30" FREESTANDING
ELECTRIC RANGE
SERVICE MANUAL
CAUTION
BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
MODEL: LREL6323*
Any reproduction, duplication, distribution (including by way of email, facsimile or other electronic means), publication,
modification, copying or transmission of this Service Manual is STRICTLY PROHIBITED unless you have obtained the
prior written consent of the LG Electronics entity from which you received this Service Manual.
The material covered by this prohibition includes, without limitation, any text, graphics or logos in this Service Manual.
Copyright © 2021 LG Electronics Inc. All rights reserved. Only training and service purposes
MFL71688313_Rev00. 04162021

Advertisement

loading

Summary of Contents for LG LREL6323 Series

  • Page 1 Service Manual is STRICTLY PROHIBITED unless you have obtained the prior written consent of the LG Electronics entity from which you received this Service Manual. The material covered by this prohibition includes, without limitation, any text, graphics or logos in this Service Manual.
  • Page 2 SAFETY PRECAUTIONS Repairs of the appliance should be carried out by a licensed technician only. Incorrect repairs may result in dangerous situations. If you need repairs, contact an LG Service Center or your dealer. If the power cord is defective, it must be replaced by a qualified service agent with a UL listed range cord.
  • Page 3 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-17 Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 4: Table Of Contents

    - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 11-1 ~ 11-6 Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 5 - Failure to do so can result in vibration, noise, and poor performance of convection when operating. - Failure to do so can result in personal injury as the door is very heavy. Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 6 - Storage drawer : Remove drawer and verify leveling leg is inserted into and fully secured by the anti-tip devices. Refer to the installation manual for proper anti-tip bracket installation. Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 7 Use extreme caution when moving the grease kettle or disposing Be sure you know which control pads operate each surface unit. of hot grease. Make sure you turned on the correct surface unit. Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 8 MODEL & SERIAL NUMBER LABEL AND TECH SHEET LOCATIONS The Model/Serial Number label and Tech Sheet locations are shown below. Model & Serial Number Location Tech Sheet Location (On Rear Cover) Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 9 (backguard top) Exterior - Depth 26 1/2 (Door), 28 (with handle) Net weight: Lbs (Kg) 152.1lbs (69kg) 120/240V : 12.9 kW , 120/208V : 9.7 kW Power Rating Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 10 All foods should be turned at least once except fish, which does not need to be turned. Broil element Hidden bake element Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 11 Start button approximately 150 ˚F. The COOKTOP HOT indicator also appears during the self clean cycle. Smart Diagnosis™ Flashing Time Cooktop Control Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 12 1. Touch START key to start oven. Start 3. Press to accept the change. 2. Touch CLEAR/OFF key to cancel a program during cooking or Erase during programming. Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 13 Press Settings repeatedly until Auto appears in CONVECTION BAKE and CONVECTION ROAST the display. modes. Auto conversion Press 1 START 10. BROIL On/off ONCE HIGH START TWICE Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 14 Main PCB Surface Elements Door Locking Motor & Micro Switch Door Latch Assembly Oven Sensor Door Switch Oven Light Broil Heater Convection Motor Hinge Hanger Bake Heater Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 15 4. Remove the 20 screws from the rear cover and remove the cover. Control Cover Rear Cover 8. Replace the control panel assembly. Main PCB Regulator Motor Cover Bracket Support Barrier Control panel Assembly Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 16: Composition Of Control

