HCD-GX90D/RV800D
SERVICE MANUAL
Ver 1.3 2003. 05
• HCD-GX90D/RV800D are the tuner, deck, DVD
and amplifier section in MHC-GX90D/RV800D.
This system incorporates Dolby* Digital, Pro Logic
Surround, DTS**, and the DTS Digital Surround
System.
* Manufactured under license from Dolby
Laboratories.
"Dolby", "Pro Logic", and the double-D symbol
are trademarks of Dolby Laboratories.
** Manufactured under license from Digital Theater
Systems, Inc. "DTS" and "DTS Digital Surround"
are registered trademarks of Digital Theater
Systems, Inc.
Amplifier section
North American model:
HCD-GX90D
Continuous RMS power output (reference)
Front speaker:
60 + 60 watts
(6 ohms at 1 kHz, 10%
THD)
Center speaker:
45 watts (8 ohms at 1 kHz,
10% THD)
Rear speaker:
40 + 40 watts
(6 ohms at 1 kHz, 10%
THD)
Sub woofer:
55 watts (4 ohms at 1 kHz,
10% THD)
Total harmonic distortion less than 0.07%
(6 ohms at 1 kHz, 70 W)
European model:
HCD-RV800D
DIN power output
Front speaker:
45 + 45 watts
(6 ohms at 1 kHz, DIN)
Center speaker:
33 watts
(8 ohms at 1 kHz, DIN)
Rear speaker:
30 watts
(6 ohms at 1 kHz, DIN)
Sub woofer:
38 watts
(4 ohms at 1 kHz, DIN)
Continuous RMS power output (reference)
Front speaker:
60 + 60 watts
(6 ohms at 1 kHz, 10%
THD)
Center speaker:
45 watts (8 ohms at 1 kHz,
10% THD)
Rear speaker:
40 + 40 watts
(6 ohms at 1 kHz, 10%
THD)
Sony Corporation
9-874-118-04
2003E16-1
Home Audio Company
© 2003.05
Published by Sony Engineering Corporation
Photo : HCD-RV800D
Model Name Using Similar Mechanism
DVD
DVD Mechanism Type
Section
Base Unit Name
Model Name Using Similar Mechanism
Tape deck
Section
Tape Transport Mechanism Type
SPECIFICATIONS
Sub woofer:
55 watts
(4 ohms at 1 kHz, 10%
THD)
Music power output (reference)
Front speaker:
120 + 120 watts
(6 ohms at 1 kHz, 10%
THD)
Center speaker:
90 watts (8 ohms at 1 kHz,
10% THD)
Rear speaker:
80 + 80 watts
(6 ohms at 1 kHz, 10%
THD)
Sub woofer:
110 watts
(4 ohms at 1 kHz, 10%
THD)
COMPONENT VIDEO OUT:
Y: 1 Vp-p, 75 ohms
P
, P
: 0.7 Vp-p, 75 ohms
B
R
PHONES (stereo mini jack):
accepts headphones of
8 ohms or more
Front speaker:
accepts impedance of 6 to
16 ohms
Rear speaker
accepts impedance of
24 ohms
Center speaker
accepts impedance of
24 ohms
MINI HI-FI COMPONENT SYSTEM
US Model
Canadian Model
HCD-GX90D
AEP Model
UK Model
HCD-RV800D
NEW
CDM58D-DVBU17
DVBU17
NEW
CWM43RR-01
Sub woofer speaker
accepts impedance of
12 to 16 ohms
Disc player section
System
Compact disc and digital
audio and video system
Laser
Semiconductor laser
(DVD: λ=650 nm,
CD: λ=780 nm)
Emission duration:
continuous
Wavelength
780 – 790 nm
Frequency response
DVD (PCM 48 kHz):
2 Hz – 22 kHz (±1 dB)
CD: 2 Hz – 20 kHz
(±1 dB)
Video color system format
NTSC, PAL
CD OPTICAL DIGITAL OUT
(Square optical connector jack, rear panel)
Wavelength
660 nm
Output Level
–18 dBm
— Continued on next page —
