Frigidaire FEB30T6F Factory Parts Catalog

Double electric wall oven
Hide thumbs Also See for FEB30T6F:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Factory Parts Catalog
FEB30T6FC.tif CPLEB30T9FCA.eps BUFEB30T6DSC.eps BLFEB30T6DSC.eps
DFEB30S5DCA.eps
318046121.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FEB30T6FCA
37054383E60S1
Series
30" double
Color
stainless
Market
North America
Wiring Diagram
318046121
Owner's Guide
318200943
Installation Instructions 318201514
Service Data Sheet
318047306
Timer Guide
318200137
Publication No.
5995470837
06/07/26
(EN/SERVICE/ECL)
377
DOUBLE ELECTRIC

WALL OVEN

Model No.
FEB30T6F
©
Copyright
2006 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FEB30T6F

Summary of Contents for Frigidaire FEB30T6F

  • Page 1: Wall Oven

    North America Wiring Diagram 318046121 Owner's Guide 318200943 Installation Instructions 318201514 Service Data Sheet 318047306 Timer Guide 318200137 DOUBLE ELECTRIC WALL OVEN Publication No. 5995470837 06/07/26 (EN/SERVICE/ECL) © Copyright 2006 Electrolux Home Products, Inc. Model No. FEB30T6F All rights reserved.

  • Page 2: Control Panel

    Publication No: 5995470837 FEB30T6FCA CONTROL PANEL 07/06...
  • Page 3 FEB30T6FCA CONTROL PANEL DESCRIPTION Shield, oven top Cover, box Control Panel Assembly, steel/glass, stainless/black, w/touch pad Control, electronic, ES610W2, dual oven Spacer, power board, (2) Spacer, (2) Board, relay, dual oven Harness, wiring, control-relay Screw, 8 x 0.500 Publication No: 5995470837...

  • Page 4: Upper Oven

    Publication No: 5995470837 07/06 FEB30T6FCA UPPER OVEN 108A BUFEB30T6DSC...
  • Page 5 Rack, oven Pan, broiler Insert, broiler pan Switch, light Receptacle, oven light Insulation, oven light Bulb/Lamp, light Lens, oven light, glass Retainer, light cover Bumper, (2) Probe, oven temp Cover, hinge cutout Screw, 10-32 x 0.437 Housing, oven light Insulation, oven wrapper Insulation, oven back Insulation, 1/2"...

  • Page 6: Lower Oven

    Publication No: 5995470837 07/06 FEB30T6FCA LOWER OVEN 108A BLFEB30T6DSC...
  • Page 7 Bracket, cable mtg. Motor, latch assy Harness, wiring, main, latch Wiring Harness, latch, BAS Wiring Harness, latch, NO BAS Trim, oven front, black, bottom Bracket, side, bottom, (2) Cover, fan Motor, blower Screw, truss head, 8-18 x 0.375 Bracket, fan support...
  • Page 8 Publication No: 5995470837 FEB30T6FCA DOORS 07/06...
  • Page 9 5303300265 5303323277 # Functional Parts * Non-Illustrated Parts FEB30T6FCA DOORS DESCRIPTION Trim, oven door, side, (2) Cover, rear door, black, (2) Baffle, door Insulation, oven door Insulation, oven door Glass, oven door, heat barrier Liner, door Screw, handle mtg, 10-14 x 1/2, (2)

  • Page 10: Wiring Diagram

    Publication No: 5995470837 OUTSIDE INTSIDE OVEN CIRCUIT // CIRCUITO DE HORNO // CIRCUIT DU FOUR INTERIOR EXTERIOR INTERIEUR EXTERIEUR BK-7 OR/O/OU BK-8 (BK-8)* TERMINAL BLOCK BLOQUE DE CONEXION BLOC DE CONNECTION BROIL ELEMENT/ THERMAL CIRCUIT BREAKER/ ELEMENTO DE INTERRUPTOR DE CIRCUITO...
