Service Manual FV-08VQC5 FV-11VQC5 This service information is designed for experienced repair technicians only and is not designed for use by the general public. It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product. Products powered by electricity should be serviced or repaired only by experienced professional technicians.
33 FFV1320001S ESP Mark 34 FFV0810010S Warning Label 35 FFV2260003S UL Mark 36 FFV2260002S HVI Mark 37 FFV6730045S Warning Label 38 FFV5720015S Scale Tape Part Name Q'ty Not Include Humid Sensor Lead Wire Not Include Sensor Box Assy FV-08VQC5 FV-11VQC5 Remark...
Page 9
FFV7000089S Truss Tap Screw FFV7000168S Screw Assembly FFV7000195S Pan Tap Screw FFV7000074S Truss Tap Screw FFV7000140S Pan Tap Screw FFV7000145S Truss Tap Screw Part Name Q'ty English,For CA Market/USA Market French,For USA Market Spanish,For CA Market Include Spring Washer&P.R Washer FV-08VQC5 FV-11VQC5 Remark...
Page 10
4. Parts List Part No. FFV1600111S Frame Assembly FFV0420027S Bracket Cover FFV0800001S Casing Support FFV0000121S Adapter Assembly FFV0900048S Connector Plate FFV0900049S Connector Assy V FFV3402103S Earth Lead Wire Assy FFV2800012S Junction Cover FFV0760028S Capacitor Box 10 FFV3702217S Motor Assembly (10) FFV3702215S Motor Assembly 11 FFV3730086S Motor Support 12 FFV0400103S Blade 13 FFV7020021S Nut...
Page 11
4. Parts List Part No. 39 FFV2260003S UL Mark 40 FFV2260002S HVI Mark 41 FFV6730045S Warning Label 42 FFV5720015S Scale Tape 43 FFV6730051S Wiring Label 44 FFV5710023S Suspension Bracket Ⅰ 45 FFV5710024S Suspension Bracket Ⅱ 46 FFV5710018S Suspension Bracket Ⅳ 47 FFV5710019S Suspension Bracket Ⅲ...
