Washing Machine
WA4000HS_DC68-03414B-06_EN.indd 1
WA4000HS_DC68-03414B-06_EN.indd 1
user manual
imagine
the possibilities
Thank you for purchasing a Samsung product.
WA90H4200SG
WA75H4400SS
WA75H4200SW
WA70H4400SS
WA70H4000SG
WA70H4000SW
WA65H4200SW
WA60H4000SG
2021-10-21
2021-10-21
10:59:24
10:59:24
Advertisement
Table of Contents
Related Manuals for Samsung WA90H4200SG
Summary of Contents for Samsung WA90H4200SG
- Page 1 WA90H4200SG WA75H4400SS WA75H4200SW WA70H4400SS WA70H4000SG WA70H4000SW WA65H4200SW WA60H4000SG Washing Machine user manual imagine the possibilities Thank you for purchasing a Samsung product. WA4000HS_DC68-03414B-06_EN.indd 1 WA4000HS_DC68-03414B-06_EN.indd 1 2021-10-21 2021-10-21 10:59:24 10:59:24...
-
Page 2: Table Of Contents
contents SAFETY INSTRUCTIONS Safety instructions Description of part SETTING UP YOUR WASHER How to wash automatically depends on the laundry Control Panel MANUAL FUNCTIONS Manual functions INSTALLATION & MAINTENANCE Environment Levelling Connecting the water supply hose Assembling the rat protection panel (option) How to connect the drain hose (option) Adding detergent Adding fabric softener... - Page 3 safety instructions Please note that the following precautions for safety intend to prevent unpredictable danger and damage by helping the proper use in safety. When using hot water in washing, please make sure that the water should not exceed 50 °C. •...
- Page 4 safety instructions 8. CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cut-out, this appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by the utility.
- Page 5 The use for business purposes qualifies as product misuse. In this case, the product will not be covered by the standard warranty provided by Samsung and no responsibility can be attributed to Samsung for malfunctions or damages resulting from such misuse.
-
Page 6: Setting Up Your Washer
setting up your washer DESCRIPTION OF PART The User’s Manual is for common use. Make use of the User’s Manual depending upon your washing machine model. Be sure to keep the lid closed Water supply hose (Cold) during washing and spinning. Water supply hose (Hot) Detergent box Filter... - Page 7 CHECKING BEFORE WASHING AND CARING FOR GARMENTS Must follow the checkpoints in order to avoid machine problems or damages on garments. • If the below problems are caused by customer’s faults, separate service fee will be charged. Checkpoints Before Starting Washing Check if the clothes are bleaching or not.
- Page 8 setting up your washer CARING FOR CLOTHES BEFORE WASHING Take out personal belongings from pockets. • Caution, Check the pockets! Hairpins and coins cause damages to clothes and washing machine. They make noise and problems to the machine. Must check the pocket. If pants zippers are open while washing, the spin basket may be damaged.
- Page 9 Curtains, fl oating garments or blue jeans shall be pressed not to fl oat on the water. • If they are floated on the water, press Start/Pause button to stop and press them to sock in the water. If the washing goes on with clothes floating on the water, it may cause damages to the clothes and the washing machine as well as unsatisfactory washing result.
-
Page 10: How To Wash Automatically Depends On The Laundry
setting up your washer HOW TO WASH AUTOMATICALLY DEPENDS ON THE LAUNDRY Before starting washing, check the following; • Connect the water supply hose to the water tap. Leave a tap open. Plug the power cord in. Make sure to lay down the drain hose. Washing for the fi... -
Page 11: Control Panel
CONTROL PANEL For more details, see control panel of your washing machine. Displays the remaining wash time. Digital graphic Displays the error state if a problem occurs in the washing machine so that you display can take action. The water level is automatically adjusted. However, you can select the water level Water Level manually by pressing this button. - Page 12 setting up your washer Fuzzy Selects the best washing program automatically. If you want to wash those frequently used towels or less dirty Quick laundry time. Because washing is speedy, it is good for light or less stained laundry. Delicates Washable sweater, cardigan, delicate clothes etc.
