting combination of “delay stop turn off delay start” or “delay start delay stop” turn on is workable. Both "timer o " indicator and "timer on" indicator will illuminate then. The timer setting can be canceled by either pressing and holding the timer button for 2 seconds, or pressing the power on/o button at any time to turn o the unit...
- Page 13 OPERATING INSTRUCTIONS YOU WILL SEE: TO CHANGE TEMPERATURE DISPLAY: Remote Sensing indicator NOTE: Unit display shows the set DO THIS: temperature. Remote display is actual PRESS AND HOLD THE UP/DOWN temperature. BUTTONS SIMULTANEOUSLY The Remote Sensing function can be FOR 3 SECONDS terminated either by pressing the Remote Sensing button again or the main ON/OFF YOU WILL SEE:...
- Page 14 If the display reads “AS” or “ES” , a sensor adjuster tablet until the desired has failed. Contact your Authorized Left/Right direction is obtained. Pivot Frigidaire Service Center. horizontal louvers until the desired Up/Down direction is obtained. ADDITIONAL THINGS YOU SHOULD KNOW...
-
Page 15: Care And Cleaning
CARE AND CLEANING & ENERGY SAVING IDEAS Cabinet Cleaning Clean your air conditioner occasionally to keep it looking new. Be sure to unplug the • Be sure to unplug the air conditioner to unit before cleaning to prevent shock or prevent shock or fire hazard. -
Page 16: Before You Call
BEFORE YOU CALL Before calling for service, review this list. It may save you time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. OCCURRENCE SOLUTION • Wall plug disconnected. Push plug firmly into wall outlet. •... - Page 17 • Set temperature too low. lncrease set temperature. Room too cold. • Remote Sensing activated (on some models) and remote control located in Hot Spot - Relocate remote control or deactivate remote sensing. If These Solutions Fail, Call 1-800-944-9044(US)/1-800-265-8352(Canada) For Frigidaire Service.
-
Page 18: Major Appliance Limited Warranty
MAJOR APPLIANCE LIMITED WARRANTY Your appliance is covered by a limited one-year warranty for functional repairs only. For one year from your original date of purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed, used and maintained in accordance with the provided instructions. - Page 20 Our home is your home. Visit us if you need help with any of these things: owner support accessories service registration (See your registration card for more information.) Frigidaire.com 1-800-944-9044 Frigidaire.ca 1-800-265-8352...
