1 Safety Precautions 1.1. General Guidelines 1. When conducting repairs and servicing, do not attempt to modify the equipment, its parts or its materials. 2. When wiring units (with cables, flexible cables or lead wires) are supplied as repair parts and only one wire or some of the wires have been broken or disconnected, do not attempt to repair or re-wire the units.
2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor [chip] components.
2.2. About lead free solder (PbF) Note: Lead is listed as (Pb) in the periodic table of elements. In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder. The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu). That is Tin (Sn), Silver (Ag) and Copper (Cu) although other types are available.
3 Service Navigation 3.1. PCB Layout Board Name Function Power Supply Non serviceable. P-Board should be exchanged for service. Main AV input, processing Remote receiver, Power LED, C.A.T.S sensor Data Driver (Lower Right) Data Driver (Lower Center) Data Driver (Lower Left) Scan Drive Sustain Drive Sustain out (Lower)
4 Specifications Sound (160 mm × 40 mm) × 2, 8Ω Speaker Audio output 20 W ( 10 W + 10 W ) M3 (3.5 mm) stereo mini Jack × 1 Headphones Receiving systems / Band name (A/Z) PAL B/G Reception of Off air broadcasts Digital TV 7 MHz VHF/UHF (Australia) free-to-air TV broadcast reception (A)
Page 9
0 °C - 40 °C Usage temperature range Battery* Coin-shaped lithium battery CR2025 Operation time: Approx. 75 hours in continuous use of the battery made by Panasonic Viewing range* Within 3.2 m from front surface of the TV Materials Main body: Resin...
5.1.3. Model and Keys: Model No. Keys One-to-One DTCP-IP Widevine Netflix (For USB Rec.) TH-P60UT50A/Z TH-P60UT50M/P None None 5.2. USB HDD Recording (A/Z only) 5.2.1. General information: Digital TV programmes can be recorded in USB HDD. A One-to-One key generated in A-board by SELF CHECK binds TV and USB-HDD for communication.
6 Service Mode 6.1. How to enter into Service Mode 6.1.1. Purpose After exchange parts, check and adjust the contents of adjustment mode. While pressing [VOLUME ( - )] button of the main unit, press [i] button of the remote control three times within 2 seconds. Note: Service Mode can not be entered when 3D signal input.
Page 12
6.1.4. Contents of adjustment mode • Value is shown as a hexadecimal number. • Preset value differs depending on models. • After entering the adjustment mode, take note of the value in each item before starting adjustment. Main item Sub item Sample Data Remark ADJUST...
6.2. Option - Mirror Picture can be reversed left and right or up and down. 00 : Default (Normal picture is displayed) 01 : Picture is reversed left and right. 02 : Picture is reversed up and down. Hint : If the defective symptom (e.g. Vertical bar or Horizontal bar) is moved by selection of this mirror, the possible cause is in A-board.
6.4. DRV Check - USB HDD Check 1. Select [DRV Check - USBHDD Check] in Service Mode. 2. Press [OK] button on the remote control for more than 3 seconds. 6.5. Hotel mode Item Function 1. Purpose Hotel Mode Select hotel mode On/Off Restrict a function for hotels.
6.6. Data Copy by SD Card 6.6.1. Purpose (a) Board replacement (Copy the data when exchanging A-board): When exchanging A-board, the data in original A-board can be copied to SD card and then copy to new A-board. (b) Hotel (Copy the data when installing a number of units in hotel or any facility): When installing a number of units in hotel or any facility, the data in master TV can be copied to SD card and then copy to other TVs.
Page 16
6.6.3. Data copy from TV set to SD Card 1. Turn on the TV set. 2. Insert SD card with a startup file (pwd file) to SD slot. On-screen Display will be appeared according to the startup file automatically. 3. Input a following password for (a) or (b) by using remote control. (a) For Board replacement : 2770 (b) For Hotel : 4850 Data will be copied from TV set to SD card.
Page 17
6.6.4. Data copy from SD Card to TV set 1. Turn on the TV set. 2. Insert SD card with Data to SD slot. On-screen Display will be appeared according to the Data folder automatically. 3. Input a following password for (a) or (b) by using remote control. (a) For Board replacement : 2771 (b) For Hotel : 4851 Data will be copied from SD card to TV set.
7 Troubleshooting Guide Use the self-check function to test the unit. 1. Checking the IIC bus lines 2. Power LED Blinking timing 7.1. Check of the IIC bus lines 7.1.1. How to access 7.1.1.1. Self-check indication only: Produce TV reception screen, and while pressing [VOLUME ( - )] button on the main unit, press [OK] button on the remote control for more than 3 seconds.
