FEATURES
Corner Master
By having adopted a brand new concept design that is appropriate for walls,
the Robot Cleaner's cleaning performance is incredibly efficient.
Learning Mode
The Robot Cleaner is capable of memorizing the cleaning environment via its
Smart Operation feature for smarter cleaning.
Turbo Mode
In the Turbo mode, the Robot Cleaner operates the suction motor and the
brushes at a greater speed giving cleaner results.
When selected, the "Turbo" mode is automatically activated on carpets,
which enables the Robot Cleaner to run more efficiently.
Drawer Mop Plate (Option)
The "Drawer mop plate" makes it much easier for users to fit and remove the
mop without having to turn over the device.
My Space Mode
By commanding it to clean a particular area, the Robot Cleaner quickly
cleans that desired area.
Repeat Cleaning
The Robot Cleaner will continuously clean.
Zigzag
Location Search Function
If the Robot Cleaner is moved from a spot while operating, the device will
automatically search for the previous location and return to the spot from
where it was interrupted.

Advertisement

Table of Contents
loading

Related Manuals for LG VR9647PS

Summary of Contents for LG VR9647PS

  • Page 1 FEATURES Corner Master By having adopted a brand new concept design that is appropriate for walls, the Robot Cleaner's cleaning performance is incredibly efficient. Learning Mode The Robot Cleaner is capable of memorizing the cleaning environment via its Smart Operation feature for smarter cleaning. Turbo Mode In the Turbo mode, the Robot Cleaner operates the suction motor and the brushes at a greater speed giving cleaner results.

  • Page 2: Table Of Contents

    CONTENTS BEFORE USING HANDLING METHOD AFTER USE Safety precautions Cleaning the dust bin Included with product Cleaning the dust bin filter Parts description - robot cleaner Cleaning the brush 10~11 Button functions – robot cleaner Cleaning the sensors/charging terminals Display status information Cleaning the side brush Before you start C leaning the ultra microfiber mop Overview...

  • Page 3: 2~6 Safety Precautions

    3. If the supply cord is damaged, it must be replaced by LG Electronics Service Agent in order to avoid a hazard 4. This appliance can be used by children aged from 8 years and above and persons with reduced physical,...
  • Page 4 Failure to follow this warning product failure. can cause electric shock, fire or product failure. If the power cord is broken, do not plug it in. Take the product to an LG Electronics Authorised service repairer. Do not place the home station Always use a dedicated power and the Robot Cleaner near a outlet with a 10 amp rating.
  • Page 5 SAFETy PRECAUTIONS WARNING Do not spray or use Turn the power supply off immediately if any abnormal inflammable materials, sound, odor, or smoke is surfactants, or drinking water in the vicinity of the Robot generated from the Robot Cleaner by removing it from Cleaner.
  • Page 6 Doing so can cause product failure. failure. Do not put any water or detergent on the Robot Cleaner. If liquids get inside of the Robot Cleaner, turn off the power supply and contact an LG Electronics sales agent or customer care center.
  • Page 7 SAFETy PRECAUTIONS CAUTION If the floor is wet or has wet When the robot cleaner is operating, it may hit the chair spots, wipe them up before leg, desk leg, table leg or using the Robot Cleaner. Do not use the Robot Cleaner on other narrow pieces of furniture.

  • Page 8: Included With Product

    INCLUDED WITH PRODUCT Robot Cleaner Remote controller Home station ► Figures can be different from actual objects. Cleaning Tool Dust bin filter (spare) DVD Manual (option) for cleaning sensors for cleaning the filter Cleaning brush Mop plate (option) Ultra microfiber mop (It’s on the dust bin cover) (2 pieces) (option) Pet Brush...

  • Page 9: 8~9 Parts Description - Robot Cleaner 10~11

    PARTS DESCRIPTION - ROBOT CLEANER Plan view Upper camera sensor Dust bin cover Display & function buttons Dust bin compartment release button Front view Ultrasonic sensors Obstacle detecting sensor window Detecting sensors of home station & Receiving sensors of remote controller Front camera Rear view Main Power switch...
  • Page 10 PART DESCRIPTION – HOME STATION / DUST BIN Home station Remote controller holder Charging terminal Power cord fixing hook Dust bin Dust bin handle Cleaning brush Dust bin cover Suction port flap Sponge filter Dust bin lid opening button EPA filter Filter cover ► Figures can be different from actual objects.

