READ ALL INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN.
※ Keep the waveguide cover clean at all times.
Wipe the oven interior with a soft damp cloth after each use.
If you leave grease or fat anywhere in the cavity it may overheat, smoke or even catch fire
when next using the oven.
O V E N
M A N U A L
M O D E L S
SMC1131CW-CR
Followed by letter indicating color B=black, W=white
C O N T E N T S
Microwave Energy .................... 3
Frequency Interference Statement ............
2
24T745A
5
6
6
7
8
9-10
11
23
Advertisement
Table of Contents
Related Manuals for Sharp Carousel SMC1131CW-CR
Summary of Contents for Sharp Carousel SMC1131CW-CR
-
Page 1: Table Of Contents
24T745A R E F U R B I S H E D M I C R O W A V E O V E N O P E RAT I O N M A N U A L M O D E L S SMC1131CW-CR Followed by letter indicating color B=black, W=white C O N T E N T S... -
Page 2: For Customer Assistance
CONTACT SHARP If at any time you have questions or comments concerning your SHARP product, please contact the SHARP Customer Assistance Center. They are available to assist you through multiple contact methods for your convenience: EMAIL... -
Page 3: Precautions To Avoid Possible Exposure To Excessive Microwave Energy
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. -
Page 4: Important Safety Instructions
I M P O R T A N T S A F E T Y I N S T R U C T I O N S When using electrical appliances, basic safety precautions should be followed, including the following: WARNING-To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave energy: 11. -
Page 5: Frequency Interference Statement
F E D E R A L C O M M U N I C A T I O N S C O M M I S S I O N R A D I O F R E Q U E N C Y I N T E R F E R E N C E S T A T E M E N T WARNING: This equipment generates and uses ISM frequency energy and if not installed and used properly, that is in strict accordance with the manufacturer's instructions, may cause interference to radio and television... -
Page 6: Installation Guide
I N S T A L L A T I O N G U I D E 1. Examine the oven after unpacking. Check for damage such as a misaligned door, broken door or dent in the cavity. If any damage is visible, DO NOT INSTALL, and notify your dealer immediately. 2. -
Page 7: Specifications
S P E C I F I C A T I O N S 120V AC, 60Hz SINGLE PHASE WITH POWER SUPPLY GROUNDING INPUT POWER 1500 W MICROWAVE ENERGY OUTPUT 1000 W FREQUENCY 2,450MHz OUTSIDE DIMENSIONS (W x H x D) 20.3 x 12.0 x 14.8 in. -
Page 8: Features Diagram
F E A T U R E S D I A G R A M 1 Door latch - When the door is closed, it will 8 Waveguide cover - Protects the microwave automatically shut off. If the door is opened outlet from splashes of cooking foods. - Page 9 F E A T U R E S D I A G R A M 1 DISPLAY - Cooking time, power level, 9 EXPRESS COOK - Used to set 1-6 minutes indicators and current time are displayed. preset cooking time at 100% power level. 2 ONE TOUCH COOK - Used to cook or 0 KITCHEN TIMER - Used as a minute timer, reheat specific quantites of food.
-
Page 10: Operation Procedure
O P E R A T I O N P R O C E D U R E This section includes useful information about oven operation. Plug power supply cord into a standard 3-pronged Time clock returns to the present time when the 13 Amp, 120V AC 60Hz power outlet. -
Page 11: Controls
C O N T R O L S SETTING THE CLOCK When the oven is first plugged in, the display will show “:0” and a tone will sound. If the AC power ever goes off, the display show “ : 0” when the power comes back on. 1. - Page 12 C O N T R O L S KITCHEN TIMER MODE (CONTINUED) HOW TO USE TO DELAY THE START OF COOKING 1. Press KITCHEN TIMER pad. The TIMER indicator lights and “ : 0” is displayed. 2. Press the amount of time you want The display will show what you pressed.
- Page 13 C O N T R O L S AUTO DEFROSTING AUTO DEFROST lets you easily defrost food by eliminating guesswork in determining defrosting time. Follow the steps below for easy defrosting. 1. Press MEAT pad. The lb indicator light and “ 1.0 ” is displayed. 2.
- Page 14 C O N T R O L S TIME DEFROSTING When TIME DEFROST is selected, the automatic cycle divides the defrosting time into periods of alternating defrost and stand times by cycling on and off. 1. Press DEFROST pad. The Defrost indicator lights and “ : 0” is displayed. 2.
- Page 15 C O N T R O L S COOKING IN TWO STAGES All recipes require the frozen foods to be defrosted fully before cooking. This oven can be programmed to automatically defrost foods before cooking. 1. Press DEFROST pad. The Defrost indicator lights and “ : 0” is displayed.
