FR1516 Troubleshooting Guide

Table of Contents

How to set the NAV path file....................................................................Page 1
A device info screen appears when I load either the Tom Tom or
HEMA navigation.......................................................................................Page 3
My unit is stuck on a white screen with a cross....................................Page 4
My reverse camera is showing a black screen.......................................Page 6
My unit freezes...........................................................................................Page 7
After I have viewed my reverse camera and disengaged reverse, a black
image appears on my screen for about 15 seconds..............................Page 7
My unit is intermittently picking up satellites........................................Page 8
My unit is not picking up satellites at all.................................................Page 8
My unit is not reading the SD card...........................................................Page 8

Advertisement

Table of Contents
loading

Related Manuals for Polaris FR-1516

Summary of Contents for Polaris FR-1516

  • Page 1: Table Of Contents

    FR1516 Troubleshooting Guide Table of Contents How to set the NAV path file…………………………………………………………..Page 1 My NAV path file is not saving after the car is shutdown………………….Page 3 A device info screen appears when I load either the Tom Tom or HEMA navigation…………………………………………………………………………...Page 3 My unit is stuck on a white screen with a cross……………………………...Page 4 My reverse camera is showing a black screen………………………………...Page 6...

  • Page 2: How To Set The Nav Path File

    How to set the Nav path file If the system is setup with both street mapping and off road mapping the correct mapping software should load when you press the applicable icon. If it is not loading correctly (for example the off road maps are loading when you press Tom Tom and vice versa) please follow the steps below to ensure that your nav path file is set correctly: Touch SETUP from the main menu...
  • Page 3 Touch: \StorageCard\Mobilenavigator\ Navigation.exe to highlight it and press OK to save Off Road maps If you have the off road mapping loaded please select OFF ROAD MAP from the setup menu Touch: \StorageCard\Oziexplorer\ OziExplorerCE.exe to highlight it and press OK to save If the above steps have been followed correctly then you should have no issue with your maps loading.

  • Page 4: My Nav Path File Is Not Saving After The Car Is Shutdown

    My NAV path file is not saving after car is shutdown If the NAV path file is not saving after you turn off the car and it keeps prompting you to set the NAV path file when you touch navigation, don't set it here.

  • Page 5: My Unit Is Stuck On A White Screen With A Cross

    My unit is stuck on a white screen with a cross. If the unit is stuck on the calibration screen, you will need to calibrate it correctly in order to exit from this screen. You need to use something along the lines of a stylus pen or something small enough so that you can touch the centre of the cross correctly.
  • Page 6 Once you have the appropriate tool, please hold your tool down on the centre of the cross. The cross will move around the screen automatically Follow the same procedure with all of the crosses until you see OK at the top of the screen.

  • Page 7: My Reverse Camera Is Showing A Black Screen

    My reverse camera is showing a black screen The system is designed to take a second camera. If you do not have a second camera hooked up, you may have accidentally switched it over to the caravan camera by accident and it is now defaulting to the non-existent camera. When you are in reverse gear, press the VAN button to switch back over to your reverse camera.

  • Page 8: My Unit Freezes

    My unit freezes Try resetting the unit. The RESET button is located next to the power button. Grab something small enough to fit into the RESET hole and push it in until the unit restarts. If this does not fix the issue then please contact your service agent. After I have viewed my reverse camera and disengaged reverse gear, a black image appears on my screen for about 15 seconds.

  • Page 9: My Unit Is Intermittently Picking Up Satellites

    Press the minus button to change the setting to FRONT CAMERA OFF If you do not have the front cam setting, please contact your service agent as your unit requires an update. My unit is intermittently picking up satellites Some installers position the GPS antenna underneath the dash, however we recommend that the GPS antenna be located on top of the dashboard for better signal.