-
Page 13: Manual Functions
manual functions Possible to select the function for each program. (Example) For a simple washing as the little dirt program : Power Select the little dirt program Wash Start/Pause Press the Power button. WASH ONLY Press the Wash button. Press the Start/Pause button. Washing goes on for 1 time. -
Page 14: Installation & Maintenance
installation & maintenance The User’s Manual is for common use. Make use of the User’s Manual depending upon your washing machine model. ENVIRONMENT Leave some space Maintain at least 10 cm between the washer and the wall. Place the washer on a sturdy fl at surface. If the washer is placed on an uneven or weak surface, noise or vibration occurs. -
Page 15: Assembling The Rat Protection Panel (Option)
4. Connect the water supply hose to the adaptor. Pull down the part (c) of the water supply hose. When the part (c) is released, the hose is automatically connected to the adaptor making a ‘click’ sound. 5. Connect the other end of the water supply hose to the inlet water valve at the back of the washer. -
Page 16: How To Connect The Drain Hose (Option)
installation & maintenance HOW TO CONNECT THE DRAIN HOSE (OPTION) IN CASE OF PUMP-DRAINED WASHER cap-hose Take out the cap-hose and connect the Be sure to join tightly the drain hose into the outlet-hose. (option) drainoutlet on the back of the machine. Drain hose Hose guide Be sure to join tightly the drain hose into the... -
Page 17: Adding Detergent
CAUTIONS WHEN INSERTING THE DRAIN HOSE Less than 3 m 1. Don’t exceed more than 3 m when the 2. Be careful to drain water out at the end of drain hose is used by connecting with the drain hose. other hoses. -
Page 18: Water Supply Connector Filter
installation & maintenance WATER SUPPLY CONNECTOR FILTER 1. Pull out the fi lter and wash well. 2. Pull in the fi lter and connect the hose to the inlet water valve tightly. 3. Check if there is a leakage. Note to tighten up the connector. CLEANING THE FILTER Clean the filter net often to keep the washer clean. -
Page 19: Troubleshooting
troubleshooting PROBLEM CHECK Washing machine won’t work • Is the water tap opened? • Is the washer plugged in? • Is the power cut off? • Is there enough water? Water dose not drain • Is the drain hose down?(No pump) •... - Page 20 washing machine won’t work? PROBLEM CHECK The power is cut off. Is the electric voltage normal? Is the washer plugged in? Plug in the electric cord. Water does not drain. Is the drain hose down? Put the drain hose down. Is the drain hose folded? Unfold the drain hose.
- Page 21 PROBLEM CHECK The water leaks at the water supply Did you press the Start/Pause button after selecting the water hose connector. supply? If the Start/Pause button is not pressed, water is not supplied. Press the Start/Pause button. Is the faucet closed? Turn on the faucet.
- Page 22 WA90H4200SG, WA75H4400SS, WA75H4200SW, WA70H4400SS, WA70H4000SG, WA70H4000SW, WA65H4200SW, WA60H4000SG WA90H4200SG 9.0 kg WA75H4400SS 7.5 kg WA75H4200SW MAX. MASS OF DRY WA70H4400SS CLOTH IN kg WA70H4000SG 7.0 kg WA70H4000SW WA65H4200SW 6.5 kg WA60H4000SG 6.0 kg AC 230 V / 60 Hz...
- Page 23 memo English - 23 WA4000HS_DC68-03414B-06_EN.indd 23 WA4000HS_DC68-03414B-06_EN.indd 23 2021-10-21 2021-10-21 10:59:36 10:59:36...
- Page 24 1-800-10-726-7864 [ PLDT Toll Free ] PHILIPPINES 1-800-8-726-7864 [ Globe Landline and Mobile ] www.samsung.com/ph/support 02-8-422-2111 [ Standard Landline ] 1800-88-9999 MALAYSIA www.samsung.com/my/support +603-7713 7420 (Overseas contact) SINGAPORE 1800 7267864 | 1800-SAMSUNG www.samsung.com/sg/support PAKISTAN 0800-Samsung (7267864) www.samsung.com/pk/support DC68-03414B-06 WA4000HS_DC68-03414B-06_EN.indd 24 WA4000HS_DC68-03414B-06_EN.indd 24 2021-10-21 2021-10-21...
