Please use this Manual together with Service Manual model MC-9026/MC-9028 Order No. MELCOM 9204-78, MC-9027/MC-
9029 Order No. MELCOM 9510-93 and MC-9030 Order No. MELCOM 9808-303
SPECIFICATIONS
Model
Power Source
Frequency (Hz)
Motor Power
Dust Capacity
Dimensions (H x W x L)
Weight (With Attachment)
Cord Length
Attachments
*
Specifications are subject to change without notice for further improvement.
MC-9050
AC127V, AC220V~240V
1400W
15.0 litres
514mm x 340mm x 366mm
6.9kg
MC-9050/MC-9060/MC-9070
MC-9060
50/60Hz
1500W
17.0 litres
544mm x 340mm x 366mm
7.5kg
8.0m
Hose, Extension Wand, Floor Nozzle
Extension Wand Holder
Crevice Tool Upholstery Nozzle
© 2004 Matsushita Electric Co., (M) Bhd. All rights
reserved. Unauthorized copying and distribution is a
violation of law. (Company No. 6100K)
Order Number: MEL0403016C3
Vacuum Cleaner
MC-9070
AC220V~240V
1600W
20.0 litres
584mm x 340mm x 366mm
7.6kg