  • Page 11: Button Functions - Robot Cleaner

    BUTTON FUNCTIONS – ROBOT CLEANER • If the button is pressed, ‘Turbo Mode’ will be set with a voice confirmation. TURBO • If the button is pressed whilst in ‘Turbo Mode’, it will be canceled. • Used to turn the power on from Standby, start or stop cleaning. • If the button is pressed whilst the unit is powered ON, it will start cleaning.
  • Page 12 BUTTON FUNCTIONS – REMOTE CONTROLLER Power Pressing this button will turn the power on from Standby Home or the power will be returned Used to recharge the Robot to Standby while the power is Cleaner by making it return to ON.

  • Page 13: Display Status Information

    DISPLAy STATUS INFORMATION Mute icon Lock icon This icon indicates Indicates whether whether the Mute is ON 'Lock‘ is activated or OFF. or not. Battery icon Remote This icon indicates the connection Icon residual battery level, Is Displayed when the it flashes if the battery smartphone connect to needs recharging.

  • Page 14: Before You Start

    BEFORE yOU START Check these items before cleaning • Do not use this device in a room where a child is left alone. The child could be injured. • Remove fragile or unnecessary objects from the room to be cleaned. Especially, remove expensive ceramics and valuables from the floor.

  • Page 15: Overview

    OVERVIEW Install the home station. (p15) Insert the power cord plug into an outlet and locate the station against a wall. If power is not supplied to the home station, the Robot Cleaner will not charge. Turn on the power supply of the Robot Cleaner.

  • Page 16: How To Install The Home Station

    Do not operate the Robot Cleaner if the Home Station has a damaged cord or plug, if it is not working properly, or if it has been damaged or dropped. To avoid electrical hazards, the cord must be replaced by LG Electronics, Inc. or a qualified service person.

  • Page 17: How To Turn The Robot Cleaner Power Supply On & Off

    HOW TO TURN THE ROBOT CLEANER POWER SUPPLy ON & OFF Turning on the main power supply Make sure the Power Switch is on at the rear-left of the Robot Cleaner. If the power is OFF, turn the switch ON. ※...

  • Page 18: How To Start And Stop Cleaning

    HOW TO START AND STOP CLEANING Using the buttons on the Robot Cleaner After the Robot Cleaner main power switch is turned on, press the START/STOP button to begin cleaning. A melody will sound and cleaning will begin. Press the START/STOP button during the cleaning cycle to stop cleaning.

  • Page 19: How To Charge The Battery

    HOW TO CHARGE THE BATTERy Automatic charging The Robot Cleaner returns to the home station at the end of a cleaning cycle or when its battery is running low. ※ If 10 minutes elapse without the Robot Cleaner moving or the battery is too low, the power will be automatically turned OFF.
  • Page 20 HOW TO CHARGE THE BATTERy Remaining Battery Charge Indicator The Battery level is indicated on the Status Display, as follows. • If recharging is in progress, the Battery Level indicator flashes showing the battery charge status level. • If recharging is complete, only the 'Battery' and 'Clean Mode' icons are displayed to save the energy. • Upon the need for recharging, only the first level of the Battery charge level indicator will be on and flashing.

  • Page 21: Cleaning Modes

    CLEANING MODES Zigzag Cleaning In ‘Zigzag’ mode, Robot Cleaner repeats a zigzag operation to clean each and every spot in the cleaning area. If you need to quickly clean an area choose ‘Zigzag’ mode. Press ‘Mode’ button on Remote Controller or main unit to select ‘Zigzag’...
  • Page 22 CLEANING MODES My Space Cleaning Pressing 'My Space' on the Remote Controller will set the My Space cleaning mode with a voice message. For cleaning of particular spaces, select this mode. The 1st stage: Use the Remote Controller to manually set the parameters of each cleaning block.

  • Page 23: Auxiliary Cleaning Modes

    AUxILIARy CLEANING MODES Manual Cleaning By pressing a direction key on the Remote Controller, you can move the Robot Cleaner manually. Robot Cleaner will clean the area, by pressing the forward/backward/left/right buttons accordingly on the keypad of the remote control. While in 'Manual' mode, the robot cleaner will run into obstacles placed behind it if the backward key on the remote is pressed or held down.
  • Page 24 AUxILIARy CLEANING MODES Turbo Mode Pressing the 'Turbo' button on the Remote Controller or main unit will activate 'Turbo' mode, with a voice message. While in 'Turbo' mode, pressing the same button will cancel 'Turbo' mode, with a voice message. In 'Turbo' mode, Robot Cleaner runs more intensely for a powerful clean.

