Siemens RUGGEDCOM RX1501 Installation Manual page 25

Installing the Device
2.5.2 Connecting Low DC Power
1. Connect the power supply terminal block to the device.
Figure 2.9
16
All manuals and user guides at all-guides.com
1
European-style (Euroblock) Terminal Block
1
Positive (+) Terminal
2
Negative (-) Terminal
3
Ground Terminal
4
DC Terminal Block Wiring – European-style (Euroblock) Terminal Block for 12P,
24P and 48P Power Supplies
4
2
Not Connected
1
Removable Screw Terminal Block
2
Non-removable Screw Terminal Block
3
Positive (+) Terminal
4
Negative (-) Terminal
5
2 3 4
1 5 1 6 4 5 6
3
RUGGEDCOM RX1501
Installation Manual, 05/2020, C79000-G8976-1054-17