- Page 16 C O N T R O L S +30 SEC +30 sec allows you to reheat for 30 seconds at 100% (full power) by simply pressing the +30 sec pad. By repeatedly pressing the +30 sec pad, you can also extend reheating time to 59 minutes 59 seconds by 30 second increments.
- Page 17 C O N T R O L S ONE TOUCH COOK (CONTINUED) 1. Press FROZEN PIZZA pad once When you press FROZEN PIZZA pad once, “ 7 ” for 7 oz pizza or twice for 14 oz is displayed. pizza. After 1.5 seconds, the display is changed into the cooking time and the oven starts cooking.
- Page 18 C O N T R O L S ONE TOUCH COOK (CONTINUED) 1. Press POTATO pad once for 1 ea, When you press POTATO pad once, "1" is twice for 2 ea or three times for 3 displayed. ea of potatoes. After 1.5 seconds, the display is changed into cooking time and the oven starts cooking.
- Page 19 C O N T R O L S CHILD SAFETY LOCK Child safety lock feature may lock the control panel to prevent the oven from being accidentally started or used by children. To lock, press and hold STOP/CLEAR pad for 3 seconds.
-
Page 20: Care Of Your Microwave Oven
C A R E O F Y O U R M I C R O W A V E O V E N The oven should be cleaned regularly and any food deposits removed. Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation. - Page 21 C A R E O F Y O U R M I C R O W A V E O V E N BEFORE YOU CALL FOR SERVICE Refer to following checklist, you may prevent an unnecessary service call. * The oven doesn’t work : * Sparking in the cavity;...
-
Page 22: Questions And Answers
Q U E S T I O N S A N D A N S W E R S * Q : I accidentally ran my microwave oven without * Q : What does “standing time” mean? any food in it. Is it damaged? A : “Standing time”... -
Page 23: Cooking Instructions
C O O K I N G I N S T R U C T I O N S UTENSIL GUIDE Only use utensils that are suitable for use in microwave ovens. To cook food in the microwave oven, the microwaves must be able to penetrate the food, without being reflected or absorbed by the dish used. - Page 24 C O O K I N G I N S T R U C T I O N S USE YOUR MICROWAVE OVEN SAFELY General Use Do not attempt to defeat or tamper with safety Do not operate the oven if door seals or sealing interlocks.
- Page 25 C O O K I N G I N S T R U C T I O N S MICROWAVING PRINCIPLES Microwave energy has been used in this country to cook and reheat food since early experiments with RADAR in World War ll.
- Page 26 C O O K I N G I N S T R U C T I O N S COOKING TECHNIQUES STANDING TIME STARTING TEMPERATURE Dense foods e.g. meat, jacket potatoes and cakes, The colder the food, the longer it takes to heat up. Food require standing time(inside or outside of the oven) after from a fridge takes longer to reheat than food at room cooking, to allow heat to finish conducting to cook the...
- Page 27 C O O K I N G I N S T R U C T I O N S DEFROSTING GUIDE ▶ Do not defrost covered meat. Covering might allow ▶ When defrosted, food should be cool, but softened in cooking to take place.
- Page 28 C O O K I N G I N S T R U C T I O N S COOKING & REHEATING CHART Cooking chart C O O K I N G T I M E I T E M P O W E R L E V E L S P E C I A L I N S T R U C T I O N P E R L B .
- Page 29 C O O K I N G I N S T R U C T I O N S COOKING & REHEATING CHART Reheating chart • Baby food particularly needs to be checked carefully before serving to prevent burns. • When heating pre-packaged ready-cooked foods, always follow the pack instructions carefully. •...
- Page 30 C O O K I N G I N S T R U C T I O N S VEGETABLE CHART Use a suitable glass pyrex bowl with lid. Add 30-45ml cold water(2-3 tbsp.) for every 250g unless another water quantity is recommended - see table.
- Page 31 C O O K I N G I N S T R U C T I O N S RECIPES TOMATO & ORANGE SOUP 1 oz.(25g) butter 1. Melt the butter in a large bowl on PL10 for 30 1 medium onion, chopped seconds.
- Page 32 C O O K I N G I N S T R U C T I O N S BLUE CHEESE & CHIVE JACKETS 2 baking potatoes, 1. Prick each potato in several places. Cook on PL10 for (approx.9 oz.(250g) each) 7-9 minutes.
- Page 33 C O O K I N G I N S T R U C T I O N S SCRAMBLED EGG oz.(15g) butter 1. Melt the butter in a bowl on PL10 for 30 seconds. 2 eggs 2. Add the eggs, milk and seasoning and mix well. 2 tbsp(30ml) milk 3.
- Page 34 SHARP ELECTRONICS CORPORATION 100 Paragon Drive, Montvale, NJ 07645 APR. 2020...