7.2. Power LED Blinking timing chart 1. Subject Information of LED Flashing timing chart. 2. Contents When an abnormality has occurred the unit, the protection circuit operates and reset to the stand by mode. At this time, the defective block can be identified by the number of blinks of the Power LED on the front panel of the unit. Blinking Times Contents Check point...
7.3. No Power First check point There are following 3 states of No Power indication by power LED. 1. No lit 2. Green is lit then turns red blinking a few seconds later. (See Power LED Blinking timing chart) 3. Only red is lit.
8 Service Fixture & Tools 8.1. SC jig Purpose: To find the failure board (SC or SU/SD) when the power LED is blinking 7 times. SC jig: Jumper connector to connect to SC50 connector on SC board Part number: TZSC09187 How to use: Caution: Remove SC jig from SC board after inspection.
9 Disassembly and Assembly Instructions 9.1. Disassembly Flow Chart for the Unit This is a disassembly chart. When assembling, perform this chart conversely.
9.2. Disassembly Procedure for the Unit 9.2.1. Remove the Pedestal stand 9.2.4. Remove the Bluetooth module 1. Remove the Plasma panel section from the servicing 1. Remove the screw (×1 ) and remove the Bluetooth stand and lay on a flat surface such as a table (covered module.
Page 26
9.2.7. Remove the P-Board 9.2.9. Remove the A-Board Caution: 1. Remove the screws (×4 To remove P.C.B. wait 1 minute after power was off for 2. Remove the claws (×2 discharge from electrolysis capacitors. 3. Remove the Side terminal cover and the Side shield 1.
Page 27
9.2.11. Remove the SU-Board 9.2.13. Remove the SC-Board 1. Disconnect the flexible cables (SU1, SU2, SU3, SU4 and 1. Disconnect the connector (SC2). SU5) connected to the SU-Board. 2. Disconnect the flexible cable (SC20). 2. Disconnect the flexible cable (SU11-SD11) and the bridge 3.
Page 28
9.2.15. Remove the SS2-Board 9.2.17. Remove the Stand bracket plate 1. Disconnect the flexible cables (SS65 and SS67). , ×2 1. Remove the Stand bracket fastening screws (×6 2. Remove the screws (×2 ) and remove the SS2-Board. , ×2 ) and remove the Stand bracket plate.
Page 29
9.2.21. Remove the Cabinet assy from the 9.2.22. Remove the Contact metals Plasma panel section 1. Remove the screws (×10 2. Remove the Contact metal side (L, R). 1. Place the Cabinet assy on a flat surface of a table (covered by a soft cloth) and a cushion.
Page 30
9.2.25. Remove the C3-Board 1. Disconnect the flexible cables (CB12, CB13, CB14 and CB15). 2. Disconnect the flexible cables (C31, C32, C36 and C37). 3. Remove the screws (×3 ) and remove the C3-Board. 9.2.26. Replace the Plasma panel Caution: Place the Plasma panel on a flat surface of a table (covered by a soft cloth) and a cushion.
10 Measurements and Adjustments 10.1. Adjustment 10.1.1. Vsus selection Caution: When Plasma panel or A-board is replaced, Vsus should be set to LOW or HIGH. Procedure 1. Go into main item [VSUS] in Service Mode. LOW or HIGH will be displayed. 2.
Page 32
10.1.2. White balance adjustment Name of measuring instrument Remarks Color analyzer (Minolta CS-2000 or equivalent) Procedure Remarks 1. Enter the Service mode. 2. Receive the Analog-RF (except for no signal) or set CVBS/YUV/HDMI (no signal is available). 3. Select [WB-ADJ] by using [1] and [2] key in the remote controller. 4.
11 Block Diagram 11.1. Main Block Diagram MAIN AV INPUT,PROCESSING HDMI1-2 (HDMI2) ETHERNET DATA TMDS DATA ETHERNET LAN CON I/F ETHERPHY HDMI I/F ARC_OUT IFD_OUT USB I/F USB_1-2 TUNER TUNER I/F BLUETOOTH R/G/B/H/V R/G/B/H/V PEAKS-LD4 SD CARD DATA CVBS SD CARD SD CARD I/F AV IN IR_DCDC_ON...
11.3. Block (2/4) Diagram MAIN AV INPUT,PROCESSING IC9300 PD6H VIDEO DATA PLASMA AI VIDEO DATA LVDS DATA H/V Sync Control VIDEO DATA Sub Filed Processor P+3.3V IC9803 P+1.2V P+3.3V DCDC15V P+1.2V IIC0 DATA DRIVER CONTROL 1.2V +1.2V IC9005 P+2.5V DCDCEN D_UHZ VJ9005 +2.5V...