  • Page 25: Time Setting

    TIME SETTING You can set or change the current time on the Robot Cleaner. Pressing ‘Clock' button on the Remote Controller, when the Robot Cleaner is in standby mode, will start the clock setting mode. Set the hour by using ‘▲▼’ buttons on Flickering Remote Controller. Set the minutes using ‘▲▼’ buttons on Flickering Remote Controller.

  • Page 26: Scheduled Cleaning

    SCHEDULED CLEANING You can schedule cleaning so that the Robot Cleaner starts cleaning at a scheduled time. Pressing 'Schedule' button on Remote Controller, only when the Robot Cleaner is recharging, will start the scheduled cleaning setting. Setting/Cancelling the schedule cleaning is only possible when the unit is recharging on the home station Select ‘Once reservation’...

  • Page 27: Mop Cleaning (Option)

    MOP CLEANING (OPTION) By attaching the ultra microfiber mop, you can effectively use the Robot Cleaner to remove dust on hard floor surfaces. When the mop plate is attached, the Robot Cleaner will not climb on to carpets or over thresholds, in order to prevent transferring dirt from the mop.

  • Page 28: Location Search Function

    LOCATION SEARCH FUNCTION The Robot Cleaner remembers its location while cleaning. If the user moves the Robot Cleaner while it is operating, it will search for the location it was moved from by using its navigational location search function before continuing to clean. ※...

  • Page 29: Smart Diagnosis

    SMART DIAGNOSIS Robot Cleaner uses this Smart Diagnosis feature to run a self-diagnosis. If any irregularity is found from the diagnosis, please contact the local LG Electronics service center. ※ During Smart Diagnosis, the Robot Cleaner will move about within a 50 cm radius. So, make sure no objects are in the way within a 1 m radius around the Home Station, before starting Smart Diagnosis.
  • Page 30 Charging cannot be done due to a problem in infrared Run Smart Diagnosis again and, if the same message is sensor. announced, contact an LG Electronics service center. Charging cannot be done due to a problem in Run Smart Diagnosis again and, if the same message is ultrasonic sensor.