    2. Pull the range away from the wall so that you can access the rear panel. 3. Remove the lamp, controller and back cover. (See the page 3-2) Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 17 Open oven door and remove the 3screws located at the front of the cook-top, then close the door. Step. 5 Lift up the cooktop assembly and turn the cooktop assembly over (protect the cooktop surface). Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 18 3. Raise the cooktop (See the page 3-4 for the procedure). Push 4. To remove the door latch: a) Remove the two screws from the door latch and remove the latch. 2 Screw Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 19 2. Open the oven door and remove the racks from inside the oven. 3. To remove the outer broil element: a) Remove the 4 screws from the front and rear brackets. 2 front bracket screws Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 20 180 degrees. (shown as below: assembly sequence 1 6. Use the nipper to cut the 10 connections on the Bake heater cover and Rear panel. Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 21 Conv. Moto r Motor Bracke t Fan cove r Fan blad e Spring Washer Mounting screw (3ea ) Washer Fan Cover Screw (4ea ) Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 22 4. Insert a n bulb and replace bulb cover by 6. Disconnect the wires from the socket terminals. turning clockwise. Glass cover & Bulb Inner Ring Glass cover & Bulb Outer Ring <Viewed From Rear Panel> Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 23 The motor operates to unlock door at that time. 1 Screw Latch driver motor 6. Unhook the Latch rod from the cam. 3-10 Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 24 Remove rear cover & motor cover (See step 3~4 on page 3-2) c) Disconnect the wire connection. d) Remove the oven sensor. Oven temperature sensor Wire connection 1 screws Copyright © LG Electronics Inc. All rights reserved. 3-11 Only training and service purposes...
  • Page 25 - Failure to follow this warning result in severe personal injury. 4. Remove the drawer. 3-12 Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 26 5 degrees. (refer to the Fig.2) position. <Fig.2> Step. 5 Step. 5 Lift door up and out until the hinge arm is clear of the Close the oven door. slot. Copyright © LG Electronics Inc. All rights reserved. 3-13 Only training and service purposes...
  • Page 27 3. Remove the 2 top door screws. 2 Top liner screws Bracket 4. Remove the 7 bottom screws from the door liner. 7 screws 3-14 Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 28 Lift the hinge hanger out of the door liner slot. Inner oven door Glass & Bracket 4 top door screws Insulation Insulation Hinge Door frame Copyright © LG Electronics Inc. All rights reserved. 3-15 Only training and service purposes...
  • Page 29 1. Open the oven door to its fully down position. 2. Pull the oven door gasket clips out of the liner holes until all of the clips are removed. Liner Hole 3-16 Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 30 5. Raise the cooktop assembly (See the page 3-4 For the procedure). NOTE: put the cooktop assembly down on the side panel which is not detached. 6. Remove 4 screws from the side panel. Copyright © LG Electronics Inc. All rights reserved. 3-17 Only training and service purposes...
  • Page 31 1. Refer to page 3-10 for the servicing procedure 103Ω 2. Measure the resistance If not replace (Multiple meter scale: R x 1) Abnormal: Infinite (open) below 5Ω (shorted) Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 32 1.09 kΩ ± 10% 2. Measure the resistance after cooling down If not replace (Multiple meter scale: R x 1000) NOTE: Ω Value was tested at room temperature (77F/25˚C) Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 33 1. Remove wire leads Abnomal : Infinite(opened) 2. Measure resistance after cooling down NOTE: Ω Value was tested at room temperature (77F/25˚C) Be careful the element is sensitive to temperature. Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 34 With the temperature below 150˚F, the meter should indicate an open circuit(infinite). Above 150˚F With the temperature above 150˚F, the meter continuity (0 Ω) should indicate continuity (0Ω). Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 35 With the temperature below 150˚F, the meter should indicate an open circuit(infinite). Above 150˚F With the temperature above 150˚F, the meter continuity (0 Ω) should indicate continuity (0 Ω). Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 36 With the temperature below 150˚F, the meter should indicate an open circuit(infinite). Above 150˚F With the temperature above 150˚F, the meter continuity (0 Ω) should indicate continuity (0 Ω). Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 37 Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 38 COMPOSITION OF CONTROL Wiring Diagram Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 39 COMPOSITION OF CONTROL Main PCB Front Back Tact & Display PCB Controller assembly Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 40 COMPOSITION OF CONTROL Main PCB Tact & Display PCB LED Module Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 41: Check The Failure Code

    If the oven do not has any failure, the Oven will show it like FIG. 2 < FIG. 2 > NOTE: After checking for the F code, press the “CLEAR” key to remove all codes. Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 42: Failure Code Summary

    5 minutes on preheating. Door Lock Fail In case of Door Lock Failure in operating Lock motor. 1. Electric Wiring 2. Motor’s Resistance 3. Micro Switch Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 43: Basic Check Summary

    -. Check: : All heater relays are open/short WIRE COLORS SYMBO L C OLOR WHITE BLAC K RE D YELLO W PINK BLUE BROW N GREEN G RAY ORANGE VIOLET Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 44: Checking Flow Chart By Failure

