4. Connection cable between outdoor unit and AHU-Kit
a. PZ3 / PZH3 connection wiring
For the power supply cable of the outdoor units, refer to the relevant installation instructions of the
outdoor unit in question.
Connection cable between AHU kit and outdoor unit:
Outdoor Unit
U-36 ~ 71PZ3E5
U-100 ~ 140PZ3E5, U-100 ~ 140PZ3E8
U-36~60PZH3E5
U-71 ~ 140PZH3E5, U-71 ~ 140PZH3E8
Connection cable
0,75 mm² (min.)
0,75 mm² (min.)
0,75 mm² (min.)
0,75 mm² (min.)