12 Wiring Connection Diagram 12.1. Caution statement. Caution: Please confirm that all flexible cables are assembled correctly. Also make sure that they are locked in the connectors. Verify by giving the flexible cables a very slight pull. 12.2. Wiring (1)
Page 44
Model No. : TH-P60UT50A/M/P/Z Schematic Diagram Note...
Page 45
Model No. : TH-P60UT50A/M/P/Z Replacement Parts List Note...
Page 46
Model No. : TH-P60UT50A/M/P/Z A-Board (1/16)
Page 47
Model No. : TH-P60UT50A/M/P/Z A-Board (2/16)
Page 48
Model No. : TH-P60UT50A/M/P/Z A-Board (3/16)
Page 49
Model No. : TH-P60UT50A/M/P/Z A-Board (4/16)
Page 50
Model No. : TH-P60UT50A/M/P/Z A-Board (5/16)
Page 51
Model No. : TH-P60UT50A/M/P/Z A-Board (6/16)
Page 52
Model No. : TH-P60UT50A/M/P/Z A-Board (7/16) and K-Board...
Page 53
Model No. : TH-P60UT50A/M/P/Z A-Board (8/16) S-10...
Page 54
Model No. : TH-P60UT50A/M/P/Z A-Board (9/16) S-11...
Page 55
Model No. : TH-P60UT50A/M/P/Z A-Board (10/16) S-12...
Page 56
Model No. : TH-P60UT50A/M/P/Z A-Board (11/16) S-13...
Page 57
Model No. : TH-P60UT50A/M/P/Z A-Board (12/16) S-14...
Page 58
Model No. : TH-P60UT50A/M/P/Z A-Board (13/16) S-15...
Page 59
Model No. : TH-P60UT50A/M/P/Z A-Board (14/16) S-16...
Page 60
Model No. : TH-P60UT50A/M/P/Z A-Board (15/16) S-17...
Page 61
Model No. : TH-P60UT50A/M/P/Z A-Board (16/16) S-18...
Page 62
Model No. : TH-P60UT50A/M/P/Z C1-Board S-19...
Page 63
Model No. : TH-P60UT50A/M/P/Z C2-Board (1/2) S-20...
Page 64
Model No. : TH-P60UT50A/M/P/Z C2-Board (2/2) S-21...
Page 65
Model No. : TH-P60UT50A/M/P/Z C3-Board (1/2) S-22...
Page 66
Model No. : TH-P60UT50A/M/P/Z C3-Board (2/2) S-23...
Page 67
Model No. : TH-P60UT50A/M/P/Z SC-Board (1/3) S-24...
Page 68
Model No. : TH-P60UT50A/M/P/Z SC-Board (2/3) S-25...
Page 69
Model No. : TH-P60UT50A/M/P/Z SC-Board (3/3) S-26...
Page 70
Model No. : TH-P60UT50A/M/P/Z SS-Board (1/2) S-27...
Page 71
Model No. : TH-P60UT50A/M/P/Z SS-Board (2/2) and SS2-Board S-28...
Page 72
Model No. : TH-P60UT50A/M/P/Z A-Board (Foil Side) S-29...
Page 73
Model No. : TH-P60UT50A/M/P/Z A-Board (Component Side) S-30...
Page 74
Model No. : TH-P60UT50A/M/P/Z K-Board S-31...
Page 75
Model No. : TH-P60UT50A/M/P/Z C1-Board S-32...
Page 76
Model No. : TH-P60UT50A/M/P/Z C2-Board S-33...
Page 77
Model No. : TH-P60UT50A/M/P/Z C3-Board S-34...
Page 78
Model No. : TH-P60UT50A/M/P/Z SC-Board (Foil Side) S-35...
Page 79
Model No. : TH-P60UT50A/M/P/Z SC-Board (Component Side) S-36...
Page 80
Model No. : TH-P60UT50A/M/P/Z SS-Board (Foil Side) S-37...
Page 81
Model No. : TH-P60UT50A/M/P/Z SS-Board (Component Side) S-38...
Page 82
Model No. : TH-P60UT50A/M/P/Z SS2-Board S-39...
Page 83
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks TZTNP01PTUZ A-PRINT COMPLETE 1 (Z) (RTL)PAVCTH TZTNP01RCUA A-PRINT COMPLETE 1 (A) (RTL)PAVCTH TZTNP01PHUM A-PRINT COMPLETE 1 (M) (RTL)PAVCTH TZTNP01PGUP A-PRINT COMPLETE 1 (P) (RTL)PAVCTH...
