Dell Inspiron 11 3000 Setup And Specifications
2-in-1
Hide thumbs
Also See for Inspiron 11 3000:
- Quick start manual ,
- Service manual (110 pages) ,
- Setup and specifications (24 pages)
Related Manuals for Dell Inspiron 11 3000
Summary of Contents for Dell Inspiron 11 3000
- Page 1 Inspiron 11 3000 2-in-1 Setup and Specifications Regulatory Model: P25T Regulatory Type: P25T002 November 2021 Rev. A04...
- Page 2 A WARNING indicates a potential for property damage, personal injury, or death. © 2017-2018 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.
-
Page 3: Table Of Contents
Ports and Connectors............................... 12 Communications................................. 12 Video..................................... 12 Audio..................................... 12 Storage....................................12 Media-card reader................................13 Display....................................13 Keyboard....................................13 Camera....................................14 Touchpad..................................... 14 Battery....................................14 Power Adapter..................................15 Computer Environment..............................15 Chapter 5: Keyboard shortcuts....................16 Chapter 6: Getting help and contacting Dell.................18 Contents... -
Page 4: Chapter 1: Set Up Your Computer
SLN151664 at www.dell.com/support. For Windows: Follow the on-screen instructions to complete the setup. When setting up, Dell recommends that you: ● Connect to a network for Windows updates. NOTE: If connecting to a secured wireless network, enter the password for the wireless network access when prompted. - Page 5 Table 1. Locate Dell apps (continued) Dell Update Updates your computer with critical fixes and latest device drivers as they become available. Dell Digital Delivery Download software applications, which are purchased but not pre-installed on your computer. 4. Create recovery drive for Windows.
-
Page 6: Chapter 2: Create A Usb Recovery Drive For Windows
1. Connect the USB recovery drive to your computer. 2. Restart your computer. 3. Press F12 after the Dell logo is displayed on the screen to access the boot menu. A Preparing one-time boot menu message appears. 4. After the boot menu loads, select the USB recovery device under UEFI BOOT. -
Page 7: Chapter 3: Views
Press to put the computer in sleep state if it is turned on. Press and hold for 4 seconds to force shut-down the computer. NOTE: You can customize the power-button behavior in Power Options. For more information, see Me and My Dell at www.dell.com/support/manuals. 2. Volume-control button Press to increase or decrease the volume. -
Page 8: Display
Display 1. Left microphone Provides digital sound input for audio recording and voice calls. 2. Camera Enables you to video chat, capture photos, and record videos. 3. Camera-status light Turns on when the camera is in use. 4. Right microphone Provides digital sound input for audio recording and voice calls. -
Page 9: Bottom
Press to right-click. 5. Right speaker Provides audio output. Bottom 1. Service Tag label The Service Tag is a unique alphanumeric identifier that enables Dell service technicians to identify the hardware components in your computer and access warranty information. Modes Notebook Views... - Page 10 Tablet Stand Tent Views...
-
Page 11: Chapter 4: Specifications
Specifications Computer model Inspiron 11–3179 Dimensions and weight Table 2. Dimensions and weight Height 21.85 mm (0.86 in) Width 291.61 mm (11.48 in) Depth 201.92 mm (7.95 in) Weight 1.35 kg (2.98 lb) NOTE: The weight of your laptop varies depending on the configuration ordered and the manufacturing variability. -
Page 12: Ports And Connectors
Ports and Connectors Table 6. Ports and connectors External: ● One USB 3.1 Gen 1 port ● Two USB 2.0 ports Audio/Video ● One HDMI port ● One headset (headphone and microphone combo) port Table 7. Ports and connectors Internal: One M.2 slot for Wi-Fi and Bluetooth combo card Communications Table 8. -
Page 13: Media-Card Reader
Table 11. Storage specifications (continued) ● One Solid State Drive (SSD) Media-card reader Table 12. Media-card reader specifications Type One microSD-card slot Cards supported ● Micro Secure Digital (microSD) ● Micro Secure Digital High Capacity (microSDHC) ● Micro SD Extended Capacity (microSDXC) Display Table 13. -
Page 14: Camera
Camera Table 15. Camera specifications Resolution ● Still image: 0.92 megapixel ● Video: 1280 x 720 (HD) at 30 fps (frames per second) Diagonal-viewing angle 74 degrees Touchpad Table 16. Touchpad Resolution Horizontal 1940 Vertical 1040 Dimensions Height 55 mm (2.16 in) Width 100 mm (3.93 in) Battery... -
Page 15: Power Adapter
Power Adapter Table 18. Power-adapter specifications Type 45 W 65 W Input voltage 100 VAC–240 VAC Input frequency 50 Hz–60 Hz Input current (maximum) 1.30 A 1.70 A Output current (continuous) 2.31 A 3.34 A Rated output voltage 19.50 VDC Temperature range: Operating 0°C to 40°C (32°F to 104°F) Temperature range: Storage... -
Page 16: Chapter 5: Keyboard Shortcuts
Keyboard shortcuts NOTE: Keyboard characters may differ depending on the keyboard language configuration. Keys used for shortcuts remain the same across all language configurations. Table 20. List of keyboard shortcuts Icons Description Mute audio Decrease volume Increase volume Play previous track/chapter Play/Pause Play next track/chapter Switch to external display... - Page 17 Table 20. List of keyboard shortcuts (continued) Icons Description Page Down Keyboard shortcuts...
-
Page 18: Chapter 6: Getting Help And Contacting Dell
Getting help and contacting Dell Self-help resources You can get information and help on Dell products and services using these self-help resources: Table 21. Self-help resources Information about Dell products and services www.dell.com Dell Help & Support app Tips Contact Support In Windows search, type Contact Support, and press Enter.
