Page 1
HT752TP_NAACLLD_ENG_MFL37641052 DVD RECEIVER OWNER’S MANUAL MODEL: HT752TP Main Unit - HT752TP-D0 Speakers - SH72TP-F SH72TP-S SH72TP-C SH72TP-A Before connecting, operating or adjusting this product, please read this instruction booklet carefully and completely.
Page 2
CAUTION: The apparatus should not be exposed to water CAUTION (dripping or splashing) and no objects filled with liquids, such RISK OF ELECTRIC SHOCK as vases, should be placed on the apparatus. DO NOT OPEN CAUTION concerning the Power Cord Most appliances recommend they be placed upon CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK...
Introduction Maintenance and Service Maintenance and Service ....3 Before use ......4 Refer to the information in this chapter before Front Panel/Rear Panel .
Introduction Before use Types of Playable Discs To ensure proper use of this product, please read this (8 cm / 12 cm disc) owner’s manual carefully and retain it for future reference. Video CD (VCD) (8 cm / 12 cm disc) This manual provides information on the operation Audio CD and maintenance of your DVD/CD Receiver.
Front Panel/Rear Panel STANDBY/ON ( VOLUME indicator - Lights red when STOP (x) the standby mode of unit is off. MONO/STEREO/ PAUSE (X X ) FUNCTION POWER Press and hold this button for about 3 DISC slot seconds, then press repeatedly to select other function.
RESOL. Changes the resolution depending on To start a search for a specific PTY type. your TV. HDMI Controls the TV. (LG TV only) Switches the HDMI mode to HDMI (See page16) (active) and OFF (inactive). Remote Control Operation Range...
Installation and Setup TV Connection SCART connection Connect the EURO AV1 (TO TV) connector on the Make one of the following connections, depending on DVD/CD Receiver to the corresponding jacks on the the capabilities of your existing equipment. TV using the scart cable (T). Tips: If your television is a high-definition or “digital ready”...
Optional Equipment Connection AV2 AUDIO INPUT (L/R)/ VIDEO INPUT USB connection connection (A) Connect the USB port of USB Memory (or MP3 Connect a OUTPUT of auxiliary device to the AV2 player, etc.) to the USB port on the rear of the unit. AUDIO INPUT (L/R)/ VIDEO INPUT connector.
Speaker System Connection 1. Connect the SYSTEM connector on the DVD/CD Receiver to the SYSTEM connector on the active subwoofer with the supplied system cable (S). If you don’t connect rightly the system cable, the “CHECK CABLE” appears in the display window. 2.
HDMI Connection About HDMI HDMI (High Definition Multimedia Interface) supports both video and audio on a single digital connection for an easy all- digital output to an HDMI or DI-equipped TV. Connection to an HDMI TV requires an HDMI cable while connection to a DVI-equipped TV requires a DVI HDMI compatible TV adapter besides a HDMI cable.
Displaying Disc Information GENERAL OPERATION On - screen 1. Press SETUP. The Setup menu appears. 2. Use v / V to select the desired option then press You can display various information about the disc B to move to the second level. The screen shows loaded on-screen.
DISPLAY DISPLAY 16 : 9 TV Aspect Widescreen Display Mode Progressive Scan Move Select TV Aspect 4:3 – Select when a standard 4:3 TV is connected. 16:9 – Select when a 16:9 wide TV is connected. Display Mode The display Mode setting works only when the TV Aspect mode is set to “4:3”.
AUDIO 5.1 Speaker Setup Make the following settings for the built-in 5.1 channel Each DVD disc has a variety of audio output options. surround decoder. Set the receiver’s AUDIO options according to the type of audio system you use. 1. Press ENTER, and the 5.1 Speaker Setup menu appears.
LOCK (Parental Control) Area Code Enter the code of the area whose standards were LOCK used to rate the DVD video disc, based on the list on Rating Unlock page 24. Password **** Area Code 1. Select “Area Code” on the LOCK menu then press B.
Operation General features Buttons Operations Discs EJECT Pulls out the disc. X (PAUSE) During playback, press X to pause playback. Press X repeatedly to play Frame-by-Frame. DivX SKIP (. / >) During playback, press SKIP (. or >) to go to the next chapter/track or to return to the beginning of the current chapter/track.
DivX Your remote control is capable of operating your To enter a Marker DVD/CD Receiver as well as limited functions of LG You can start playback from up to nine memorized points. To enter a marker, press MARKER at the Follow the instructions below to operate your LG TV.
Playing an Audio CD or MP3/WMA file Programmed Playback This unit can play Audio CDs or MP3/WMA files. The program function enables you to store your favorite tracks from any disc in the receiver memory. A MP3/ WMA/ Audio CD program can contain 300 tracks.
Viewing a JPEG file JPEG JPEG disc compatibility with this player is limited as follows: This unit can play discs with JPEG files. • Depending upon the size and the number of Before playing JPEG recordings, read the notes on JPEG files, it could take a long time for the JPEG Recordings on the right.
Playing a DivX Movie file DivX disc compatibility with this player is limited as follows: Using this DVD/CD Receiver you can play DivX disc. • Available resolution size of the DivX file is under 1. Insert a disc. The MOVIE menu appears on the TV 800x600 (W x H) pixel.
DVD Audio Discs Moving to another GROUP Some DVD Audio discs divide contents into different DVD Audio is a new disc format building on the groups. Your player enables you to quickly access success of DVD to provide high quality, different groups during playback via the on-screen uncompressed, multi-channel audio for a new display.
Presetting the Radio Stations Listening to the Radio You can preset 50 stations for FM and AM (MW). Preset radio stations in the DVD/CD Receiver’s Before tuning, make sure that you have turned down memory first (see “Presetting radio stations” on the the volume.
RDS Operation Programme Search (PTY) A major benefit of RDS is its ability to encode This unit is equipped with RDS (Radio Data System), broadcasts with Programme Type (PTY) codes that which brings a wide range of information to FM radio. indicate the type of material being broadcast.
The SLEEP indicator and the sleep time appears in the display window. XTS-P ON The unique sound quality of the LG Technology 2. Each time you press SLEEP the setting creates the optimum sound for you to play the changes in the following order.
Reference Language Codes Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu. Language Code Language Code Language Code Language Code Abkhazian 6566 Fiji 7074 Lingala 7678 Singhalese 8373 Afar 6565 Finnish 7073 Lithuanian...
Troubleshooting Check the following guide for the possible cause of a problem before contacting service. Correction Symptom Cause • Plug the power cord securely into the • The power cord is disconnected. No power. wall outlet. • Insert a disc. (Check that the DVD or, •...
Page 26
Cause Correction Symptom • The antenna is positioned or connected Radio stations cannot • Connect the antenna securely. poorly. be tuned in. • Adjust the antennas and connect an external antenna if necessary. • The signal strength of the stations is too •...
Specifications Power supply Refer to main label. Power consumption Refer to main label. Net Weight 2.2 kg External dimensions (W x H x D) 430 x 57 x 295 mm Operating conditions Temperature: 5°C to 35°C, Operation status: Horizontal Operating humidity 5% to 85% Laser Semiconductor laser, wavelength 650 nm...