Page 84
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C3047 F1G1A105A047 C 1UF 10V C3050 F1K1E106A134 C 10UF, 25V C3057 F1G1A105A047 C 1UF 10V C3058 F1G1A105A047 C 1UF 10V C3084 F1G1A105A047 C 1UF 10V...
Page 85
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C6720 F1G1H220A834 C 22PF, 50V 1 PAVCTH C6721 F1G1H220A834 C 22PF, 50V 1 PAVCTH C6722 F1G1E472A144 C 4700pF 25V 1 PAVCTH C6723 F1G1H101A834 C 100PF 50V...
Page 86
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C8230 F1G1C104A077 C 0.1UF 16V C8231 F1G1C104A077 C 0.1UF 16V C8232 F1G1C104A077 C 0.1UF 16V C8300 F1G1H100A833 C 10PF 50V 1 PAVCTH C8301 F1G1H100A833...
Page 87
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C8772 F1G1C104A077 C 0.1UF 16V C8773 F1G1C104A077 C 0.1UF 16V C8790 F1J1A106A110 C 10UF, 10V 1 PAVCTH C8791 F1J1A106A110 C 10UF, 10V 1 PAVCTH...
Page 88
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C16052 ECJ1VB1H392K C 3900UF, 50V C16061 F1K2J821A043 C 820PF, 630V 1 PAVCTH C16074 F1L2J472A021 C 4700PF, 630V 1 PAVCTH C16104 F1H1E470A130 C 47PF, 25V...
Page 89
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C16584 ECJ1VB1H392K C 3900UF, 50V C16593 F1H1H102A831 C 1000PF, 50V 1 PAVCTH C16602 F1H1H2200008 C 22PF, 50V C16603 F1K2J471A042 C 470PF, 630V 1 PAVCTH C16631 F0C2E225A286 C 2.2UF, 250V...
Page 90
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C17206 F1H1A105A099 C 1UF, 10V 1 PAVCTH C17221 ECJ1XB1C104K C 0.1UF, Z, 16V C17222 ECJ1XB1C104K C 0.1UF, Z, 16V C17234 F1H1H102A831 C 1000PF, 50V...
Page 91
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks D16021 B0FCBN000002 DIODE 1 PAVCTH D16022 B0FCBN000002 DIODE 1 PAVCTH D16042 B0FBCN000012 DIODE 1 PAVCTH D16051 B0FBCN000012 DIODE 1 PAVCTH D16071 B0ECKP000055 DIODE D16072 B0ECKP000055...
Page 92
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks D16720 B0ECHR000004 DIODE D16728 B0ECKP000055 DIODE D16823 DA3X103E0L DIODE 1 PAVCTH D16824 DA2J10100L DIODE D16825 DZ2J330M0L ZENER DIODE D16826 DZ2J330M0L ZENER DIODE D16828 DA2J10100L...
Page 93
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks IC16787 C0DBZYY00532 1 PAVCTH IC16795 C0CBALC00012 IC16921 C1ZBZ0004557 1 PAVCTH IC17201 C0JBAU000088 IC17202 C0JBAU000088 IC17301 C0JBAU000088 JK3001 K1FY315A0014 CONNECTOR 1 PAVCTH JK3100B K1U920A00004 CONNECTOR UNIT...
Page 94
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks PA2000 K5H4022A0031 FUSE PA8704 K5H5022A0031 FUSE PC16131 B3PBE0000065 1 PAVCTH PC16191 B3PBA0000625 1 PAVCTH PC16251 B3PBA0000580 PC16301 B3PBA0000580 PC16461 B3PBE0000065 1 PAVCTH PC16462 B3PBE0000060...
Page 95
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks Q16647 B1CBGD000001 Q16648 DSC2001Q0L TRANSISTOR Q16652 B1ADCE000027 TRANSISTOR Q16660 B1CFNQ000003 1 PAVCTH Q16661 B1JBER000002 TRANSISTOR Q16762 B1HFPFA00001 TRANSISTOR Q16815 B1ABCE000015 TRANSISTOR Q16817 DSC2001Q0L TRANSISTOR...
Page 96
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R2051 ERJ2RKF3091X M 3.09KOHM, J. 1/16W 1 PAVCTH R2052 D1BA6041A023 M 6.04KOHM,F.1/16 W 1 PAVCTH R2053 D1BA1692A023 M 16.9KOHM,F.1/16 W 1 PAVCTH R2054 D0GA223JA023...
Page 97
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R3322 D0GA473JA023 M 47KOHM, J,1/16W R3323 D0GA103JA023 M10KOHM, J.1/16 W R3324 D0GA102JA023 M1KOHM, J.1/16 W R3342 D0GA331JA023 M 330 OHM, J,1/16W R3343 D0GA331JA023 M 330 OHM, J,1/16W...
