- Page 1 User Manual GETTING STARTED? EASY. ZGH65411XB ZGH65414XB ZGH65414XX EN User Manual...
-
Page 2: Safety Information
SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. -
Page 3: Safety Instructions
NEVER try to extinguish a fire with water, but switch off the • appliance and then cover flame e.g. with a lid or a fire blanket. CAUTION: The cooking process has to be supervised. A short • term cooking process has to be supervised continuously. WARNING: Danger of fire: Do not store items on the cooking •... -
Page 4: Electrical Connection
• Do not install the appliance adjacent to a door removed from the holder), earth leakage trips or under a window. This prevents hot cookware and contactors. falling from the appliance when the door or the • The electrical installation must have an isolation window is opened. - Page 5 • Used oil, that can contain food remnants, can • Discoloration of the enamel or stainless steel cause fire at a lower temperature than oil used has no effect on the performance of the for the first time. appliance. • Do not put flammable products or items that are CARE AND CLEANING wet with flammable products in, near or on the...
-
Page 6: Product Description
PRODUCT DESCRIPTION COOKING SURFACE LAYOUT Semi-rapid burner Rapid burner Auxiliary burner Control knobs CONTROL KNOB Symbol Description Symbol Description minimum gas supply no gas supply / off position ignition position / maximum gas supply DAILY USE B. Burner crown WARNING! Refer to Safety chapters. C. -
Page 7: Turning The Burner Off
If after some tries the burner does not If the burner accidentally goes out, light, check if the crown and its cap turn the control knob to the off position are in correct positions. and try to light the burner again after minimum 1 minute. -
Page 8: Care And Cleaning
CARE AND CLEANING WARNING! Refer to Safety chapters. GENERAL INFORMATION • Clean the hob after each use. • Always use cookware with a clean base. • Scratches or dark stains on the surface have no effect on how the hob operates. •... -
Page 9: Troubleshooting
TROUBLESHOOTING WARNING! Refer to Safety chapters. WHAT TO DO IF... Problem Possible cause Remedy There is no spark when you try The hob is not connected to an Check if the hob is correctly to activate the spark generator. electrical supply or it is con- connected to the electrical nected incorrectly. -
Page 10: Labels Supplied With The Accessories Bag
LABELS SUPPLIED WITH THE ACCESSORIES Stick the adhesive labels as indicated below: MOD. MOD. MOD. TYPE PROD.NO. IP20 PROD.NO. PROD.NO. SER.NO. 0049 SER.NO SER.NO 03 IT DATA DATA MADE IN ITALY A. Stick it on Guarantee Card and send this part C. -
Page 11: Injectors Replacement
should be consulted to determine the requisite air When the final connection has been made, it is vent requirements. essential that a thorough leak test is carried out on the hob and installation. For appliances installed in the Republic of Ireland please refer to the NSAI- Domestic Gas Installation Make sure that the main connection pipe does not I.S. - Page 12 WARNING! Make sure the flame does not go out when you quickly turn the knob from the maximum position to the minimum position. ELECTRICAL CONNECTION • Do not pull the mains cable to disconnect the appliance. Always pull the mains plug (if applicable).
-
Page 13: Replacement Of The Connection Cable
1. Connect the green and yellow (earth) wire to the terminal which is marked with the letter 'E', or the earth symbol , or coloured green and yellow. 2. Connect the blue (neutral) wire to the terminal A. Green and Yellow which is marked with the letter 'N' or coloured B. -
Page 14: Possibilities For Insertion
min. 600 mm min. 650 mm min. 100 mm min. 55 mm 30 mm 560 mm 400 mm 50 mm A) supplied bracket If a furniture unit is installed at a distance of 400 mm above the hob, there must be a minimum safety distance of 50 mm to the left or right from the edge of the hob. -
Page 15: Technical Data
A. Removable panel B. Space for connections min 30 mm Kitchen unit with oven The electrical connection of the hob and the oven min 5 mm must be installed separately for safety reasons and (max 150 mm) to let easy remove oven from the unit. 60 mm TECHNICAL DATA HOB DIMENSIONS... -
Page 16: Energy Efficiency
G31 37 mbar Rapid 0,75 Semi-rapid 0,45 Auxiliary 0,33 ENERGY EFFICIENCY PRODUCT INFORMATION ACCORDING TO EU 66/2014 Model identification ZGH65411XB, ZGH65414XB, ZGH65414XX Type of hob Built-in hob Number of gas burners Left rear - Semi-rapid 59.4% Right rear - Semi-rapid 56.3%... - Page 20 WWW.ZANUSSI.COM/SHOP...
