Health & Safety, Use & Care, Installation Guide and Online Warranty Registration Information 產品安全指引、使用說明、安裝指南及 網上登記保養資料 Model AWA07520N / AWA07520R 產品型號 AWA09220N / AWA09220R AWA18020N / AWA18020R...
Page 3
Dear User, Thank you for choosing Whirlpool air conditioner. Our design is based on the best efficiency and the lowest noise operation and it can keep the room comfortable. Please read this operating manual carefully before operating the unit and keep it for consultation.
Page 4
Function Introduction Window type room air conditioners can regulate the room temperature and dry the room. It is convenient for your work, study and life. It can be widely used in residence, shop, hotel, office, library and laboratory, and so on. Dehumidifying in rainy or Cooling in summer humid season...
Page 5
Safety Precaution · Read the safety precaution carefully before using this appliance. Incorrect operation will cause injuries and damage, please pay special attention to below sign: · To prevent personal injury, injury to others and product damage. · User should strictly follow the operating instructions. Or it may cause product ·...
Page 6
Safety Precaution Operation Precaution This appliance is not intended for use by persons (including children) with reduced · physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Page 7
Operating Condition Please operate air conditioner in the correct condition as followings. DRY mode operation COOL mode operation Outdoor temperature should be in range of 18 to 43 Outdoor temperature should be in range of 18 to 43 , otherwise it is possible for air conditioner otherwise it is possible for air conditioner to breakdown.
Page 8
Installation Instruction Window type air conditioner is so valuable and the improper installation of it will cause a lot of damage! Please associate the professional technician to install the unit and don’t install it by yourself. Location: Avoid other heat sources or direct sun light. The condensation water must be drained away conveniently.
Page 9
Installation Instruction Installation procedure: 1) Remove the sticker from the front panel. Horizontal line 2) Put the unit into the installation hole. When installing the unit, it should be slanted down to the back to avoid the enlargement of noise or vibration. (Slant between 6-10mm.) (Shown at right figure.) The installation place should be strong enough to avoid the enlargement of noise or vibration.
Page 10
Installation Instruction Note: Drain pan and drain hose must be installed before using reverse cycle models. Drain hose or tubing can be purchased locally to satisfy your particular needs. Notes for installation Remove Before removing air conditioner to the other place, you should contact the seller firstly.
Page 11
Parts Identification & Operations Electronic Mechanical Panel outlook picture, just for reference, please take the real until as standard. Panel outlook picture, just for reference, please take the real until as standard. Cabinet Cabinet Air inlet Air inlet louver louver Front Front grille...
Page 12
Parts Identification & Operations For Mechanical only Applicable Models : AWA07520N/ AWA09220N/ AWA18020N Main Control Panel 1. Operation Mode Selection Knob OFF – Stop the operation. FAN – Fan operation LOW COOL – Cooling operation at low speed MED COOL - Cooling operation at medium speed HIGH COOL - Cooling operation at high speed 2.
Page 13
Parts Identification & Operations For Electronic only Applicable Models : AWA07520R/ AWA09220R/ AWA18020R Main Control Panel Power button Press this button to turn on the unit. Press this button again to turn off the unit. Swing button Press this button to start up the auto swing function. Fan speed button Press this button to select fan speed (High/Low).
Page 14
Parts Identification & Operations Remote Control Power button Press it to start or stop operation. Mode button Press it to select operation mode (6TH SENSE/COOL/DRY/FAN). Press it to decrease temperature setting. Press it to increase temperature setting. Fan speed button Press it to set fan speed.
Page 15
Parts Identification & Operations Introduction for buttons on remote controller Power button : Press this button to turn on the unit. Press this button again to turn off the unit. Mode button : Each time you press the button, a mode is selected in a sequence that goes from 6TH SENSE, COOL, DRY, FAN, as the following: 6th sense COOL...
Page 16
Parts Identification & Operations Note: ● This is a general use remote controller, it could be used for the air conditioners with multifunction; For some function, which the model doesn't have, if press the corresponding button on the remote controller that the unit will keep the original running status.
Page 17
Parts Identification & Operations Replacing batteries in remote controller 1. Remove the cover from the back of the remote control.To avoid small parts Using a tool to push the latch choking hazard, it is suggested to open the cover by tools (e.g. flat screwdriver).
Page 18
Operation Tips Operation for comfort and economy Keep the room temp. uniform. Keep blind or curtains closed Do not overcool the room Adjust the vertical and horizontal Do not let sunshine enter the temperature. This is not good for airflow direction to ensure a uni- room directly when the air con- health and waste electricity.
Page 19
Caution Operation for safety and health 1) The plug must be accessible after the appliance is positioned. 2) Do not use this appliance in the laundry room. 3) If the power cord is damaged, it must be replaced by the manufacture or its service agent in void of hazard. Do not pull out the power cord.
Page 20
Care and maintenance Cleaning unit 1. Cut power off before cleaning. Air filter The air filter behind the intake grille should be washed at Plug out only after least once every two weeks or as often as it needs cleaning. air conditioner stops at all.
Page 21
Trouble shooting guide Please check the following items before asking for repair, it saves your time and money. Fault phenomenon Troubleshooting Is there a power failure? Is the plug out? Air conditioner does not Is power fuse or switch off? operate at all.
Page 22
After-sales Service Immediately stop all operations and plug out, please contact your dealer in the following situations. *Operation starts or stops abnormally; *Power fuse or switch often breaks; *Carelessly splash water or something into air conditioner; *Electrical lines are much hot or lines cover breaks; *Other strange situations.
Page 23
Safeguarding the Environment Scrapping Notice Scrapping Packaging 1. The packaging can be 100% recycled as confirmed by the recycling symbol . The various parts of the packaging must not be dispersed in the environment, but must be scrapped in line with local authority regulations.
Page 45
Register your product online 網上登記新產品保養 Save the planet and register your product warranty online! Enjoy extra 1-month free warranty upon online registration. 「惠」環保出力,減少用紙!於網上登記產品更可獲額外多一個月保養。 https://rebrand.ly/WPwarranty...