  • Page 31: Smart Application Function

    SMART APPLICATION FUNCTION You can control the Robot Cleaner from your smartphone. The "LG Roboking" application provides the following functions: • HomeView, HomeGuard, Cleaning Diary, Schedule Cleaning, Smart Diagnosis AP with Internet access Smartphone (Android or iOS) Robot Cleaner with network access What to check before using the product Some models and OS versions may restrict the use, or render the application inoperable from the smartphone.
  • Page 32 SMART APPLICATION FUNCTION Signing up for membership You need to subscribe your personal login ID on the server to control the Robot Cleaner from your smartphone. 1. The [Startup Screen] opens when you run the "Smart ThinQ" application. Select “nation / Language” and click “Sign in”.
  • Page 33 SMART APPLICATION FUNCTION How to register the product (Android) You will need to register the product on the application to control the Robot Cleaner from your smartphone. Add your Robot Cleaner to the app with the Wi-Fi feature to use the Smart function. 1.
  • Page 34 SMART APPLICATION FUNCTION Wi-Fi / Register product (Android) Product registration can be done using the "Wi-Fi" function for Robot cleaner. 1. Check whether the "Smart ThinQ" mark is printed or not. If there is a “Smart ThinQ” mark on the product, press the "Yes" button. [Product category] • Registering the product is required for the initial connection only;...
  • Page 35 SMART APPLICATION FUNCTION Product network / Register product (Android) 1. Long-press the "TURBO(Register/3sec)" button on Roboking for 3 seconds. The [Select AP(Wi-Fi)] screen will open soon. 2. By selecting your AP on the "Wi-Fi network" list, you will automatically be directed to the product registration mode.
  • Page 36 SMART APPLICATION FUNCTION How to register the product (iOS) You will need to register the product on the application to control the Robot Cleaner from your smartphone. Add your Robot Cleaner to the app with the Wi-Fi feature to use the Smart function. 1.
  • Page 37 SMART APPLICATION FUNCTION Product network / Register product (iOS) 1. Please long-press the “Turbo” button for 3 seconds while the Robot cleaner is turned on. The [Select ‘LG_HOMBOT_REG~’ Wi-Fi] screen will open soon. 2. Please turn on the “Wi-Fi connection” function in iPhone “Settings.” 3.
  • Page 38 SMART APPLICATION FUNCTION Startup screen of application The following screen will open when you connect to the Robot Cleaner for the first time from the "Smart ThinQ" application: Displays the product's You can check for any nickname. alert history. Menu The home icon selects HomeGuard, Schedule the product list page.
  • Page 39 SMART APPLICATION FUNCTION Startup screen of application Menu HomeGuard, Schedule Cleaning, Cleaning Diary, Smart Diagnosis, Setting. HomeView You can use the remotecontrol function, and monitor the surrounding environment around the robot cleaner through the front camera. Mode Menu Cleaning mode, Repeat mode, Turbo mode.
  • Page 40 SMART APPLICATION FUNCTION HomeView (interface configuration) Open HomeView; the following control screen icons will appear: HomeView main menu Each button provides the corresponding function. Status icons Wi-Fi, battery, Reserve Cleaning, cleaning mode, Turbo mode, repeat mode, lighting mode, and cleaning time are displayed here. Mode setting Click each icon to toggle Cleaning modes, Repeat mode, Turbo mode, and Lighting.
  • Page 41 SMART APPLICATION FUNCTION HomeView (Cleaning) You can change to the cleaning mode during HomeView and have the Robot Cleaner start cleaning by clicking “Start cleaning." [Waiting to clean] Click “Start cleaning” to engage the cleaning mode. You can select another cleaning mode by clicking the “Mode setting”...
  • Page 42 SMART APPLICATION FUNCTION HomeView (Redock for charging) Click “Start Charging” when the Robot Cleaner is not charging to have the Robot Cleaner start searching for the Home station. Click "Stop" to have the Robot Cleaner stop searching. [Moving to Home station] [Charging] HomeView (Manual control) Press the "Manual Control"...
  • Page 43 SMART APPLICATION FUNCTION Menu - HomeGuard (Main screen) HomeGuard lets you monitor the house through the Robot Cleaner's camera at its designated location while you are away from home. The Robot Cleaner will take pictures of any activity it detects and sends them to you as Alerts.
  • Page 44 SMART APPLICATION FUNCTION Menu - HomeGuard (Location setting) To start HomeGuard, first, you have to set the location where the Robot Cleaner will remain during the HomeGuard mode. Select the location on the virtual map. 1. Click the target location on the map or drag the Robot Cleaner to the desired location within the designated area.
  • Page 45 SMART APPLICATION FUNCTION Menu - HomeGuard (Location setting) 3. Check if the location is satisfactory from the video feed and click "Save" to complete location setup. [Saving Location setting] • The Robot Cleaner searches for the saved location with the Home station as the starting point, so you will have to set up the location again if the station has been moved.
  • Page 46 SMART APPLICATION FUNCTION Menu - HomeGuard (Alert) Upon detecting any movement while in HomeGuard mode, the Robot Cleaner takes pictures and sends an alert to your smartphone. Press "Confirm" on the alert pop-up to view the picture or use the "Call" "View home".
  • Page 47 SMART APPLICATION FUNCTION Menu – Schedule Cleaning You can schedule the time you want the Robot Cleaner to start cleaning. To set up Schedule cleaning, toggle across the Schedule cleaning key to turn it on or off in the Schedule cleaning menu.
  • Page 48 SMART APPLICATION FUNCTION Menu – Cleaning Diary You can view the diary to find out when the Robot Cleaner did the cleaning. Cleaning Diary records information such as date, mode, and the start and completion times of each cleaning. Click Play button on the right of the completed cleaning list; an active cleaning map of that particular cleaning event will appear.
  • Page 49 Be sure to resolve any issue identified in the diagnosis by taking a corresponding measure. If the symptom persists, contact the customer service center of LG Electronics. • Smart Diagnosis on the application provides the same function as that of the remote control.
  • Page 50 SMART APPLICATION FUNCTION Menu – Setting You can check or change the current information set up on Robot Cleaner. Click Voice gender to change the voice of the Robot Cleaner to male or female. Click Product nickname to change the current nickname of the Robot Cleaner; a pop-up where you can enter a new nickname opens (up to 10 characters allowed including English, Korean and numeric).
  • Page 51 SMART APPLICATION FUNCTION Misc. 1 - Software update The network-enabled model of the Robot Cleaner can update the software automatically via the application. 1. Make sure that the "Smart ThinQ" application is up to date on the Play Store.(Unless you update the app to the latest version, software update will not be available.) 2.
  • Page 52 SMART APPLICATION FUNCTION Misc. 2 - Mode You can order to robot cleaner simply without connection with robot cleaner through Mode function. Mode function has total 4 functions. If you push ‘Applied’ button, Robot cleaner will act according to Mode like below.