    CHECKING FLOW CHART BY FAILURE Symptom Check Point 1. Power Failure 1. Check Electric Wiring (Dead) 2. Check the Main PCB 2. No Display Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 45 Check the connection of Power If defective harness, Cord. Normal? replace or fix Reconnect. If defective harness, replace or fix Check the connection of Main PCB. (CN01) Nomal? Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 46 Check the connection of L1 and N Reconnect. at Terminal block. Normal? Check the Thermostat - Normal : Short Replace the Thermostat - Abnormal : Open Normal? Replace the main PCB Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 47 CN21 Main PCB CN21 Reconnect. If defective harness, replace or fix. If the same phenomenon occurs even though after fixed connection, you should replace the Display PCB Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 48 CHECKING FLOW CHART BY FAILURE Symptom Check Point 1. No heating 1. Check Electric Wiring 2. F9 2. Check Heater’s Resistance. 3. Check the Sensor (thermistor). TAB01~06 CN10 CN10 Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 49 Reconnect. If defective harness, Is the Connector disconnected Replace or fix or loose? (1) Electric wiring of Relay PCB All taps. (2) Electric wiring of electric element Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 50 CHECKING FLOW CHART BY FAILURE Replace the failed igniter Check the resistance of each heater. Normal? (Measure the resistance after cooling down. The resistance is shown below) Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 51 3. press the “BAKE”, “BROIL” button at the same time again. Software version 2 seconds 2 seconds 4. “+” 3 click(t3) Start Normal : . e r Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 52 Is the resistance of thermistor normal? Thermistor Check Pin 1 and 2 of CN10 in main PCB. Normal – approximately 0.6~1K ohm at 25 . CN10 Replace the Main PCB Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 53 1. Door Lock System Failure 1. Check the Electric wiring 2. F-10 2. Check the Motor’s Resistance 3. Check the Relay PCB (Door Lock Relay) CN02 9-10 Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 54 Normal? Reconnect Check the oven door lock switch(micro switch) (measure the resistance Normally open type) Door latch Door latch open Locked Continuity Infinite Copyright © LG Electronics Inc. All rights reserved. 9-11 Only training and service purposes...
  • Page 55 2.6 kΩ abnormal: infinite or below 5 Ω Normal? Replace the door locking motor Check the looseness of CN02 Normal? Reconnect Replace the main PCB 9-12 Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 56 Symptom Check Point 1. Sensing Fail 1. Check the Electric wiring 2. F1 2. Check the sensor (thermistor) resistance 3. F2 CN10 CN10(Pin 1 and 2) Copyright © LG Electronics Inc. All rights reserved. 9-13 Only training and service purposes...
  • Page 57 Sensing Fail, F1, F2? Unplug the unit Reconnect or adjust the Is the Connector connection disconnected or loose? (1) Sensor connection (2) CN10 of Main PCB Sensor connection CN10 9-14 Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 58 Check : Pin 1 and 2 of CN10 of Main PCB Normal – approximately 0.6~1 K ohm at 25 CN10 Replace the Main PCB Copyright © LG Electronics Inc. All rights reserved. 9-15 Only training and service purposes...
  • Page 59 CHECKING FLOW CHART BY FAILURE Symptom Check Point 1. Oven hot 1. Check the Resistance of the Relay. 2. F-6 TAB01~06 CN10 9-16 Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 60 CHECKING FLOW CHART BY FAILURE F6(Oven Hot) Unplug the unit Check the DLB Relay damage Replace the Main PCB (measure the resistance) Normal Abnormal Copyright © LG Electronics Inc. All rights reserved. 9-17 Only training and service purposes...
  • Page 61 Replace the Main PCB thermistor normal? Check : Pin 1 and 2 of CN10 of Main PCB Normal – approximately 0.6~1 K ohm at 25 CN10 Replace the Thermistor 9-18 Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 62 CHECKING FLOW CHART BY FAILURE Symptom Check Point 1.Key not working Check the Key working 2.F3 CN20 Copyright © LG Electronics Inc. All rights reserved. 9-19 Only training and service purposes...
  • Page 63 Does the beep sound when the power is turned on again? Reconnect or adjust the connection Is the connector disconnected or loose? Check : CN20 Is it OK? CN20 CN20 Replace the Display PCB 9-20 Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 64: Trouble Shooting

    Reset circuit breaker and try oven again. Test door switch and check the point of Oven stop for Self clean contact between door and door switch door switch cycle Copyright © LG Electronics Inc. All rights reserved. 10-1 Only training and service purposes...
  • Page 65 Premature burnout of bake Improper use of oven(e.g. being element used to heat the home) Oven door difficult to open Worn or broken broil stop roller. 10-2 Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 66 Low level noise is normal Failures Codes Refer to “Failure codes” parts (page 7-1) Oven temperature too hot or too cold in owners manual Copyright © LG Electronics Inc. All rights reserved. 10-3 Only training and service purposes...
  • Page 67: Exploded View

    #EV# EXPLODED VIEW INTRODUCTION MODEL: Customer Model Product Code SVC Model CONTROLLER PARTS COOKTOP PARTS DOOR PARTS CAVITY PARTS DRAWER PARTS Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 68 DOOR PARTS W243 102U W225 1801 1000 102S W225 1028 1733 1020 W222 1704 1735 W101 1021 W321 W108 1009 1466 1733 W101 W321 102S 1704 102L Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 69 #EV# CONTROLLER PARTS 2006 2374 3075 2050 2381 2084 2052 2087 2441 2084 2034 H211 2037 2028 H212 2128 2036 H213 Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 70 #EV# COOKTOP PARTS 305 6 340 1 330 3 3022 320 4 330 1 330 3 330 2 3204 3204 3204 3014 Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 71 #EV# DRAWER PARTS 8603 8530 8514 8501 8035 8507 8530 850L 850R 8524 850 8 3541 303 6 851D 8503 3541 851 D Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
  • Page 72 5506 W225 5951 W232 W301 W233 5021 5508 W230 5512 5407 W301 W225 5556 W230 551 0 W229 5515 9381 5514 501 4 5401 8511 3501 5032 Copyright © LG Electronics Inc. All rights reserved. Only training and service purposes...
