Sharp QT-V5E Service Manual page 33

NO. PARTS CODE
[5] TRANSFORMERS
T101 9HX11844002600
T102 9HX11925001900
T401 9HX12306600110
!
[6] COILS
L100
L101 9HX11600100000
L102 9HX11993560400
L103 9HX11600100000
L104 9HX11994580400
L105 9HX11600470000
L105 9HX11913000703
L106 9HX11600470000
L201 9HX11600010000
L202 9HX11600100002
L203 9HX11600100002
L301 9HX11601220000
[7] VARIABLE CAPACITORS
TC101 9HX11513001000
TC102 9HX11513001000
[8] VIBRATORS
X101 9HX12002720016
X301 9HX12003276801
X302 9HX12025000000
[9] CAPACITORS
C101 9HX11215122002
C102 9HX11217410002
C103 9HX11217410002
C104 9HX11303071060
C105 9HX11216210002
C106 9HX11216210002
C107 9HX11216210002
C108 9HX11216210002
C109 9HX11216210002
C110 9HX11215047002
C111 9HX11216210002
C112 9HX11308044720
C113 9HX11217310002
C114 9HX11216210002
C115 9HX11217410002
C116 9HX11303064760
C117 9HX11215033002
C118 9HX11215033002
C128 9HX11216322002
C129 9HX11308051020
C130 9HX11308042220
C131 9HX11308044720
C133 9HX11214005002
C136 9HX11308054720
C137 9HX11308051020
C138 9HX11308051020
C139 9HX11217315002
C140 9HX11217315002
C141 9HX11308051020
C142 9HX11216210002
C143 9HX11303072260
C144 9HX11214003002
C145 9HX11217410002
C146 9HX11216210002
C147 9HX11217310002
C149 9HX11215047002
C150 9HX11216210002
C151 9HX11215010002
C152 9HX11217410002
C153 9HX11216322002
C154 9HX11303064760
C155 9HX11216322002
C156 9HX11217410002
C157 9HX11215047002
C158 9HX11217410002
C159 9HX11216322002
C160 9HX11214005002
C161 9HX11216210002
C162 9HX11214008002
C163 9HX11217347002
C164 9HX11215133002
C166 9HX11214005002
C168 9HX11303064760
C169 9HX11217410002
C170 9HX11215110002
C171 9HX11215110002
PRICE NEW PART
RANK MARK RANK
AM IFT YEL 7mm (7232)AHK7-850981
AM OSC RED 10mm (7938)CEC 0A10-862928
7321 X'FORMER,NC-B4749TM3 BS-STD,240V,EI-66/28,FUSED
INDUCTOR (R-TYPE) 10uH (OD3x8)
COIL 3T5 D3.5 #0.6 ACW <3564>
INDUCTOR (R-TYPE) 10uH (OD3x8)
COIL 3T5 D4.5 #0.8 ACW <4584>
CHOKE COIL 47uH
AM COIL 62:24 D10 (3+1) (L1=125
CHOKE COIL 47uH
CHOKE COIL 1uH (CW57-1ROM)
CHOKE COIL 10uH,2A (CW65-100K)
CHOKE COIL 10uH,2A (CW65-100K)
CHOKE COIL 220uH (H500-0039-28K)
CAP TRIMMER 10p 3 LEADS
CAP TRIMMER 10p 3 LEADS
CRYSTAL 7.2MHz (HC49U)+-30PPM / JF7.200-134
CRYSTAL JF32.768-140 d2x6
CRYSTAL JF5.000000-1101-185MHZ +-30ppm (HC49U)
CHIP CAP 50V+-10% 220p (0603)
CHIP CAP 50V +80-20% 0.1u (0603)=100000p
CHIP CAP 50V +80-20% 0.1u (0603)=100000p
E CAP 16V +80-20% 100u (5x11)
CHIP CAP 50V+-20% 0.001u (0603)=1000p
CHIP CAP 50V+-20% 0.001u (0603)=1000p
CHIP CAP 50V+-20% 0.001u (0603)=1000p
CHIP CAP 50V+-20% 0.001u (0603)=1000p
CHIP CAP 50V+-20% 0.001u (0603)=1000p
CHIP CAP 50V+-10% 47p (0603)
CHIP CAP 50V+-20% 0.001u (0603)=1000p
E CAP 50V+-20% 0.47u (5x11)
CHIP CAP 50V +80-20% 0.01u (0603)=10000p
CHIP CAP 50V+-20% 0.001u (0603)=1000p
CHIP CAP 50V +80-20% 0.1u (0603)=100000p
E CAP 16V +80-20% 47u
CHIP CAP 50V+-10% 33p (0603)
CHIP CAP 50V+-10% 33p (0603)
CHIP CAP 50V+-20% 0.022u (0603)=22000p
E CAP 50V+-20% 1u (5x11)
E CAP 50V+-20% 0.22u (5x11)
E CAP 50V+-20% 0.47u (5x11)
CHIP CAP 50V+-5% 5p (0603)
E CAP 50V+-20% 4.7 (5x11)
E CAP 50V+-20% 1u (5x11)
E CAP 50V+-20% 1u (5x11)
CHIP CAP 50V +80-20% 0.015u (0603)=15000p
CHIP CAP 50V +80-20% 0.015u (0603)=15000p
E CAP 50V+-20% 1u (5x11)
CHIP CAP 50V+-20% 0.001u (0603)=1000p
E CAP 16V +80-20% 220u
CHIP CAP 50V+-5% 3p (0603)
CHIP CAP 50V +80-20% 0.1u (0603)=100000p
CHIP CAP 50V+-20% 0.001u (0603)=1000p
CHIP CAP 50V +80-20% 0.01u (0603)=10000p
CHIP CAP 50V+-10% 47p (0603)
CHIP CAP 50V+-20% 0.001u (0603)=1000p
CHIP CAP 50V+-10% 10p (0603)
CHIP CAP 50V +80-20% 0.1u (0603)=100000p
CHIP CAP 50V+-20% 0.022u (0603)=22000p
E CAP 16V +80-20% 47u
CHIP CAP 50V+-20% 0.022u (0603)=22000p
CHIP CAP 50V +80-20% 0.1u (0603)=100000p
CHIP CAP 50V+-10% 47p (0603)
CHIP CAP 50V +80-20% 0.1u (0603)=100000p
CHIP CAP 50V+-20% 0.022u (0603)=22000p
CHIP CAP 50V+-5% 5p (0603)
CHIP CAP 50V+-20% 0.001u (0603)=1000p
CHIP CAP 50V+-5% 8p (0603)
CHIP CAP 50U +80-20% 0.047U (0603)
CHIP CAP 50V+-10% 330p (0603)
CHIP CAP 50V+-5% 5p (0603)
E CAP 16V +80-20% 47u
CHIP CAP 50V +80-20% 0.1u (0603)=100000p
CHIP CAP 50V+-10% 100p (0603)
CHIP CAP 50V+-10% 100p (0603)
3
QT-V5E/QT-V5H
DESCRIPTION