Page 98
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R8208 D1BA2700A023 M 270 OHM,F.1/16 W 1 PAVCTH R8217 D0GA221JA023 M220 OHM, J.1/16 W R8218 D0GA221JA023 M220 OHM, J.1/16 W R8219 D1BA2400A023 M 240 OHM,F.1/16 W...
Page 99
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R8658 D0GA680JA023 M 68 OHM, J,1/16W R8659 D0GA680JA023 M 68 OHM, J,1/16W R8660 D0GA680JA023 M 68 OHM, J,1/16W R8661 D0GA680JA023 M 68 OHM, J,1/16W...
Page 100
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R8910 D0GA103JA023 M10KOHM, J.1/16 W R8914 D0GA472JA023 M 4.7KOHM, J,1/16W R8917 D0GA103JA023 M10KOHM, J.1/16 W R8918 D0GA103JA023 M10KOHM, J.1/16 W R8919 D0GA103JA023 M10KOHM, J.1/16 W...
Page 101
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R16031 D0GF473JA048 M 47KOHM,J,1/3W R16032 D0GF473JA048 M 47KOHM,J,1/3W R16042 D0GF5R6JA047 M 5.6 OHM,J, 1/3W R16052 D0GF5R6JA047 M 5.6 OHM,J, 1/3W R16072 D0D2100JA038 W 100 OHM,2W...
Page 102
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R16466 D0GF473JA048 M 47KOHM,J,1/3W R16467 D0GF473JA048 M 47KOHM,J,1/3W R16471 D0GB203JA065 M 20KOHM J 1/10W R16472 D0GB222JA065 M 2.2KOHM,J,1/10W R16473 D0GD561JA052 M 560 OHM,J,1/8W R16474 D0GB102JA065...
Page 103
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R16681 D0GD100JA059 M 10 OHM,J,1/4W R16682 D0GD100JA059 M 10 OHM,J,1/4W R16684 D0GD100JA059 M 10 OHM,J,1/4W R16685 D1BD1500A066 M 150 OHM,F.1/8 W 1 PAVCTH R16686 D0GB103JA065...
Page 104
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R16946 D0GB221JA065 M 220 OHM J 1/10W R16947 D0GB472JA065 M 4.7KOHM, J,1/10W R16948 D0GB471JA065 M 470 OHM,J,1/10W R17101 D0GB101JA065 M 100 OHM,J,1/10W R17102 D0GB101JA065...
Page 105
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R17296 D0GB331JA065 M330 OHM J 1/10W R17311 D0GB101JA065 M 100 OHM,J,1/10W R17312 D0GB101JA065 M 100 OHM,J,1/10W R17313 D0GB101JA065 M 100 OHM,J,1/10W R17314 D0GB101JA065 M 100 OHM,J,1/10W...
Page 106
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks ZA16106 K4AD01Z00003 TERMINAL ZA16111 K4AA04D00002 TERMINAL ZA16116 K4AA04D00002 TERMINAL ZA16401 K4AZ01D00004 TERMINAL ZA16402 K4AZ01D00004 TERMINAL ZA16403 K4AZ01D00004 TERMINAL ZA16411 K4AA04D00002 TERMINAL ZA16412 K4AA04D00002 TERMINAL...
Page 107
Model No. : TH-P60UT50A/M/P/Z Exploded View 1 S-64...
Page 108
Model No. : TH-P60UT50A/M/P/Z Exploded View 2 S-65...
Page 109
Model No. : TH-P60UT50A/M/P/Z Accessories S-66...
Page 110
Model No. : TH-P60UT50A/M/P/Z Packing S-67...
Page 111
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks J0KG00000011 FERRITE CORE 1 (A) (Z) J0KG00000146 FERRITE CORE PACK FOR LAN CABLE 1 (A) (Z) K2AHYH000057 AC-INLET WITH CABLE 1 PAVCTH K2CK3YY00061 AC CORD...
Page 112
Model No. : TH-P60UT50A/M/P/Z Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks TSCKZ0010027 CABLE(A20-SC20) 1 PAVCTH TSCKZ0010030 CABLE(A33-SS33) 1 PAVCTH TSCLZ0010024 CABLE(C26-C36) 1 PAVCTH TSCLZ0010025 CABLE(C27-C37) 1 PAVCTH TSCLZ0010026 CABLE(C10-C20) 1 PAVCTH TSXM217 CABLE(SU11-SD11) TTU4TA0336 REAR COVER...