  • Page 53: Product Info Initialization

    3. Pressing "Start/Stop" again will turn Robot Cleaner on with a melody. ※ Any dispute between seller and buyer is an issue between the two parties. LG Electronics provides a product initialization function for smooth transaction. • Initialization returns the following information as factory default setting.

  • Page 54: Cleaning The Dust Bin

    CLEANING THE DUST BIN If the dust bin is full, suction power can be reduced. Clean the dust bin before or after each cleaning session. Clean the dust bin using the following sequence: 1. Open the dust bin compartment cover by pressing the PUSH button on the Robot Cleaner. 2.

  • Page 55: Cleaning The Dust Bin Filter

    CLEANING THE DUST BIN FILTER The Dust Bin Filter consists of a EPA Filter and Sponge Filter. Clean both the EPA and Sponge filters as per the following sequence. 1. Pull the hook on the left of the EPA Filter module on the rear side of Dust Bin to separate the EPA Filter and the sponge.

  • Page 56: Cleaning The Brush

    CLEANING THE BRUSH The rotating Brush, located on the bottom of Robot Cleaner, helps collect the dust. Clean the Brush as per the following sequence. ※ Before turning over the main unit, lay a soft cloth on the floor and remove the Dust Bin. Otherwise, the main unit can get scratched and dust will fall from the Dust Bin.

  • Page 57: Cleaning The Sensors/Charging Terminals

    CLEANING THE SENSORS/CHARGING TERMINALS There are sensors on the Robot Cleaner that detect obstacles, stairways and the home station for charging the battery. In order to maintain the performance of the Robot Cleaner, regularly clean the sensors and charging terminals as follows: 1. Turn off the power switch on the rear side of the Robot Cleaner. Injury can be caused by the activation of the Robot Cleaner if the main power is not turned off.

  • Page 58: Cleaning The Side Brush

    CLEANING THE SIDE BRUSH Foreign objects/materials such as hair can easily adhere to the side brush. Remove such materials at least once a week. If excessive amounts of foreign materials are stuck to the brush, there is the risk of damage to the brushes. If the floor is rough or frequently cleaned, the side brushes may bend or become deformed.

  • Page 59: Leaning The Ultra Microfiber Mop

    ※ If the Mop is used in a damp or wet state, it will cause the Robot Cleaner to malfunction. • To avoid product malfunction, only use the ultra microfiber mop provided with the Robot Cleaner. • Additional microfiber mops can be purchased by visiting a nearby LG Electronics service center.

  • Page 60: Troubleshooting

    TROUBLESHOOTING Upon a voice message, "The wheels are not touching the floor. Please move Roboking onto flat floor." A warning message will be given if a wheel does not contact the floor surface for any reason. • Is a wheel trapped in the front door, balcony, stairway, etc? ► Move the Robot Cleaner on to the flat floor.
  • Page 61 TROUBLESHOOTING Upon a voice message, "Please check if the dust bin is installed with the filter." A warning message will be given if there is no Dust Bin or Filter housing fitted. • Is the Dust Bin fitted to the Robot Cleaner? ► Open the Dust Bin compartment cover and check to ensure the Dust Bin is in place.
  • Page 62 TROUBLESHOOTING Upon a voice message, "Please remove foreign material from the brushes on the bottom." A warning message will be given if foreign materials restrict the Brush's rotation. Turn off the main power switch on the rear of the Robot Cleaner. Lay a soft cloth on the floor and put the Robot Cleaner upside down on it.

  • Page 63: Before You Call For Service

    BEFORE yOU CALL FOR SERVICE Confirm before reporting the failure of Robot Cleaner. Problem Solutions (Reference page) The power supply cannot be Check that the power switch is turned on. (Page 16) turned on. The power supply This is not a failure. Robot Cleaner has its own power saving function. automatically turns off.

  • Page 64: Reference Items

    REFERENCE ITEMS Open source software notice To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this product, please visit http://opensource.lge.com. In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download.

  • Page 65: Iec 62929 Standard] Setting For Cleaning Performance Test

    [IEC 62929 STANDARD] SETTING FOR CLEANING PERFORMANCE TEST Dust Removal Test - Box(Hard Floor & Carpet) 1. Put fully charged Robot Cleaner down on start point and turn on. 2. Push ‘TURBO’ button on the Robot Cleaner or ‘Turbo’ button on the Remote Controller and Robot Cleaner will be set Turbo Mode.
